Name: Jetson Orin NX edge AI computer with 16GB memory and four 2.5GbE PoE+ ports.
Brand: Neousys Technology
SKU: NRU-154-JON16

INDUSTRIAL SOLUTION?

Discover embedded, communication and automation solutions tailored to your application.

NRU-154-JON16

Jetson Orin NX edge AI computer with 16GB memory and four 2.5GbE PoE+ ports.

Request a quote

Manufacturer Neousys Technology
Category: Industrial Computer
The NRU-154-JON16 combines NVIDIA Jetson Orin NX with 16GB LPDDR5 and a 128GB NVMe drive containing a pre-installed system image. This compact, fanless edge AI computer provides four 2.5GbE PoE+ ports with a shared 50W power budget for IP and industrial GigE cameras. Gigabit Ethernet, USB 2.0, DisplayPort, RS-232 and isolated RS-485 provide additional connectivity. Its flattop heatsink transfers heat to a metal enclosure and supports fanless operation between -25°C and 60°C under the specified mounting conditions.

Compact fanless edge AI computer with NVIDIA Jetson Orin NX, 16GB LPDDR5, 128GB NVMe and a pre-installed system image. It provides four 2.5GbE PoE+ camera ports with a 50W total budget, one GbE port, two USB 2.0 ports, DisplayPort, RS-232 and isolated RS-485. The flattop heatsink supports conduction-cooled installation in sealed cabinets. Dimensions are 116 x 171 x 27 mm; fanless operating temperature is -25°C to 60°C under the specified mounting conditions.

Processor Platform NVIDIA Jetson Orin NX with NVIDIA Ampere GPU and ARM Cortex CPU
Installed Memory 16 GB LPDDR5
Series AI Inference Performance Up to 100 TOPS
Key Features NVIDIA Jetson Orin NX; 16GB LPDDR5; up to 100 TOPS series performance; 128GB NVMe; 4x 2.5GbE PoE+; 50W PoE budget; flattop conduction heatsink; fanless operation; JetPack support
Included NVMe Capacity 128 GB
NVMe Interface M.2 2242 M-key, PCIe Gen4 x2
PoE+ Camera Ports 4 ports
PoE+ Port Speed 2.5 Gbps
PoE Power Budget 50 W total
Serial Interfaces 1x RS-232; 1x isolated RS-485
Maximum Display Resolution 3840 x 2160 at 60Hz
Dimensions 116 x 171 x 27 mm
Weight 1.0 kg
Form Factor Compact fanless wall-mount computer with flattop conduction heatsink
Connector 4x 2.5GbE PoE+, 1x GbE, 2x USB 2.0, DisplayPort, RS-232, isolated RS-485, micro USB OTG, 12V DC input
Dimensions 116 x 171 x 27 mm
Operating Temperature -25 to 60 °C
Storage Temperature -40 to 85 °C
Operating Temperature -25°C to 60°C fanless at 20W TDP with specified heat-conduction mounting
DC Input 12 V DC
Bus Interface M.2 2242 M-key, PCIe Gen4 x2
Resolution DisplayPort up to 3840 x 2160 at 60Hz
Accessories PA-60W-OW
