Fanless dual-port 10GbE PCIe adapter with RoCEv2 for wide-temperature operation.

PCIe-N572

Fanless dual-port 10GbE PCIe adapter with RoCEv2 for wide-temperature operation.

Request a quote

Manufacturer Neousys Technology
Category: Vision & Video
The PCIe-N572 is a rugged dual-port 10GBASE-T network card for applications that do not require PoE power delivery. Its Broadcom BCM57416 controller supports RoCEv2 RDMA for direct zero-copy data transfer, jumbo frames up to 9.6 KB and verified throughput above 9.62 Gbps. The PCIe Gen3 x4 card supports 10G and 1G links with CAT 6a cabling up to 100 m. It can be installed with a low-profile or standard-height bracket and supports fanless operation from -25°C to 70°C with airflow.

Non-PoE wide-temperature PCIe Gen3 x4 network adapter with two 10GBASE-T ports based on the Broadcom BCM57416 controller. It supports 10G/1G links, RoCEv2 RDMA, throughput above 9.62 Gbps and 9.6 KB jumbo frames. The single-slot card accepts low-profile or standard-height brackets and operates from -25°C to 70°C fanlessly with airflow.

Bus Interface PCI Express Gen3 x4
Supported PCIe Lane Configurations x8, x4, x1
Bus Interface PCI Express Gen3 x4; supports x8, x4 and x1 PCIe lanes
10GbE Port Count 2 ports
Ethernet Controller Broadcom BCM57416
Supported Link Speeds 10G, 1G Gbps
Network Standards 10GBASE-T IEEE 802.3an; 1000BASE-T IEEE 802.3ab
Maximum Jumbo Frame Size 9.6 KB
RDMA Protocol RoCEv2
Verified Throughput >9.62 Gbps
PoE Capability Not supported
Cable Requirement CAT 6a or better
Maximum Cable Length 100 m
Operating Temperature -25 to 70 °C
Cooling Mode Fanless operation with airflow
Operating Temperature -25°C to 70°C fanless operation with airflow
EMC Compliance CE/FCC Class B; EN 55032 and EN 55035
Card Form Factor Single-slot low-profile or standard-height PCIe card
Low-Profile Dimensions 167.65 x 68.9 mm (W x H)
Standard-Height Dimensions 167.65 x 111.2 mm (W x H)
Form Factor Single-slot low-profile or standard-height PCIe card
Connector 2x 10GBASE-T Ethernet ports
Dimensions 167.65 mm W x 68.9 mm H with low-profile bracket; 167.65 mm W x 111.2 mm H with standard-height bracket
DMA RoCEv2 RDMA; direct zero-copy transfer to host memory
Key Features Two 10GBASE-T ports; Broadcom BCM57416 controller; RoCEv2 RDMA; 9.6 KB jumbo frames; throughput above 9.62 Gbps; fanless wide-temperature operation; CAT 6a reach up to 100 m; non-PoE design
