Name: IP66 fanless Jetson Orin edge AI computer with six GMSL2 camera ports.
Brand: Neousys Technology
SKU: NRU-161V-AWP

INDUSTRIELLE LÖSUNG?

Entdecken Sie Embedded-, Kommunikations- und Automatisierungslösungen für Ihre Anwendung.

IP66 fanless Jetson Orin edge AI computer with six GMSL2 camera ports.

NRU-161V-AWP

IP66 fanless Jetson Orin edge AI computer with six GMSL2 camera ports.

Angebot anfragen

Hersteller Neousys Technology
Kategorie: Industrial Computer
Der NRU-161V-AWP ist ein kompakter, lüfterloser Edge-AI-Computer für NVIDIA Jetson Orin NX oder Orin Nano. Sein IP66-geschütztes Gehäuse und der Betriebstemperaturbereich von -25 bis 70 °C eignen ihn für Außenanlagen, Fahrzeuge, Roboter und industrielle Bildverarbeitung. Sechs wasserdichte GMSL2-Anschlüsse mit FAKRA-Z-Steckern unterstützen ausgewählte Kameras mit IMX390-, ISX031- oder IMX490-Sensoren. Hinzu kommen Gigabit Ethernet, CAN FD, RS-232, USB, VGA, GPS-PPS-Eingang sowie Steckplätze für NVMe, Mini-PCIe und LTE/5G. Die DC-Versorgung von 8 bis 35 V bietet eine integrierte Zündungssteuerung.

IP66 fanless edge AI computer supporting NVIDIA Jetson Orin NX or Orin Nano modules. Provides six waterproof GMSL2 FAKRA Z camera connectors, one M12 Gigabit Ethernet port, CAN FD, RS-232, two USB 2.0 ports, VGA, GPS PPS input, mini PCIe, LTE/5G M.2 B-key and NVMe M.2 M-key expansion. Operates from -25°C to 70°C and accepts 8V to 35V DC input with ignition control.

Supported Processor Modules NVIDIA Jetson Orin NX or Jetson Orin Nano
Maximum AI Performance Up to 100 sparse TOPS (INT8) with Jetson Orin NX TOPS
Memory Options Orin NX: 16GB/8GB LPDDR5 at 3200MHz; Orin Nano: 8GB/4GB LPDDR5 at 2133MHz
GMSL2 Camera Ports 6 ports
Supported Camera Configurations 6x AC-IMX390 2MP@30FPS; 6x AC-ISX031 3MP@30FPS; 4x AC-IMX490 5MP@30FPS
Gigabit Ethernet Ports 1 port
CAN FD Ports 1 port
Serial Ports 1x RS-232
Isolated GPS PPS Inputs 1 input
Digital I/O 1x isolated GPS PPS input
USB Ports 2x USB 2.0; 1x USB Type-C for flashing and OTG
VGA Output Resolution 1920x1080 at 60Hz
NVMe Socket 1x M.2 2242 M-key, PCIe Gen3 x1
Mini PCI Express Socket 1x full-size, PCIe and USB 2.0
Cellular Module Socket 1x M.2 3042/3052 B-key with dual micro SIM support
DC Input Range 8 to 35 V DC
Ignition Power Control Built-in
Dimensions 225 x 136 x 55 mm
Weight 3.0 kg
Mounting VESA 75 and wall mount
Form Factor Fanless IP66 low-profile rugged computer
Connector 6x FAKRA Z GMSL2; M12 X-coded GbE; M12 A-coded power, USB, serial/CAN/PPS and VGA; USB Type-C
Dimensions 225 x 136 x 55 mm, excluding wall mount
Ingress Protection IP66 waterproof and dustproof
Operating Temperature -25 to 70 °C
Storage Temperature -40 to 85 °C
Humidity 10 to 90, non-condensing % RH
Vibration Standard MIL-STD-810H Method 514.8 Category 4
Shock Standard MIL-STD-810H Method 516.8 Procedure I
Operating Temperature -25°C to 70°C with passive cooling in 20W TDP mode
Bus Interface Gigabit Ethernet; CAN FD; RS-232; USB 2.0; PCIe; GMSL2
Resolution VGA output up to 1920x1080 at 60Hz
Key Features NVIDIA Jetson Orin NX or Orin Nano; IP66 waterproof and dustproof; 6x GMSL2 camera ports; fanless operation; up to 100 sparse INT8 TOPS with Orin NX; CAN FD; ignition power control; wide-range DC input; NVMe and cellular expansion
Accessories PA-60W-OW, PA-160W-OW, AC-ISX031-H60, AC-ISX031-H120, AC-ISX031-H190, AC-IMX390-H60, AC-IMX390-H120, AC-IMX390-H190, AC-IMX490-H30, AC-IMX490-H60, AC-IMX490-H120, Cblkit-NRU-161V-AWP, Cbl-FAKRA-ZFM-ZFM-12M, Cbl-M12X8M-RJ45F-100CM, Cbl-M12A8M-2U2TA-180CM1, Cbl-M12A8M-2DB9M_OW2-180CM1, Cbl-M12A17M-VGA-180CM2
