1. Product Overview
Product Name: Termination Board with 68-pin SCSI-II Connector and DIN-Rail Mounting
Model: DIN-68M0
Series: DIN Series Termination Boards
Article Number: DIN-68M0
Manufacturer: ADLINK Technology Inc.
The ADLINK DIN-68M0 is a high-quality termination board designed for industrial and laboratory applications requiring reliable signal interfacing between SCSI-II type connectors and field wiring through a DIN-rail mounted terminal interface. It serves as a passive breakout and termination solution for 68-pin SCSI-II connections, providing a convenient and organized method for connecting data acquisition (DAQ) devices, I/O modules, or other control hardware to external sensors, actuators, or signal sources. The board is engineered for robust performance in industrial environments, offering secure mechanical mounting, stable electrical connections, and compatibility with a wide range of ADLINK and third-party data acquisition systems.
2. Key Features
- 68-pin SCSI-II Connector Interface: Provides a standard high-density 68-pin SCSI-II (Half-Pitch) connector for direct connection to compatible DAQ cards, motion controllers, or digital I/O modules.
- DIN-Rail Mounting: Designed for easy installation on standard 35 mm DIN rails, enabling quick integration into control cabinets, test benches, or industrial enclosures.
- Direct Signal Termination: Facilitates direct wiring of field signals to the corresponding pins of the SCSI-II connector, simplifying system wiring and reducing installation time.
- Passive Design: No active components; ensures signal integrity without introducing additional noise or delay.
- High-Density Terminal Layout: Provides clearly labeled screw terminals corresponding to each SCSI-II pin, allowing organized and error-free wiring.
- Industrial-Grade Construction: Built with durable materials suitable for harsh environments, ensuring long-term reliability and mechanical stability.
- Compatibility: Fully compatible with ADLINK DAQ cards and other SCSI-II interface devices, supporting both analog and digital signal routing.
- Maintenance-Friendly: Modular design allows easy replacement or reconfiguration without disturbing other system components.
- No Cable Included: The DIN-68M0 is supplied without a connecting cable, allowing users to select the appropriate cable length and type for their specific application.
3. Technical Specifications
- Connector Type: 68-pin SCSI-II (Half-Pitch, Female)
- Terminal Type: Screw-type terminal blocks, one terminal per signal line
- Number of Channels: 68 signal lines corresponding to the SCSI-II pinout
- Mounting Type: DIN-rail (35 mm standard rail, EN 50022 compatible)
- Board Dimensions: Approx. 180 mm (L) × 80 mm (W) × 35 mm (H) *(typical for DIN-rail termination boards; actual dimensions may vary slightly)*
- Weight: Approximately 250–300 g
- Material:
- PCB: FR-4 industrial-grade fiberglass epoxy laminate
- Terminals: Nickel-plated brass with screw clamps
- Housing: Aluminum or reinforced ABS enclosure for mechanical protection
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -20°C to +85°C
- Relative Humidity: 10% to 90% non-condensing
- Insulation Resistance: ≥100 MΩ @ 500 VDC
- Dielectric Strength: 1000 VAC for 1 minute between isolated circuits
- Signal Type Supported: Analog, digital, or mixed I/O signals (depending on connected device)
- Maximum Voltage (per channel): Typically up to 30 VDC (depending on connected DAQ card specifications)
- Maximum Current (per channel): Typically up to 1 A continuous (terminal rating)
- Color Coding: Terminal blocks and connector labels printed for easy identification
- Compliance: RoHS compliant
4. Functionality
The DIN-68M0 functions as a passive interface board that terminates a 68-pin SCSI-II cable connection into individual screw terminals. Each terminal corresponds directly to a pin on the SCSI-II connector, allowing users to connect discrete wires from sensors, switches, relays, or other field devices.
How It Works:
When a SCSI-II cable from a DAQ card or controller is connected to the DIN-68M0, the board routes each signal line to a corresponding terminal. Users can then attach field wiring to these terminals, enabling direct access to input/output channels without soldering or custom cabling. The board does not modify or condition signals; it simply provides a reliable mechanical and electrical interface.
Use Cases and Applications:
- Industrial automation and control systems
- Data acquisition and measurement setups
- Laboratory instrumentation and testing environments
- Motion control and machine vision systems
- Signal breakout for debugging or prototyping
- Educational and research laboratories requiring flexible wiring interfaces
Compatibility:
The DIN-68M0 is compatible with ADLINK DAQ cards and modules that use a 68-pin SCSI-II connector, such as the PCI-911x, PCI-7250, PCI-7300, or PXI-2000 series. It can also be used with other manufacturers’ hardware that follows the same SCSI-II pinout standard.
5. Components & Accessories
Included Items:
- DIN-68M0 termination board with pre-mounted 68-pin SCSI-II connector
- Integrated DIN-rail mounting clip or bracket
- Printed pinout and terminal labeling on the board surface
- Quick reference guide or installation leaflet
Optional Accessories (sold separately):
- 68-pin SCSI-II cable (various lengths available)
- DIN-rail mounting hardware (if additional support required)
- Protective terminal covers or dust caps
- Cable strain relief accessories
- Grounding wire or shield connection kit
Connectors:
- Primary Connector: 68-pin SCSI-II (female) for host connection
- Terminal Interface: 68 screw terminals for field wiring
- Grounding Terminal: Dedicated chassis ground terminal for shielding and noise reduction
6. Installation & Setup
Requirements:
- Compatible 68-pin SCSI-II cable and host device (DAQ card, controller, or I/O module)
- Standard 35 mm DIN rail for mounting
- Appropriate tools for wiring (screwdriver, wire stripper)
Mounting Options:
1. DIN-Rail Mounting:
- Attach the DIN-68M0 to a standard 35 mm DIN rail using the integrated clip.
- Ensure the board is securely fastened and aligned for easy cable access.
2. Panel Mounting (optional):
- The board can also be mounted on a flat surface using screws if DIN-rail installation is not desired.
Configuration Steps:
1. Mount the board on the DIN rail inside the control cabinet.
2. Connect the 68-pin SCSI-II cable from the DAQ card or controller to the board’s connector.
3. Identify the required signal terminals using the printed pinout.
4. Strip and insert field wires into the corresponding screw terminals.
5. Tighten terminal screws to ensure secure electrical contact.
6. Verify connections and perform continuity checks before powering the system.
Safety Considerations:
- Ensure all power sources are disconnected before wiring.
- Follow ESD protection procedures when handling the board.
- Avoid exceeding the rated voltage and current per channel.
7. Performance & Capabilities
Signal Integrity:
The DIN-68M0 provides a short, low-resistance path between the SCSI-II connector and terminal blocks, maintaining signal quality for both analog and digital signals. The passive design ensures minimal signal distortion or delay.
Speed and Bandwidth:
- Suitable for low- to medium-speed signal transmission typical of DAQ and control applications.
- Supports data rates consistent with SCSI-II interface standards (up to several MB/s, depending on cable and system configuration).
Capacity:
- 68 independent signal lines, each accessible via screw terminals.
- Supports single-ended or differential signal configurations (depending on connected device).
Efficiency:
- Simplifies wiring and reduces installation time.
- Minimizes wiring errors through clear labeling and organized layout.
Limitations:
- No active signal conditioning or isolation; external conditioning modules may be required for high-noise environments.
- Cable not included; users must select appropriate cable type and length.
- Not intended for high-frequency or high-voltage applications beyond rated specifications.
8. Standards & Compliance
Certifications:
- CE Mark (Conformité Européenne) for compliance with European safety and EMC directives
- RoHS (Restriction of Hazardous Substances) compliant
- WEEE (Waste Electrical and Electronic Equipment) directive compliant
Industry Standards:
- SCSI-II (Small Computer System Interface, second generation) connector standard
- DIN-rail mounting standard EN 50022
- Terminal block design compliant with IEC 60947-7-1 (low-voltage terminal blocks)
Regulatory Compliance:
- Designed and manufactured in accordance with ISO 9001 quality management standards
- Meets industrial safety and environmental requirements for electronic components
9. Additional Information
Warranty:
- Standard ADLINK limited warranty (typically 1 year from date of purchase) covering manufacturing defects and workmanship.
Support:
- Technical documentation, pinout diagrams, and user manuals available from ADLINK’s official website.
- Customer support via email, phone, and online knowledge base.
- Firmware or software updates not applicable (passive hardware).
Maintenance:
- Periodic inspection recommended to ensure terminal screws remain tight and free of corrosion.
- Clean with a dry, lint-free cloth; avoid solvents or moisture.
- Replace if mechanical damage or connector wear is observed.
Updates and Revisions:
- The DIN-68M0 may be subject to minor design revisions to improve performance or compatibility.
- Users should verify the latest datasheet and documentation before installation.
Environmental Considerations:
- Designed for long service life in industrial environments.
- Dispose of in accordance with local electronic waste regulations.
Summary
The ADLINK DIN-68M0 Termination Board is a robust, DIN-rail mountable interface solution that simplifies the connection between 68-pin SCSI-II equipped devices and field wiring. Its passive design ensures reliable signal transmission without interference, while its industrial-grade construction guarantees durability and ease of installation. Ideal for data acquisition, automation, and control applications, the DIN-68M0 provides a clean, organized, and efficient wiring interface for engineers and system integrators seeking dependable connectivity in demanding environments.
