- **High‑precision analog input:** 16 single‑ended channels, 16‑bit resolution, bipolar ±10 V input range, 100 kS/s (10 µs/channel) conversion rate. - **Digital I/O:** 4 TTL‑level inputs + 4 TTL‑level outputs (positive logic). - **Counter:** 1 channel, 32‑bit up‑counter, max frequency 10 MHz (1 MHz for isolated variant). - **Buffer memory:** 1 k‑word onboard FIFO/RING buffer enabling background sampling independent of host CPU load. - **Trigger and clock control:** Sampling start/stop selectable by software command, external trigger, or comparison of conversion data; internal or external sampling clock. - **Digital filter:** 1 µs software‑selectable filter suppresses chattering on external trigger, sampling clock, digital input, and counter signals. - **Software calibration:** All analog calibration performed in software; user can store additional adjustment data to compensate for environmental drift. - **Bus isolation (variant AI‑1616LI‑PE):** Digital isolator separates PC bus from external I/O circuits, improving noise immunity. - **Compatibility:** Connector and function compatible with legacy PCI ADI16‑16(LPCI)L boards, simplifying migration. - **Comprehensive software support:** Windows and Linux drivers, C‑LOGGER data‑logger, MATLAB ML‑DAQ library, and LabVIEW VI‑DAQ plug‑ins. - **Low‑profile PCI Express x1 interface:** Compliant with PCI Express Base Specification Rev 1.0a; fits compact industrial PCs. - **Operating environment:** 0 – 50 °C, 10 – 90 % RH (non‑condensing).

Manufacturer: Contec

Category: A/D General Purpose PCIe

- **Multi‑function Analog I/O:** Combines 8 analog input channels (16‑bit, ±10 V), 2 analog output channels (16‑bit, ±10 V), 4 digital inputs, 4 digital outputs, and one 32‑bit counter. - **High‑Resolution Conversion:** 16‑bit A/D and D/A converters deliver precise signal acquisition and generation up to 100 kS/s per channel. - **Buffer Memory:** 1 k‑word FIFO or ring buffer for both analog input and output, enabling background operation independent of host CPU load. - **Trigger and Clock Flexibility:** Supports software, external trigger, and external clock synchronization for both input and output. - **Software Calibration:** All analog channels can be calibrated via software; user calibration data can be stored in addition to factory settings. - **Digital Filtering:** 1 µs selectable digital filter on digital inputs, counter inputs, and external control signals to suppress chattering and noise. - **Low Profile Design:** Compliant with PCI Express Base Specification Rev. 1.0a (x1 lane). Supplied with both low‑profile and full‑height brackets. - **Comprehensive Software Support:** Includes Windows API‑PAC(W32) driver library, Linux API‑AIO(LNX) drivers, C‑LOGGER data logger, and free downloadable MATLAB (ML‑DAQ) and LabVIEW (VI‑DAQ) libraries. - **Data Logging and Visualization:** C‑LOGGER software enables real‑time graphing, file storage, and Excel data export without programming. - **RoHS and VCCI Compliant:** Meets environmental and electromagnetic compatibility standards.

Manufacturer: Contec

Category: A/D General Purpose PCIe
