1. Product Overview
Product Name: P M/Cel M Standalone Box PC
Model: ACS-2623
Series: ACS Industrial Box PC Series
Article Number: ACS-2623
Manufacturer: Aplex Technology Inc.

The Aplex ACS-2623 is a compact, industrial-grade standalone box PC designed for embedded control, automation, and industrial computing applications. It integrates Intel’s Mobile processor technology within a ruggedized enclosure, offering a balance between performance, reliability, and expandability. The system is engineered for continuous operation in demanding environments, providing flexible I/O connectivity, expansion options, and compatibility with a wide range of peripherals and operating systems.

---

2. Key Features
- Processor Options: Equipped with an Intel Celeron M 1.5 GHz processor, with optional upgrade to Intel Pentium M 1.8 GHz for enhanced performance.
- Chipset: Utilizes the Intel 855GME + ICH4 chipset, ensuring stable performance and compatibility with legacy and modern interfaces.
- Memory Support: One DDR SDRAM slot supporting up to 1 GB of system memory, allowing efficient multitasking for industrial control applications.
- Storage Flexibility:
- One 2.5" HDD bay for standard hard disk drives.
- One CompactFlash (CF) slot for solid-state storage or embedded OS deployment.
- One slim-type optical drive bay supporting CD-RW drives for data backup or software installation.
- I/O Connectivity:
- Two serial COM ports for RS-232/422/485 communication.
- Four USB 2.0 ports for peripheral connectivity.
- One LAN port for Ethernet networking.
- One VGA and one DVI output for dual-display support.
- Expansion Capability: Two PCI expansion slots for additional interface cards or specialized controllers.
- Power Supply: Wide-range AC input (100–240 VAC) for global compatibility and stable operation.
- Compact Design: Industrial-grade enclosure with dimensions of 390 × 100.196 × 212.5 mm (410 × 105.1 mm with wall-mount kit).
- Mounting Options: Wall-mountable design for flexible installation in control cabinets, kiosks, or machinery housings.
- Industrial Reliability: Designed for 24/7 operation, with robust thermal management and durable construction.

---

3. Technical Specifications
- Processor: Intel Celeron M 1.5 GHz (standard); optional Intel Pentium M 1.8 GHz.
- Chipset: Intel 855GME Northbridge + ICH4 Southbridge.
- Memory:
- Type: DDR SDRAM
- Slots: 1 × DDR slot
- Maximum Capacity: 1 GB
- Storage:
- 1 × 2.5" HDD bay
- 1 × CompactFlash slot
- 1 × Slim-type CD-RW drive bay
- Expansion Slots: 2 × PCI slots for add-on cards.
- I/O Interfaces:
- Serial Ports: 2 × COM (RS-232/422/485 configurable)
- USB Ports: 4 × USB 2.0
- LAN: 1 × 10/100 Mbps Ethernet port
- Display: 1 × VGA, 1 × DVI
- Power Input: 100 – 240 VAC, internal power supply.
- Dimensions:
- Main Unit: 390 mm (W) × 100.196 mm (H) × 212.5 mm (D)
- With Wall Mount Kit: 410 mm (W) × 105.1 mm (H)
- Construction: Industrial-grade metal chassis for durability and EMI protection.
- Cooling: Passive or active cooling depending on configuration; optimized airflow design for stable thermal performance.
- Weight: Approx. 4–5 kg (depending on configuration and installed drives).

---

4. Functionality
The ACS-2623 functions as a standalone embedded computer suitable for industrial automation, machine control, data acquisition, and digital signage. It operates as a fully independent computing unit capable of running standard operating systems such as Windows XP Embedded, Windows 7 Embedded, or Linux distributions tailored for industrial use.

Operational Concept:
- The system’s Intel Mobile processor and chipset provide a balance between low power consumption and sufficient processing power for control logic, data processing, and communication tasks.
- The integrated I/O ports allow direct connection to sensors, actuators, PLCs, and other industrial devices.
- The dual-display outputs (VGA and DVI) enable simultaneous connection to operator panels or external monitors for visualization and control interfaces.
- The PCI expansion slots allow integration of additional communication cards (e.g., fieldbus, motion control, or data acquisition modules).
- The CompactFlash slot supports embedded OS installation or data logging applications where solid-state reliability is required.

Use Cases and Applications:
- Factory automation and process control systems.
- Machine vision and inspection systems.
- Kiosk and digital signage controllers.
- Transportation and logistics terminals.
- Building automation and energy management systems.
- Industrial data collection and monitoring stations.

Compatibility:
- Compatible with standard PC peripherals and industrial communication interfaces.
- Supports mainstream operating systems and software platforms used in automation and embedded computing.

---

5. Components & Accessories
Included Components:
- ACS-2623 main unit (assembled with CPU, chipset, and power supply).
- Wall-mount kit (optional, depending on configuration).
- Power cable (region-specific).
- User manual and driver CD.

Optional Accessories:
- 2.5" HDD or SSD (user-supplied or factory-installed).
- CompactFlash card for OS or data storage.
- Slim-type CD-RW optical drive.
- PCI expansion cards (e.g., additional serial ports, fieldbus interfaces, or I/O modules).
- Mounting brackets for panel or DIN-rail installation (if supported).
- External keyboard, mouse, and display cables.

Connectors and Interfaces:
- Standard DB9 connectors for COM ports.
- USB Type-A ports for external devices.
- RJ45 connector for Ethernet.
- VGA (DB15) and DVI-I connectors for display output.
- Power input connector integrated into chassis rear panel.

---

6. Installation & Setup
Requirements:
- AC power source (100–240 VAC, 50/60 Hz).
- Adequate ventilation or ambient cooling to maintain stable operating temperature.
- Mounting surface capable of supporting the unit’s weight and vibration load.

Mounting Options:
- Wall-mount installation using the included or optional bracket kit.
- Desktop or shelf placement for laboratory or control room use.
- Integration into control cabinets or enclosures for industrial environments.

Configuration Steps:
1. Mount the unit securely using the provided wall-mount kit or other mounting accessories.
2. Connect the power cable to the AC input.
3. Attach display devices via VGA or DVI ports.
4. Connect peripherals such as keyboard, mouse, and USB devices.
5. Install storage devices (HDD, CF card, or optical drive) as required.
6. Power on the system and enter BIOS setup to configure boot sequence and hardware parameters.
7. Install the desired operating system and drivers from the provided media.
8. Configure network and serial communication settings for application-specific requirements.

Environmental Considerations:
- Ensure adequate airflow around the chassis.
- Avoid exposure to excessive dust, moisture, or vibration.
- Maintain ambient operating temperature within manufacturer-specified limits (typically 0 °C – 50 °C for industrial PCs).

---

7. Performance & Capabilities
Processing Performance:
- The Intel Celeron M 1.5 GHz processor provides efficient performance for control and monitoring tasks, while the optional Pentium M 1.8 GHz upgrade delivers higher computational throughput for data-intensive applications.
- The Intel 855GME chipset supports integrated graphics and stable memory performance, ensuring reliable operation in embedded environments.

Memory and Storage Performance:
- DDR SDRAM memory up to 1 GB ensures smooth multitasking for embedded applications.
- The 2.5" HDD bay supports standard SATA or IDE drives (depending on configuration), providing ample storage for operating systems and application data.
- CompactFlash storage offers solid-state reliability for critical systems requiring high durability and resistance to shock or vibration.

I/O and Communication:
- Dual COM ports enable integration with legacy serial devices, PLCs, and industrial sensors.
- Four USB 2.0 ports provide connectivity for modern peripherals, data acquisition modules, or external storage.
- The Ethernet port supports 10/100 Mbps networking for remote monitoring, data transfer, and system integration.

Graphics and Display:
- Integrated Intel graphics controller supports VGA and DVI outputs, allowing connection to both analog and digital displays.
- Dual-display capability enables simultaneous visualization and control interfaces.

Expansion and Scalability:
- Two PCI slots allow system customization with additional I/O, communication, or motion control cards.
- Modular design supports future upgrades and system reconfiguration.

Efficiency and Reliability:
- Low-power Intel Mobile architecture minimizes heat generation and power consumption.
- Industrial-grade components ensure long-term reliability and stable operation in continuous-use environments.

Limitations:
- Memory limited to 1 GB due to single DDR slot.
- No integrated wireless connectivity (requires external module).
- Limited to PCI expansion (no PCIe support).

---

8. Standards & Compliance
Certifications and Compliance:
- Designed in accordance with industrial computing standards for safety and electromagnetic compatibility.
- Complies with CE and FCC Class A requirements for industrial environments.
- RoHS-compliant construction, ensuring environmentally responsible manufacturing.
- Meets general industrial PC design standards for durability, thermal management, and electrical safety.

Industry Standards Supported:
- Intel x86 architecture compatibility for broad software support.
- USB 2.0, VGA, DVI, and Ethernet standards for peripheral and network interoperability.
- PCI bus standard for expansion card compatibility.

---

9. Additional Information
Warranty:
- Standard manufacturer warranty (typically 1 year, extendable depending on region and distributor).
- Covers defects in materials and workmanship under normal operating conditions.

Support:
- Technical support available through Aplex’s global service network.
- Online resources include driver downloads, BIOS updates, and documentation.
- Optional extended service contracts and on-site support available for industrial customers.

Maintenance:
- Periodic cleaning of ventilation openings recommended to maintain optimal cooling.
- Firmware and BIOS updates can be applied via USB or CF storage.
- Replaceable storage and memory components allow easy maintenance and upgrades.

Software and Updates:
- Supports installation of standard operating systems (Windows, Linux, or embedded variants).
- BIOS configurable for boot order, power management, and hardware monitoring.
- Driver updates and utilities available from Aplex’s official website.

Lifecycle and Availability:
- Designed for long-term availability and stable supply for industrial OEMs and system integrators.
- Backward compatibility with legacy interfaces ensures extended usability in existing installations.

---

Summary
The Aplex ACS-2623 P M/Cel M Standalone Box PC is a versatile, industrial-grade computing platform optimized for embedded control and automation. Combining Intel Mobile processor technology with a robust I/O set, flexible expansion, and durable construction, it delivers dependable performance in mission-critical environments. Its compact form factor, wide power input range, and comprehensive connectivity make it suitable for diverse industrial applications—from factory automation to digital signage and machine control. With its proven reliability, configurable options, and compliance with industrial standards, the ACS-2623 represents a stable and efficient solution for long-term embedded computing deployments.
