Comprehensive Product Summary – SUNIX ESW‑2060 Industrial Lite‑Managed 6‑Port Ethernet Switch
*(Approx. 12,000 characters / ~3,000 tokens)*
### 1. Product Overview
Product Name: Industrial Grade Lite‑Managed 6×TX Switch
Model: ESW‑2060
Series: ESW‑2000 Series (Lite‑Managed Industrial Ethernet Switches)
Article Number: ESW‑2060
Manufacturer: SUNIX Co., Ltd.
Product Category: Industrial Ethernet Switches – Lite‑Managed Type
The SUNIX ESW‑2060 is a rugged, industrial‑grade, Lite‑Managed Ethernet switch designed for mission‑critical automation and control networks. It provides six 10/100Base‑T(X) RJ‑45 ports with advanced redundancy, diagnostic, and management features optimized for harsh industrial environments. As part of the ESW‑2000 series, it combines compact mechanical design, redundant power inputs, and SUNIX’s proprietary ELITE‑Ring™ technology to deliver ultra‑fast network recovery (<10 ms) and continuous operation under extreme conditions.
### 2. Key Features
- 6× 10/100Base‑T(X) RJ‑45 Ports: Auto‑negotiation and Auto‑MDI/MDI‑X support for flexible copper Ethernet connectivity up to 100 m per segment.
- Lite‑Managed Functionality: Web‑based configuration and SUNIX Commander Pro Windows utility for simplified management without full SNMP overhead.
- ELITE‑Ring™ Redundancy: Proprietary ring redundancy technology with recovery time < 10 ms across up to 250 connected units, ensuring uninterrupted data flow.
- RSTP/STP Support: IEEE 802.1w Rapid Spanning Tree Protocol and standard STP for network resilience and loop prevention.
- Port‑Based VLAN: IEEE 802.1Q compliant VLAN segmentation for traffic isolation and security.
- Security Features: IP‑based and MAC‑based access control to prevent unauthorized network access.
- Diagnostics and Alarms: Configurable relay output, alarm LED, e‑mail warning, and system log for proactive fault detection.
- Dual Redundant Power Inputs: 12–48 V DC (nominal 24 V DC) via 7‑pin removable terminal block and DC jack, with reverse polarity protection.
- Industrial‑Grade Protection: ESD protection 4 kV DC on Ethernet ports, surge protection 2 kV DC on power input.
- Wide Temperature Range: Operates reliably from –40 °C to +70 °C; storage –40 °C to +85 °C.
- Compact IP30 Aluminium Enclosure: 106 × 52 × 144 mm, DIN‑rail or wall‑mountable for flexible installation.
- Low Power Consumption: Maximum 7.5 W typical.
- Comprehensive EMC/EMS Compliance: Meets EN61000‑4‑2/3/4/5/6, FCC Part 15 Class A, CISPR 22 Class A.
- 5‑Year Warranty: Long‑term reliability backed by SUNIX industrial support.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|------------------|
| Ethernet Ports | 6 × 10/100Base‑T(X) RJ‑45, Auto‑Negotiation, Auto‑MDI/MDI‑X |
| Standards Compliance | IEEE 802.3 (10Base‑T), IEEE 802.3u (100Base‑TX), IEEE 802.3w (RSTP), IEEE 802.3x (Flow Control), IEEE 802.1Q (VLAN) |
| Transmission Speed | 10/100 Mbps (auto‑negotiation) |
| Transmission Distance | Up to 100 m (Cat 5/5e UTP) |
| Switching Method | Store‑and‑Forward |
| MAC Address Table | 1 K entries |
| Flow Control | IEEE 802.3x full‑duplex, back‑pressure half‑duplex |
| VLAN Support | Port‑based VLAN |
| Redundancy | ELITE‑Ring™ (< 10 ms recovery), STP, RSTP |
| Diagnostics | Alarm relay output, alarm LED, e‑mail warning, system log |
| Configuration Interfaces | Web browser GUI, SUNIX Commander Pro (Windows utility) |
| Power Input | Dual 12–48 V DC (nominal 24 V DC) via 7‑pin terminal block + DC jack |
| Power Consumption | ≤ 7.5 W |
| Relay Output | 1 × configurable alarm relay (1 A @ 24 V DC) |
| Protection | ESD 4 kV DC (Ethernet), Surge 2 kV DC (Power), Reverse polarity protection |
| Enclosure | IP30 aluminium housing |
| Dimensions (W × D × H) | 106 × 52 × 144 mm |
| Weight | Approx. 0.8 kg |
| Mounting | DIN‑rail and wall‑mountable |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Operating Humidity | 5 % to 95 % RH (non‑condensing) |
| Shock / Vibration / Free‑fall | IEC 60068‑2‑27 / ‑6 / ‑32 compliant |
| EMC / EMS | EN61000‑4‑2 (ESD), EN61000‑4‑3 (RS), EN61000‑4‑4 (EFT), EN61000‑4‑5 (Surge Level 3), EN61000‑4‑6 (CS Level 3), FCC Part 15 Class A, CISPR 22 Class A |
| Safety / Reliability | UL 60950, CAN/CSA‑C22.2 No. 60950 (series compliance) |
| Warranty | 5 years |
### 4. Functionality
The ESW‑2060 functions as a Lite‑Managed Fast Ethernet switch providing deterministic, redundant communication for industrial automation networks. It supports six copper ports for 10/100 Mbps Ethernet devices such as PLCs, HMIs, sensors, and controllers.
Operation Principle:
- The switch uses store‑and‑forward packet switching with auto‑learning MAC table.
- ELITE‑Ring™ redundancy ensures that if any link in the ring topology fails, traffic is rerouted within < 10 ms, maintaining uninterrupted communication.
- RSTP/STP protocols provide additional loop‑free redundancy for mixed network topologies.
- Port‑based VLAN segmentation isolates traffic between functional groups or departments.
- Integrated alarm relay and e‑mail notification alert operators to power or link failures.
Use Cases & Applications:
- Factory and process automation networks
- Transportation and traffic control systems
- Building management and utility automation
- Energy and power substation communication
- Industrial monitoring and SCADA systems
Compatibility:
- Interoperable with standard Ethernet devices (IEEE 802.3 compliant)
- Compatible with SUNIX Commander Pro management software
- Supports integration with other SUNIX ESW‑series managed or unmanaged switches
### 5. Components & Accessories
Included Items:
- ESW‑2060 switch unit
- 7‑pin removable terminal block (for dual DC input + relay output)
- DC jack power connector
- DIN‑rail mounting kit (pre‑installed)
- Wall‑mounting kit with screws (M3 × 5)
- Quick Installation Guide (QIG)
- Dust cover and documentation CD
Optional Accessories:
- External 12–48 V DC power supply
- ST/SC fiber transceivers (for other ESW‑2000 variants)
- Grounding wire and industrial cabinet mounting hardware
Connectors:
- RJ‑45 × 6 (10/100Base‑T(X))
- 7‑pin terminal block: [V1+, V1–, Relay+, Relay–, V2+, V2–, GND]
- DC jack (12–45 V DC input)
### 6. Installation & Setup
Power Requirements:
- External DC supply 12–48 V DC (24 V nominal), 1 A @ 12 V DC typical.
- No power switch; device powers on when connected.
- Reverse polarity protection prevents damage from incorrect wiring.
Mounting Options:
- DIN‑Rail Installation:
1. Attach the integrated metal spring clip to the DIN‑rail.
2. Push until a “click” confirms secure mounting.
- Wall Mounting:
1. Remove the DIN‑rail kit.
2. Attach wall‑mount panel using six M3 × 5 screws.
3. Fix the assembly to the wall surface.
Configuration:
- Connect a PC via Ethernet and access the web interface at default IP 192.168.1.1.
- Default credentials: admin / admin.
- Configure IP, VLAN, redundancy, and alarm settings through the web GUI or SUNIX Commander Pro utility.
- Supports firmware upgrade via TFTP, configuration backup/restore, and factory reset (via reset button > 5 s).
LED Indicators:
- Ready (Green): System operational.
- PWR1/PWR2 (Green): Power input 1/2 active.
- Master (Green): Device is ELITE‑Ring master.
- E‑Ring (Green): ELITE‑Ring enabled/active.
- Fault (Amber): Power or port failure detected.
- LNK/ACT (Green): Port link/activity.
### 7. Performance & Capabilities
- Switching Capacity: 1.2 Gbps (non‑blocking)
- Packet Forwarding Rate: 0.9 Mpps (64‑byte packets)
- Latency: < 10 µs typical
- Redundancy Recovery: < 10 ms (ELITE‑Ring™)
- Power Efficiency: ≤ 7.5 W max, fanless passive cooling
- Reliability: MTBF > 200,000 hours (estimated)
- Environmental Robustness: Operates continuously in –40 °C to +70 °C, 5–95 % RH, vibration and shock resistant.
Limitations:
- Fast Ethernet (100 Mbps max) only; no Gigabit uplinks.
- Lite‑Managed – does not support SNMP or advanced QoS features of full managed models.
- Port‑based VLAN only (no 802.1Q tagged trunking).
### 8. Standards & Compliance
Ethernet Standards:
- IEEE 802.3 (10Base‑T)
- IEEE 802.3u (100Base‑TX)
- IEEE 802.3w (RSTP)
- IEEE 802.3x (Flow Control)
- IEEE 802.1Q (VLAN)
Redundancy Protocols:
- SUNIX ELITE‑Ring™ (< 10 ms recovery)
- STP / RSTP (IEEE 802.1D / 802.1w)
Environmental & EMC/EMS Compliance:
- EN61000‑4‑2 (ESD)
- EN61000‑4‑3 (RS)
- EN61000‑4‑4 (EFT)
- EN61000‑4‑5 (Surge Level 3)
- EN61000‑4‑6 (CS Level 3)
- FCC Part 15 Class A
- CISPR 22 (EN55022) Class A
Safety & Reliability:
- UL 60950, CAN/CSA‑C22.2 No. 60950 (series compliance)
- IEC 60068‑2‑27 (Shock)
- IEC 60068‑2‑6 (Vibration)
- IEC 60068‑2‑32 (Free‑fall)
- IP30 Ingress Protection rating
Environmental Responsibility:
- RoHS compliant
- Fanless design reduces energy consumption and maintenance
### 9. Additional Information
Warranty & Support:
- Warranty Period: 5 years limited hardware warranty.
- Technical Support: SUNIX provides global support via email (info@sunix.com.tw) and website (www.sunix.com.tw).
- Firmware & Software Updates: Available through SUNIX Commander Pro and TFTP firmware upgrade utility.
- Maintenance: No moving parts; periodic dust removal and terminal tightening recommended.
- Serviceability: Supports configuration backup/restore and factory reset for rapid field replacement.
Product Family Context:
The ESW‑2060 belongs to the ESW‑2000 Lite‑Managed series, which also includes:
- ESW‑2050: 5‑port 10/100Base‑T(X) Lite‑Managed Switch
- ESW‑2042MM/SS: 4 × 10/100Base‑T(X) + 2 × 100Base‑FX (MM/SM) Lite‑Managed Switches
- ESW‑2080: 8‑port 10/100Base‑T(X) Lite‑Managed Switch
All models share the same management interface and redundancy architecture, allowing mixed deployment in industrial networks.
Manufacturer Contact:
SUNIX Co., Ltd.
Tel: +886‑2‑8913‑1987 Fax: +886‑2‑8913‑1986
Email: info@sunix.com.tw Website: www.sunix.com.tw
### Summary
The SUNIX ESW‑2060 is a compact, robust, and cost‑effective industrial Lite‑Managed Ethernet switch engineered for deterministic and resilient communication in automation networks. With six 10/100Base‑T(X) ports, dual redundant power inputs, and ELITE‑Ring™ redundancy (< 10 ms recovery), it ensures continuous operation even under link or power failure conditions. Its wide temperature range (–40 °C to +70 °C), IP30 aluminium enclosure, and industrial EMC protection make it ideal for deployment in harsh environments such as factories, substations, and transportation systems.
The ESW‑2060 bridges the gap between unmanaged and fully managed switches by offering essential management functions—web configuration, VLAN, redundancy, and alarm monitoring—without the complexity or cost of enterprise‑grade management. Backed by a 5‑year warranty and SUNIX’s industrial networking expertise, the ESW‑2060 provides a reliable foundation for building secure, redundant, and easily maintainable Ethernet infrastructures in mission‑critical industrial applications.
*(Approx. 12,000 characters / ~3,000 tokens)*
### 1. Product Overview
Product Name: Industrial Grade Lite‑Managed 6×TX Switch
Model: ESW‑2060
Series: ESW‑2000 Series (Lite‑Managed Industrial Ethernet Switches)
Article Number: ESW‑2060
Manufacturer: SUNIX Co., Ltd.
Product Category: Industrial Ethernet Switches – Lite‑Managed Type
The SUNIX ESW‑2060 is a rugged, industrial‑grade, Lite‑Managed Ethernet switch designed for mission‑critical automation and control networks. It provides six 10/100Base‑T(X) RJ‑45 ports with advanced redundancy, diagnostic, and management features optimized for harsh industrial environments. As part of the ESW‑2000 series, it combines compact mechanical design, redundant power inputs, and SUNIX’s proprietary ELITE‑Ring™ technology to deliver ultra‑fast network recovery (<10 ms) and continuous operation under extreme conditions.
### 2. Key Features
- 6× 10/100Base‑T(X) RJ‑45 Ports: Auto‑negotiation and Auto‑MDI/MDI‑X support for flexible copper Ethernet connectivity up to 100 m per segment.
- Lite‑Managed Functionality: Web‑based configuration and SUNIX Commander Pro Windows utility for simplified management without full SNMP overhead.
- ELITE‑Ring™ Redundancy: Proprietary ring redundancy technology with recovery time < 10 ms across up to 250 connected units, ensuring uninterrupted data flow.
- RSTP/STP Support: IEEE 802.1w Rapid Spanning Tree Protocol and standard STP for network resilience and loop prevention.
- Port‑Based VLAN: IEEE 802.1Q compliant VLAN segmentation for traffic isolation and security.
- Security Features: IP‑based and MAC‑based access control to prevent unauthorized network access.
- Diagnostics and Alarms: Configurable relay output, alarm LED, e‑mail warning, and system log for proactive fault detection.
- Dual Redundant Power Inputs: 12–48 V DC (nominal 24 V DC) via 7‑pin removable terminal block and DC jack, with reverse polarity protection.
- Industrial‑Grade Protection: ESD protection 4 kV DC on Ethernet ports, surge protection 2 kV DC on power input.
- Wide Temperature Range: Operates reliably from –40 °C to +70 °C; storage –40 °C to +85 °C.
- Compact IP30 Aluminium Enclosure: 106 × 52 × 144 mm, DIN‑rail or wall‑mountable for flexible installation.
- Low Power Consumption: Maximum 7.5 W typical.
- Comprehensive EMC/EMS Compliance: Meets EN61000‑4‑2/3/4/5/6, FCC Part 15 Class A, CISPR 22 Class A.
- 5‑Year Warranty: Long‑term reliability backed by SUNIX industrial support.
### 3. Technical Specifications
| Parameter | Specification |
|----------------|------------------|
| Ethernet Ports | 6 × 10/100Base‑T(X) RJ‑45, Auto‑Negotiation, Auto‑MDI/MDI‑X |
| Standards Compliance | IEEE 802.3 (10Base‑T), IEEE 802.3u (100Base‑TX), IEEE 802.3w (RSTP), IEEE 802.3x (Flow Control), IEEE 802.1Q (VLAN) |
| Transmission Speed | 10/100 Mbps (auto‑negotiation) |
| Transmission Distance | Up to 100 m (Cat 5/5e UTP) |
| Switching Method | Store‑and‑Forward |
| MAC Address Table | 1 K entries |
| Flow Control | IEEE 802.3x full‑duplex, back‑pressure half‑duplex |
| VLAN Support | Port‑based VLAN |
| Redundancy | ELITE‑Ring™ (< 10 ms recovery), STP, RSTP |
| Diagnostics | Alarm relay output, alarm LED, e‑mail warning, system log |
| Configuration Interfaces | Web browser GUI, SUNIX Commander Pro (Windows utility) |
| Power Input | Dual 12–48 V DC (nominal 24 V DC) via 7‑pin terminal block + DC jack |
| Power Consumption | ≤ 7.5 W |
| Relay Output | 1 × configurable alarm relay (1 A @ 24 V DC) |
| Protection | ESD 4 kV DC (Ethernet), Surge 2 kV DC (Power), Reverse polarity protection |
| Enclosure | IP30 aluminium housing |
| Dimensions (W × D × H) | 106 × 52 × 144 mm |
| Weight | Approx. 0.8 kg |
| Mounting | DIN‑rail and wall‑mountable |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Operating Humidity | 5 % to 95 % RH (non‑condensing) |
| Shock / Vibration / Free‑fall | IEC 60068‑2‑27 / ‑6 / ‑32 compliant |
| EMC / EMS | EN61000‑4‑2 (ESD), EN61000‑4‑3 (RS), EN61000‑4‑4 (EFT), EN61000‑4‑5 (Surge Level 3), EN61000‑4‑6 (CS Level 3), FCC Part 15 Class A, CISPR 22 Class A |
| Safety / Reliability | UL 60950, CAN/CSA‑C22.2 No. 60950 (series compliance) |
| Warranty | 5 years |
### 4. Functionality
The ESW‑2060 functions as a Lite‑Managed Fast Ethernet switch providing deterministic, redundant communication for industrial automation networks. It supports six copper ports for 10/100 Mbps Ethernet devices such as PLCs, HMIs, sensors, and controllers.
Operation Principle:
- The switch uses store‑and‑forward packet switching with auto‑learning MAC table.
- ELITE‑Ring™ redundancy ensures that if any link in the ring topology fails, traffic is rerouted within < 10 ms, maintaining uninterrupted communication.
- RSTP/STP protocols provide additional loop‑free redundancy for mixed network topologies.
- Port‑based VLAN segmentation isolates traffic between functional groups or departments.
- Integrated alarm relay and e‑mail notification alert operators to power or link failures.
Use Cases & Applications:
- Factory and process automation networks
- Transportation and traffic control systems
- Building management and utility automation
- Energy and power substation communication
- Industrial monitoring and SCADA systems
Compatibility:
- Interoperable with standard Ethernet devices (IEEE 802.3 compliant)
- Compatible with SUNIX Commander Pro management software
- Supports integration with other SUNIX ESW‑series managed or unmanaged switches
### 5. Components & Accessories
Included Items:
- ESW‑2060 switch unit
- 7‑pin removable terminal block (for dual DC input + relay output)
- DC jack power connector
- DIN‑rail mounting kit (pre‑installed)
- Wall‑mounting kit with screws (M3 × 5)
- Quick Installation Guide (QIG)
- Dust cover and documentation CD
Optional Accessories:
- External 12–48 V DC power supply
- ST/SC fiber transceivers (for other ESW‑2000 variants)
- Grounding wire and industrial cabinet mounting hardware
Connectors:
- RJ‑45 × 6 (10/100Base‑T(X))
- 7‑pin terminal block: [V1+, V1–, Relay+, Relay–, V2+, V2–, GND]
- DC jack (12–45 V DC input)
### 6. Installation & Setup
Power Requirements:
- External DC supply 12–48 V DC (24 V nominal), 1 A @ 12 V DC typical.
- No power switch; device powers on when connected.
- Reverse polarity protection prevents damage from incorrect wiring.
Mounting Options:
- DIN‑Rail Installation:
1. Attach the integrated metal spring clip to the DIN‑rail.
2. Push until a “click” confirms secure mounting.
- Wall Mounting:
1. Remove the DIN‑rail kit.
2. Attach wall‑mount panel using six M3 × 5 screws.
3. Fix the assembly to the wall surface.
Configuration:
- Connect a PC via Ethernet and access the web interface at default IP 192.168.1.1.
- Default credentials: admin / admin.
- Configure IP, VLAN, redundancy, and alarm settings through the web GUI or SUNIX Commander Pro utility.
- Supports firmware upgrade via TFTP, configuration backup/restore, and factory reset (via reset button > 5 s).
LED Indicators:
- Ready (Green): System operational.
- PWR1/PWR2 (Green): Power input 1/2 active.
- Master (Green): Device is ELITE‑Ring master.
- E‑Ring (Green): ELITE‑Ring enabled/active.
- Fault (Amber): Power or port failure detected.
- LNK/ACT (Green): Port link/activity.
### 7. Performance & Capabilities
- Switching Capacity: 1.2 Gbps (non‑blocking)
- Packet Forwarding Rate: 0.9 Mpps (64‑byte packets)
- Latency: < 10 µs typical
- Redundancy Recovery: < 10 ms (ELITE‑Ring™)
- Power Efficiency: ≤ 7.5 W max, fanless passive cooling
- Reliability: MTBF > 200,000 hours (estimated)
- Environmental Robustness: Operates continuously in –40 °C to +70 °C, 5–95 % RH, vibration and shock resistant.
Limitations:
- Fast Ethernet (100 Mbps max) only; no Gigabit uplinks.
- Lite‑Managed – does not support SNMP or advanced QoS features of full managed models.
- Port‑based VLAN only (no 802.1Q tagged trunking).
### 8. Standards & Compliance
Ethernet Standards:
- IEEE 802.3 (10Base‑T)
- IEEE 802.3u (100Base‑TX)
- IEEE 802.3w (RSTP)
- IEEE 802.3x (Flow Control)
- IEEE 802.1Q (VLAN)
Redundancy Protocols:
- SUNIX ELITE‑Ring™ (< 10 ms recovery)
- STP / RSTP (IEEE 802.1D / 802.1w)
Environmental & EMC/EMS Compliance:
- EN61000‑4‑2 (ESD)
- EN61000‑4‑3 (RS)
- EN61000‑4‑4 (EFT)
- EN61000‑4‑5 (Surge Level 3)
- EN61000‑4‑6 (CS Level 3)
- FCC Part 15 Class A
- CISPR 22 (EN55022) Class A
Safety & Reliability:
- UL 60950, CAN/CSA‑C22.2 No. 60950 (series compliance)
- IEC 60068‑2‑27 (Shock)
- IEC 60068‑2‑6 (Vibration)
- IEC 60068‑2‑32 (Free‑fall)
- IP30 Ingress Protection rating
Environmental Responsibility:
- RoHS compliant
- Fanless design reduces energy consumption and maintenance
### 9. Additional Information
Warranty & Support:
- Warranty Period: 5 years limited hardware warranty.
- Technical Support: SUNIX provides global support via email (info@sunix.com.tw) and website (www.sunix.com.tw).
- Firmware & Software Updates: Available through SUNIX Commander Pro and TFTP firmware upgrade utility.
- Maintenance: No moving parts; periodic dust removal and terminal tightening recommended.
- Serviceability: Supports configuration backup/restore and factory reset for rapid field replacement.
Product Family Context:
The ESW‑2060 belongs to the ESW‑2000 Lite‑Managed series, which also includes:
- ESW‑2050: 5‑port 10/100Base‑T(X) Lite‑Managed Switch
- ESW‑2042MM/SS: 4 × 10/100Base‑T(X) + 2 × 100Base‑FX (MM/SM) Lite‑Managed Switches
- ESW‑2080: 8‑port 10/100Base‑T(X) Lite‑Managed Switch
All models share the same management interface and redundancy architecture, allowing mixed deployment in industrial networks.
Manufacturer Contact:
SUNIX Co., Ltd.
Tel: +886‑2‑8913‑1987 Fax: +886‑2‑8913‑1986
Email: info@sunix.com.tw Website: www.sunix.com.tw
### Summary
The SUNIX ESW‑2060 is a compact, robust, and cost‑effective industrial Lite‑Managed Ethernet switch engineered for deterministic and resilient communication in automation networks. With six 10/100Base‑T(X) ports, dual redundant power inputs, and ELITE‑Ring™ redundancy (< 10 ms recovery), it ensures continuous operation even under link or power failure conditions. Its wide temperature range (–40 °C to +70 °C), IP30 aluminium enclosure, and industrial EMC protection make it ideal for deployment in harsh environments such as factories, substations, and transportation systems.
The ESW‑2060 bridges the gap between unmanaged and fully managed switches by offering essential management functions—web configuration, VLAN, redundancy, and alarm monitoring—without the complexity or cost of enterprise‑grade management. Backed by a 5‑year warranty and SUNIX’s industrial networking expertise, the ESW‑2060 provides a reliable foundation for building secure, redundant, and easily maintainable Ethernet infrastructures in mission‑critical industrial applications.
-
EthernetSwitches.pdf
PDF Catalog
-
Lite-Managed quick start.pdf
Manual
Kein Zubehör vorhanden.
