Comprehensive Product Summary: ORing IES‑3062FX‑MM‑SC Industrial Managed Ethernet Switch

---

### 1. Product Overview

Product Name: Industrial Managed Ethernet Switch
Model: IES‑3062FX‑MM‑SC
Series: IES‑3000 Series
Article Number: IES‑3062FX‑MM‑SC
Manufacturer: ORing Industrial Networking Corp.
Manufacturer Address: 4F., No.3, Lane 235, Baociao Rd., Sindian City, Taipei County 23145, Taiwan, R.O.C.
Website: [www.oring-networking.com](http://www.oring-networking.com)
Support Email: support@oring-networking.com

The IES‑3062FX‑MM‑SC is a rugged, fully managed industrial Ethernet switch designed for mission‑critical automation and control networks. It belongs to ORing’s IES‑3000 Series, a family of high‑performance managed switches engineered for harsh industrial environments. This model integrates six 10/100Base‑T(X) copper ports and two 100Base‑FX multimode fiber ports with SC connectors, providing flexible connectivity for mixed copper‑fiber infrastructures.

---

### 2. Key Features

- High‑Performance Managed Switching:
Eight‑port managed switch with 6×10/100Base‑T(X) RJ‑45 ports and 2×100Base‑FX multimode SC fiber ports.
- Ultra‑Fast Redundant Ethernet Ring:
ORing’s proprietary O‑Ring technology provides recovery times under 10 ms across up to 250 connected units, ensuring near‑instantaneous network self‑healing.
- Comprehensive Redundancy Protocols:
Supports O‑Ring, Open‑Ring, O‑RSTP, RSTP (802.1w), MSTP (802.1s), and Dual Homing for flexible redundancy topologies.
- Advanced Network Management:
Managed via Web GUI, Telnet, Console (RS‑232), CLI, SNMP v1/v2c/v3, and ORing’s Open‑Vision software for centralized monitoring.
- Robust Industrial Design:
IP‑30 metal enclosure, DIN‑rail or wall‑mount installation, triple redundant 12–48 V DC power inputs, and extended ‑40 °C to +70 °C operating range.
- Enhanced Security:
802.1X port‑based authentication, MAC‑based port security, IP access control, SNMPv3 encryption, and RADIUS centralized authentication.
- Comprehensive VLAN and QoS Support:
IEEE 802.1Q VLAN tagging, GVRP, QinQ, and 802.1p QoS with four priority queues for deterministic traffic handling.
- Event and Alarm Management:
Fault relay output, alarm LED, e‑mail and SNMP trap notifications, and system log (SYSLOG) for proactive fault detection.
- Flexible Configuration and Diagnostics:
Web‑based configuration, firmware upgrade via TFTP, backup/restore, port mirroring, rate limiting, and extensive diagnostic tools.
- High Immunity and Reliability:
ESD protection 4 kV DC on Ethernet ports, surge protection 2 kV DC on power inputs, and compliance with IEC 60068 shock/vibration standards.

---

### 3. Technical Specifications

Technology & Standards
- IEEE 802.3 10Base‑T
- IEEE 802.3u 100Base‑TX/FX
- IEEE 802.3z 1000Base‑LX
- IEEE 802.3ab 1000Base‑TX
- IEEE 802.3ad Link Aggregation Control Protocol (LACP)
- IEEE 802.3x Flow Control
- IEEE 802.1D Spanning Tree Protocol
- IEEE 802.1w Rapid Spanning Tree Protocol
- IEEE 802.1s Multiple Spanning Tree Protocol
- IEEE 802.1p Class of Service
- IEEE 802.1Q VLAN Tagging
- IEEE 802.1ad QinQ VLAN stacking
- IEEE 802.1X Port‑based Authentication
- IEEE 802.1AB LLDP

Switching Architecture
- MAC Address Table: 8192 entries
- Priority Queues: 4
- Switching Method: Store‑and‑Forward
- Flow Control: IEEE 802.3x full‑duplex and back‑pressure half‑duplex

Interfaces
- Copper Ports: 6 × 10/100Base‑T(X) RJ‑45, auto‑negotiation, auto MDI/MDI‑X
- Fiber Ports: 2 × 100Base‑FX multimode SC connectors
- Wavelength: 1310 nm
- Fiber Type: 50/125 µm or 62.5/125 µm
- Transmission Distance: 0 – 2 km
- Console Port: 1 × RS‑232 (RJ‑45) for CLI management
- Relay Output: 1 A @ 24 V DC fault relay

LED Indicators
- Power 1/2/3 (Green)
- Ring Master (Green)
- Ring Status (Green, blinking patterns for normal/fault)
- Fault (Amber)
- Per‑Port: Link/Activity (Green), Full Duplex (Amber)

Power Requirements
- Dual DC inputs via 7‑pin terminal block (PWR1/PWR2): 12 – 48 V DC
- Auxiliary DC input via power jack (PWR3): 12 – 45 V DC
- Reverse Polarity Protection: Yes (terminal block)
- Power Consumption: ≤ 10 W (typical ≈ 9 W)

Mechanical & Environmental
- Dimensions (W × D × H): 52 × 106 × 144 mm
- Enclosure: IP‑30 rated metal housing
- Mounting: DIN‑rail (default) or wall‑mount (kit included)
- Operating Temperature: ‑40 °C to +70 °C
- Storage Temperature: ‑40 °C to +85 °C
- Humidity: 5 – 95 % RH, non‑condensing
- Weight: approx. 0.9 kg

Environmental Immunity
- ESD Protection: EN 61000‑4‑2 (Level 4, ±4 kV contact)
- Surge Protection: EN 61000‑4‑5 (Level 3, ±2 kV DC)
- EFT/Burst: EN 61000‑4‑4
- Radiated Immunity: EN 61000‑4‑3
- Conducted Immunity: EN 61000‑4‑6
- Shock: IEC 60068‑2‑27
- Vibration: IEC 60068‑2‑6
- Free Fall: IEC 60068‑2‑32

---

### 4. Functionality

Operation & Management
The IES‑3062FX‑MM‑SC operates as a Layer 2 managed switch supporting advanced redundancy, VLAN segmentation, and QoS prioritization. Configuration is accessible through:
- Web Browser Interface: Embedded HTML/Java‑based GUI (default IP 192.168.10.1, user admin/admin).
- Command Line Interface (CLI): via RS‑232 console or Telnet.
- SNMP Management: v1/v2c/v3 with RMON and trap support.
- Open‑Vision Software: ORing’s centralized management suite for multi‑device configuration and monitoring.

Use Cases & Applications
- Factory automation and process control networks
- Transportation and traffic monitoring systems
- Power substations and utility SCADA networks
- Oil, gas, and mining communication backbones
- Intelligent building and security surveillance systems

Compatibility
Interoperable with standard Ethernet devices, third‑party SNMP management platforms, and ORing’s proprietary redundancy protocols. Supports integration with existing STP/RSTP networks and vendor‑specific rings via Open‑Ring mode.

---

### 5. Components & Accessories

Included Items
- IES‑3062FX‑MM‑SC switch unit
- DIN‑rail mounting kit (pre‑installed)
- Wall‑mount bracket and screws
- Console cable (DB‑9 F to RJ‑45)
- Quick installation guide and documentation

Optional Accessories
- External DC power supplies (12–48 V DC)
- Fiber patch cords (SC multimode)
- ORing Open‑Vision network management software license

Connectors
- RJ‑45 (Ethernet)
- SC (fiber)
- 7‑pin terminal block (power + relay)
- 2.1 mm DC power jack
- RJ‑45 console port

---

### 6. Installation & Setup

Mounting Options
- DIN‑Rail: Standard installation using rear spring clip; simply hook and press until a click is heard.
- Wall Mount: Remove DIN‑rail bracket, attach wall‑mount plate with six screws, and secure to flat surface.

Power Connection
Connect redundant DC sources to PWR1 and PWR2 terminals; optional PWR3 via DC jack. The relay output can be wired to external alarms for power or port failure indication.

Network Cabling
- Copper: Cat 5/5e UTP, 100 m max.
- Fiber: Multimode 50/125 µm or 62.5/125 µm, up to 2 km @ 1310 nm.
- Console: RS‑232 DB‑9 F to RJ‑45 cable (included).

Initial Configuration
1. Power on the device; verify PWR LEDs.
2. Connect PC to any RJ‑45 port.
3. Access Web GUI at 192.168.10.1 (admin/admin).
4. Configure IP, VLANs, redundancy, and security settings.
5. Save configuration to flash memory.

---

### 7. Performance & Capabilities

Switching Performance
- Non‑blocking wire‑speed switching on all ports.
- Store‑and‑forward architecture ensures error‑free packet forwarding.
- MAC address learning with aging control.

Redundancy & Recovery
- O‑Ring: < 10 ms recovery across ≤ 250 nodes.
- Dual Homing: Active/backup uplinks to external RSTP networks.
- Coupling Ring: Interconnects two O‑Rings for segmented redundancy.
- O‑RSTP: Optimized RSTP with sub‑10 ms recovery.

Traffic Management
- QoS: 802.1p (4 queues), port‑based, COS/TOS/DSCP classification.
- Rate Limiting: Ingress/egress bandwidth control per port.
- Port Trunking: Static or 802.3ad LACP aggregation.
- IGMP Snooping: v1/v2/v3 multicast optimization.

Security & Access Control
- 802.1X authentication with RADIUS.
- MAC address filtering and blacklisting.
- IP‑based management access restriction.
- SNMPv3 encrypted authentication.

Diagnostics & Monitoring
- Port statistics, MAC table, event logs, and ping utility.
- Port mirroring for traffic analysis.
- System alarms via SYSLOG, SMTP, or relay output.

Limitations
- Layer 2 switching only (no Layer 3 routing).
- Fiber distance limited to 2 km (multimode).

---

### 8. Standards & Compliance

Ethernet & Network Standards
Compliant with IEEE 802.3/802.3u/802.3x/802.1D/802.1Q/802.1p/802.1w/802.1s/802.1X/802.1AB/802.3ad.

EMC & Safety Certifications
- EMI: FCC Part 15 Class A, CISPR 22 (EN 55022 Class A)
- EMS: EN 61000‑4‑2 (ESD), ‑4‑3 (RS), ‑4‑4 (EFT), ‑4‑5 (Surge), ‑4‑6 (CS)
- Shock: IEC 60068‑2‑27
- Vibration: IEC 60068‑2‑6
- Free Fall: IEC 60068‑2‑32
- Safety: EN 60950 (Information Technology Equipment)
- Ingress Protection: IP‑30

Environmental Compliance
Designed for industrial temperature range and high humidity tolerance; RoHS‑compliant construction.

---

### 9. Additional Information

Warranty: 5 years limited manufacturer warranty.
Support: Technical assistance via ORing support portal and e‑mail.
Maintenance: Firmware upgrades via TFTP or Web interface; configuration backup/restore supported.
Software Updates: Periodic firmware and Open‑Vision software updates available from ORing website.
Mean Time Between Failures (MTBF): > 300,000 hours (estimated).

Summary of Advantages:
The ORing IES‑3062FX‑MM‑SC delivers industrial‑grade reliability, rapid redundancy, and comprehensive management in a compact IP‑30 enclosure. Its triple power redundancy, wide temperature tolerance, and extensive protocol support make it ideal for critical infrastructure networks requiring continuous uptime and secure, deterministic Ethernet communication.

---

End of Product Summary – IES‑3062FX‑MM‑SC Industrial Managed 2×100FX MM + 6×100TX Switch
