Comprehensive Product Summary: HSL-R8DI16-M-P

---

### 1. Product Overview

Product Name: HSL-R8DI16-M-P
Article Number: HSL-R8DI16-M-P
Series: HSL (High Speed Link for Industry Automation Solutions)
Manufacturer: ADLINK Technology Inc.
Product Type: Robust HSL I/O daughter board with 8-channel relay outputs and 16-channel PNP sourcing inputs
Product Description: The HSL-R8DI16-M-P is a robust, metal-covered industrial I/O module designed for high-speed distributed control applications. It integrates eight relay output channels and sixteen PNP sourcing input channels, providing a reliable interface between field devices and HSL-based automation systems. The module is part of ADLINK’s HSL family, which enables high-speed, deterministic communication for industrial automation and machine control.

---

### 2. Key Features

- Dual Functionality: Combines 8 relay output channels and 16 PNP input channels on a single daughter board, optimizing space and simplifying wiring.
- High-Speed Link (HSL) Technology: Utilizes ADLINK’s proprietary HSL communication protocol for fast, deterministic data exchange between controllers and distributed I/O modules.
- Robust Construction: Metal enclosure provides superior protection against electromagnetic interference (EMI) and mechanical stress, ensuring reliable operation in harsh industrial environments.
- Flexible Power Input: Operates with a wide DC voltage range of +10V to +30V, suitable for various industrial power systems.
- LED Indicators: Integrated LED indicators for power, communication link, and I/O channel status facilitate quick diagnostics and maintenance.
- DIN-Rail Mounting Compatibility: Designed for easy installation on standard DIN rails using compatible terminal bases (HSL-TB32-U-DIN, HSL-TB64-DIN).
- Scalable System Integration: Fully compatible with other HSL modules such as HSL-DO32-DB and HSL-DI32-DB, enabling modular expansion of I/O capacity.
- Industrial-Grade Reliability: Designed for continuous operation in industrial automation, process control, and machine monitoring applications.
- Fast Response Time: Typical ON/OFF response time of 2 ms ensures real-time performance for control tasks.
- Comprehensive Address Configuration: DIP switch-based addressing allows flexible allocation of module addresses within the HSL network.

---

### 3. Technical Specifications

General Specifications:
- Model: HSL-R8DI16-M-P
- Type: Relay output and PNP input daughter board
- Channels: 8 relay outputs, 16 PNP sourcing inputs
- Communication Interface: RS-422 differential signaling (RX+/RX-, TX+/TX-)
- Power Supply: +10V to +30V DC external power input
- Power Consumption: Approximately 1.8 W
- Weight: Approx. 72 g (board only)
- Material: Metal cover for enhanced durability and EMI shielding

Electrical Characteristics:
- Relay Output Type: Mechanical relay contacts
- Input Type: PNP sourcing digital inputs
- Output Load Capacity: Up to 300 mA per channel at 24V DC (typical for PNP outputs)
- Input Voltage Range: 10V–30V DC (logic high detection)
- Response Time: ON: 2 ms max; OFF: 2 ms max
- Isolation: Channel-to-channel and channel-to-system isolation for noise immunity

Physical Dimensions:
- Daughter Board Only: 100 mm (L) × 78.2 mm (W)
- With HSL-TB32-DO-DIN Terminal Base: 126 mm (L) × 120.1 mm (W) × 107.3 mm (H)
- With HSL-TB64-DIN Terminal Base: 168.7 mm (L) × 120.1 mm (W) × 107.3 mm (H)

Environmental Conditions:
- Operating Temperature: 0°C to 55°C (typical industrial range)
- Storage Temperature: -20°C to 85°C
- Humidity: 10%–90% RH, non-condensing
- Vibration Resistance: Designed for industrial environments with moderate vibration levels

---

### 4. Functionality

The HSL-R8DI16-M-P serves as a distributed I/O interface within an HSL-based automation network. It connects to a host controller or master module via RS-422 differential communication lines, enabling high-speed data transfer and deterministic control.

Operation Principle:
- Input Function: The 16 PNP sourcing input channels detect the ON/OFF status of external sensors, switches, or proximity detectors. Each input channel sources current to the connected device, providing reliable signal acquisition.
- Output Function: The 8 relay output channels control external actuators such as solenoids, contactors, or indicator lamps. Each relay output can switch DC or AC loads, providing electrical isolation between control logic and field devices.
- Communication: The module exchanges I/O data with the HSL master through high-speed serial communication, ensuring synchronized updates across the network.
- Addressing: DIP switches on the board define the module’s address within the HSL network. The addressing scheme allows consecutive address allocation for multiple modules.

Applications:
- Factory automation and process control
- Machine tool control and monitoring
- Packaging and material handling systems
- Distributed I/O for PLC and PC-based control systems
- Building automation and environmental monitoring

Compatibility:
- Fully compatible with ADLINK HSL terminal bases:
- HSL-TB32-U-DIN
- HSL-TB32-DO-DIN
- HSL-TB64-DIN
- Integrates seamlessly with other HSL modules such as HSL-DO32-DB and HSL-DI32-DB.

---

### 5. Components & Accessories

Included Components:
- HSL-R8DI16-M-P daughter board with metal cover
- Onboard DIP switch for address configuration
- LED indicators for power, link, and I/O status

Optional Accessories:
- HSL-TB32-U-DIN: 32-channel I/O terminal base with DIN socket
- HSL-TB32-DO-DIN: 32-channel I/O terminal base for NPN output modules
- HSL-TB64-DIN: 64-channel I/O terminal base for expanded I/O configurations
- Cabling: RS-422 communication cables for connection to HSL master modules
- Mounting Hardware: DIN rail clips and screws for secure installation

Connectors:
- JP3/JP4 Terminal Headers: Provide access to power, communication, and discrete I/O channels.
- Power: +VS (+10V~+30V DC), GND
- Communication: RX+/RX-, TX+/TX-
- Discrete Outputs: DO0–DO31 (depending on configuration)

---

### 6. Installation & Setup

Requirements:
- External DC power supply (10V–30V DC)
- Compatible HSL terminal base (TB32 or TB64 series)
- RS-422 communication link to HSL master controller

Mounting Options:
- DIN-rail mounting via terminal base (HSL-TB32-U-DIN or HSL-TB64-DIN)
- Panel mounting possible with appropriate brackets

Configuration Steps:
1. Mount the Terminal Base: Secure the terminal base to the DIN rail.
2. Attach the Daughter Board: Insert the HSL-R8DI16-M-P onto the terminal base connector.
3. Set the Address: Use the onboard DIP switch to assign the module’s address within the HSL network. Bit 1 is fixed to ON for odd address allocation.
4. Connect Power: Supply +10V to +30V DC to the +VS and GND terminals.
5. Connect Communication Lines: Wire the RS-422 lines (RX+/RX-, TX+/TX-) to the HSL master.
6. Wire I/O Devices: Connect sensors to input channels and actuators to relay outputs.
7. Verify LED Indicators: Ensure power (red), link (green), and I/O (yellow) LEDs indicate normal operation.

---

### 7. Performance & Capabilities

Speed and Response:
- 2 ms maximum ON/OFF response time ensures real-time control performance suitable for high-speed automation tasks.

Capacity:
- 8 relay outputs capable of switching moderate loads (up to 300 mA at 24V DC typical).
- 16 PNP inputs for sourcing-type sensors and switches.

Efficiency:
- Low power consumption (1.8 W typical) minimizes heat generation and energy usage.
- Efficient communication via HSL protocol reduces network latency and improves throughput.

Reliability:
- Metal enclosure provides mechanical protection and EMI shielding.
- LED diagnostics simplify troubleshooting and reduce downtime.
- Designed for continuous 24/7 operation in industrial environments.

Limitations:
- Relay outputs are mechanical and subject to wear over extended use; periodic inspection recommended.
- Not suitable for high-current or high-voltage switching beyond rated specifications.

---

### 8. Standards & Compliance

Certifications and Compliance:
- CE Marking: Conforms to European safety and EMC directives.
- RoHS Compliance: Manufactured in accordance with the Restriction of Hazardous Substances Directive.
- Industrial Standards: Designed to meet IEC and EN standards for industrial control equipment.
- Trademark: HSL® is a registered trademark of ADLINK Technology Inc.

Regulatory Notes:
- Specifications and contents are subject to change without notice.
- All other product names and trademarks are the property of their respective owners.

---

### 9. Additional Information

Warranty:
- Standard manufacturer’s warranty provided by ADLINK Technology Inc. (typically one year, depending on region and distributor).

Technical Support:
- Service Email: service@adlink.com.tw
- Technical Assistance: NuDAM@adlink.com.tw
- Telephone: +886-2-82265877
- Fax: +886-2-82265717
- Website: [www.adlink.com.tw](http://www.adlink.com.tw)

Maintenance:
- Periodic inspection of relay contacts recommended for long-term reliability.
- Keep module free from dust and moisture; ensure adequate ventilation.
- Verify LED indicators regularly to confirm proper operation.

Firmware & Updates:
- Firmware updates and configuration utilities available through ADLINK’s support portal.
- Compatible with ADLINK’s HSL configuration software for network setup and diagnostics.

Ordering Information:
- HSL-R8DI16-M-P: 8-channel relay output, 16-channel PNP input daughter board with metal cover
- HSL-DO32-DB-N: 32-channel discrete NPN sinking output daughter board
- HSL-DO32-DB-P: 32-channel discrete PNP sourcing output daughter board
- HSL-TB32-U-DIN: 32-channel I/O terminal base with DIN socket
- HSL-TB32-DO-DIN: 32-channel I/O terminal base for NPN output modules
- HSL-TB64-DIN: 64-channel I/O terminal base with DIN socket

---

### Summary

The ADLINK HSL-R8DI16-M-P is a high-performance, industrial-grade I/O module designed for distributed automation systems utilizing the HSL communication protocol. Combining eight relay outputs and sixteen PNP inputs in a compact, metal-enclosed form factor, it delivers robust performance, flexible configuration, and reliable operation in demanding industrial environments. With its wide power range, fast response, and modular compatibility, the HSL-R8DI16-M-P is an ideal choice for machine control, process automation, and distributed I/O applications requiring both input monitoring and output actuation within a unified, high-speed communication framework.
