Comprehensive Product Summary – SUNIX IDS‑2042P‑I Industrial Serial Device Server
### 1. Product Overview
Product Name: Industrial Serial Device Server
Model: IDS‑2042P‑I
Series: IDS 2000 Series (Industrial Device Servers)
Article Number: IDS‑2042P‑I
Manufacturer: SUNIX Co., Ltd.
Product Type: 4‑Port RS‑422/485 to Dual Ethernet (10/100Base‑T(X)) PoE PD Device Server
Description: The SUNIX IDS‑2042P‑I is an industrial‑grade serial‑to‑Ethernet device server designed to connect up to four isolated RS‑422/485 serial devices to two redundant 10/100 Mbps Ethernet LAN ports. It supports Power over Ethernet (PoE) on ETH2 (IEEE 802.3af PD compliant), redundant DC power inputs, and advanced network management and security features. The unit is housed in a rugged IP30 metal enclosure suitable for DIN‑rail or wall mounting in harsh industrial environments.
### 2. Key Features
- Dual Ethernet Redundancy: Two 10/100Base‑T(X) RJ‑45 ports provide network redundancy with automatic recovery time under 10 ms, ensuring uninterrupted communication in case of link failure.
- PoE PD Functionality: ETH2 port supports IEEE 802.3af Power Device (PD) standard, allowing the unit to be powered directly via Ethernet with up to 8 W consumption.
- 4 Isolated Serial Ports: Four RS‑422/485 ports with 2.5 kV isolation and 15 kV ESD protection safeguard connected equipment from electrical surges and interference.
- Flexible Serial Modes: Each port can be independently configured for RS‑422, 2‑wire RS‑485, or 4‑wire RS‑485 operation.
- Versatile Communication Modes: Supports Virtual COM, TCP Server, TCP Client, UDP, and Serial Tunnel modes for flexible integration into existing systems.
- High Security: HTTPS, SSL, SSH, WEP/WPA/WPA2, 802.1X, Radius, and TKIP encryption ensure secure data transmission and management access.
- Event Notification System: Alerts via Syslog, E‑mail, SNMP Trap, Relay Output, and Beeper for proactive fault management.
- Redundant Power Inputs: Dual 12–48 V DC inputs on a 6‑pin removable terminal block with reverse polarity protection.
- Industrial‑Grade Design: Metal IP30 enclosure, wide operating temperature range (‑10 °C to 55 °C), and vibration/shock resistance per IEC 60068 standards.
- Comprehensive Software Suite: Includes IDS‑Tools for Windows for device discovery, configuration, monitoring, and group firmware updates.
- Cross‑Platform Drivers: Virtual COM driver for Windows NT/2000/XP/2003/Vista and fixed TTY driver for Linux systems.
- Compact and Flexible Installation: 52 × 106 × 144 mm enclosure supports both DIN‑rail and wall‑mount installation.
- Long‑Term Reliability: MTBF ≥ 200,000 hours and backed by a 5‑year manufacturer warranty.
### 3. Technical Specifications
Serial Communication
- Number of Ports: 4 × RS‑422/485
- Connector Type: 5‑pin terminal block
- Baud Rate: 110 bps – 460.8 kbps
- Data Bits: 5, 6, 7, 8
- Parity: Odd, Even, None, Mark, Space
- Stop Bits: 1, 1.5, 2
- Flow Control: XON/XOFF, RTS/CTS, DTR/DSR
- RS‑422 Signals: TxD+, TxD‑, RxD+, RxD‑, GND
- RS‑485 (4‑wire): TxD+, TxD‑, RxD+, RxD‑, GND
- RS‑485 (2‑wire): Data+, Data‑, GND
- Isolation: 2.5 kV DC isolation per port
- ESD Protection: 15 kV air discharge
Ethernet Interface
- Ports: 2 × RJ‑45 10/100 Mbps (auto‑negotiation, auto MDI/MDI‑X)
- Redundancy: Dual LAN redundancy with < 10 ms recovery
- Magnetic Isolation: 1.5 kV
- Supported Protocols: ICMP, IP, TCP, UDP, DHCP, BootP, ARP/RARP, DNS, SNMP MIB II, HTTPS, SSL, SSH
- PoE Port: ETH2 (IEEE 802.3af PD compliant)
- PoE Power Consumption: ≤ 8 W
- PoE Protection: Overload and short‑circuit protection
- Isolation Voltage: ≥ 1000 V DC
- Isolation Resistance: ≥ 100 MΩ
Power Requirements
- Input Voltage: 12 – 48 V DC (dual inputs)
- Connector: 6‑pin removable terminal block
- Reverse Polarity Protection: Yes
- Power Consumption: ≤ 7 W (DC input)
Environmental Conditions
- Operating Temperature: ‑10 °C to 55 °C
- Storage Temperature: ‑20 °C to 85 °C
- Operating Humidity: 5 % – 95 % RH (non‑condensing)
Mechanical
- Enclosure: Metal, IP30 protection
- Dimensions (W × D × H): 52 × 106 × 144 mm (excluding connectors)
- Mounting Options: DIN‑rail or wall mount
- Weight: Approx. 0.8 kg (typical)
Reliability & Warranty
- MTBF: ≥ 200,000 hours
- Warranty: 5 years
### 4. Functionality
The IDS‑2042P‑I functions as a bridge between legacy serial devices and modern Ethernet networks. Each of its four isolated RS‑422/485 ports can be independently configured for communication parameters and operation modes. The device encapsulates serial data into TCP/IP packets, enabling remote access, monitoring, and control over LAN or WAN.
Supported Operation Modes:
- Virtual COM Mode: Maps serial ports to virtual COM ports on Windows hosts, allowing existing software to communicate transparently over Ethernet.
- TCP Server Mode: Listens for incoming TCP connections from clients; supports up to 5 simultaneous connections.
- TCP Client Mode: Initiates TCP connections to remote servers on startup or upon data transmission.
- UDP Mode: Enables unicast or multicast communication for low‑latency data exchange.
- Serial Tunnel Mode: Couples two IDS devices to create a transparent serial link over Ethernet.
Use Cases & Applications:
- Industrial automation and PLC communication
- SCADA and data acquisition systems
- Remote monitoring of sensors, meters, and controllers
- Building management and access control systems
- Transportation and energy infrastructure monitoring
- Integration of legacy serial equipment into IP‑based networks
Compatibility:
- Operating Systems: Windows NT/2000/XP/2003/Vista (Virtual COM driver), Linux (fixed TTY driver)
- Network Integration: Compatible with standard Ethernet switches, routers, and NAT environments (supports NAT pass‑through).
### 5. Components & Accessories
Included Items:
- IDS‑2042P‑I device server unit
- DIN‑rail mounting kit (pre‑installed)
- Wall‑mounting kit with screws
- Quick Install Guide (QIG)
- Software CD containing IDS‑Tools utility and drivers
Optional Accessories:
- 12–48 V DC power adapter (not included by default)
- Additional DIN‑rail or wall‑mount brackets
- Terminal block connectors (replacement parts)
Connectors:
- Serial: 4 × 5‑pin terminal blocks
- Ethernet: 2 × RJ‑45 (10/100 Mbps)
- Power: 6‑pin removable terminal block (PWR1, PWR2, Relay Output)
- Relay Output: 1 × configurable relay (1 A @ 24 V DC)
- Reset Button: Restores factory defaults after 5 seconds press
### 6. Installation & Setup
Mounting Options:
- DIN‑Rail Installation:
1. Attach the metal spring clip to the DIN‑rail.
2. Push the device until it clicks securely into place.
- Wall‑Mount Installation:
1. Remove the DIN‑rail bracket.
2. Attach the wall‑mount panel using the provided screws.
3. Secure the unit to the wall surface.
Power Connection:
- Connect 12–48 V DC to PWR1 and/or PWR2 terminals.
- ETH2 can receive power via PoE (IEEE 802.3af PD).
- The device automatically selects the available power source and supports redundant input failover.
Network Configuration:
- Default IP Address: 192.168.1.1
- Configuration Interfaces: Web (HTTPS), SSH Console, or IDS‑Tools Windows Utility.
- Supports DHCP/BOOTP for automatic IP assignment or static IP configuration.
- NAT pass‑through enables remote management behind routers.
Software Setup:
- Install IDS‑Tools from the included CD.
- Use auto‑discovery to locate devices on the network.
- Configure serial port parameters, network settings, and operation modes.
- Firmware updates and group configuration can be performed remotely.
LED Indicators:
- PoE LED: Green = PoE active; Red blinking = IP conflict/DHCP error.
- PWR1/PWR2 LEDs: Green = power active; Red blinking = network error.
- Fault LED: Red = fault event detected.
- Serial TX/RX LEDs: Green = transmit; Red = receive.
- ETH1/ETH2 LEDs: Green = 100 Mbps; Amber = 10 Mbps link/activity.
### 7. Performance & Capabilities
- Serial Speed: Up to 460.8 kbps per port.
- Network Throughput: Optimized for low‑latency industrial communication.
- Redundancy Recovery: < 10 ms failover between Ethernet ports.
- Simultaneous Connections: Up to 5 concurrent Virtual COM/TCP/UDP links per port.
- PoE Power Budget: 8 W maximum (IEEE 802.3af PD).
- Power Efficiency: ≤ 7 W DC consumption under normal operation.
- Reliability: Continuous operation in industrial environments with high EMI/RFI immunity.
- Limitations: RS‑232 not supported on this model (only RS‑422/485).
### 8. Standards & Compliance
Electrical & EMC Compliance:
- EMI: FCC Part 15, CISPR (EN55022) Class A
- EMS: EN61000‑4‑2 (ESD), EN61000‑4‑3 (RS), EN61000‑4‑4 (EFT), EN61000‑4‑5 (Surge Level 3), EN61000‑4‑6 (CS Level 3)
- Shock: IEC 60068‑2‑27
- Vibration: IEC 60068‑2‑6
- Free Fall: IEC 60068‑2‑32
Network & Protocol Standards:
- IEEE 802.3 (10Base‑T), IEEE 802.3u (100Base‑TX), IEEE 802.3af (PoE PD)
- TCP/IP protocol stack compliance (ICMP, ARP, DHCP, DNS, SNMP MIB II)
- HTTPS and SSH for secure management sessions
Environmental & Safety:
- IP30 enclosure protection rating
- Operating temperature range ‑10 °C to 55 °C
- Humidity tolerance 5 % – 95 % (non‑condensing)
### 9. Additional Information
Warranty & Support:
- Warranty Period: 5 years limited hardware warranty.
- Technical Support: Available via e‑mail (info@sunix.com.tw) and official website (www.sunix.com.tw).
- Software Updates: Firmware and driver updates available through SUNIX support portal.
- Maintenance: No periodic maintenance required beyond standard cleaning and firmware updates.
- MTBF: ≥ 200,000 hours ensuring long‑term operation in industrial applications.
Manufacturer Contact:
SUNIX Co., Ltd.
Tel: +886‑2‑8913‑1987 Fax: +886‑2‑8913‑1986
Website: [www.sunix.com.tw](http://www.sunix.com.tw)
E‑mail: info@sunix.com.tw
### Summary
The SUNIX IDS‑2042P‑I is a robust, feature‑rich industrial device server engineered for mission‑critical serial‑to‑Ethernet communication. With four isolated RS‑422/485 ports, dual redundant Ethernet interfaces, and integrated PoE PD capability, it ensures reliable data connectivity and power flexibility in demanding environments. Its advanced management suite, secure communication protocols, and rapid redundancy recovery make it ideal for automation, SCADA, and remote monitoring systems. The compact IP30 metal housing, wide power input range, and comprehensive software support position the IDS‑2042P‑I as a high‑performance, long‑life solution for industrial networking and communication integration.
### 1. Product Overview
Product Name: Industrial Serial Device Server
Model: IDS‑2042P‑I
Series: IDS 2000 Series (Industrial Device Servers)
Article Number: IDS‑2042P‑I
Manufacturer: SUNIX Co., Ltd.
Product Type: 4‑Port RS‑422/485 to Dual Ethernet (10/100Base‑T(X)) PoE PD Device Server
Description: The SUNIX IDS‑2042P‑I is an industrial‑grade serial‑to‑Ethernet device server designed to connect up to four isolated RS‑422/485 serial devices to two redundant 10/100 Mbps Ethernet LAN ports. It supports Power over Ethernet (PoE) on ETH2 (IEEE 802.3af PD compliant), redundant DC power inputs, and advanced network management and security features. The unit is housed in a rugged IP30 metal enclosure suitable for DIN‑rail or wall mounting in harsh industrial environments.
### 2. Key Features
- Dual Ethernet Redundancy: Two 10/100Base‑T(X) RJ‑45 ports provide network redundancy with automatic recovery time under 10 ms, ensuring uninterrupted communication in case of link failure.
- PoE PD Functionality: ETH2 port supports IEEE 802.3af Power Device (PD) standard, allowing the unit to be powered directly via Ethernet with up to 8 W consumption.
- 4 Isolated Serial Ports: Four RS‑422/485 ports with 2.5 kV isolation and 15 kV ESD protection safeguard connected equipment from electrical surges and interference.
- Flexible Serial Modes: Each port can be independently configured for RS‑422, 2‑wire RS‑485, or 4‑wire RS‑485 operation.
- Versatile Communication Modes: Supports Virtual COM, TCP Server, TCP Client, UDP, and Serial Tunnel modes for flexible integration into existing systems.
- High Security: HTTPS, SSL, SSH, WEP/WPA/WPA2, 802.1X, Radius, and TKIP encryption ensure secure data transmission and management access.
- Event Notification System: Alerts via Syslog, E‑mail, SNMP Trap, Relay Output, and Beeper for proactive fault management.
- Redundant Power Inputs: Dual 12–48 V DC inputs on a 6‑pin removable terminal block with reverse polarity protection.
- Industrial‑Grade Design: Metal IP30 enclosure, wide operating temperature range (‑10 °C to 55 °C), and vibration/shock resistance per IEC 60068 standards.
- Comprehensive Software Suite: Includes IDS‑Tools for Windows for device discovery, configuration, monitoring, and group firmware updates.
- Cross‑Platform Drivers: Virtual COM driver for Windows NT/2000/XP/2003/Vista and fixed TTY driver for Linux systems.
- Compact and Flexible Installation: 52 × 106 × 144 mm enclosure supports both DIN‑rail and wall‑mount installation.
- Long‑Term Reliability: MTBF ≥ 200,000 hours and backed by a 5‑year manufacturer warranty.
### 3. Technical Specifications
Serial Communication
- Number of Ports: 4 × RS‑422/485
- Connector Type: 5‑pin terminal block
- Baud Rate: 110 bps – 460.8 kbps
- Data Bits: 5, 6, 7, 8
- Parity: Odd, Even, None, Mark, Space
- Stop Bits: 1, 1.5, 2
- Flow Control: XON/XOFF, RTS/CTS, DTR/DSR
- RS‑422 Signals: TxD+, TxD‑, RxD+, RxD‑, GND
- RS‑485 (4‑wire): TxD+, TxD‑, RxD+, RxD‑, GND
- RS‑485 (2‑wire): Data+, Data‑, GND
- Isolation: 2.5 kV DC isolation per port
- ESD Protection: 15 kV air discharge
Ethernet Interface
- Ports: 2 × RJ‑45 10/100 Mbps (auto‑negotiation, auto MDI/MDI‑X)
- Redundancy: Dual LAN redundancy with < 10 ms recovery
- Magnetic Isolation: 1.5 kV
- Supported Protocols: ICMP, IP, TCP, UDP, DHCP, BootP, ARP/RARP, DNS, SNMP MIB II, HTTPS, SSL, SSH
- PoE Port: ETH2 (IEEE 802.3af PD compliant)
- PoE Power Consumption: ≤ 8 W
- PoE Protection: Overload and short‑circuit protection
- Isolation Voltage: ≥ 1000 V DC
- Isolation Resistance: ≥ 100 MΩ
Power Requirements
- Input Voltage: 12 – 48 V DC (dual inputs)
- Connector: 6‑pin removable terminal block
- Reverse Polarity Protection: Yes
- Power Consumption: ≤ 7 W (DC input)
Environmental Conditions
- Operating Temperature: ‑10 °C to 55 °C
- Storage Temperature: ‑20 °C to 85 °C
- Operating Humidity: 5 % – 95 % RH (non‑condensing)
Mechanical
- Enclosure: Metal, IP30 protection
- Dimensions (W × D × H): 52 × 106 × 144 mm (excluding connectors)
- Mounting Options: DIN‑rail or wall mount
- Weight: Approx. 0.8 kg (typical)
Reliability & Warranty
- MTBF: ≥ 200,000 hours
- Warranty: 5 years
### 4. Functionality
The IDS‑2042P‑I functions as a bridge between legacy serial devices and modern Ethernet networks. Each of its four isolated RS‑422/485 ports can be independently configured for communication parameters and operation modes. The device encapsulates serial data into TCP/IP packets, enabling remote access, monitoring, and control over LAN or WAN.
Supported Operation Modes:
- Virtual COM Mode: Maps serial ports to virtual COM ports on Windows hosts, allowing existing software to communicate transparently over Ethernet.
- TCP Server Mode: Listens for incoming TCP connections from clients; supports up to 5 simultaneous connections.
- TCP Client Mode: Initiates TCP connections to remote servers on startup or upon data transmission.
- UDP Mode: Enables unicast or multicast communication for low‑latency data exchange.
- Serial Tunnel Mode: Couples two IDS devices to create a transparent serial link over Ethernet.
Use Cases & Applications:
- Industrial automation and PLC communication
- SCADA and data acquisition systems
- Remote monitoring of sensors, meters, and controllers
- Building management and access control systems
- Transportation and energy infrastructure monitoring
- Integration of legacy serial equipment into IP‑based networks
Compatibility:
- Operating Systems: Windows NT/2000/XP/2003/Vista (Virtual COM driver), Linux (fixed TTY driver)
- Network Integration: Compatible with standard Ethernet switches, routers, and NAT environments (supports NAT pass‑through).
### 5. Components & Accessories
Included Items:
- IDS‑2042P‑I device server unit
- DIN‑rail mounting kit (pre‑installed)
- Wall‑mounting kit with screws
- Quick Install Guide (QIG)
- Software CD containing IDS‑Tools utility and drivers
Optional Accessories:
- 12–48 V DC power adapter (not included by default)
- Additional DIN‑rail or wall‑mount brackets
- Terminal block connectors (replacement parts)
Connectors:
- Serial: 4 × 5‑pin terminal blocks
- Ethernet: 2 × RJ‑45 (10/100 Mbps)
- Power: 6‑pin removable terminal block (PWR1, PWR2, Relay Output)
- Relay Output: 1 × configurable relay (1 A @ 24 V DC)
- Reset Button: Restores factory defaults after 5 seconds press
### 6. Installation & Setup
Mounting Options:
- DIN‑Rail Installation:
1. Attach the metal spring clip to the DIN‑rail.
2. Push the device until it clicks securely into place.
- Wall‑Mount Installation:
1. Remove the DIN‑rail bracket.
2. Attach the wall‑mount panel using the provided screws.
3. Secure the unit to the wall surface.
Power Connection:
- Connect 12–48 V DC to PWR1 and/or PWR2 terminals.
- ETH2 can receive power via PoE (IEEE 802.3af PD).
- The device automatically selects the available power source and supports redundant input failover.
Network Configuration:
- Default IP Address: 192.168.1.1
- Configuration Interfaces: Web (HTTPS), SSH Console, or IDS‑Tools Windows Utility.
- Supports DHCP/BOOTP for automatic IP assignment or static IP configuration.
- NAT pass‑through enables remote management behind routers.
Software Setup:
- Install IDS‑Tools from the included CD.
- Use auto‑discovery to locate devices on the network.
- Configure serial port parameters, network settings, and operation modes.
- Firmware updates and group configuration can be performed remotely.
LED Indicators:
- PoE LED: Green = PoE active; Red blinking = IP conflict/DHCP error.
- PWR1/PWR2 LEDs: Green = power active; Red blinking = network error.
- Fault LED: Red = fault event detected.
- Serial TX/RX LEDs: Green = transmit; Red = receive.
- ETH1/ETH2 LEDs: Green = 100 Mbps; Amber = 10 Mbps link/activity.
### 7. Performance & Capabilities
- Serial Speed: Up to 460.8 kbps per port.
- Network Throughput: Optimized for low‑latency industrial communication.
- Redundancy Recovery: < 10 ms failover between Ethernet ports.
- Simultaneous Connections: Up to 5 concurrent Virtual COM/TCP/UDP links per port.
- PoE Power Budget: 8 W maximum (IEEE 802.3af PD).
- Power Efficiency: ≤ 7 W DC consumption under normal operation.
- Reliability: Continuous operation in industrial environments with high EMI/RFI immunity.
- Limitations: RS‑232 not supported on this model (only RS‑422/485).
### 8. Standards & Compliance
Electrical & EMC Compliance:
- EMI: FCC Part 15, CISPR (EN55022) Class A
- EMS: EN61000‑4‑2 (ESD), EN61000‑4‑3 (RS), EN61000‑4‑4 (EFT), EN61000‑4‑5 (Surge Level 3), EN61000‑4‑6 (CS Level 3)
- Shock: IEC 60068‑2‑27
- Vibration: IEC 60068‑2‑6
- Free Fall: IEC 60068‑2‑32
Network & Protocol Standards:
- IEEE 802.3 (10Base‑T), IEEE 802.3u (100Base‑TX), IEEE 802.3af (PoE PD)
- TCP/IP protocol stack compliance (ICMP, ARP, DHCP, DNS, SNMP MIB II)
- HTTPS and SSH for secure management sessions
Environmental & Safety:
- IP30 enclosure protection rating
- Operating temperature range ‑10 °C to 55 °C
- Humidity tolerance 5 % – 95 % (non‑condensing)
### 9. Additional Information
Warranty & Support:
- Warranty Period: 5 years limited hardware warranty.
- Technical Support: Available via e‑mail (info@sunix.com.tw) and official website (www.sunix.com.tw).
- Software Updates: Firmware and driver updates available through SUNIX support portal.
- Maintenance: No periodic maintenance required beyond standard cleaning and firmware updates.
- MTBF: ≥ 200,000 hours ensuring long‑term operation in industrial applications.
Manufacturer Contact:
SUNIX Co., Ltd.
Tel: +886‑2‑8913‑1987 Fax: +886‑2‑8913‑1986
Website: [www.sunix.com.tw](http://www.sunix.com.tw)
E‑mail: info@sunix.com.tw
### Summary
The SUNIX IDS‑2042P‑I is a robust, feature‑rich industrial device server engineered for mission‑critical serial‑to‑Ethernet communication. With four isolated RS‑422/485 ports, dual redundant Ethernet interfaces, and integrated PoE PD capability, it ensures reliable data connectivity and power flexibility in demanding environments. Its advanced management suite, secure communication protocols, and rapid redundancy recovery make it ideal for automation, SCADA, and remote monitoring systems. The compact IP30 metal housing, wide power input range, and comprehensive software support position the IDS‑2042P‑I as a high‑performance, long‑life solution for industrial networking and communication integration.
-
IndustrialDeviceServers.pdf
PDF Catalog
-
IDS-3042.pdf
Manual
-
IDS_quick_start.pdf
Manual
No accessories available.
