Comprehensive Product Summary – Nuvo-5100VTC Fanless In-Vehicle Controller
### 1. Product Overview
Product Name: Nuvo-5100VTC
Model: Nuvo-5100VTC
Series: Nuvo-5100VTC Series (includes Nuvo-5100VTC, Nuvo-5104VTC, Nuvo-5108VTC)
Article Number: Nuvo-5100VTC
Manufacturer: Neousys Technology Inc.
Product Type: Fanless In-Vehicle Controller with Intel® 6th-Gen Core™ Processor and Q170 Chipset
The Nuvo-5100VTC is a rugged, fanless in-vehicle embedded controller designed for transportation, railway, and mobile surveillance applications. It integrates Intel® 6th-Generation Core™ i7/i5/i3 processors, a Q170 chipset, and multiple PoE+ ports with M12 or RJ45 connectors. The system is engineered for high reliability under extreme environmental conditions, supporting wide temperature operation (-40°C to 70°C), vibration resistance, and ignition power control for automotive deployment.
### 2. Key Features
- Intel® 6th-Gen Core™ i7/i5/i3 CPU Support:
LGA1151 socket supporting Intel® Core™ i7-6700TE, i5-6500TE, and i3-6100TE processors (35W TDP).
Provides high-performance computing and integrated Intel® HD Graphics 530 GPU.
- Fanless Design:
Completely fanless architecture ensures silent operation and long-term reliability in harsh environments.
- Power over Ethernet (PoE+):
Four IEEE 802.3at (25.5W) PoE+ ports via M12 x-coded connectors (Nuvo-5100VTC) or RJ45 (Nuvo-5104VTC/5108VTC).
Each port acts as a Power Sourcing Equipment (PSE) for IP cameras or sensors.
- Wide Power Input Range:
8–35 VDC input via 3-pin pluggable terminal block with ignition control and power sequencing.
- Rugged Connectivity:
M12 x-coded connectors ensure secure Ethernet connections under vibration and shock conditions.
- Comprehensive I/O:
Includes 4x USB 3.0, 4x USB 2.0, 3x COM ports (RS-232/422/485), 1x CAN 2.0 port, 4x isolated DI and 4x isolated DO, audio I/O, and dual Gigabit Ethernet.
- Storage Flexibility:
Dual 2.5” SATA drive bays (1x hot-swappable tray, 1x internal) supporting RAID 0/1.
One full-size mSATA slot (muxed with mini-PCIe).
- Expansion Capability:
Four full-size mini-PCIe sockets with SIM card support for 3G/4G/Wi-Fi/GPS modules.
- Display Outputs:
Triple independent display support via VGA, DVI-D, and dual DisplayPort (up to 4K2K resolution).
- Environmental Robustness:
Certified for EN 50155 (railway), EN 61373 (shock/vibration), and E-Mark (automotive).
Operating temperature: -40°C to +70°C (with SSD).
- Ignition Power Control:
MCU-based ignition control with programmable on/off delay, low battery protection, and smart off-delay modes.
- Compact and Durable:
Dimensions: 240 mm (W) x 225 mm (D) x 79 mm (H); Weight: 3.3 kg.
Aluminum chassis with patented damping bracket for vibration isolation.
### 3. Technical Specifications
Processor Options:
- Intel® Core™ i7-6700TE (8MB Cache, 2.4/3.4 GHz, 35W TDP)
- Intel® Core™ i5-6500TE (6MB Cache, 2.3/3.3 GHz, 35W TDP)
- Intel® Core™ i3-6100TE (4MB Cache, 2.7 GHz, 35W TDP)
Chipset: Intel® Q170 Platform Controller Hub
Graphics: Integrated Intel® HD Graphics 530
Memory: Up to 32 GB DDR4-2133 SDRAM via two SO-DIMM slots
Storage:
- 1x hot-swappable 2.5” SATA HDD/SSD tray
- 1x internal 2.5” SATA HDD/SSD port (RAID 0/1 support)
- 1x full-size mSATA (muxed with mini-PCIe)
Expansion:
- 4x full-size mini-PCIe sockets (two with SIM slots, one muxed with mSATA, two USB-only)
- TPM 2.0 and Intel® AMT 11.0 support
I/O Interfaces:
- Ethernet: 2x Gigabit Ethernet (Intel® I219, I210)
- PoE+: 4x IEEE 802.3at (25.5W) M12 x-coded (Nuvo-5100VTC)
- USB: 4x USB 3.0, 4x USB 2.0
- Serial: 2x RS-232/422/485 (COM1, COM3), 1x RS-232 (COM2)
- CAN Bus: 1x CAN 2.0 port
- DIO: 4x isolated DI, 4x isolated DO (2500 Vrms isolation)
- Audio: 1x Mic-in, 1x Speaker-out
- Video: 1x VGA, 1x DVI-D, 2x DisplayPort (up to 4096x2304)
Power Supply:
- 8–35 VDC input via 3-pin terminal block
- Ignition control with programmable delay
- Power consumption (typical):
- i7-6700TE: 49.2W (2.05A@24V)
- i5-6500TE: 47.8W (1.99A@24V)
- i3-6100TE: 39.4W (1.64A@24V)
Mechanical:
- Dimensions: 240 x 225 x 79 mm
- Weight: 3.3 kg
- Mounting: Damping bracket (standard) or optional DIN-rail
Environmental:
- Operating Temperature: -40°C to +70°C (SSD required for sub-zero)
- Storage Temperature: -40°C to +85°C
- Humidity: 10–90%, non-condensing
- Vibration: 5 Grms, 5–500 Hz, 3 axes (IEC60068-2-64)
- Shock: 50 Grms, 11 ms half-sine (IEC60068-2-27)
### 4. Functionality
The Nuvo-5100VTC operates as a high-performance embedded controller for in-vehicle and railway systems. It manages data acquisition, video surveillance, and communication tasks through its PoE+ ports, CAN bus, and digital I/O interfaces.
Use Cases:
- Mobile video surveillance (IP camera integration via PoE+)
- Fleet management and telematics
- Railway control and monitoring systems
- Industrial automation and edge computing
- Intelligent transportation systems (ITS)
Compatibility:
Supports Windows 7/8/10 (x64), Windows Embedded Standard 7, and major Linux distributions (Ubuntu, Debian, CentOS, Fedora, OpenSUSE).
Operation:
The system can be powered on via ignition signal, front power button, external switch, or Wake-on-LAN. Ignition control ensures safe startup/shutdown synchronized with vehicle operation.
### 5. Components & Accessories
Included Items:
- Nuvo-5100VTC main unit
- Damping bracket with shock-absorbing grommets
- 3-pin power terminal block
- Key for hot-swappable HDD tray
- HDD thermal pad (if HDD not installed)
- Screw pack
- Neousys Drivers & Utilities DVD
Optional Accessories:
- C-M12-RJ45-LAN-5M: M12 (8-pole X-coded) to RJ45 CAT6 cable, 5m
- C-M12-RJ45-LAN-10M: M12 (8-pole X-coded) to RJ45 CAT6 cable, 10m
- DINRAIL-O: DIN-rail mounting kit
- PA-120W-OW: 120W AC/DC adapter (20V/6A, -30°C to +70°C operation)
### 6. Installation & Setup
Mounting Options:
- Standard anti-vibration damping bracket (horizontal installation recommended)
- Wall-mount configuration using M4 screws
- Optional DIN-rail mounting for cabinet integration
Power Connection:
- 3-pin terminal block for 8–35V DC input and ignition signal
- Ensure correct polarity and voltage before connection
Storage Installation:
- Internal 2.5” SATA drive secured with thermal pad and screws
- External hot-swappable 2.5” HDD/SSD tray with lock and RAID support
Expansion Installation:
- Four mini-PCIe sockets for wireless modules (3G/4G/Wi-Fi/GPS)
- SIM slots accessible internally or via rear panel
Ignition Control Configuration:
- Rotary switch with 16 modes (0–15) for power-on/off delay and hard-off timeout
- BIOS-configurable ignition parameters (mode 15) for custom timing and voltage thresholds
### 7. Performance & Capabilities
- Processing Power: Up to Intel® Core™ i7-6700TE, 4 cores, 8 threads, 3.4 GHz turbo
- Graphics: Intel® HD Graphics 530 supporting triple independent displays
- Network Throughput: Dedicated PCIe lanes per Ethernet port for full bandwidth
- PoE Power Delivery: 25.5W per port, IEEE 802.3at compliant
- Storage Performance: SATA 6 Gb/s interface, RAID 0/1 for redundancy or speed
- Reliability: Watchdog timer, hardware monitoring, and ignition-based power sequencing
- Limitations: CPUs above 35W TDP limited to 50°C max ambient; thermal throttling may occur under sustained load
### 8. Standards & Compliance
Certifications:
- EN 50155 (Railway applications – electronic equipment)
- EN 50121-3-2 / EN 50121-2-1 / EN 50121-2-2 (EMC for railway)
- EN 61373 (Shock and vibration)
- E-Mark (Nuvo-5108VTC, automotive compliance)
- CE/FCC Class A (EN 55022, EN 55024, EN 55032)
Safety & Environmental:
- RoHS compliant
- Designed for industrial and transportation-grade reliability
### 9. Additional Information
Warranty & Support:
Neousys provides a standard limited warranty covering manufacturing defects. Firmware, BIOS, and driver updates are available through the official Neousys website. Technical support is accessible via regional offices in Taiwan, USA, and China.
Maintenance:
- Only qualified personnel should service the system.
- Disconnect power before servicing or installing components.
- Use anti-static precautions when handling internal modules.
Software & Drivers:
- Automatic driver installation via included DVD
- Manual driver installation supported for Windows and Linux
- WDT_DIO driver package provides APIs for watchdog timer, DIO, PoE control, and ignition monitoring
Firmware & BIOS Features:
- Configurable COM port modes (RS-232/422/485)
- CAN bus termination control
- SATA AHCI/RAID configuration
- TPM 2.0 enablement
- Wake-on-LAN and power recovery options
- Ignition control parameters (delay, voltage thresholds, smart off-delay)
Operating System Support:
- Windows 7/8/10 (x86/x64)
- Windows Embedded Standard 7
- Linux distributions (Ubuntu, Debian, CentOS, Fedora, OpenSUSE)
Maintenance Tools:
- Watchdog Timer (WDT) for system recovery
- Digital I/O APIs for sensor/actuator control
- CAN bus APIs for vehicle communication
- Ignition and PoE control APIs for power management
### Summary
The Neousys Nuvo-5100VTC is a robust, fanless in-vehicle computing platform engineered for demanding transportation and industrial environments. With Intel® 6th-Gen Core™ processing, multiple PoE+ ports, wide-range DC input, and comprehensive I/O, it delivers exceptional performance for mobile surveillance, fleet management, and railway automation. Its rugged design, extended temperature tolerance, and compliance with EN 50155 and E-Mark standards make it a reliable choice for mission-critical vehicular applications.
The system’s modular expansion, ignition power control, and software integration capabilities ensure flexibility and long-term scalability for embedded and edge computing deployments.
### 1. Product Overview
Product Name: Nuvo-5100VTC
Model: Nuvo-5100VTC
Series: Nuvo-5100VTC Series (includes Nuvo-5100VTC, Nuvo-5104VTC, Nuvo-5108VTC)
Article Number: Nuvo-5100VTC
Manufacturer: Neousys Technology Inc.
Product Type: Fanless In-Vehicle Controller with Intel® 6th-Gen Core™ Processor and Q170 Chipset
The Nuvo-5100VTC is a rugged, fanless in-vehicle embedded controller designed for transportation, railway, and mobile surveillance applications. It integrates Intel® 6th-Generation Core™ i7/i5/i3 processors, a Q170 chipset, and multiple PoE+ ports with M12 or RJ45 connectors. The system is engineered for high reliability under extreme environmental conditions, supporting wide temperature operation (-40°C to 70°C), vibration resistance, and ignition power control for automotive deployment.
### 2. Key Features
- Intel® 6th-Gen Core™ i7/i5/i3 CPU Support:
LGA1151 socket supporting Intel® Core™ i7-6700TE, i5-6500TE, and i3-6100TE processors (35W TDP).
Provides high-performance computing and integrated Intel® HD Graphics 530 GPU.
- Fanless Design:
Completely fanless architecture ensures silent operation and long-term reliability in harsh environments.
- Power over Ethernet (PoE+):
Four IEEE 802.3at (25.5W) PoE+ ports via M12 x-coded connectors (Nuvo-5100VTC) or RJ45 (Nuvo-5104VTC/5108VTC).
Each port acts as a Power Sourcing Equipment (PSE) for IP cameras or sensors.
- Wide Power Input Range:
8–35 VDC input via 3-pin pluggable terminal block with ignition control and power sequencing.
- Rugged Connectivity:
M12 x-coded connectors ensure secure Ethernet connections under vibration and shock conditions.
- Comprehensive I/O:
Includes 4x USB 3.0, 4x USB 2.0, 3x COM ports (RS-232/422/485), 1x CAN 2.0 port, 4x isolated DI and 4x isolated DO, audio I/O, and dual Gigabit Ethernet.
- Storage Flexibility:
Dual 2.5” SATA drive bays (1x hot-swappable tray, 1x internal) supporting RAID 0/1.
One full-size mSATA slot (muxed with mini-PCIe).
- Expansion Capability:
Four full-size mini-PCIe sockets with SIM card support for 3G/4G/Wi-Fi/GPS modules.
- Display Outputs:
Triple independent display support via VGA, DVI-D, and dual DisplayPort (up to 4K2K resolution).
- Environmental Robustness:
Certified for EN 50155 (railway), EN 61373 (shock/vibration), and E-Mark (automotive).
Operating temperature: -40°C to +70°C (with SSD).
- Ignition Power Control:
MCU-based ignition control with programmable on/off delay, low battery protection, and smart off-delay modes.
- Compact and Durable:
Dimensions: 240 mm (W) x 225 mm (D) x 79 mm (H); Weight: 3.3 kg.
Aluminum chassis with patented damping bracket for vibration isolation.
### 3. Technical Specifications
Processor Options:
- Intel® Core™ i7-6700TE (8MB Cache, 2.4/3.4 GHz, 35W TDP)
- Intel® Core™ i5-6500TE (6MB Cache, 2.3/3.3 GHz, 35W TDP)
- Intel® Core™ i3-6100TE (4MB Cache, 2.7 GHz, 35W TDP)
Chipset: Intel® Q170 Platform Controller Hub
Graphics: Integrated Intel® HD Graphics 530
Memory: Up to 32 GB DDR4-2133 SDRAM via two SO-DIMM slots
Storage:
- 1x hot-swappable 2.5” SATA HDD/SSD tray
- 1x internal 2.5” SATA HDD/SSD port (RAID 0/1 support)
- 1x full-size mSATA (muxed with mini-PCIe)
Expansion:
- 4x full-size mini-PCIe sockets (two with SIM slots, one muxed with mSATA, two USB-only)
- TPM 2.0 and Intel® AMT 11.0 support
I/O Interfaces:
- Ethernet: 2x Gigabit Ethernet (Intel® I219, I210)
- PoE+: 4x IEEE 802.3at (25.5W) M12 x-coded (Nuvo-5100VTC)
- USB: 4x USB 3.0, 4x USB 2.0
- Serial: 2x RS-232/422/485 (COM1, COM3), 1x RS-232 (COM2)
- CAN Bus: 1x CAN 2.0 port
- DIO: 4x isolated DI, 4x isolated DO (2500 Vrms isolation)
- Audio: 1x Mic-in, 1x Speaker-out
- Video: 1x VGA, 1x DVI-D, 2x DisplayPort (up to 4096x2304)
Power Supply:
- 8–35 VDC input via 3-pin terminal block
- Ignition control with programmable delay
- Power consumption (typical):
- i7-6700TE: 49.2W (2.05A@24V)
- i5-6500TE: 47.8W (1.99A@24V)
- i3-6100TE: 39.4W (1.64A@24V)
Mechanical:
- Dimensions: 240 x 225 x 79 mm
- Weight: 3.3 kg
- Mounting: Damping bracket (standard) or optional DIN-rail
Environmental:
- Operating Temperature: -40°C to +70°C (SSD required for sub-zero)
- Storage Temperature: -40°C to +85°C
- Humidity: 10–90%, non-condensing
- Vibration: 5 Grms, 5–500 Hz, 3 axes (IEC60068-2-64)
- Shock: 50 Grms, 11 ms half-sine (IEC60068-2-27)
### 4. Functionality
The Nuvo-5100VTC operates as a high-performance embedded controller for in-vehicle and railway systems. It manages data acquisition, video surveillance, and communication tasks through its PoE+ ports, CAN bus, and digital I/O interfaces.
Use Cases:
- Mobile video surveillance (IP camera integration via PoE+)
- Fleet management and telematics
- Railway control and monitoring systems
- Industrial automation and edge computing
- Intelligent transportation systems (ITS)
Compatibility:
Supports Windows 7/8/10 (x64), Windows Embedded Standard 7, and major Linux distributions (Ubuntu, Debian, CentOS, Fedora, OpenSUSE).
Operation:
The system can be powered on via ignition signal, front power button, external switch, or Wake-on-LAN. Ignition control ensures safe startup/shutdown synchronized with vehicle operation.
### 5. Components & Accessories
Included Items:
- Nuvo-5100VTC main unit
- Damping bracket with shock-absorbing grommets
- 3-pin power terminal block
- Key for hot-swappable HDD tray
- HDD thermal pad (if HDD not installed)
- Screw pack
- Neousys Drivers & Utilities DVD
Optional Accessories:
- C-M12-RJ45-LAN-5M: M12 (8-pole X-coded) to RJ45 CAT6 cable, 5m
- C-M12-RJ45-LAN-10M: M12 (8-pole X-coded) to RJ45 CAT6 cable, 10m
- DINRAIL-O: DIN-rail mounting kit
- PA-120W-OW: 120W AC/DC adapter (20V/6A, -30°C to +70°C operation)
### 6. Installation & Setup
Mounting Options:
- Standard anti-vibration damping bracket (horizontal installation recommended)
- Wall-mount configuration using M4 screws
- Optional DIN-rail mounting for cabinet integration
Power Connection:
- 3-pin terminal block for 8–35V DC input and ignition signal
- Ensure correct polarity and voltage before connection
Storage Installation:
- Internal 2.5” SATA drive secured with thermal pad and screws
- External hot-swappable 2.5” HDD/SSD tray with lock and RAID support
Expansion Installation:
- Four mini-PCIe sockets for wireless modules (3G/4G/Wi-Fi/GPS)
- SIM slots accessible internally or via rear panel
Ignition Control Configuration:
- Rotary switch with 16 modes (0–15) for power-on/off delay and hard-off timeout
- BIOS-configurable ignition parameters (mode 15) for custom timing and voltage thresholds
### 7. Performance & Capabilities
- Processing Power: Up to Intel® Core™ i7-6700TE, 4 cores, 8 threads, 3.4 GHz turbo
- Graphics: Intel® HD Graphics 530 supporting triple independent displays
- Network Throughput: Dedicated PCIe lanes per Ethernet port for full bandwidth
- PoE Power Delivery: 25.5W per port, IEEE 802.3at compliant
- Storage Performance: SATA 6 Gb/s interface, RAID 0/1 for redundancy or speed
- Reliability: Watchdog timer, hardware monitoring, and ignition-based power sequencing
- Limitations: CPUs above 35W TDP limited to 50°C max ambient; thermal throttling may occur under sustained load
### 8. Standards & Compliance
Certifications:
- EN 50155 (Railway applications – electronic equipment)
- EN 50121-3-2 / EN 50121-2-1 / EN 50121-2-2 (EMC for railway)
- EN 61373 (Shock and vibration)
- E-Mark (Nuvo-5108VTC, automotive compliance)
- CE/FCC Class A (EN 55022, EN 55024, EN 55032)
Safety & Environmental:
- RoHS compliant
- Designed for industrial and transportation-grade reliability
### 9. Additional Information
Warranty & Support:
Neousys provides a standard limited warranty covering manufacturing defects. Firmware, BIOS, and driver updates are available through the official Neousys website. Technical support is accessible via regional offices in Taiwan, USA, and China.
Maintenance:
- Only qualified personnel should service the system.
- Disconnect power before servicing or installing components.
- Use anti-static precautions when handling internal modules.
Software & Drivers:
- Automatic driver installation via included DVD
- Manual driver installation supported for Windows and Linux
- WDT_DIO driver package provides APIs for watchdog timer, DIO, PoE control, and ignition monitoring
Firmware & BIOS Features:
- Configurable COM port modes (RS-232/422/485)
- CAN bus termination control
- SATA AHCI/RAID configuration
- TPM 2.0 enablement
- Wake-on-LAN and power recovery options
- Ignition control parameters (delay, voltage thresholds, smart off-delay)
Operating System Support:
- Windows 7/8/10 (x86/x64)
- Windows Embedded Standard 7
- Linux distributions (Ubuntu, Debian, CentOS, Fedora, OpenSUSE)
Maintenance Tools:
- Watchdog Timer (WDT) for system recovery
- Digital I/O APIs for sensor/actuator control
- CAN bus APIs for vehicle communication
- Ignition and PoE control APIs for power management
### Summary
The Neousys Nuvo-5100VTC is a robust, fanless in-vehicle computing platform engineered for demanding transportation and industrial environments. With Intel® 6th-Gen Core™ processing, multiple PoE+ ports, wide-range DC input, and comprehensive I/O, it delivers exceptional performance for mobile surveillance, fleet management, and railway automation. Its rugged design, extended temperature tolerance, and compliance with EN 50155 and E-Mark standards make it a reliable choice for mission-critical vehicular applications.
The system’s modular expansion, ignition power control, and software integration capabilities ensure flexibility and long-term scalability for embedded and edge computing deployments.
-
Nuvo-5100VTC_Datasheet.pdf
PDF Catalog
- Nuvo-PA-160W - 160W AC/DC Power Adapter for Nuvo-1300af/3005 PoE models
- Nuvo-PA-120W - 120W AC/DC Power Adapter for Nuvo-3000 series
