- **EtherCAT Communication:** Fully compliant with EtherCAT protocol (IEEE 802.3 100BASE-TX), enabling high-speed, deterministic communication between master and slave devices. - **Digital Inputs:** 8 isolated wet/dry contact digital input channels supporting 24V logic levels. - **Relay Outputs:** 4 relay outputs (2 Form A and 2 Form C) for flexible control of external devices. - **LED Indicators:** Individual LEDs for each digital input channel and system status indicators for power and communication states. - **Wide Power Range:** Operates from 12V to 48V DC (±10%), suitable for various industrial power systems. - **Compact Industrial Design:** Rugged enclosure with DIN-rail mounting capability for easy integration into control cabinets. - **Temperature Resilience:** Operates reliably in harsh environments with an extended temperature range of -25°C to +75°C. - **Flexible Network Topology:** Supports daisy-chain and ring configurations for scalable EtherCAT networks. - **Service-Friendly Wiring:** Modular terminal blocks for simplified installation and maintenance. - **High Reliability:** Gold-plated silver relay contacts ensure long mechanical and electrical endurance. - **Configuration via ESI File:** Easy integration with EtherCAT masters using XML-based EtherCAT Slave Information (ESI) files.

Hersteller: Keine Kategorie

Kategorie: Remote IO Modules

- **EtherCAT Communication Protocol:** Fully compliant with the EtherCAT® standard (IEEE 802.3 100BASE-TX), enabling high-speed deterministic communication and real-time data exchange. - **Dual RJ-45 Ports:** Two Ethernet ports (IN/OUT) for daisy-chain or ring topology configurations, supporting up to 100 m between stations. - **Digital I/O Configuration:** - 8 isolated digital input channels (wet/dry contact selectable) - 8 isolated digital output channels (open collector type) - **Wide Power Supply Range:** Operates from 12 VDC to 48 VDC (±10%), allowing flexible integration into various industrial power systems. - **Compact Industrial Design:** Rugged aluminum/plastic enclosure with DIN-rail mounting capability for easy installation in control cabinets. - **LED Indicators:** - 8 LEDs for digital input status - 8 LEDs for digital output status - Power and status LEDs for module diagnostics - **High Environmental Tolerance:** Operating temperature range from -25°C to +75°C, storage temperature from -30°C to +80°C, and relative humidity tolerance of 10–90% (non-condensing). - **Low Power Consumption:** Maximum 2.7 W at 24 VDC. - **Flexible Network Topology:** Supports daisy-chain and ring configurations, reducing cabling complexity and infrastructure costs. - **Easy Configuration:** Compatible with EtherCAT master tools such as Beckhoff TwinCAT and EtherCAT Configurator via ESI (EtherCAT Slave Information) XML file.

Hersteller: Keine Kategorie

Kategorie: Remote IO Modules

- **EtherCAT Communication:** Fully compliant with the EtherCAT protocol (IEEE 802.3 100BASE-TX), enabling high-speed, deterministic communication for industrial automation systems. - **16 Digital Inputs:** Supports 16 isolated digital input channels configurable for wet or dry contact operation. - **Wide Input Voltage Range:** Accepts input signals from 3.5 V to 24 V for ON state, with OFF voltage below 1 V. - **Status Indication:** Each input channel is equipped with a dedicated LED indicator reflecting real-time input status. - **Industrial Design:** Compact, rugged housing suitable for DIN-rail installation, with robust electrical isolation and environmental protection. - **Flexible Network Topology:** Supports daisy-chain and ring network configurations, allowing up to 100 m between stations using shielded Cat5 or higher Ethernet cables. - **Power Flexibility:** Operates from a 12–48 VDC power supply (±10%), with low power consumption (max. 2.7 W at 24 VDC). - **Wide Temperature Range:** Designed for harsh industrial environments with an operating range of -25°C to +75°C and storage range of -30°C to +80°C. - **Compact Dimensions:** 115 mm × 110 mm × 30 mm, optimized for space-constrained control cabinets. - **Ease of Integration:** Configuration via EtherCAT master using standard ESI (EtherCAT Slave Information) XML files. - **Visual Diagnostics:** Power and status LEDs provide clear indication of device state (INIT, Pre-Operational, Safe-Operational, Operational). - **Service-Friendly Wiring:** Modular terminal blocks for power and I/O connections simplify installation and maintenance.

Hersteller: Keine Kategorie

Kategorie: Remote IO Modules

- **EtherCAT Communication Protocol:** Fully compliant with EtherCAT® standards (IEEE 802.3 100BASE-TX), enabling deterministic, high-speed data exchange with EtherCAT masters. - **16 Isolated Digital Outputs:** Each channel supports open-collector output type, suitable for driving external loads such as relays, solenoids, and indicator lamps. - **Wide Load Voltage Range:** Supports 4.5–32 VDC load voltage, providing flexibility for various industrial devices. - **High Output Current Capability:** Each channel can handle 400–1000 mA, depending on load and voltage conditions. - **LED Status Indicators:** 16 individual LEDs display the real-time status of each digital output channel, simplifying diagnostics and maintenance. - **Dual RJ-45 Ports:** Two Ethernet ports (IN/OUT) allow daisy-chain or ring topology connections, reducing cabling complexity. - **Compact DIN-Rail Mountable Design:** 115 × 110 × 30 mm enclosure optimized for control cabinet installation. - **Wide Operating Temperature Range:** Designed for harsh industrial environments, operating reliably from -25°C to +75°C. - **Flexible Power Input:** Accepts 12–48 VDC (±10%) supply voltage, supporting a variety of industrial power systems. - **Low Power Consumption:** Maximum 2.7 W at 24 VDC ensures energy-efficient operation. - **Robust Construction:** Industrial-grade housing with frame ground (FG) connection for enhanced electrical safety and noise immunity. - **Easy Configuration:** Supports configuration via EtherCAT Master tools such as Beckhoff TwinCAT or EtherCAT Configurator using the provided ESI XML file. - **Service-Friendly Wiring:** Modular terminal blocks for power and I/O connections simplify installation and maintenance.

Hersteller: Keine Kategorie

Kategorie: Remote IO Modules
