- **64 Isolated Digital Output Channels:** Provides 64 optically isolated digital output channels for industrial control and automation. - **High Isolation Voltage:** 5000 V RMS channel‑to‑system isolation ensures protection against high‑voltage transients and ground loops. - **Rear I/O Configuration:** Designed for rear I/O access via CompactPCI backplane, enabling clean front‑panel integration and cable management. - **Common Ground Configuration:** All output channels share a common ground reference, simplifying wiring for standard industrial loads. - **High Output Drive Capability:** Each output channel can sink up to 500 mA at 24 V DC, suitable for driving relays, solenoids, and indicators. - **Wide Output Voltage Range:** Supports 5 V DC minimum to 35 V DC maximum output voltage. - **Optical Isolation:** Protects host systems from voltage spikes, surges, and noise interference. - **CompactPCI Compliance:** Fully compliant with PICMG 2.0 R2.1 CompactPCI specification, 3U Eurocard form factor. - **Rugged Industrial Connector:** 100‑pin SCSI‑II female connector for secure, high‑density signal interfacing. - **Software Support:** Compatible with Windows 7/8.1 x86/x64 and Linux; drivers and SDKs available for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Diagnostic LEDs:** Four user‑programmable LEDs for system status indication and debugging. - **Geographic Addressing:** Supports CompactPCI slot number identification via backplane geographic addressing. - **High Reliability:** Designed for continuous operation in industrial environments with extended temperature and humidity tolerance.

Hersteller: Adlink Technology Inc.

Kategorie: DIO Isolated PXI/PXIe/cPCI

- **64 isolated digital output channels** with common power configuration (source current type). - **Rear I/O interface** via a 100‑pin SCSI‑II female connector for compact system integration. - **High isolation voltage:** 5000 V RMS channel‑to‑system isolation for maximum protection. - **High output drive capability:** - Source current up to **500 mA per channel** (single channel ON). - **260 mA per channel** when all channels are ON at 24 V. - **Wide output voltage range:** 5 V DC minimum to 35 V DC maximum. - **Common power configuration:** all outputs share a single external power source (VDD). - **3U CompactPCI form factor**, compliant with **PICMG 2.0 R2.1**. - **Rear I/O signaling** through J2 connector; no front‑panel I/O connectors. - **Rugged design** with optical isolation to protect host systems from high voltages and ground loops. - **Plug‑and‑Play PCI configuration** using the PLX PCI‑9050 controller, fully compliant with PCI 2.1. - **Software support:** Windows 7/8.1 x86/x64 and Linux drivers; compatible with LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility software:** AD‑Logger for data monitoring and testing. - **High reliability:** designed for continuous operation in industrial environments (0 °C – 60 °C).

Hersteller: Adlink Technology Inc.

Kategorie: DIO Isolated PXI/PXIe/cPCI

- **64 Isolated Digital Output Channels:** Provides 64 independent, optically isolated digital output channels for high‑density control applications. - **Source Current Output Type:** Uses transistor source configuration (TD62783 devices) for sourcing current to external loads. - **High Isolation Voltage:** 5000 V RMS channel‑to‑system isolation ensures protection against high‑voltage transients and ground loops. - **High Output Drive Capability:** Each channel can source up to 500 mA at 24 V DC; all channels ON simultaneously can source 260 mA per channel. - **Wide Output Voltage Range:** Supports 5 V DC minimum to 35 V DC maximum output voltage. - **CompactPCI 3U Eurocard Form Factor:** Fully compliant with PICMG 2.0 R2.1 CompactPCI specification. - **Rugged 100‑Pin SCSI‑II Connector:** Provides a single, high‑density interface for all I/O channels. - **Optical Isolation:** Protects host systems from voltage surges and eliminates ground loop interference. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; drivers and SDKs available for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** Includes AD‑Logger for data monitoring and testing. - **High Reliability:** Designed for industrial environments with operating temperature range 0 °C – 60 °C and humidity up to 95 % non‑condensing. - **Comprehensive SDK:** Supports PCIS‑DASK, LabVIEW, HP‑VEE, DAQBench ActiveX, ISaGRAF, InControl, and OPC Server integration.

Hersteller: Adlink Technology Inc.

Kategorie: DIO Isolated PXI/PXIe/cPCI

- **CompactPCI 3U Eurocard Design:** Fully compliant with PICMG 2.0 R2.1, ensuring interoperability with standard CompactPCI backplanes. - **8‑Channel SPDT Relay Outputs:** All relays are Form C (Single‑Pole Double‑Throw) type, non‑latching, supporting both AC and DC loads. - **16‑Channel Isolated Digital Inputs:** Optically isolated, non‑polarity inputs with optional RC filtering for noise suppression. - **High Isolation Voltage:** 5000 VRMS channel‑to‑system isolation for digital inputs, 1000 VRMS relay contact breakdown voltage. - **Onboard LED Indicators:** Each relay output has a dedicated LED for visual status monitoring. - **Relay Output Readback:** Software‑accessible readback registers allow verification of relay states. - **Onboard Relay Driving Circuits:** Integrated driver circuitry ensures reliable relay actuation without external components. - **Wide Input Voltage Range:** Accepts 3–24 V AC/DC input signals, tolerant to industrial noise. - **Rugged I/O Connector:** 50‑pin SCSI‑II female connector for secure, high‑density signal interfacing. - **Software Support:** Compatible with Windows and Linux drivers, and integrates with LabVIEW™, MATLAB®, and ADLINK’s DAQPilot SDK. - **Applications:** Industrial ON/OFF control, external relay driving, limit switch monitoring, and integration with A/D and D/A systems for complete data acquisition and control solutions.

Hersteller: Adlink Technology Inc.

Kategorie: DIO Isolated PXI/PXIe/cPCI

- **Integrated Graphics Accelerator:** Built around the Chips & Technologies 69000 video accelerator, offering hardware-accelerated 2D graphics performance suitable for industrial visualization and control applications. - **Onboard Video Memory:** Includes 2 MB of integrated SDRAM video memory, enabling high-resolution and high-color-depth display modes without external memory modules. - **Dual Display Support:** Capable of driving both traditional analog CRT monitors and various flat-panel display technologies (LCD, EL, gas plasma). - **High-Resolution Output:** - CRT displays: up to 1024 × 768 resolution in 64K colors. - Flat-panel displays: up to 800 × 600 resolution in 16.7 million colors. - **CompactPCI 3U Form Factor:** Fully compliant with the PICMG CompactPCI 3U mechanical and electrical specifications, ensuring compatibility with standard CompactPCI backplanes and chassis. - **Flexible Panel Configuration:** Supports up to 14 different LCD panel types selectable via onboard jumpers (JP2), allowing adaptation to various display modules. - **Adjustable Power and Clock Settings:** - Flat panel power selectable between +5V and +3.3V (JP3). - Flat panel clock polarity selectable (JP1). - **Standard VGA Output:** Equipped with a 15-pin D-Sub VGA connector for analog display connection. - **Wide Operating Temperature Range:** Designed for industrial environments with an operating range of 0°C to 60°C (32°F to 140°F). - **Software Driver Support:** Compatible with Microsoft Windows 95, 98, and NT 4.0 operating systems, with dedicated driver installation procedures and refresh rate utilities.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **High-Performance Graphics Controller:** Powered by the **C&T69000** graphics chipset, the cPCI-8216 delivers stable and efficient 2D graphics acceleration suitable for industrial HMI, control panels, and visualization systems. - **Dual Display Interface:** Supports both **VGA output** for standard analog monitors and **LVDS output** for direct connection to flat-panel LCDs, offering flexibility in display configurations. - **CompactPCI Form Factor:** Fully compliant with the **CompactPCI (cPCI)** standard, ensuring compatibility with a wide range of industrial backplanes and system chassis. - **LVDS Interface Support:** Integrated **LVDS interface** allows direct connection to TFT LCD panels without the need for additional converter boards, reducing system complexity and improving signal integrity. - **Industrial-Grade Reliability:** Designed for continuous operation in demanding environments, with extended temperature tolerance, vibration resistance, and long product lifecycle support. - **Plug-and-Play Integration:** Seamless integration into existing CompactPCI systems with minimal configuration required. - **Low Power Consumption:** Optimized for embedded systems where power efficiency and thermal management are critical. - **Driver and OS Support:** Compatible with major operating systems used in industrial computing, including Windows Embedded, Linux, and real-time operating systems (RTOS).

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **High-Performance Graphics Controller:** Utilizes the **SMI Lynx3DM SM721** chipset, a proven embedded graphics processor known for its stability and low power consumption. - **Dedicated 4 MB VRAM:** Provides sufficient video memory for smooth rendering of 2D and 3D graphics in industrial and embedded applications. - **Multiple Display Resolutions:** - Up to **1024 × 768 pixels at 24-bit color depth** - Up to **1280 × 1024 pixels at 16-bit color depth** - Up to **1600 × 1200 pixels at 16-bit color depth** - **Dual Display Output:** Supports both **LCD and VGA** interfaces, allowing flexible display configurations for panel-mounted or external monitors. - **CompactPCI Form Factor:** Fully compliant with the **CompactPCI (cPCI) standard**, ensuring compatibility with a wide range of industrial backplanes and systems. - **Compact Design:** Measures **160 mm × 100 mm**, optimized for embedded and rack-mounted systems with limited space. - **Industrial-Grade Reliability:** Designed for continuous operation in demanding environments, offering stable performance and long product lifecycle support. - **Plug-and-Play Integration:** Seamless integration into existing CompactPCI systems with minimal configuration required.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **High-Performance Graphics Controller:** Equipped with the **SMI Lynx3DM SM721** chipset, offering efficient 2D and 3D graphics acceleration suitable for embedded visualization and control interfaces. - **Dedicated Video Memory:** Integrated **4 MB VRAM** ensures stable and high-speed frame buffering for smooth image rendering and display performance. - **Multiple Display Resolutions:** Supports a range of resolutions including **1024×768 at 24-bit color depth**, **1280×1024**, and **1600×1200 at 16-bit color depth**, providing flexibility for various display requirements. - **Rear I/O Connectivity:** Designed for **rear I/O output**, enabling clean front-panel layouts and improved cable management in CompactPCI chassis. - **CompactPCI Form Factor:** Fully compliant with the **CompactPCI (cPCI) standard**, ensuring compatibility with standard backplanes and system architectures. - **Industrial-Grade Design:** Engineered for reliability and long-term operation in demanding environments, with robust construction and stable thermal performance. - **Compact Dimensions:** Measuring **160 mm × 100 mm**, the card fits standard 3U CompactPCI slots, optimizing space utilization in embedded systems. - **High Color Fidelity:** Supports up to **24-bit true color** for vivid and accurate image reproduction. - **Low Power Consumption:** Optimized for embedded systems where power efficiency and thermal management are critical. - **ADLINK Quality Assurance:** Backed by ADLINK’s reputation for industrial-grade reliability, lifecycle support, and compliance with embedded computing standards.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **64-bit PCI Bus Interface:** Supports full 64-bit PCI signaling for high-bandwidth data transfer between the CompactPCI backplane and the PMC module. - **PMC Expansion Capability:** Provides one standard PMC site compliant with IEEE 1386.1, allowing integration of a wide range of PMC I/O and processing modules. - **Compact 3U Form Factor:** Designed for 3U CompactPCI systems, measuring 160 mm x 100 mm, ensuring compatibility with standard CompactPCI chassis and backplanes. - **High-Speed Data Throughput:** Optimized for 64-bit, 33/66 MHz PCI operation, enabling efficient communication between the host CPU and PMC devices. - **Industrial-Grade Design:** Built for rugged environments with high mechanical stability and reliable signal integrity. - **Flexible System Integration:** Enables system designers to add custom or third-party PMC modules for specialized functions such as data acquisition, communication, or signal processing. - **ADLINK Quality and Support:** Backed by ADLINK’s extensive experience in embedded computing and industrial-grade hardware design.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **CompactPCI 3U Form Factor:** Fully compliant with PICMG 2.11 CompactPCI power interface standard, ensuring interoperability with standard 3U/6U CompactPCI chassis and backplanes. - **Redundant Power Architecture:** Supports dual‑redundant configuration for high‑availability systems; hot‑swappable design allows replacement without system shutdown. - **Input Voltage:** 24 V DC nominal input, designed for industrial DC power environments. - **Output Power:** 150 W total continuous output capacity, optimized for embedded and industrial computing platforms. - **Connector Interface:** Standard 47‑pin Positronic PCIH47M400A1 connector for DC input/output and control signals, ensuring compatibility with ADLINK cBP‑3062 redundant backplane. - **High Reliability:** Industrial‑grade design with over‑voltage, over‑current, and thermal protection; MTBF exceeding 100,000 hours (MIL‑HDBK‑217E). - **Hot‑Swappable Operation:** Enables live insertion and removal in redundant configurations, minimizing downtime. - **Compact and Lightweight:** 3U mechanical envelope (40 mm W × 128.5 mm H × 172.8 mm D) with weight approximately 0.85 kg. - **Comprehensive Protection:** Includes input surge suppression, output short‑circuit protection, and automatic recovery after fault removal. - **Status Indicators:** Front‑panel LEDs for “POWER OK” (green) and “FAULT” (red) provide immediate visual diagnostics. - **Compliance:** Meets international safety and EMC standards (UL 1950, EN 60950, CE Mark, EN 55022 Class A, EN 50082‑2).

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **CompactPCI 3U Form Factor:** Fully compliant with PICMG 2.11 power interface standards for 3U/6U CompactPCI systems. - **Redundant Hot‑Swappable Design:** Enables parallel operation of multiple units for load sharing and fault tolerance. - **DC Input Operation:** Accepts 18 – 36 V DC input voltage, ideal for telecom, transportation, and mobile industrial systems. - **High Output Power:** Delivers up to 175 W total output with multiple regulated voltage rails (+5 V, +3.3 V, +12 V, −12 V). - **Current Sharing:** Supports active current sharing on +5 V and +3.3 V outputs within ±10 % for redundant configurations. - **Comprehensive Protection:** Over‑voltage, over‑current, under‑voltage, surge, and thermal shutdown protection with automatic recovery. - **Status Indicators:** Front‑panel LEDs for “Power OK” (green) and “Fault” (red) status indication. - **High Efficiency:** Typical conversion efficiency of 73 %. - **Safety and EMC Compliance:** Meets UL, TUV/VDE EN60950, CE, and FCC Class A standards. - **Rugged Industrial Reliability:** MTBF of 100,000 hours (MIL‑HDBK‑217E) and designed for continuous 24/7 operation. - **Operating Temperature Range:** 0 °C – 70 °C (full power up to 40 °C with 15 CFM forced air). - **Compact and Lightweight:** 3U module, approximately 0.85 kg, suitable for high‑density rack systems.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **PICMG® 2.11 Compliance:** Fully compliant with the CompactPCI® Power Interface standard, ensuring interoperability with standard CompactPCI® backplanes and chassis. - **3U CompactPCI® 8HP Form Factor:** Compact 100 x 160 mm board size, occupying two slots (8HP width) in a 3U chassis. - **47-pin Power Connector:** Standardized interface for DC input and DC output connections, supporting hot-swap operation. - **250 W DC Output Power:** Provides stable and efficient power delivery for CompactPCI® systems. - **Active Power Factor Correction (PFC):** Meets IEC1000-3-2 harmonic correction requirements, achieving a typical power factor of 0.95–0.97. - **Hot-Swappable Design:** Enables replacement or maintenance without system shutdown, minimizing downtime. - **N+1 Redundancy Support:** Internal OR-ing diodes allow multiple units to operate in parallel for fault-tolerant power configurations. - **Active Current Sharing:** Ensures balanced load distribution among redundant modules. - **Comprehensive Protection:** Includes over-temperature, over-current, over-load, and over-voltage protection on all output rails. - **Status Indicators:** Dual LED indicators (green for power, amber for fault) provide immediate visual status feedback. - **Remote Control and Monitoring:** Supports remote ON/OFF control, power failure (FAL#), and degradation (DEG#) signals for system-level management. - **EMI Compliance:** Meets EN 55022 and FCC Class A emission standards. - **Wide Operating Temperature Range:** -40 °C to +70 °C at full load with airflow, suitable for harsh industrial environments. - **High Efficiency:** Typical efficiency of 78–79%, optimizing thermal performance and energy utilization.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **Wide Input Range:** Operates from 16.6VDC to 160VDC, supporting nominal voltages of 24V, 48V, 72V, and 110VDC, ideal for railway and industrial environments. - **High Output Power:** Provides up to 120W under fanless convection cooling and up to 300W with forced-air cooling (400 LFM or higher). - **CompactPCI® Compliance:** Fully compliant with PICMG® 2.11 CompactPCI® Power Interface specifications, ensuring interoperability with standard CompactPCI® backplanes and systems. - **Redundant Operation:** Supports N+1 redundancy with internal OR-ing diodes on all outputs, enabling hot-swap replacement and uninterrupted system operation. - **Hot-Swap Capability:** Designed for live insertion and removal without system shutdown, minimizing downtime in critical applications. - **Railway-Grade Reliability:** Certified to EN 50155 Class S2 and C2 for power stability and environmental resilience in railway systems. - **Wide Operating Temperature:** Operates from -40°C to +85°C with appropriate cooling, ensuring reliable performance in harsh environments. - **Comprehensive Protection:** Includes over-temperature, over-current, over-load, and over-voltage protection on all output rails. - **Status Indicators:** Equipped with front-panel LEDs for power (green) and fault (red) indication. - **Remote Control & Monitoring:** Provides remote ON/OFF control, power failure (FAL#), and power degradation (DEG#) signals for system integration and monitoring. - **High Efficiency:** Typical efficiency of 85% at 24VDC input (120W) and up to 89% at 110VDC input (300W). - **Conformal Coating Option:** Available with conformal coating for enhanced protection against humidity, dust, and corrosive environments.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **PICMG® 2.11 Compliance:** Fully compliant with the CompactPCI® Power Interface standard, ensuring interoperability with standard CompactPCI® backplanes and systems. - **3U CompactPCI® 8HP Form Factor:** Compact 100 x 160 mm, 2-slot (8HP) wide design suitable for 3U CompactPCI® chassis. - **Wide DC Input Range:** Operates from 36 to 72 VDC, optimized for 48 VDC nominal systems. - **High Output Power:** Provides up to 250 W continuous output power across multiple voltage rails. - **Hot-Swap Redundancy:** Supports hot-swappable operation and N+1 redundancy through internal OR-ing diodes, enabling continuous uptime during maintenance or module replacement. - **Active Current Sharing:** Ensures balanced load distribution among multiple power modules in redundant configurations. - **Comprehensive Protection:** Includes over-temperature, over-current, over-load, and over-voltage protection on all outputs. - **Status Indicators:** Front-panel LEDs indicate power and fault conditions for quick diagnostics. - **Remote Control & Monitoring:** Supports remote ON/OFF control, power failure signal (FAL#), and power degradation signal (DEG#) for system-level management. - **High Efficiency:** Typical efficiency of 78–79%, minimizing heat generation and improving energy utilization. - **EMI & Safety Compliance:** Meets EN 55022 and FCC Class A EMI standards, and certified to IEC950 and IEC60950 Class I safety standards. - **Rugged Environmental Design:** Operates from -40°C to +70°C with appropriate airflow, suitable for industrial and telecom environments.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **CompactPCI 3U Form Factor:** Designed to fit standard 3U CompactPCI card cages and backplanes compliant with PICMG 2.11. - **Wide DC Input Range:** Accepts 36 – 72 V DC, supporting telecom and industrial DC power systems. - **Output Power:** Delivers up to 150 W total continuous output power. - **Redundant Operation:** Supports hot‑swap and current‑sharing for redundant configurations. - **Standard 47‑Pin Connector:** Ensures mechanical and electrical compatibility with CompactPCI backplanes such as ADLINK cBP‑3062. - **High Efficiency:** Typical conversion efficiency around 73 %. - **Protection Circuits:** Over‑voltage, over‑current, under‑voltage, and thermal shutdown protection with automatic recovery. - **Status Indicators:** Front‑panel LEDs for Power (green) and Fault (red) indication. - **Safety and EMC Compliance:** Meets UL 1950, CSA C22.2 No. 950, EN 60950, and CE EMC standards. - **Hot‑Swappable Design:** Enables replacement without system shutdown, ensuring high availability. - **Compact and Lightweight:** Approximately 0.85 kg, optimized for dense rack‑mount systems.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **CompactPCI 3U Redundant Design:** Fully compliant with PICMG 2.11 power interface standards, enabling seamless integration into CompactPCI backplanes. - **Hot‑Swappable Operation:** Supports live insertion and removal without system shutdown, ensuring continuous uptime in redundant configurations. - **Wide DC Input Range:** Accepts 36 – 72 V DC input (nominal 48 V DC), suitable for telecom and industrial DC power environments. - **High Output Power:** Delivers up to 175 W total output across multiple voltage rails (+5 V, +3.3 V, +12 V, −12 V). - **Parallel Operation and Load Sharing:** Supports current sharing on +5 V and +3.3 V outputs within ±10 % for redundant or load‑balanced systems. - **Comprehensive Protection:** Over‑voltage, over‑current, under‑voltage, short‑circuit, and over‑temperature protection with automatic recovery. - **Status Indicators:** Front‑panel LEDs for **POWER (green)** and **FAULT (red)** provide immediate visual status of input and fault conditions. - **High Efficiency and Reliability:** Typical efficiency of 73 %; MTBF of 100,000 hours (MIL‑HDBK‑217E). - **Safety and EMC Compliance:** Meets UL, TUV/VDE EN60950, CE, and FCC Class A standards. - **Compact Form Factor:** 3U height, 40 mm width, 172.8 mm depth; lightweight (≈ 0.85 kg). - **Plug‑and‑Play Compatibility:** Designed for use with ADLINK cBP‑3062 redundant backplane or other PICMG 2.11‑compliant 47‑pin backplanes.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **PICMG® 2.11 Compliance:** Fully compliant with the CompactPCI® Power Interface standard, ensuring interoperability with standard CompactPCI® backplanes and chassis. - **3U 8HP Form Factor:** Compact 3U height (100 × 160 mm) and 8HP width (two slots), suitable for high‑density rackmount systems. - **Universal AC Input:** Accepts 90–264 VAC input voltage range at 47–63 Hz, supporting global operation without manual voltage selection. - **Active Power Factor Correction (PFC):** Achieves a typical power factor of 0.95–0.97, meeting IEC1000‑3‑2 harmonic correction standards for improved efficiency and reduced input current distortion. - **Hot‑Swappable Design:** Enables replacement or maintenance without system shutdown, supporting continuous system uptime. - **N+1 Redundancy:** Internal OR‑ing diodes allow multiple units to operate in parallel for fault‑tolerant power configurations. - **Active Current Sharing:** Balances load current among parallel modules to enhance reliability and extend service life. - **Comprehensive Protection:** Includes over‑temperature, over‑current, over‑load, and over‑voltage protection on all output rails. - **Status Indicators:** Dual LED indicators—green for power status and amber for fault indication—provide immediate visual feedback. - **Remote Control & Monitoring:** Supports remote ON/OFF control, power failure (FAL#), and degradation (DEG#) signals for system management integration. - **High Efficiency:** Typical conversion efficiency of 78–79%, minimizing heat generation and power loss. - **Low Ripple & Noise:** 50 mV ripple on 5 V and 3.3 V outputs; 120 mV on ±12 V outputs, ensuring clean power for sensitive electronics. - **Environmental Robustness:** Operates from ‑40 °C to +70 °C with appropriate airflow, suitable for harsh industrial environments. - **EMI/EMC Compliance:** Meets EN 55022 and FCC Class A emission standards.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **Universal AC Input Range:** 85 – 265 VAC, 45 – 440 Hz, supporting global operation without manual voltage selection. - **Output Power:** 150 W continuous total output, optimized for CompactPCI 3U systems. - **Redundant Operation:** Supports dual‑redundant configurations for uninterrupted system power. - **Standard 47‑Pin Interface:** Compliant with PICMG 2.11 power connector standard (Positronic PCIH47 series). - **Hot‑Swappable Design:** Enables live insertion and removal without system shutdown. - **Compact 3U Form Factor:** Fits standard 3U CompactPCI chassis and backplanes. - **High Efficiency:** Typical conversion efficiency of approximately 73 %. - **Comprehensive Protection:** Over‑current, over‑voltage, under‑voltage, surge, and thermal protection with automatic recovery. - **Status Indicators:** Front‑panel LEDs for Power (ON/OK) and Fault (FAIL) conditions. - **Parallel Current Sharing:** Supports load sharing across multiple units on +5 V and +3.3 V rails. - **Safety and EMC Compliance:** Meets UL 1950, CSA C22.2 No. 950, EN 60950, and CE EMI/EMS standards. - **Industrial‑Grade Reliability:** MTBF > 100,000 hours (MIL‑HDBK‑217E), designed for 24/7 operation. - **Operating Temperature Range:** 0 °C – 70 °C (full power to 40 °C with forced air).

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **Universal AC Input:** Accepts 85 – 265 VAC, 45 – 440 Hz, enabling global operation without manual voltage selection. - **CompactPCI 3U Form Factor:** Fully compliant with PICMG 2.11 power interface specifications using a 47‑pin Positronic connector. - **Redundant Hot‑Swappable Design:** Supports parallel operation and current sharing for +5 V and +3.3 V rails, ensuring uninterrupted system power. - **High Reliability:** MTBF of 100,000 hours (MIL‑HDBK‑217E, part‑count method). - **Comprehensive Protection:** Over‑voltage, over‑current, under‑voltage, surge, and thermal protection with automatic recovery. - **Status Indicators:** Front‑panel LEDs for “Power OK” (green) and “Fault” (red) conditions. - **High Efficiency:** Typical conversion efficiency of 73 %. - **Safety and EMC Compliance:** Certified to UL, TUV/VDE EN60950, CE EMI EN55022 Class A, and EMS EN50082‑2 standards. - **Environmental Robustness:** Operates from 0 °C to 70 °C with forced‑air cooling; storage –10 °C to +85 °C; up to 6,400 m altitude. - **Compact and Lightweight:** 40 mm (W) × 128.5 mm (H) × 172.8 mm (D); weight ≈ 0.85 kg. - **Plug‑and‑Play Integration:** Designed for ADLINK cPCIS‑1000/2000 series chassis and compatible backplanes (e.g., cBP‑3062).

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **Redundant Hot‑Swappable Design:** Enables uninterrupted system operation during PSU replacement or failure. - **Universal AC Input:** Accepts 90 – 264 VAC, 45 – 440 Hz single‑phase input, supporting global deployment. - **High Power Density:** 175 W maximum output in a compact 3U form factor. - **Multiple DC Outputs:** Provides +5 V, +3.3 V, +12 V, and −12 V regulated outputs. - **Parallel Current Sharing:** Supports load sharing within ±10 % on +5 V output when multiple units operate in parallel. - **Comprehensive Protection:** Over‑current, over‑voltage, under‑voltage, short‑circuit, surge, and over‑temperature protection with automatic recovery. - **Status Indicators:** Front‑panel LEDs for “Power OK” (green) and “Fail” (red) status. - **High Efficiency and Power Factor:** Typical efficiency 73 %, power factor 0.99. - **Wide Frequency Range:** Operates from 45 Hz to 440 Hz, suitable for both commercial and military power systems. - **Industrial Reliability:** MTBF ≥ 50,000 hours (MIL‑HDBK‑217E), MTTR ≈ 5 minutes. - **Standards Compliance:** Meets UL 1950, CSA C22.2 No. 950, EN 60950/TÜV, CE, FCC Class A, and VDE Class A requirements. - **Environmental Robustness:** Operates 0 – 70 °C (full power to 40 °C with 15 CFM airflow), storage −40 – 85 °C, 95 % RH non‑condensing. - **CompactPCI Integration:** Fully compliant with PICMG 2.11 power interface standard using 31‑pin DIN 41612 connector.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Power Supplies

- **Comprehensive SCSI Compatibility:** Supports SCSI I, SCSI II, Ultra SCSI, and Ultra Wide SCSI protocols, ensuring interoperability with a wide range of SCSI devices and legacy equipment. - **Dual Connector Configuration:** Equipped with an **external 68-pin shielded connector** for Ultra Wide SCSI devices and an **internal 50-pin connector** for standard SCSI peripherals, enabling flexible system integration. - **CompactPCI Form Factor:** Designed for **CompactPCI (cPCI)** systems, providing a rugged, modular, and high-performance interface suitable for industrial and embedded applications. - **Dual Voltage Operation:** Operates with both **3.3V and 5V signaling**, ensuring compatibility with various CompactPCI backplanes and system configurations. - **High Data Throughput:** Supports Ultra Wide SCSI transfer rates up to 40 MB/s, enabling fast and reliable data exchange between host systems and connected devices. - **Industrial-Grade Design:** Built for continuous operation in demanding environments, featuring robust connectors, EMI shielding, and high-quality PCB materials. - **Plug-and-Play Integration:** Fully compliant with CompactPCI specifications, allowing straightforward installation and configuration within standard cPCI chassis. - **Backward Compatibility:** Maintains support for older SCSI standards, ensuring seamless integration with existing infrastructure and legacy peripherals. - **Shielded External Interface:** The 68-pin external connector is shielded to minimize electromagnetic interference (EMI) and maintain signal integrity in electrically noisy environments. - **Flexible Application Range:** Suitable for data acquisition systems, industrial automation, test and measurement setups, and embedded computing platforms requiring SCSI connectivity.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **Comprehensive SCSI Support:** Compatible with SCSI I, SCSI II, Ultra SCSI, and Ultra Wide SCSI protocols, enabling integration with a wide variety of storage and peripheral devices. - **Rear I/O Design:** Incorporates a **transition board** for rear I/O applications, allowing all external connections to be routed through the rear of the chassis for improved cable management and front-panel accessibility. - **Dual Connector Configuration:** Features both an **external 68-pin shielded connector** and an **internal 50-pin connector**, providing flexible connectivity options for different SCSI device configurations. - **Voltage Flexibility:** Supports **3.3V and 5V operation**, ensuring compatibility with diverse CompactPCI backplanes and system power environments. - **High Data Throughput:** Designed to support the full bandwidth of Ultra Wide SCSI, enabling data transfer rates up to 40 MB/s per channel under optimal conditions. - **Industrial-Grade Reliability:** Built for continuous operation in demanding industrial and embedded computing environments, with robust signal integrity and EMI shielding. - **CompactPCI Compliance:** Fully compliant with the **PICMG 2.x CompactPCI** specifications, ensuring interoperability with standard CompactPCI chassis and peripheral modules. - **Transition Board Integration:** The included transition board simplifies rear I/O deployment, reducing installation complexity and improving system maintainability.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI Interface Cards

- **CompactPCI 3U Compatibility:** Designed for 3U CompactPCI boards compliant with PICMG 2.0 R2.1. - **4U Wall‑Mount Enclosure:** Provides additional vertical clearance for cooling and cable management. - **Integrated Cooling System:** Equipped with multiple DC brushless fans for forced‑air cooling; removable fans and air filters simplify maintenance. - **Backplane Integration:** Includes a 32‑bit, 6‑slot CompactPCI backplane (cBP‑3206) supporting one system slot and up to five peripheral slots. - **Flexible Power Options:** Compatible with ADLINK’s redundant and non‑redundant power supply units (cPS‑150R, cPS‑175/AC, cPS‑175/48, cPS‑175/24) or standard ATX PSUs via cPCI‑PSF frame. - **High Mechanical Integrity:** Constructed from industrial‑grade materials with EMC shielding gaskets on front, rear, and side panels. - **Modular Design:** Supports optional drive bay frames (cPCI‑DBF) and LCD kits (cPCI‑LCD) for system expansion. - **Versatile Mounting:** Suitable for wall‑mount, rack‑mount, or desktop configurations. - **Serviceability:** Hot‑swappable power supply support and easily removable cooling modules. - **Compliance:** Meets CompactPCI, PICMG 2.0, and PICMG 2.11 standards for mechanical and electrical interfaces.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI 3U 19'' Chassis

- **CompactPCI 3U/4U Architecture:** Supports 3U CompactPCI boards in a 4U‑high wall‑mount chassis, compliant with PICMG 2.0 R2.1. - **Integrated Display:** Built‑in 6.3‑inch high‑brightness TFT LCD for system status, diagnostics, or user interface applications. - **Backplane Configuration:** Equipped with a 32‑bit, 6‑slot CompactPCI backplane (cBP‑3206) supporting one system slot and up to five I/O slots. - **Cooling System:** Integrated DC brushless fans with removable air filters for efficient thermal management and easy maintenance. - **Flexible Power Options:** Compatible with ADLINK’s cPS‑150R, cPS‑175 series, or standard ATX PSUs via cPCI‑PSF frame; shipped without PSU for user customization. - **Mechanical Robustness:** Industrial‑grade aluminum chassis with EMC shielding gaskets on front, rear, and side panels. - **Mounting Flexibility:** Designed for wall‑mount, rack‑mount, or desktop installation; optional handles and foot stands for portability. - **Modular Design:** Supports modular sub‑systems, including LCD kits, redundant power supplies, and rear I/O configurations. - **High Reliability:** Designed for continuous industrial operation with wide temperature tolerance and long‑life components. - **Serviceability:** Hot‑swappable power supply support (when equipped with redundant PSU backplane) and removable cooling modules.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI 3U 19'' Chassis

- **CompactPCI 3U/4U Architecture:** Designed for 3U CompactPCI boards within a 4U‑high wall‑mount chassis, compliant with PICMG 2.0 R2.1. - **Integrated Display:** Built‑in 6.3‑inch high‑brightness TFT LCD for local monitoring or user interface. - **Backplane:** Equipped with a 32‑bit, 6‑slot CompactPCI backplane (model cBP‑3206) supporting one system slot and up to five peripheral slots. - **Power System:** Includes cPWR‑1500A AC power supply, providing stable regulated outputs for CompactPCI modules. - **Cooling System:** Dual or quad 12 V DC brushless fans with bottom‑mounted air intake and removable filters for efficient cooling and easy maintenance. - **Mechanical Design:** Rugged aluminum/steel construction with EMC shielding gaskets on front, rear, and side panels. - **Mounting Flexibility:** Wall‑mount configuration with optional rack‑mount kit; suitable for industrial cabinets or control panels. - **Serviceability:** Modular sub‑assemblies (LCD, PSU, backplane, fans) for quick replacement and upgrade. - **Compatibility:** Supports standard CompactPCI CPU and I/O boards, compliant with PICMG 2.0 and 2.11 power interface standards. - **Environmental Robustness:** Operating temperature range −10 °C to +70 °C; designed for continuous industrial operation.

Hersteller: Adlink Technology Inc.

Kategorie: cPCI 3U 19'' Chassis
