- High‑Speed Managed Switching:
16 × 10/100Base‑TX RJ‑45 ports plus 2 × Gigabit SX/LX combo ports (10/100/1000Base‑T or 1000Base‑X SFP).
Supports full‑duplex operation with throughput up to 200 Mbps per Fast Ethernet port.
- Ultra‑Fast Redundant Ring:
SUNIX ELITE‑Ring™ technology provides sub‑10 ms recovery time, ensuring uninterrupted data flow even during link or node failures. Supports Ring Coupling and Dual Homing for complex topologies.
- Comprehensive Management Interfaces:
Configuration via Web browser (HTTPS), Telnet, Serial Console (RS‑232), SNMP v1/v2c/v3, and SUNIX Commander Pro Windows utility.
Supports CLI (Command Line Interface) for advanced configuration and scripting.
- Advanced Network Control:
- IEEE 802.1Q VLAN tagging and GVRP for VLAN propagation
- IEEE 802.1p QoS/ToS prioritization for deterministic traffic
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) and IEEE 802.1d STP
- IEEE 802.3ad Port Trunking (LACP) for bandwidth aggregation
- IGMP Snooping (v1/v2/v3) for multicast optimization
- RMON (Groups 1, 2, 3, 9) for remote monitoring
- Security & Access Control:
- IEEE 802.1X user authentication with RADIUS server integration
- IP and MAC‑based access control lists (ACLs)
- Port security (MAC binding) and DHCP filtering
- SNMPv3 encrypted authentication and access security
- HTTPS and SSH for secure management sessions
- Diagnostics & Alerts:
- Configurable relay output alarm and alarm LED
- E‑mail notifications and SNMP traps for event reporting
- Port mirroring for traffic analysis
- Broadcast storm protection and port break alarms
- Industrial‑Grade Design:
- Dual redundant 12–48 V DC power inputs (terminal block + DC jack)
- ESD protection: 4 kV DC on Ethernet ports
- Surge protection: 2 kV DC on power input
- Reverse polarity protection
- Operating temperature: 0 °C – 70 °C
- IP30 aluminum enclosure, 2U rack‑mountable
- Reliability & Longevity:
Designed for 24/7 continuous operation in vibration, shock, and temperature‑extreme environments.
Backed by a 5‑year manufacturer warranty.
16 × 10/100Base‑TX RJ‑45 ports plus 2 × Gigabit SX/LX combo ports (10/100/1000Base‑T or 1000Base‑X SFP).
Supports full‑duplex operation with throughput up to 200 Mbps per Fast Ethernet port.
- Ultra‑Fast Redundant Ring:
SUNIX ELITE‑Ring™ technology provides sub‑10 ms recovery time, ensuring uninterrupted data flow even during link or node failures. Supports Ring Coupling and Dual Homing for complex topologies.
- Comprehensive Management Interfaces:
Configuration via Web browser (HTTPS), Telnet, Serial Console (RS‑232), SNMP v1/v2c/v3, and SUNIX Commander Pro Windows utility.
Supports CLI (Command Line Interface) for advanced configuration and scripting.
- Advanced Network Control:
- IEEE 802.1Q VLAN tagging and GVRP for VLAN propagation
- IEEE 802.1p QoS/ToS prioritization for deterministic traffic
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) and IEEE 802.1d STP
- IEEE 802.3ad Port Trunking (LACP) for bandwidth aggregation
- IGMP Snooping (v1/v2/v3) for multicast optimization
- RMON (Groups 1, 2, 3, 9) for remote monitoring
- Security & Access Control:
- IEEE 802.1X user authentication with RADIUS server integration
- IP and MAC‑based access control lists (ACLs)
- Port security (MAC binding) and DHCP filtering
- SNMPv3 encrypted authentication and access security
- HTTPS and SSH for secure management sessions
- Diagnostics & Alerts:
- Configurable relay output alarm and alarm LED
- E‑mail notifications and SNMP traps for event reporting
- Port mirroring for traffic analysis
- Broadcast storm protection and port break alarms
- Industrial‑Grade Design:
- Dual redundant 12–48 V DC power inputs (terminal block + DC jack)
- ESD protection: 4 kV DC on Ethernet ports
- Surge protection: 2 kV DC on power input
- Reverse polarity protection
- Operating temperature: 0 °C – 70 °C
- IP30 aluminum enclosure, 2U rack‑mountable
- Reliability & Longevity:
Designed for 24/7 continuous operation in vibration, shock, and temperature‑extreme environments.
Backed by a 5‑year manufacturer warranty.
Comprehensive Product Summary – SUNIX ESW‑5162‑GP Managed Industrial Gigabit Ethernet Switch
*(Approx. 12,000 characters / ~3,000 tokens)*
### 1. Product Overview
Product Name: Managed Gigabit SX/LX 16‑Port Industrial Ethernet Switch
Model: ESW‑5162‑GP
Series: SUNIX ESW Series – Managed Gigabit Redundant Ethernet Switches
Article Number: ESW‑5162‑GP
Manufacturer: SUNIX Co., Ltd. (Taiwan)
Product Category: Industrial Managed Ethernet Switches
The SUNIX ESW‑5162‑GP is a high‑performance, fully managed Layer 2 industrial Ethernet switch designed for mission‑critical automation, transportation, and utility applications. It provides 16 Fast Ethernet (10/100Base‑TX) ports and two Gigabit SX/LX combo ports, supporting both copper and fiber connectivity. The switch integrates SUNIX’s proprietary ELITE‑Ring™ redundancy technology, achieving network recovery times of less than 10 milliseconds across up to 50 interconnected units. Engineered for harsh industrial environments, it features redundant power inputs, robust surge and ESD protection, and an IP30 aluminum enclosure suitable for rack‑mount installation.
### 2. Key Features
- High‑Speed Managed Switching:
16 × 10/100Base‑TX RJ‑45 ports plus 2 × Gigabit SX/LX combo ports (10/100/1000Base‑T or 1000Base‑X SFP).
Supports full‑duplex operation with throughput up to 200 Mbps per Fast Ethernet port.
- Ultra‑Fast Redundant Ring:
SUNIX ELITE‑Ring™ technology provides sub‑10 ms recovery time, ensuring uninterrupted data flow even during link or node failures. Supports Ring Coupling and Dual Homing for complex topologies.
- Comprehensive Management Interfaces:
Configuration via Web browser (HTTPS), Telnet, Serial Console (RS‑232), SNMP v1/v2c/v3, and SUNIX Commander Pro Windows utility.
Supports CLI (Command Line Interface) for advanced configuration and scripting.
- Advanced Network Control:
- IEEE 802.1Q VLAN tagging and GVRP for VLAN propagation
- IEEE 802.1p QoS/ToS prioritization for deterministic traffic
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) and IEEE 802.1d STP
- IEEE 802.3ad Port Trunking (LACP) for bandwidth aggregation
- IGMP Snooping (v1/v2/v3) for multicast optimization
- RMON (Groups 1, 2, 3, 9) for remote monitoring
- Security & Access Control:
- IEEE 802.1X user authentication with RADIUS server integration
- IP and MAC‑based access control lists (ACLs)
- Port security (MAC binding) and DHCP filtering
- SNMPv3 encrypted authentication and access security
- HTTPS and SSH for secure management sessions
- Diagnostics & Alerts:
- Configurable relay output alarm and alarm LED
- E‑mail notifications and SNMP traps for event reporting
- Port mirroring for traffic analysis
- Broadcast storm protection and port break alarms
- Industrial‑Grade Design:
- Dual redundant 12–48 V DC power inputs (terminal block + DC jack)
- ESD protection: 4 kV DC on Ethernet ports
- Surge protection: 2 kV DC on power input
- Reverse polarity protection
- Operating temperature: 0 °C – 70 °C
- IP30 aluminum enclosure, 2U rack‑mountable
- Reliability & Longevity:
Designed for 24/7 continuous operation in vibration, shock, and temperature‑extreme environments.
Backed by a 5‑year manufacturer warranty.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|------------------|
| Ethernet Standards | IEEE 802.3 (10Base‑T), 802.3u (100Base‑TX), 802.3z (Gigabit Fiber), 802.3ab (1000Base‑T), 802.3x (Flow Control), 802.3ad (LACP), 802.1d (STP), 802.1w (RSTP), 802.1p (QoS), 802.1Q (VLAN), 802.1x (Authentication) |
| Ports | 16 × 10/100Base‑TX RJ‑45 + 2 × Gigabit SX/LX combo ports (RJ‑45/SFP) |
| Transmission Speed | 10/100/1000 Mbps (auto‑negotiation) |
| Transmission Distance | RJ‑45: up to 100 m; Fiber: 2 km – 80 km (depending on transceiver) |
| MAC Address Table | 8 K entries |
| Priority Queues | 4 hardware queues |
| Processing Type | Store‑and‑Forward |
| Diagnostics | Relay output, LEDs, SNMP traps, e‑mail alerts, port mirroring |
| Configuration Interfaces | Web (HTTP/HTTPS), Telnet, Serial Console (RS‑232, 9600 bps 8N1), SNMP, SUNIX Commander Pro |
| Redundancy | ELITE‑Ring™ (< 10 ms recovery), STP, RSTP |
| VLAN Support | IEEE 802.1Q tagged VLANs and port‑based VLANs |
| Security | IP/MAC filtering, RADIUS, 802.1X, ACLs, HTTPS/SSH |
| Traffic Control | Rate limiting, port lock, DHCP/TFTP/SNTP, QoS/ToS |
| Power Input | Dual 12 – 48 V DC (nominal 24 V DC) |
| Power Consumption | Max 18 W |
| Connectors | 6‑pin removable terminal block + DC jack |
| Protection | ESD 4 kV DC (Ethernet), Surge 2 kV DC (Power), Reverse polarity |
| Enclosure | IP30 aluminum, rack‑mount (2U) |
| Dimensions (D × W × H) | 280 × 440 × 44 mm |
| Weight | Approx. 3.5 kg |
| Operating Temperature | 0 °C – 70 °C |
| Storage Temperature | –10 °C – 85 °C |
| Humidity | 5 % – 95 % RH (non‑condensing) |
| Safety Certifications | UL 60950, UL 508, CAN/CSA‑C22.2 No. 60950 |
| Hazardous Location | UL/cUL Class I, Div 2 |
| EMC Compliance | FCC Part 15 Class A, CISPR (EN55022) Class A, CE |
| Shock/Vibration | IEC 60068‑2‑27 (Shock), IEC 60068‑2‑32 (Free‑fall), IEC 60068‑2‑6 (Vibration) |
| Warranty | 5 Years |
### 4. Functionality
The ESW‑5162‑GP operates as a managed Layer 2 switch providing deterministic Ethernet communication for industrial automation. It supports both copper and fiber interfaces, enabling flexible network topologies such as star, ring, or mixed configurations.
Operation Principle:
Data packets are processed using store‑and‑forward switching with hardware‑based filtering and prioritization. The switch automatically negotiates link speed and duplex mode per port. In ring topologies, the ELITE‑Ring™ protocol continuously monitors link integrity; upon detecting a failure, traffic is rerouted through an alternate path within 10 ms, maintaining uninterrupted communication.
Use Cases & Applications:
- Factory and process automation networks
- Transportation and traffic control systems
- Power utilities and substations
- Building automation and security systems
- Oil, gas, and water treatment facilities
- Any mission‑critical Ethernet infrastructure requiring redundancy and deterministic performance
Compatibility:
Interoperable with standard Ethernet devices and compliant with IEEE 802.3/802.1 protocols. Compatible with third‑party SNMP management platforms and SUNIX Commander Pro for centralized configuration.
### 5. Components & Accessories
Included Items:
- ESW‑5162‑GP switch unit
- Rack‑mount kit (left & right brackets)
- Power cord (AC 100–240 V)
- RS‑232 console cable (DB9‑F to RJ‑45)
- Mounting screws (M3 × 5)
- Quick Installation Guide (QIG)
- Product CD (manuals and utilities)
Optional Accessories:
- SFP fiber transceivers (multi‑mode 2 km, single‑mode 30 km – 80 km)
- DIN‑rail mounting kit (for alternative installation)
- Replacement terminal block connectors
Connectors:
- 16 × RJ‑45 10/100Base‑TX ports
- 2 × Gigabit combo ports (RJ‑45 + SFP)
- 1 × RS‑232 console port (9600 bps, 8N1)
- 6‑pin removable terminal block for DC power
- DC jack for secondary power input
### 6. Installation & Setup
Mounting Options:
- Standard 19‑inch rack‑mount (2U height) using included brackets
- Optional DIN‑rail or wall‑mount kit for industrial cabinets
Power Requirements:
- Dual 12–48 V DC inputs for redundancy
- Reverse polarity protection prevents damage from incorrect wiring
- Power consumption up to 18 W
Network Cabling:
- Copper: CAT 5/5e UTP, up to 100 m per segment
- Fiber: Multi‑mode (50/125 µm – 2 km) or single‑mode (9/125 µm – up to 80 km) via SFP modules
Initial Configuration:
1. Connect via RS‑232 console or Web browser.
2. Default IP address 192.168.1.1 / Subnet 255.255.255.0 / Gateway 192.168.1.254.
3. Default credentials: admin / admin.
4. Configure network parameters, VLANs, and redundancy settings.
5. Save configuration to flash memory to retain after reboot.
Management Tools:
- Web GUI: Embedded HTML interface for intuitive configuration.
- CLI: Full command set for advanced users (via console or Telnet).
- SUNIX Commander Pro: Windows utility for batch configuration, firmware upgrades, and topology visualization.
- SNMP: Integration with network management systems for monitoring and traps.
### 7. Performance & Capabilities
- Switching Capacity: 18 ports total (16 Fast + 2 Gigabit)
- Throughput: Wire‑speed switching on all ports; 200 Mbps per Fast Ethernet port (full duplex)
- Latency: < 10 µs for 64‑byte frames (typical)
- Redundancy Recovery: < 10 ms across up to 50 units in ELITE‑Ring™ topology
- Bandwidth Aggregation: IEEE 802.3ad LACP supports up to 4 ports per trunk group
- QoS: Four priority queues with configurable scheduling (SP, WRR 8:4:2:1, WRR 15:7:3:1, WRR 15:10:5:1)
- VLANs: Up to 256 IEEE 802.1Q VLAN groups; 64 port‑based VLANs
- MAC Table: 8,192 entries with 300 s aging time (configurable)
- IGMP Snooping: Efficient multicast filtering without flooding
- Security: 802.1X authentication, RADIUS, ACLs, DHCP filtering, IP security (10 allowed management IPs)
- Diagnostics: Port statistics, event logs, SNMP traps, e‑mail alerts, relay output alarm
- Reliability: Continuous operation under vibration, shock, and temperature extremes
Limitations:
- Designed for Layer 2 switching; does not perform Layer 3 routing.
- Operating temperature limited to 0–70 °C (for extended range, other SUNIX models available).
### 8. Standards & Compliance
IEEE Standards Supported:
- IEEE 802.3 / 802.3u / 802.3z / 802.3ab – Ethernet and Gigabit Ethernet
- IEEE 802.3x – Flow Control and Back Pressure
- IEEE 802.3ad – Link Aggregation Control Protocol (LACP)
- IEEE 802.1d / 802.1w – Spanning Tree and Rapid Spanning Tree Protocols
- IEEE 802.1p – Class of Service / QoS
- IEEE 802.1Q – VLAN Tagging and GVRP
- IEEE 802.1x – Port‑based Network Access Control
Safety & Environmental Compliance:
- UL 60950, UL 508, CAN/CSA‑C22.2 No. 60950 (Electrical Safety)
- UL/cUL Class I Division 2 (Hazardous Location)
- FCC Part 15 Class A, CISPR (EN55022) Class A, CE Mark (EMC)
- IEC 60068‑2‑27 (Shock), IEC 60068‑2‑32 (Free‑fall), IEC 60068‑2‑6 (Vibration)
- EN 61000‑4‑2 (ESD), EN 61000‑4‑3 (RS), EN 61000‑4‑4 (EFT), EN 61000‑4‑5 (Surge Level 3), EN 61000‑4‑6 (CS Level 3)
- RoHS compliant
These certifications ensure the ESW‑5162‑GP meets global industrial networking standards for safety, electromagnetic compatibility, and environmental durability.
### 9. Additional Information
Warranty & Support:
- Warranty Period: 5 years limited hardware warranty.
- Technical Support: Provided by SUNIX global service centers and authorized distributors.
- Firmware Updates: Available via TFTP or SUNIX Commander Pro utility for group upgrades.
- Maintenance:
- Periodic inspection of power connections and ventilation.
- Firmware backup and configuration export recommended.
- Replace fiber transceivers as required for distance or wavelength changes.
Software Utilities:
- SUNIX Commander Pro:
- Multi‑device discovery and configuration
- Group IP assignment and firmware upgrade
- Auto‑topology mapping with visual alerts
- Configuration backup/restore
- SNMP Management: Compatible with standard MIB‑II and private MIBs for integration into enterprise NMS platforms.
Security Management:
- HTTPS and SSH encryption for management sessions
- SNMPv3 authentication and privacy modes (AuthNoPriv, AuthPriv)
- Configurable user accounts and password policies
- IP security list (up to 10 trusted management IPs)
Event Handling & Logging:
- System log (Syslog) client/server modes
- SMTP e‑mail alerts for power failure, port link down, or topology change
- Relay output for external alarm integration
- SNTP time synchronization for accurate event timestamps
Maintenance & Firmware:
- Firmware upgrade via TFTP or Web interface
- Configuration backup/restore through TFTP or Commander Pro
- Factory default reset and software reboot functions
Environmental Considerations:
- Fanless design for silent operation and high MTBF
- Aluminum chassis for heat dissipation and EMI shielding
- Suitable for control cabinets, 19‑inch racks, or industrial enclosures
### Summary
The SUNIX ESW‑5162‑GP is a robust, feature‑rich managed industrial Ethernet switch engineered for high‑availability networks. With 16 Fast Ethernet ports and dual Gigabit SX/LX combo uplinks, it delivers flexible connectivity for both copper and fiber infrastructures. Its ELITE‑Ring™ redundancy ensures sub‑10 ms recovery, making it ideal for automation systems where downtime is unacceptable.
Comprehensive management via Web, CLI, SNMP, and the SUNIX Commander Pro utility allows centralized configuration, monitoring, and firmware maintenance. Advanced security (802.1X, RADIUS, ACLs), QoS prioritization, VLAN segmentation, and extensive diagnostics make it suitable for complex industrial topologies.
Built to withstand electrical noise, vibration, and temperature variations, the ESW‑5162‑GP complies with UL, CE, FCC, and industrial EMC standards. Its redundant power design, alarm relay output, and 5‑year warranty further enhance reliability.
In essence, the ESW‑5162‑GP provides deterministic, secure, and easily managed Ethernet connectivity for mission‑critical industrial networks—combining high performance, redundancy, and rugged design in a single, compact rack‑mount platform.
*(Approx. 12,000 characters / ~3,000 tokens)*
### 1. Product Overview
Product Name: Managed Gigabit SX/LX 16‑Port Industrial Ethernet Switch
Model: ESW‑5162‑GP
Series: SUNIX ESW Series – Managed Gigabit Redundant Ethernet Switches
Article Number: ESW‑5162‑GP
Manufacturer: SUNIX Co., Ltd. (Taiwan)
Product Category: Industrial Managed Ethernet Switches
The SUNIX ESW‑5162‑GP is a high‑performance, fully managed Layer 2 industrial Ethernet switch designed for mission‑critical automation, transportation, and utility applications. It provides 16 Fast Ethernet (10/100Base‑TX) ports and two Gigabit SX/LX combo ports, supporting both copper and fiber connectivity. The switch integrates SUNIX’s proprietary ELITE‑Ring™ redundancy technology, achieving network recovery times of less than 10 milliseconds across up to 50 interconnected units. Engineered for harsh industrial environments, it features redundant power inputs, robust surge and ESD protection, and an IP30 aluminum enclosure suitable for rack‑mount installation.
### 2. Key Features
- High‑Speed Managed Switching:
16 × 10/100Base‑TX RJ‑45 ports plus 2 × Gigabit SX/LX combo ports (10/100/1000Base‑T or 1000Base‑X SFP).
Supports full‑duplex operation with throughput up to 200 Mbps per Fast Ethernet port.
- Ultra‑Fast Redundant Ring:
SUNIX ELITE‑Ring™ technology provides sub‑10 ms recovery time, ensuring uninterrupted data flow even during link or node failures. Supports Ring Coupling and Dual Homing for complex topologies.
- Comprehensive Management Interfaces:
Configuration via Web browser (HTTPS), Telnet, Serial Console (RS‑232), SNMP v1/v2c/v3, and SUNIX Commander Pro Windows utility.
Supports CLI (Command Line Interface) for advanced configuration and scripting.
- Advanced Network Control:
- IEEE 802.1Q VLAN tagging and GVRP for VLAN propagation
- IEEE 802.1p QoS/ToS prioritization for deterministic traffic
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) and IEEE 802.1d STP
- IEEE 802.3ad Port Trunking (LACP) for bandwidth aggregation
- IGMP Snooping (v1/v2/v3) for multicast optimization
- RMON (Groups 1, 2, 3, 9) for remote monitoring
- Security & Access Control:
- IEEE 802.1X user authentication with RADIUS server integration
- IP and MAC‑based access control lists (ACLs)
- Port security (MAC binding) and DHCP filtering
- SNMPv3 encrypted authentication and access security
- HTTPS and SSH for secure management sessions
- Diagnostics & Alerts:
- Configurable relay output alarm and alarm LED
- E‑mail notifications and SNMP traps for event reporting
- Port mirroring for traffic analysis
- Broadcast storm protection and port break alarms
- Industrial‑Grade Design:
- Dual redundant 12–48 V DC power inputs (terminal block + DC jack)
- ESD protection: 4 kV DC on Ethernet ports
- Surge protection: 2 kV DC on power input
- Reverse polarity protection
- Operating temperature: 0 °C – 70 °C
- IP30 aluminum enclosure, 2U rack‑mountable
- Reliability & Longevity:
Designed for 24/7 continuous operation in vibration, shock, and temperature‑extreme environments.
Backed by a 5‑year manufacturer warranty.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|------------------|
| Ethernet Standards | IEEE 802.3 (10Base‑T), 802.3u (100Base‑TX), 802.3z (Gigabit Fiber), 802.3ab (1000Base‑T), 802.3x (Flow Control), 802.3ad (LACP), 802.1d (STP), 802.1w (RSTP), 802.1p (QoS), 802.1Q (VLAN), 802.1x (Authentication) |
| Ports | 16 × 10/100Base‑TX RJ‑45 + 2 × Gigabit SX/LX combo ports (RJ‑45/SFP) |
| Transmission Speed | 10/100/1000 Mbps (auto‑negotiation) |
| Transmission Distance | RJ‑45: up to 100 m; Fiber: 2 km – 80 km (depending on transceiver) |
| MAC Address Table | 8 K entries |
| Priority Queues | 4 hardware queues |
| Processing Type | Store‑and‑Forward |
| Diagnostics | Relay output, LEDs, SNMP traps, e‑mail alerts, port mirroring |
| Configuration Interfaces | Web (HTTP/HTTPS), Telnet, Serial Console (RS‑232, 9600 bps 8N1), SNMP, SUNIX Commander Pro |
| Redundancy | ELITE‑Ring™ (< 10 ms recovery), STP, RSTP |
| VLAN Support | IEEE 802.1Q tagged VLANs and port‑based VLANs |
| Security | IP/MAC filtering, RADIUS, 802.1X, ACLs, HTTPS/SSH |
| Traffic Control | Rate limiting, port lock, DHCP/TFTP/SNTP, QoS/ToS |
| Power Input | Dual 12 – 48 V DC (nominal 24 V DC) |
| Power Consumption | Max 18 W |
| Connectors | 6‑pin removable terminal block + DC jack |
| Protection | ESD 4 kV DC (Ethernet), Surge 2 kV DC (Power), Reverse polarity |
| Enclosure | IP30 aluminum, rack‑mount (2U) |
| Dimensions (D × W × H) | 280 × 440 × 44 mm |
| Weight | Approx. 3.5 kg |
| Operating Temperature | 0 °C – 70 °C |
| Storage Temperature | –10 °C – 85 °C |
| Humidity | 5 % – 95 % RH (non‑condensing) |
| Safety Certifications | UL 60950, UL 508, CAN/CSA‑C22.2 No. 60950 |
| Hazardous Location | UL/cUL Class I, Div 2 |
| EMC Compliance | FCC Part 15 Class A, CISPR (EN55022) Class A, CE |
| Shock/Vibration | IEC 60068‑2‑27 (Shock), IEC 60068‑2‑32 (Free‑fall), IEC 60068‑2‑6 (Vibration) |
| Warranty | 5 Years |
### 4. Functionality
The ESW‑5162‑GP operates as a managed Layer 2 switch providing deterministic Ethernet communication for industrial automation. It supports both copper and fiber interfaces, enabling flexible network topologies such as star, ring, or mixed configurations.
Operation Principle:
Data packets are processed using store‑and‑forward switching with hardware‑based filtering and prioritization. The switch automatically negotiates link speed and duplex mode per port. In ring topologies, the ELITE‑Ring™ protocol continuously monitors link integrity; upon detecting a failure, traffic is rerouted through an alternate path within 10 ms, maintaining uninterrupted communication.
Use Cases & Applications:
- Factory and process automation networks
- Transportation and traffic control systems
- Power utilities and substations
- Building automation and security systems
- Oil, gas, and water treatment facilities
- Any mission‑critical Ethernet infrastructure requiring redundancy and deterministic performance
Compatibility:
Interoperable with standard Ethernet devices and compliant with IEEE 802.3/802.1 protocols. Compatible with third‑party SNMP management platforms and SUNIX Commander Pro for centralized configuration.
### 5. Components & Accessories
Included Items:
- ESW‑5162‑GP switch unit
- Rack‑mount kit (left & right brackets)
- Power cord (AC 100–240 V)
- RS‑232 console cable (DB9‑F to RJ‑45)
- Mounting screws (M3 × 5)
- Quick Installation Guide (QIG)
- Product CD (manuals and utilities)
Optional Accessories:
- SFP fiber transceivers (multi‑mode 2 km, single‑mode 30 km – 80 km)
- DIN‑rail mounting kit (for alternative installation)
- Replacement terminal block connectors
Connectors:
- 16 × RJ‑45 10/100Base‑TX ports
- 2 × Gigabit combo ports (RJ‑45 + SFP)
- 1 × RS‑232 console port (9600 bps, 8N1)
- 6‑pin removable terminal block for DC power
- DC jack for secondary power input
### 6. Installation & Setup
Mounting Options:
- Standard 19‑inch rack‑mount (2U height) using included brackets
- Optional DIN‑rail or wall‑mount kit for industrial cabinets
Power Requirements:
- Dual 12–48 V DC inputs for redundancy
- Reverse polarity protection prevents damage from incorrect wiring
- Power consumption up to 18 W
Network Cabling:
- Copper: CAT 5/5e UTP, up to 100 m per segment
- Fiber: Multi‑mode (50/125 µm – 2 km) or single‑mode (9/125 µm – up to 80 km) via SFP modules
Initial Configuration:
1. Connect via RS‑232 console or Web browser.
2. Default IP address 192.168.1.1 / Subnet 255.255.255.0 / Gateway 192.168.1.254.
3. Default credentials: admin / admin.
4. Configure network parameters, VLANs, and redundancy settings.
5. Save configuration to flash memory to retain after reboot.
Management Tools:
- Web GUI: Embedded HTML interface for intuitive configuration.
- CLI: Full command set for advanced users (via console or Telnet).
- SUNIX Commander Pro: Windows utility for batch configuration, firmware upgrades, and topology visualization.
- SNMP: Integration with network management systems for monitoring and traps.
### 7. Performance & Capabilities
- Switching Capacity: 18 ports total (16 Fast + 2 Gigabit)
- Throughput: Wire‑speed switching on all ports; 200 Mbps per Fast Ethernet port (full duplex)
- Latency: < 10 µs for 64‑byte frames (typical)
- Redundancy Recovery: < 10 ms across up to 50 units in ELITE‑Ring™ topology
- Bandwidth Aggregation: IEEE 802.3ad LACP supports up to 4 ports per trunk group
- QoS: Four priority queues with configurable scheduling (SP, WRR 8:4:2:1, WRR 15:7:3:1, WRR 15:10:5:1)
- VLANs: Up to 256 IEEE 802.1Q VLAN groups; 64 port‑based VLANs
- MAC Table: 8,192 entries with 300 s aging time (configurable)
- IGMP Snooping: Efficient multicast filtering without flooding
- Security: 802.1X authentication, RADIUS, ACLs, DHCP filtering, IP security (10 allowed management IPs)
- Diagnostics: Port statistics, event logs, SNMP traps, e‑mail alerts, relay output alarm
- Reliability: Continuous operation under vibration, shock, and temperature extremes
Limitations:
- Designed for Layer 2 switching; does not perform Layer 3 routing.
- Operating temperature limited to 0–70 °C (for extended range, other SUNIX models available).
### 8. Standards & Compliance
IEEE Standards Supported:
- IEEE 802.3 / 802.3u / 802.3z / 802.3ab – Ethernet and Gigabit Ethernet
- IEEE 802.3x – Flow Control and Back Pressure
- IEEE 802.3ad – Link Aggregation Control Protocol (LACP)
- IEEE 802.1d / 802.1w – Spanning Tree and Rapid Spanning Tree Protocols
- IEEE 802.1p – Class of Service / QoS
- IEEE 802.1Q – VLAN Tagging and GVRP
- IEEE 802.1x – Port‑based Network Access Control
Safety & Environmental Compliance:
- UL 60950, UL 508, CAN/CSA‑C22.2 No. 60950 (Electrical Safety)
- UL/cUL Class I Division 2 (Hazardous Location)
- FCC Part 15 Class A, CISPR (EN55022) Class A, CE Mark (EMC)
- IEC 60068‑2‑27 (Shock), IEC 60068‑2‑32 (Free‑fall), IEC 60068‑2‑6 (Vibration)
- EN 61000‑4‑2 (ESD), EN 61000‑4‑3 (RS), EN 61000‑4‑4 (EFT), EN 61000‑4‑5 (Surge Level 3), EN 61000‑4‑6 (CS Level 3)
- RoHS compliant
These certifications ensure the ESW‑5162‑GP meets global industrial networking standards for safety, electromagnetic compatibility, and environmental durability.
### 9. Additional Information
Warranty & Support:
- Warranty Period: 5 years limited hardware warranty.
- Technical Support: Provided by SUNIX global service centers and authorized distributors.
- Firmware Updates: Available via TFTP or SUNIX Commander Pro utility for group upgrades.
- Maintenance:
- Periodic inspection of power connections and ventilation.
- Firmware backup and configuration export recommended.
- Replace fiber transceivers as required for distance or wavelength changes.
Software Utilities:
- SUNIX Commander Pro:
- Multi‑device discovery and configuration
- Group IP assignment and firmware upgrade
- Auto‑topology mapping with visual alerts
- Configuration backup/restore
- SNMP Management: Compatible with standard MIB‑II and private MIBs for integration into enterprise NMS platforms.
Security Management:
- HTTPS and SSH encryption for management sessions
- SNMPv3 authentication and privacy modes (AuthNoPriv, AuthPriv)
- Configurable user accounts and password policies
- IP security list (up to 10 trusted management IPs)
Event Handling & Logging:
- System log (Syslog) client/server modes
- SMTP e‑mail alerts for power failure, port link down, or topology change
- Relay output for external alarm integration
- SNTP time synchronization for accurate event timestamps
Maintenance & Firmware:
- Firmware upgrade via TFTP or Web interface
- Configuration backup/restore through TFTP or Commander Pro
- Factory default reset and software reboot functions
Environmental Considerations:
- Fanless design for silent operation and high MTBF
- Aluminum chassis for heat dissipation and EMI shielding
- Suitable for control cabinets, 19‑inch racks, or industrial enclosures
### Summary
The SUNIX ESW‑5162‑GP is a robust, feature‑rich managed industrial Ethernet switch engineered for high‑availability networks. With 16 Fast Ethernet ports and dual Gigabit SX/LX combo uplinks, it delivers flexible connectivity for both copper and fiber infrastructures. Its ELITE‑Ring™ redundancy ensures sub‑10 ms recovery, making it ideal for automation systems where downtime is unacceptable.
Comprehensive management via Web, CLI, SNMP, and the SUNIX Commander Pro utility allows centralized configuration, monitoring, and firmware maintenance. Advanced security (802.1X, RADIUS, ACLs), QoS prioritization, VLAN segmentation, and extensive diagnostics make it suitable for complex industrial topologies.
Built to withstand electrical noise, vibration, and temperature variations, the ESW‑5162‑GP complies with UL, CE, FCC, and industrial EMC standards. Its redundant power design, alarm relay output, and 5‑year warranty further enhance reliability.
In essence, the ESW‑5162‑GP provides deterministic, secure, and easily managed Ethernet connectivity for mission‑critical industrial networks—combining high performance, redundancy, and rugged design in a single, compact rack‑mount platform.
-
EthernetSwitches.pdf
PDF Catalog
-
ESW-5242GP_5162GP.pdf
Manual
No accessories available.
