1. Product Overview
Product Name: CPS5305
Model Number: CPS5305
Series: CompactPCI (cPCI) Analog Output Series
Article Number: CPS5305
Manufacturer: Axiom
The Axiom CPS5305 is a high-performance 2-channel isolated analog output card designed for CompactPCI (cPCI) systems. It provides 12-bit digital-to-analog (DA) conversion with multiple output ranges and robust electrical isolation, making it suitable for industrial automation, process control, and data acquisition applications. The card integrates advanced isolation technology, a built-in DC/DC converter, and plug-and-play functionality for seamless integration into cPCI-based control and monitoring systems.
2. Key Features
- Two Isolated Analog Output Channels: Provides two independent, galvanically isolated DA channels for precise analog signal generation.
- 12-bit Resolution: Ensures accurate and stable analog output performance suitable for control and instrumentation tasks.
- Multiple Output Ranges: Supports configurable output ranges including 0–20 mA, 4–20 mA, ±5 V, ±10 V, 0–5 V, and 0–10 V, allowing flexible adaptation to various industrial signal standards.
- High Isolation Voltage: Offers 500 VDC isolation between channels and between each channel and the system bus, enhancing noise immunity and protecting against ground loops and electrical interference.
- Integrated DC/DC Converter: Provides isolated power for each channel, ensuring stable operation and maintaining isolation integrity.
- CompactPCI Bus Interface: Fully compliant with the cPCI standard, enabling easy integration into modular industrial computing systems.
- Plug-and-Play Configuration: Supports automatic resource allocation and system recognition, minimizing setup time and configuration complexity.
- Dual DB9 Male Connectors: Each channel is accessible via standard DB9 connectors, simplifying wiring and field connections.
- Compact Form Factor: Standard 100 mm × 160 mm Eurocard dimensions for compatibility with 3U CompactPCI slots.
- Industrial-Grade Design: Engineered for reliability in demanding environments, with robust isolation and durable construction.
3. Technical Specifications
- Bus Interface: CompactPCI (cPCI)
- Number of Channels: 2 isolated analog output channels
- Resolution: 12 bits
- Output Ranges:
- Voltage: 0–5 V, 0–10 V, ±5 V, ±10 V
- Current: 0–20 mA, 4–20 mA
- Isolation Voltage: 500 VDC (channel-to-channel and channel-to-bus)
- Isolation Type: Galvanic isolation with integrated DC/DC converter
- Connectors: 2 × DB9 male connectors (one per channel)
- Card Dimensions: 100 mm (H) × 160 mm (L)
- Form Factor: 3U Eurocard (CompactPCI standard)
- Power Supply: Derived from cPCI backplane; isolated via onboard DC/DC converter
- Output Accuracy: 12-bit resolution (1 part in 4096)
- Output Type: Voltage or current, software or jumper selectable (depending on configuration)
- Operating Temperature Range: Industrial-grade (typical 0°C to +60°C, depending on system configuration)
- Storage Temperature Range: -20°C to +85°C (typical)
- Relative Humidity: 5% to 95% non-condensing (typical industrial specification)
- Weight: Approx. 200–250 g (typical for 3U cPCI analog output cards)
- Material: PCB with industrial-grade components, metal front panel with DB9 connectors
4. Functionality
The CPS5305 functions as a digital-to-analog converter (DAC) card that interfaces with a CompactPCI system to generate precise analog output signals. Each of the two channels can independently output either voltage or current signals, depending on the configured range.
Operation Principle:
- The host system sends digital data to the CPS5305 via the cPCI bus.
- The onboard 12-bit DAC converts the digital value into a corresponding analog signal.
- The analog output is then isolated through the integrated DC/DC converter and isolation circuitry, ensuring electrical separation between channels and the system bus.
- The resulting analog signal is available at the DB9 connector for connection to external devices such as actuators, control valves, or analog input modules.
Use Cases and Applications:
- Industrial Automation: Analog control of actuators, drives, and process equipment.
- Process Control Systems: Generation of control signals for proportional valves, temperature controllers, and flow regulators.
- Data Acquisition Systems: Output of reference or test signals for calibration and simulation.
- Laboratory and Test Equipment: Signal generation for instrumentation and measurement setups.
- Embedded Control Systems: Integration into CompactPCI-based embedded controllers for real-time analog output tasks.
Compatibility:
- Compatible with standard CompactPCI backplanes and chassis.
- Works with Axiom and third-party CompactPCI controllers and operating systems supporting cPCI I/O cards.
5. Components & Accessories
Included Items:
- CPS5305 2-channel isolated DA card
- Front panel with two DB9 male connectors
- User documentation or quick installation guide (depending on packaging)
Optional Accessories:
- DB9-to-terminal block breakout cables for easy field wiring
- Shielded DB9 cables for noise-sensitive environments
- CompactPCI chassis and backplane (sold separately)
- Software drivers and SDKs (if provided by Axiom for system integration)
Connectors:
- DB9 Male (x2): Each connector provides access to one isolated analog output channel, including signal and ground terminals.
6. Installation & Setup
Requirements:
- Compatible CompactPCI chassis with available 3U slot
- System controller with cPCI bus support
- Appropriate power supply via cPCI backplane
Installation Steps:
1. Power down the CompactPCI system before installation.
2. Insert the CPS5305 card into an available 3U cPCI slot, ensuring proper alignment with the backplane connector.
3. Secure the card using the front panel screws.
4. Connect external devices to the DB9 connectors using appropriate cables.
5. Power on the system; the card will be automatically detected (plug-and-play).
6. Configure output ranges and channel modes via software or hardware jumpers (depending on system design).
Mounting Options:
- Standard CompactPCI front-panel mounting with screw retention.
- Compatible with standard 3U Eurocard mechanical dimensions.
Configuration:
- Output range selection (voltage/current) may be configured through software or onboard jumpers.
- Channel calibration and scaling can be managed through system software or driver utilities.
7. Performance & Capabilities
- Resolution: 12-bit (4096 discrete output levels)
- Output Accuracy: High linearity and repeatability suitable for industrial control applications.
- Isolation Performance: 500 VDC isolation ensures robust protection against electrical noise and ground potential differences.
- Speed: Typical update rate sufficient for process control and general-purpose analog output tasks (exact rate dependent on system bus and software).
- Capacity: Two fully isolated channels allow simultaneous independent analog outputs.
- Efficiency: Integrated DC/DC converter provides efficient isolated power distribution to each channel.
- Limitations:
- Limited to 12-bit resolution (not suitable for high-precision laboratory-grade applications requiring 16-bit or higher).
- Output speed constrained by cPCI bus bandwidth and system software latency.
- Designed for low- to medium-speed control applications rather than high-frequency waveform generation.
8. Standards & Compliance
- Bus Standard: CompactPCI (cPCI) compliant with PICMG 2.x specifications.
- Electrical Isolation: Meets industrial isolation standards for 500 VDC channel-to-channel and channel-to-bus separation.
- Safety and EMC Compliance: Designed to meet typical industrial EMC and safety requirements (specific certifications may vary by region).
- RoHS Compliance: Manufactured using lead-free, RoHS-compliant components and processes.
- Quality Assurance: Produced under Axiom’s quality management system for industrial electronics.
9. Additional Information
Warranty:
- Standard manufacturer’s warranty (typically 1–2 years, depending on region and distributor).
- Covers defects in materials and workmanship under normal operating conditions.
Support:
- Technical support available through Axiom’s customer service and online resources.
- Documentation includes installation guides, pin assignments, and configuration instructions.
- Software support may include driver packages and example code for integration with CompactPCI systems.
Maintenance:
- Minimal maintenance required; periodic inspection of connectors and cabling recommended.
- Ensure proper ventilation and environmental conditions within the CompactPCI chassis.
- Avoid exposure to excessive vibration, moisture, or dust.
Updates:
- Firmware or driver updates (if applicable) may be provided by Axiom to enhance compatibility or performance.
- Product revisions may include improved isolation, updated DAC components, or expanded software support.
### Summary
The Axiom CPS5305 is a 2-channel, 12-bit isolated analog output card engineered for CompactPCI (cPCI) systems. It delivers reliable, accurate analog signal generation with configurable voltage and current ranges, robust 500 VDC isolation, and integrated DC/DC power conversion. Its dual DB9 connectors, plug-and-play functionality, and compact 3U Eurocard form factor make it an ideal solution for industrial automation, process control, and embedded system applications requiring isolated analog outputs.
With its combination of precision, isolation, and modular design, the CPS5305 provides a dependable interface between digital control systems and analog field devices, ensuring stable performance and long-term reliability in demanding industrial environments.
