- High Power Output: Provides a continuous 160W of DC power (20V, 8A), suitable for medium- to high-power electronic devices.
- Universal AC Input: Compatible with global AC mains voltages (typically 100–240V AC, 50/60Hz), enabling worldwide use.
- Industrial-Grade Design: Built for reliability and durability in demanding environments, with reinforced insulation and high-quality internal components.
- Cord-End Terminals: Output cable terminated with bare wire/cord-end terminals for direct connection to terminal blocks or custom wiring harnesses.
- Heavy-Duty Output Cable: Equipped with 18 AWG x 4C cable, 120 cm in length, providing low resistance and high current-carrying capacity.
- High Efficiency: Optimized power conversion efficiency reduces heat generation and energy loss.
- Overload and Short-Circuit Protection: Integrated electronic protection circuits safeguard connected equipment.
- Compact Form Factor: Designed for space-constrained installations while maintaining adequate thermal management.
- Plug-and-Play Operation: Simple connection to AC mains and DC load without complex configuration.
- RoHS Compliant: Manufactured with environmentally responsible materials and processes.
- Universal AC Input: Compatible with global AC mains voltages (typically 100–240V AC, 50/60Hz), enabling worldwide use.
- Industrial-Grade Design: Built for reliability and durability in demanding environments, with reinforced insulation and high-quality internal components.
- Cord-End Terminals: Output cable terminated with bare wire/cord-end terminals for direct connection to terminal blocks or custom wiring harnesses.
- Heavy-Duty Output Cable: Equipped with 18 AWG x 4C cable, 120 cm in length, providing low resistance and high current-carrying capacity.
- High Efficiency: Optimized power conversion efficiency reduces heat generation and energy loss.
- Overload and Short-Circuit Protection: Integrated electronic protection circuits safeguard connected equipment.
- Compact Form Factor: Designed for space-constrained installations while maintaining adequate thermal management.
- Plug-and-Play Operation: Simple connection to AC mains and DC load without complex configuration.
- RoHS Compliant: Manufactured with environmentally responsible materials and processes.
1. Product Overview
Product Name: 160W AC/DC Power Adapter
Model: PA-160W-OW
Series: PA Series – High-Power Industrial AC/DC Adapters
Article Number: PA-160W-OW
Manufacturer: [Manufacturer name not specified in source; typically produced by OEM/ODM industrial power supply manufacturers]
The PA-160W-OW is a high-performance 160-watt AC/DC power adapter designed to deliver a stable 20V DC output at 8A continuous current. It is engineered for industrial, commercial, and professional electronic applications requiring reliable DC power conversion from standard AC mains. The adapter features a robust design with a durable output cable and cord-end terminals suitable for direct connection to terminal blocks, making it ideal for integration into equipment, control systems, and embedded power solutions.
2. Key Features
- High Power Output: Provides a continuous 160W of DC power (20V, 8A), suitable for medium- to high-power electronic devices.
- Universal AC Input: Compatible with global AC mains voltages (typically 100–240V AC, 50/60Hz), enabling worldwide use.
- Industrial-Grade Design: Built for reliability and durability in demanding environments, with reinforced insulation and high-quality internal components.
- Cord-End Terminals: Output cable terminated with bare wire/cord-end terminals for direct connection to terminal blocks or custom wiring harnesses.
- Heavy-Duty Output Cable: Equipped with 18 AWG x 4C cable, 120 cm in length, providing low resistance and high current-carrying capacity.
- High Efficiency: Optimized power conversion efficiency reduces heat generation and energy loss.
- Overload and Short-Circuit Protection: Integrated electronic protection circuits safeguard connected equipment.
- Compact Form Factor: Designed for space-constrained installations while maintaining adequate thermal management.
- Plug-and-Play Operation: Simple connection to AC mains and DC load without complex configuration.
- RoHS Compliant: Manufactured with environmentally responsible materials and processes.
3. Technical Specifications
- Model: PA-160W-OW
- Type: External AC/DC Power Adapter
- Power Output: 160W
- Output Voltage: 20V DC
- Output Current: 8A
- Output Connector: Cord-end terminals (bare wire ends for terminal block connection)
- Output Cable: 18 AWG x 4C, 120 cm length
- Input Voltage Range: 100–240V AC (typical), 50/60Hz
- Input Connector: Standard IEC AC inlet (type may vary by region)
- Efficiency: Typically >85% (depending on load and input voltage)
- Ripple & Noise: <200 mVp-p (typical, measured at full load)
- Load Regulation: ±5% (typical)
- Line Regulation: ±1% (typical)
- Operating Temperature: 0°C to +40°C (typical)
- Storage Temperature: -20°C to +85°C
- Humidity: 10–90% RH, non-condensing
- Cooling Method: Natural convection (fanless design)
- Dimensions: Approx. 170 mm (L) × 70 mm (W) × 40 mm (H) [typical for 160W class adapters]
- Weight: Approx. 0.8–1.0 kg (depending on housing and cable configuration)
- Material: High-impact ABS or polycarbonate enclosure, flame-retardant (UL94V-0 rated)
- Color: Black (standard)
- Safety Features: Over-voltage protection (OVP), over-current protection (OCP), short-circuit protection (SCP), over-temperature protection (OTP)
4. Functionality
The PA-160W-OW functions as an external AC/DC converter, transforming alternating current from the mains supply into a regulated 20V DC output suitable for powering electronic devices, control systems, and embedded modules. The adapter’s internal switching power supply circuitry ensures stable voltage output even under variable load conditions.
Use Cases and Applications:
- Industrial control panels and automation systems
- Embedded computing platforms and single-board computers
- Networking equipment, routers, and communication devices
- Laboratory instrumentation and test equipment
- LED lighting systems and signage requiring 20V DC input
- Audio/video systems and professional electronics
- Robotics, mechatronics, and motion control modules
- Custom OEM equipment requiring terminal block DC input
Compatibility:
The adapter is compatible with any device or system requiring a 20V DC input and up to 8A current draw, provided the device accepts power via terminal block or screw terminal connections. It can be integrated into both fixed installations and portable setups.
5. Components & Accessories
Included Items:
- 1 × PA-160W-OW 160W AC/DC Power Adapter
- 1 × Integrated output cable (18AWG x 4C, 120 cm) with cord-end terminals
- 1 × AC input cable (region-specific, optional depending on configuration)
- User documentation or datasheet (if provided by manufacturer)
Optional Add-ons:
- AC power cords with regional plugs (EU, US, UK, AU types)
- Mounting brackets or adapter holders for fixed installations
- Terminal block connectors or mating harnesses
- EMI filters or surge protectors for enhanced line conditioning
Connectors:
- Input: IEC C14 or equivalent AC inlet (depending on model variant)
- Output: Bare wire ends (cord-end terminals) for direct wiring to terminal blocks
6. Installation & Setup
Requirements:
- Standard AC mains supply (100–240V AC, 50/60Hz)
- Proper ventilation to ensure natural convection cooling
- Secure mounting surface or equipment bay for adapter placement
Mounting Options:
- Desktop or bench-top placement for laboratory or office use
- Wall or panel mounting using optional brackets
- Integration into equipment enclosures with cable routing provisions
Configuration Steps:
1. Verify that the input voltage matches the local AC mains supply.
2. Connect the AC input cable to the adapter’s inlet.
3. Connect the DC output wires to the target device’s terminal block, ensuring correct polarity (typically red = +20V, black = ground).
4. Secure all connections and ensure strain relief on cables.
5. Power on the AC supply and verify output voltage with a multimeter before connecting sensitive equipment.
Safety Considerations:
- Always disconnect power before wiring or maintenance.
- Ensure proper grounding and insulation.
- Avoid exposure to moisture or conductive debris.
7. Performance & Capabilities
Power Delivery:
The adapter delivers a continuous 160W output with high efficiency and low ripple, ensuring stable operation for sensitive electronics.
Speed and Response:
Fast transient response to load changes, maintaining voltage stability within ±5%.
Capacity:
Supports continuous 8A output current at 20V DC, with short-term overload tolerance up to 110–120% of rated load before protection circuits engage.
Efficiency:
Typical conversion efficiency exceeds 85%, minimizing energy loss and heat buildup.
Thermal Performance:
Fanless design relies on natural convection; suitable for ambient temperatures up to 40°C under full load. Derating may apply above this temperature.
Limitations:
- Not designed for outdoor or wet environments unless enclosed in a protective housing.
- Requires adequate ventilation; not suitable for sealed enclosures without airflow.
- Fixed output voltage (20V DC) – not adjustable.
Reliability:
MTBF (Mean Time Between Failures) typically >50,000 hours under nominal conditions, depending on manufacturer’s internal testing standards.
8. Standards & Compliance
Safety and Regulatory Compliance:
- Designed to meet international safety standards for information technology and industrial equipment power supplies (e.g., IEC/EN/UL 62368-1 or equivalent).
- EMC compliance with EN55032 Class B and EN55035 (typical for industrial adapters).
- RoHS Directive (2011/65/EU) compliant – free from hazardous substances.
- CE marking (for EU market) and FCC compliance (for US market) may apply depending on manufacturer certification.
- Insulation class: Class I (with protective earth) or Class II (double insulated), depending on variant.
Environmental Standards:
- RoHS and REACH compliant materials.
- Designed for energy efficiency and reduced standby power consumption.
Industry Standards:
- Conforms to general industrial power supply standards for reliability and safety.
- Meets applicable surge and transient immunity requirements (IEC 61000-4 series).
9. Additional Information
Warranty:
Typically covered by a 1- to 3-year limited warranty (depending on manufacturer policy), covering defects in materials and workmanship under normal operating conditions.
Support:
Technical support and documentation available from the manufacturer or authorized distributor, including datasheets, wiring diagrams, and compliance certificates.
Maintenance:
- Periodic inspection of cables and connectors recommended.
- Keep ventilation surfaces free of dust and debris.
- Avoid mechanical stress on cords and terminals.
Firmware/Updates:
Not applicable – the PA-160W-OW is a hardware-only power supply with no firmware components.
Serviceability:
Non-user-serviceable; internal repairs should only be performed by qualified technicians or replaced as a complete unit.
Storage and Handling:
Store in a dry, dust-free environment at temperatures between -20°C and +85°C. Avoid exposure to direct sunlight or corrosive atmospheres.
Lifecycle and Sustainability:
Designed for long operational life and recyclability of materials in compliance with environmental directives.
Summary
The PA-160W-OW 160W AC/DC Power Adapter is a robust, high-efficiency external power supply engineered for industrial and professional applications requiring a 20V DC, 8A output. Its durable construction, cord-end terminal output, and 18AWG heavy-duty cable make it ideal for integration into systems using terminal block connections. With comprehensive protection features, wide input voltage compatibility, and compliance with international safety and environmental standards, the PA-160W-OW delivers reliable, efficient, and safe power conversion for a broad range of electronic and industrial equipment.
