Comprehensive Product Summary – EX9132CST-2 Serial to Ethernet Converter

---

### 1. Product Overview

Product Name: EX9132CST-2
Model: EX9132CST-2
Series: EX9132CST Series (includes EX9132CST-2, EX9132CST-RS485, EX9132CST-RS232)
Article Number: EX9132CST-2
Manufacturer: Topsccc (www.topsccc.com)
Product Type: Serial to TCP/IP Converter (Ethernet to RS-232 and RS-422/485)
Version: Manual Version 1.0.0 (30.03.2017)

The EX9132CST-2 is a compact, industrial-grade serial-to-Ethernet converter designed to connect legacy serial devices to modern IP-based networks. It integrates one RS-232 port and one RS-422/485 (auto-detect) port, enabling seamless communication between serial equipment and Ethernet LAN/WAN environments. Powered by an ST ARM Cortex-M3 32-bit processor running at 72 MHz, the device offers high performance, low latency, and reliable data conversion for industrial automation, control, and monitoring applications.

---

### 2. Key Features

- Dual Serial Interface:
One RS-232 (DB9 male) and one RS-422/485 (terminal block) port with auto-detection capability.

- High-Performance CPU:
ST ARM Cortex™-M3 32-bit processor operating at 72 MHz, optimized for real-time data conversion and low power consumption.

- Ethernet Connectivity:
10/100 Mbps auto-detect Ethernet interface with RJ-45 connector and 1.5 kV magnetic isolation for robust network protection.

- Flexible Communication Modes:
Supports TCP Server, TCP Client, UDP, Virtual COM, and Pairing modes for versatile integration into various network architectures.

- Web-Based Configuration:
Built-in HTTP server allows configuration via standard web browsers (Internet Explorer, Netscape) without additional software.

- Virtual COM Port Support:
Includes Windows-compatible Virtual COM software for transparent serial communication over TCP/IP networks.

- Dynamic IP Management:
DHCP client support for automatic IP address assignment.

- Security and Reliability:
Password-protected access, watchdog function, and firmware update capability via Ethernet.

- Industrial-Grade Protection:
Surge and overcurrent protection on RS-422/485 lines, 15 kV ESD protection on all signal lines.

- Environmental Durability:
Wide operating temperature range (-10°C to 70°C) and storage range (-20°C to 80°C).

- Compact and Stackable Design:
ABS plastic enclosure, lightweight (140 g), and optional DIN-rail or panel mounting.

- Remote Firmware Update:
Firmware can be updated online via Ethernet to maintain compatibility with evolving network standards.

---

### 3. Technical Specifications

Processor: ST ARM Cortex™-M3, 32-bit, 72 MHz
Memory: 64 KB SRAM, 256 KB Flash ROM
Ethernet Interface:
- Connector: RJ-45
- Speed: 10/100 Mbps (auto-detect)
- Protocols: ARP, IP, ICMP, UDP, TCP, HTTP, DHCP
- Isolation: 1.5 kV magnetic isolation
- Configuration: HTTP browser setup
- Security: Login password protection

Serial Interfaces:
- RS-232 Port:
- Connector: DB9 male
- Signals: Rx, Tx, GND, RTS, CTS, DTR, DSR
- Baud Rate: 300 bps to 115.2 Kbps
- Data Bits: 7 or 8
- Stop Bits: 1 or 2
- Parity: None, Odd, Even, Mark, Space

- RS-422/485 Port (Auto-Detect):
- Connector: 4-pin terminal block
- RS-422 Signals: Rx+, Rx-, Tx+, Tx-
- RS-485 Signals: Data+, Data-
- Protection: Surge and overcurrent protection
- Built-in pull high/low resistors

Power Supply:
- Input Voltage: 9–24 VDC
- Current: 500 mA
- Connector: DC jack (default) or terminal block (optional)
- Polarity: Inner positive, outer negative

Indicators:
- RX (Red): Data reception indicator
- TX (Green): Data transmission indicator
- SYS (Green): System status indicator
- LAN 10/100M LED: Network link/activity indicator

Physical Characteristics:
- Dimensions: 115 × 90 × 27 mm (W × D × H)
- Weight: 140 g
- Enclosure: ABS plastic, stackable design
- Mounting: DIN-rail and panel mounting (optional)

Environmental Conditions:
- Operating Temperature: -10°C to +70°C
- Storage Temperature: -20°C to +80°C
- Humidity: 5%–95% RH (non-condensing)

Compliance:
- RoHS Compliant
- FCC and CE Certified

Warranty: 1 Year

---

### 4. Functionality

The EX9132CST-2 functions as a transparent bridge between serial devices and Ethernet networks. It converts serial data streams (RS-232 or RS-422/485) into TCP/IP packets and vice versa, enabling remote access and control of serial equipment over LAN, WAN, or the Internet.

Operating Modes:
- TCP Server Mode: Listens for incoming connections from remote clients.
- TCP Client Mode: Initiates connections to a designated server.
- UDP Mode: Supports connectionless data transmission for broadcast or multicast applications.
- Virtual COM Mode: Emulates a standard COM port on a PC for legacy software compatibility.
- Pairing Mode: Enables point-to-point serial communication over Ethernet between two converters.

Use Cases:
- Industrial automation and control systems
- PLC and SCADA integration
- Remote monitoring of sensors, meters, and instruments
- Serial device networking in manufacturing or utilities
- Data acquisition and telemetry systems

Compatibility:
- Operating Systems: Windows 2000, 2003, XP, Vista, 7, 8, 10
- Network Protocols: TCP/IP, UDP, DHCP, HTTP, ICMP, ARP

---

### 5. Components & Accessories

Included Items:
- 1 × EX9132CST-2 converter unit
- Quick Installation Guide and Software CD

Optional Accessories:
- Power Adapter (9V/12V/24VDC, 500 mA)
- DIN Rail Mounting Kit
- Power Cable
- 2×10 removable screw terminal block (50 mm × 8 mm × 15 mm)

Connectors:
- RS-232: DB9 male
- RS-422/485: Terminal block
- Ethernet: RJ-45
- Power: DC jack or terminal block

---

### 6. Installation & Setup

Power Connection:
Connect a 9–24 VDC power supply to the DC jack (inner positive, outer negative). The device consumes approximately 500 mA.

Network Connection:
Attach an Ethernet cable from the RJ-45 port to a network switch or hub. The LAN LED will illuminate when connected.

Serial Connection:
Connect serial devices to the RS-232 or RS-422/485 ports using appropriate cables. Ensure correct pin assignments and wiring.

Reset Function:
Press and hold the reset button for 3–4 seconds to restore factory defaults. Holding for more than 5 seconds enters firmware update mode.

Configuration Steps:
1. Install and run the IP search utility “EX9132CST.exe” on a Windows PC.
2. Ensure the PC and converter are on the same subnet (default IP: 192.168.0.xxx).
3. Access the web interface via browser (default login: username “admin”, no password).
4. Configure network parameters (IP, subnet mask, gateway).
5. Set serial port parameters (baud rate, parity, stop bits, socket port).
6. Save and reboot the device to apply settings.

Testing Procedure:
- Use HyperTerminal or similar software.
- For RS-232: Short DB9 pins 2 and 3 for loopback test.
- For RS-422: Short T+ to R+ and T– to R–.
- For RS-485: Connect two devices (D+ to D+, D– to D–).
- Verify data echo to confirm successful communication.

---

### 7. Performance & Capabilities

Data Rate: 300 bps to 115.2 Kbps
Network Speed: 10/100 Mbps auto-negotiation
Socket Connections: One socket connection supported
Latency: Low-latency conversion optimized by 72 MHz ARM Cortex-M3 CPU
Reliability: Watchdog timer ensures continuous operation and automatic recovery
Protection: 15 kV ESD protection on all signal lines; surge and overcurrent protection on RS-422/485 lines
Efficiency: Low power consumption due to optimized ARM architecture
Limitations: Single socket connection per device; limited to one RS-232 and one RS-422/485 port

---

### 8. Standards & Compliance

Certifications:
- FCC (Federal Communications Commission)
- CE (Conformité Européenne)
- RoHS (Restriction of Hazardous Substances)

Industry Standards:
- IEEE 802.3 (Ethernet)
- RS-232, RS-422, RS-485 serial communication standards
- TCP/IP, UDP, DHCP, HTTP, ICMP, ARP network protocols

Environmental Compliance:
Manufactured in accordance with RoHS directives, ensuring environmentally safe materials and processes.

---

### 9. Additional Information

Warranty: 1-year limited warranty covering manufacturing defects.
Support: Technical documentation, firmware updates, and software utilities available at www.topsccc.com.
Maintenance:
- Periodically check cable connections and power supply stability.
- Use surge protection in industrial environments.
- Update firmware via Ethernet to maintain compatibility with network standards.

Firmware Updates:
Performed remotely through the web interface or update utility. Ensure stable power and network connection during the process.

Troubleshooting (FAQ Highlights):
- If the device is not detected, verify power and network connections.
- Ensure the PC and converter are on the same subnet.
- Disable firewall or antivirus temporarily during initial setup.
- Reset to factory defaults if configuration errors occur.

Pin Assignments:
- RS-232 (DB9 Male):
Pin 2: RXD, Pin 3: TXD, Pin 4: DTR, Pin 5: GND, Pin 6: DSR, Pin 7: RTS, Pin 8: CTS
- RS-422 (4-pin Terminal Block):
Pin 1: T+, Pin 2: T–, Pin 3: R+, Pin 4: R–
- RS-485 (2-pin Terminal Block):
Pin 3: D+, Pin 4: D–
- RJ-45 Ethernet: Standard 10/100Base-TX pinout

---

### Summary

The Topsccc EX9132CST-2 is a robust, cost-effective serial-to-Ethernet converter engineered for industrial and commercial applications requiring reliable integration of serial devices into IP networks. Its dual-port configuration (RS-232 and RS-422/485), high-performance ARM Cortex-M3 processor, and comprehensive protocol support make it ideal for automation, remote monitoring, and data acquisition systems. With flexible configuration options, strong electrical protection, and compliance with international standards, the EX9132CST-2 delivers dependable performance in demanding environments while simplifying network integration of legacy serial equipment.
