Comprehensive Product Summary: HSL-DI32-M-P (Robust HSL 32-Channel PNP Sourcing Input Daughter Board)

---

### 1. Product Overview

Product Name: HSL-DI32-M-P
Model Number: HSL-DI32-M-P
Series: HSL (High Speed Link for Industry Automation Solutions)
Article Number: HSL-DI32-M-P
Manufacturer: ADLINK Technology Inc.
Product Type: 32-Channel PNP Sourcing Input Daughter Board
Product Category: Industrial Automation I/O Expansion Module

The HSL-DI32-M-P is a robust, high-performance discrete input daughter board designed for use within ADLINK’s HSL (High Speed Link) industrial automation system. It provides 32 channels of PNP sourcing (wet contact) discrete inputs, optimized for high-speed, reliable signal acquisition in distributed control and monitoring applications. The module features a metal cover for enhanced durability and electromagnetic protection, making it suitable for harsh industrial environments.

---

### 2. Key Features

- 32 Discrete Input Channels: Supports 32 independent PNP sourcing input points for digital signal acquisition.
- High-Speed Link (HSL) Interface: Integrates seamlessly with ADLINK’s HSL system for distributed I/O communication.
- PNP Sourcing Input Type: Designed for wet contact or sourcing input configurations, compatible with +10V to +30V DC logic levels.
- Robust Metal Enclosure: Provides mechanical protection and EMI shielding for industrial reliability.
- LED Indicators:
- Red LED: Active DC power indication.
- Green LED (Link): Communication link status.
- Green LEDs (Inputs): Individual channel activity indicators for quick diagnostics.
- Flexible Terminal Base Options: Compatible with HSL-TB32-U-DIN (32-channel) and HSL-TB64-DIN (64-channel) terminal bases for easy wiring and DIN-rail mounting.
- Fast Response Time: 2 ms maximum ON/OFF response time ensures accurate signal capture for high-speed automation tasks.
- Address Configuration via DIP Switch: Supports configurable addressing with DIP switch settings; occupies two consecutive address allocations starting from an odd address.
- Wide Power Supply Range: Operates from +10V to +30V DC external power, ensuring compatibility with standard industrial power systems.
- Compact and Lightweight Design: Optimized for space-constrained control cabinets.
- High Reliability: Industrial-grade components and design for long-term operation in demanding environments.

---

### 3. Technical Specifications

Electrical Characteristics:
- Input Type: PNP sourcing (wet contact)
- Number of Channels: 32 discrete input channels
- Input Current (max): +10 mA per channel
- Input Impedance: 4.7 kΩ
- ON Operating Voltage (min): 14.4 V DC
- OFF Voltage (max): 5.0 V DC
- ON Response Time: ≤ 2 ms
- OFF Response Time: ≤ 2 ms

Power Requirements:
- External Power Supply: +10V to +30V DC
- Power Consumption: 1.8 W (typical)

Physical Characteristics:
- Board Dimensions (Daughter Board only): 100 mm × 78.2 mm
- With HSL-TB32-U-DIN Terminal Base: 126 mm × 120.1 mm × 107.3 mm
- With HSL-TB64-DIN Terminal Base: 168.7 mm × 120.1 mm × 107.3 mm
- Weight: 72 g

Environmental:
- Operating Temperature: Industrial range (typical for HSL modules; consult ADLINK specifications)
- Storage Temperature: As per ADLINK standard module specifications
- Humidity: 5%–95% non-condensing

Indicators:
- Power LED: Red (Active DC Power)
- Link LED: Green (Communication Link)
- Input LEDs: Green (Channel Activity)

Connectors and Interfaces:
- Communication Interface: RS-422 differential signaling (RX+/RX−, TX+/TX−)
- Power Terminals: +VS (10–30V DC), GND
- Input Terminals: DI0–DI31 (Discrete Input Channels)
- Terminal Base Compatibility: HSL-TB32-U-DIN, HSL-TB64-DIN

---

### 4. Functionality

The HSL-DI32-M-P functions as a discrete input expansion module within the ADLINK HSL distributed I/O system. It captures digital input signals from field devices such as sensors, switches, and pushbuttons, and transmits these signals to a host controller or PLC via the HSL communication bus.

Operating Principle:
- Each input channel detects a high (ON) or low (OFF) state based on the voltage level applied to the input terminal.
- The PNP sourcing configuration means that the input device sources current into the module’s input terminal when active.
- The module’s internal circuitry, including LED indicators, provides visual feedback for each channel’s status.
- The HSL communication interface transmits input data to the main controller at high speed, ensuring minimal latency.

Use Cases and Applications:
- Industrial automation and process control systems
- Machine control and monitoring
- Distributed I/O systems in manufacturing lines
- Data acquisition for digital sensors and switches
- Integration with PLCs, motion controllers, and SCADA systems

Compatibility:
- Fully compatible with ADLINK’s HSL system architecture
- Works with HSL terminal bases (HSL-TB32-U-DIN, HSL-TB64-DIN)
- Supports RS-422 communication standard for robust, noise-immune data transmission

---

### 5. Components & Accessories

Included Components:
- HSL-DI32-M-P daughter board (metal-covered)
- Onboard DIP switch for address configuration
- LED indicators for power, link, and input status

Compatible Terminal Bases (sold separately):
1. HSL-TB32-U-DIN:
- 32-channel I/O terminal base with DIN socket
- Provides terminal connections for channels 0–31
- Compact DIN-rail mountable design

2. HSL-TB64-DIN:
- 64-channel I/O terminal base with DIN socket
- Supports two daughter boards (Slot I and Slot II)
- Provides terminal connections for channels 0–63

Connectors:
- JP3 / JP4 Pin Assignments:
- Power: +VS, GND
- Communication: RX+, RX−, TX+, TX−
- Input Channels: DI0–DI31

Optional Accessories:
- DIN-rail mounting kits
- HSL communication cables
- External power supply units (10–30V DC)

---

### 6. Installation & Setup

Mounting Options:
- Designed for DIN-rail installation when used with HSL terminal bases.
- The daughter board attaches securely to the terminal base via the DIN socket interface.

Power Requirements:
- External DC power supply of +10V to +30V is required.
- Connect +VS and GND to the designated terminals on the terminal base.

Address Configuration:
- DIP switch settings determine the module’s address within the HSL network.
- The DI32 occupies two consecutive address allocations starting from an odd address.
- Switch bit 1 must be fixed to ON.
- Example address configurations:
- 100000 → Address 1, 2
- 110000 → Address 3, 4
- …
- 101111 → Address 61, 62

Wiring Configuration:
- Connect discrete input devices (sensors, switches) to DI0–DI31 terminals.
- For PNP sourcing inputs, connect the positive output of the field device to the DI terminal and the negative to GND.
- Ensure proper polarity and voltage levels to prevent damage.

Field I/O Configuration Examples:
- With HSL-TB32-U-DIN: Channels 0–31 correspond directly to terminals 0–31.
- With HSL-TB64-DIN: Channels 0–31 correspond to terminals 0–31 (Slot I) or 32–63 (Slot II).

Startup Procedure:
1. Mount the terminal base on the DIN rail.
2. Attach the HSL-DI32-M-P daughter board.
3. Connect power and communication lines.
4. Configure DIP switch address.
5. Power on and verify LED indicators for proper operation.

---

### 7. Performance & Capabilities

Speed and Response:
- ON/OFF response time ≤ 2 ms ensures rapid signal detection suitable for high-speed automation.
- RS-422 communication provides high-speed, noise-resistant data transfer between modules and controllers.

Capacity:
- 32 discrete input channels per module.
- Expandable system architecture allows multiple modules to be networked for large-scale I/O systems.

Efficiency:
- Low power consumption (1.8 W) minimizes system energy usage.
- LED indicators facilitate quick diagnostics, reducing downtime.

Limitations:
- Designed for PNP sourcing inputs only (use HSL-DI32-M-N for NPN sinking or dry contact inputs).
- Requires external 10–30V DC power supply.
- Must be used with compatible HSL terminal bases for proper operation.

---

### 8. Standards & Compliance

Certifications and Compliance:
- Designed and manufactured by ADLINK Technology Inc., a certified industrial automation hardware provider.
- Complies with industrial EMC and safety standards applicable to HSL modules.
- HSL® is a registered trademark of ADLINK Technology Inc.
- Other product names and brands are trademarks or registered trademarks of their respective holders.

Regulatory Notes:
- Specifications and contents are subject to change without notice.
- Product designed for industrial use; compliance with CE and FCC industrial class standards (typical for ADLINK HSL products).

Industry Standards:
- RS-422 differential communication standard
- DIN-rail mounting standard (EN 60715)
- Industrial DC power supply standard (10–30V DC)

---

### 9. Additional Information

Ordering Information:
- HSL-DI32-DB-P: 32-Channel Discrete PNP Sourcing Input Daughter Board
- HSL-DI32-DB-N: 32-Channel Discrete NPN Sinking Input Daughter Board
- HSL-TB32-U-DIN: 32-Channel I/O Terminal Base with DIN Socket
- HSL-TB64-DIN: 64-Channel I/O Terminal Base with DIN Socket

Warranty and Support:
- Standard ADLINK warranty applies (consult ADLINK for terms).
- Technical support available via:
- Service Email: service@adlink.com.tw
- Technical Assistance: NuDAM@adlink.com.tw
- Telephone: +886-2-82265877
- Fax: +886-2-82265717
- Website: [www.adlink.com.tw](http://www.adlink.com.tw)

Maintenance:
- Periodic inspection of terminal connections and power supply recommended.
- Ensure clean, dry operating environment to maintain long-term reliability.
- LEDs provide immediate visual feedback for troubleshooting.

Product Documentation:
- Document Reference: AM-HSLDBIO002-E1.00
- Manufacturer: ADLINK Technology Inc.
- Copyright © 2001 ADLINK Technology Inc.
- All specifications subject to change without prior notice.

---

### Summary

The ADLINK HSL-DI32-M-P is a 32-channel PNP sourcing discrete input daughter board engineered for industrial automation systems utilizing the HSL (High Speed Link) architecture. It offers fast, reliable digital input acquisition, robust construction with a metal cover, and flexible installation via DIN-rail terminal bases. With 2 ms response time, wide voltage tolerance, and comprehensive LED diagnostics, it is ideal for high-speed, distributed control applications in manufacturing, process automation, and machine monitoring.

Its compatibility with HSL-TB32-U-DIN and HSL-TB64-DIN terminal bases, combined with RS-422 communication, ensures scalable, noise-immune, and efficient integration into complex automation networks. The HSL-DI32-M-P exemplifies ADLINK’s commitment to “Opening the Automation by Fast Linking Technology.”
