1. Product Overview
Product Name: Industrial Wireless Access Point
Model: IAP-6002-WA
Series: IAP Industrial Wireless Series
Article Number: IAP-6002-WA
Manufacturer: ORing Industrial Networking Corp.
The ORing IAP-6002-WA is an industrial-grade wireless access point designed to bridge wired Ethernet networks with wireless WLAN 802.11a/b/g connectivity. It provides two 10/100Base-TX Ethernet ports and supports dual power input for redundancy, ensuring reliable operation in demanding industrial environments. The device is engineered for robust performance, flexible installation, and high reliability, making it suitable for factory automation, transportation systems, and other mission-critical applications requiring stable wireless communication.
2. Key Features
- Dual Ethernet Ports: Two 10/100Base-TX LAN interfaces for flexible network integration and redundancy.
- Wireless Connectivity: Supports IEEE 802.11a/b/g standards, enabling operation in both 2.4 GHz and 5 GHz frequency bands.
- Industrial Design: Rugged metal housing designed for harsh environments, with extended temperature tolerance and vibration resistance.
- Dual Power Inputs: Accepts 12–48 VDC dual redundant power sources, ensuring continuous operation even if one power source fails.
- Low Power Consumption: Maximum power consumption of 6 W, optimizing energy efficiency for industrial deployments.
- Alarm Contact: Integrated relay output for system event notifications or alarm signaling, enhancing monitoring and maintenance capabilities.
- Flexible Mounting Options: Supports both DIN rail and wall mounting for versatile installation in control cabinets or on flat surfaces.
- Compact Form Factor: Space-efficient design with dimensions of 52 × 106 × 144 mm, suitable for constrained industrial enclosures.
- Wide Temperature Range: Operational temperature range from -10°C to +55°C and storage range from -20°C to +85°C, ensuring reliability in diverse environmental conditions.
- Industrial Reliability: Designed for continuous operation in industrial automation, transportation, and infrastructure networks.
3. Technical Specifications
- Model: IAP-6002-WA
- Network Interface:
- 2 × 10/100Base-TX Ethernet ports (RJ-45 connectors)
- Auto MDI/MDI-X support for flexible cabling
- Wireless Interface:
- IEEE 802.11a/b/g compliant
- Frequency bands: 2.4 GHz (802.11b/g) and 5 GHz (802.11a)
- Wireless data rates up to 54 Mbps (depending on standard and environment)
- Power Supply:
- Dual DC input: 12–48 VDC
- Power consumption: Maximum 6 W
- Reverse polarity protection included
- Alarm Contact:
- 1 × relay output for alarm or event signaling
- Enclosure:
- Material: Industrial-grade metal housing
- Protection: Designed for industrial environments (dust and vibration resistant)
- Mounting Options:
- DIN rail mount (standard industrial rail)
- Wall mount (optional bracket)
- Dimensions: 52 mm (W) × 106 mm (H) × 144 mm (D)
- Weight: Approximately 800 g
- Environmental Conditions:
- Operating temperature: -10°C to +55°C
- Storage temperature: -20°C to +85°C
- Relative humidity: 5%–95% (non-condensing)
- Certifications: Designed to meet industrial EMC and safety standards (specific certifications depend on regional compliance).
4. Functionality
The IAP-6002-WA functions as a wireless access point that bridges wired Ethernet networks to wireless WLAN clients. It enables devices connected via Ethernet to communicate over a wireless network, extending connectivity to remote or mobile equipment. The unit supports IEEE 802.11a/b/g standards, allowing compatibility with a wide range of wireless devices and network infrastructures.
Use Cases and Applications:
- Factory Automation: Connects PLCs, HMIs, and sensors to central control systems wirelessly.
- Transportation Systems: Provides wireless connectivity for vehicles, stations, or trackside equipment.
- Energy and Utilities: Enables remote monitoring of substations, pipelines, or renewable energy installations.
- Warehousing and Logistics: Facilitates wireless data exchange between handheld terminals, scanners, and backend systems.
- Infrastructure Monitoring: Supports wireless communication for surveillance, environmental monitoring, and smart city applications.
Compatibility:
- Compatible with standard Ethernet-based devices and networks.
- Interoperable with 802.11a/b/g wireless clients, routers, and access points.
- Supports integration into existing industrial Ethernet architectures.
5. Components & Accessories
Included Items:
- IAP-6002-WA main unit
- DIN rail mounting kit
- Quick installation guide or user manual
- Terminal block for power and alarm connections
Optional Accessories:
- Wall mounting bracket (for alternative installation)
- External antennas (depending on wireless configuration)
- Power supply units (12–48 VDC, depending on system design)
- Ethernet cables and connectors for network integration
Connectors:
- 2 × RJ-45 ports for 10/100Base-TX Ethernet
- 1 × terminal block for dual power input and alarm relay output
- Antenna connectors (SMA or RP-SMA type, depending on configuration)
6. Installation & Setup
Requirements:
- DC power source within 12–48 V range
- Proper grounding for industrial safety
- Adequate ventilation and clearance for heat dissipation
Mounting Options:
- DIN Rail Mounting: The device can be clipped directly onto a standard 35 mm DIN rail, commonly used in industrial control panels.
- Wall Mounting: Optional brackets allow secure wall installation for fixed infrastructure setups.
Configuration:
- Initial setup typically performed via Ethernet connection using a web-based interface or configuration utility.
- Wireless parameters (SSID, channel, encryption, authentication) can be configured to match network requirements.
- Supports firmware updates and configuration backups for maintenance and version control.
- Alarm relay can be configured to trigger on specific events such as power failure, link loss, or system error.
Installation Steps (Typical):
1. Mount the device on DIN rail or wall bracket.
2. Connect power inputs (12–48 VDC) to the terminal block.
3. Connect Ethernet cables to the 10/100Base-TX ports.
4. Attach antennas (if external) and ensure proper orientation.
5. Power on the device and verify LED indicators for status.
6. Access the configuration interface to set up network parameters.
7. Performance & Capabilities
Network Performance:
- Supports full-duplex and half-duplex Ethernet operation.
- Auto-negotiation for speed and duplex mode.
- Wireless throughput up to 54 Mbps (depending on standard and environmental conditions).
Capacity:
- Capable of handling multiple simultaneous wireless clients (number depends on configuration and bandwidth usage).
- Supports bridging between wired and wireless segments for extended network coverage.
Efficiency:
- Low power consumption (max 6 W) ensures energy-efficient operation.
- Dual power inputs provide redundancy, minimizing downtime.
Reliability:
- Industrial-grade components ensure long-term stability.
- Relay output allows integration with alarm systems for proactive fault detection.
Limitations:
- Wireless performance may vary based on environmental interference, distance, and antenna configuration.
- Designed for 802.11a/b/g; does not support newer 802.11n/ac/ax standards.
8. Standards & Compliance
Wireless Standards:
- IEEE 802.11a (5 GHz band)
- IEEE 802.11b/g (2.4 GHz band)
Ethernet Standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
Electrical & Safety Compliance:
- Designed to meet industrial EMC and safety standards (specific certifications may include CE, FCC, or UL, depending on region).
- Complies with industrial power and grounding requirements.
Environmental Compliance:
- RoHS-compliant materials and manufacturing processes.
- Designed for operation in extended temperature ranges suitable for industrial environments.
Industry Standards:
- Compatible with industrial automation protocols over Ethernet (e.g., Modbus TCP/IP, Ethernet/IP, depending on network configuration).
9. Additional Information
Warranty:
- Typically covered by ORing’s standard industrial product warranty (duration varies by region and distributor, commonly 3 to 5 years).
Support:
- Technical support available through ORing’s global service network.
- Firmware updates and configuration tools provided via manufacturer’s website.
- Documentation includes user manual, quick start guide, and configuration examples.
Maintenance:
- Minimal maintenance required due to solid-state design.
- Periodic firmware updates recommended for security and performance improvements.
- Regular inspection of power and network connections advised in industrial environments.
Updates & Lifecycle:
- Firmware and software updates available for enhanced functionality and security patches.
- Backward compatibility with existing ORing industrial networking products ensures long-term integration.
Summary
The ORing IAP-6002-WA is a robust, industrial-grade wireless access point that bridges wired Ethernet networks to wireless 802.11a/b/g systems. With dual 10/100Base-TX ports, dual redundant power inputs (12–48 VDC), and a built-in alarm relay, it is engineered for reliability and flexibility in demanding industrial applications. Its compact metal housing, wide operating temperature range, and versatile mounting options make it ideal for deployment in factories, transportation systems, and infrastructure networks. Offering stable performance, low power consumption, and comprehensive configuration options, the IAP-6002-WA delivers dependable wireless connectivity for mission-critical industrial environments.
