IP69K fanless mission-critical computer with 14th/13th/12th Gen Intel Core support.

SEMIL-2207

IP69K fanless mission-critical computer with 14th/13th/12th Gen Intel Core support.
Request a quote
  • Manufacturer Neousys Technology
  • Category: Industrial Computer
  • The Neousys SEMIL-2207 is a fanless, IP69K-protected mission-critical computer for demanding industrial, field and vehicle applications. Its rugged 2U half-width 19-inch rack chassis supports 14th, 13th and 12th Gen Intel Core processors and up to 128 GB of ECC or non-ECC DDR5-4800 memory. Seven Ethernet ports, including two 10GbE and four 2.5GbE connections, two isolated CAN 2.0 ports, USB, DisplayPort and isolated serial interfaces provide versatile connectivity. It operates from -40°C to 70°C and accepts a 9–36 VDC input with integrated ignition power control.
2U 19-inch half-rack rugged computer supporting 35 W Intel 14th, 13th and 12th Gen Core processors, up to 128 GB ECC/non-ECC DDR5-4800, dual SATA with RAID 0/1 and one PCIe Gen4 x4 NVMe socket. Provides 2x 10GbE, 4x 2.5GbE, 1x GbE, 2x isolated CAN 2.0, USB, DisplayPort and four isolated serial ports through rugged M12 connectors. Features IP69K protection, -40°C to 70°C fanless operation and 9–36 VDC input with ignition control.
  • Supported Processor Generations Intel Core 14th, 13th and 12th Gen
  • Processor Socket LGA1700
  • Processor TDP 35 W
  • Supported 14th Gen Processors Core i9-14900T; Core i7-14700T; Core i5-14500T; Core i3-14100T
  • Supported 13th Gen Processors Core i9-13900TE; Core i7-13700TE; Core i5-13500TE; Core i3-13100TE
  • Supported 12th Gen Processors Core i9-12900TE; Core i7-12700TE; Core i5-12500TE
  • Chipset Intel R680E platform controller hub
  • Integrated Graphics Intel UHD Graphics 770
  • Maximum Memory Capacity 128 GB
  • Memory Type ECC/non-ECC DDR5-4800 SDRAM
  • Memory Slots 2 SODIMM slots
  • SATA Ports 2 internal SATA ports for 2.5-inch HDD/SSD
  • SATA RAID Support RAID 0/1
  • NVMe Socket 1x M.2 2280 M key, PCIe Gen4 x4
  • Mini PCIe Sockets 3 full-size sockets with SIM slots
  • Cellular Expansion Socket 1x M.2 2242/3052 B key with dual SIM
  • Wireless Expansion Socket 1x M.2 2230 E key for Wi-Fi
  • 10GbE Ports 2 ports
  • 2.5GbE Ports 4 ports
  • Gigabit Ethernet Ports 1 port
  • Wake-on-LAN Support 10GbE and GbE ports
  • CAN Bus Ports 2 isolated CAN 2.0 ports with Linux SocketCAN support
  • USB 3.2 Ports 2x Type-C USB 3.2 Gen1x1, shared with DisplayPort
  • Maximum USB Data Rate 5 Gbps
  • USB 2.0 Ports 2x M12 A-coded
  • Display Outputs 2x DisplayPort through USB Type-C
  • RS-232 Ports 3 isolated 3-wire ports
  • RS-422/485 Ports 1 isolated port
  • DC Input Range 9–36 VDC
  • Power Input Connector M12 L-coded
  • Reverse Polarity Protection Supported
  • Ignition Power Control Built-in
  • Dimensions 220 x 310 x 90.5 mm
  • Weight 6.2 kg
  • Mounting Options Rack-mount and wall-mount
  • Chassis Materials Stainless steel and aluminum
  • Form Factor 2U 19-inch half-rack, rack-mount or wall-mount
  • Connector M12 X-coded Ethernet; M12 A-coded USB/serial/CAN; M12 L-coded DC input; USB Type-C
  • Dimensions 220 x 310 x 90.5 mm (W x D x H), excluding rack-mount bracket
  • Operating Temperature -40 to 70 °C
  • Storage Temperature -40 to 85 °C
  • Relative Humidity 10–90, non-condensing %
  • Ingress Protection Rating IP69K
  • Operating Temperature -40°C to 70°C
  • Vibration Standard MIL-STD-810H 514.8C-VII, Category 4
  • Shock Standard MIL-STD-810H 516.8 Procedure I
  • EMC Standard MIL-STD-461G CE102, RE102 and RS103
  • Vehicle Power Standard MIL-STD-1275D
  • TPM Support dTPM 2.0
  • Intel AMT Support Intel vPro/AMT 16.0
  • Bus Interface 3x full-size Mini PCIe; M.2 PCIe Gen4 x4; 10GbE; 2.5GbE; GbE; CAN 2.0; USB 3.2; USB 2.0; RS-232; RS-422/485
  • Key Features IP69K fanless construction; Intel 14th/13th/12th Gen Core support; up to 128 GB ECC/non-ECC DDR5-4800; 2x 10GbE plus 4x 2.5GbE and 1x GbE; 2x isolated CAN 2.0 with SocketCAN; 9–36 VDC input with ignition control; MIL-STD-810H; MIL-STD-461G; MIL-STD-1275D
  • Accessories PA-280W-CW6P-2P, JPlate-SL, Rmkit-SL, Cbl-M12X8M-RJ45-CAT6A-500CM, Cbl-TpCPlug-DPM-1M, Cbl-M12A8M-2U2TA-180CM, Cbl-TpCPlug-U3TA-50CM, Cbl-M12A17M-VGA-180CM2, Cbl-TpCPlug-UTpCF-50CM, Cbl-M12A8M-2DB9M_OW2-180CM1, Cbl-M12X8M-RJ45-500CM, Cbl-M12S4F-OW4-180CM1, Cbl-M12A8M-2U2TA-180CM2, Cbl-M12A8M-ADJ-180CM, Cbl-M12A8M-2DB9M-180CM, Cbl-M12L5F-CordEnd5-180CM, Cblkit-M12-SEMIL2007
