Intel 14/13/12G rugged PC 2x2.5GbE,USB-C,MezIO; UL

Nuvo-9002E

Intel 14/13/12G rugged PC 2x2.5GbE,USB-C,MezIO; UL
Request a quote
  • Manufacturer Neousys Technology
  • Category: Nuvo-9000-Series
  • The Nuvo-9002E is a rugged fanless embedded computer from Neousys for demanding industrial applications. It supports Intel BTL-S and 14th/13th/12th-Gen Core processors and offers up to 128 GB of DDR5 memory, M.2 Gen4x4 NVMe storage, two SATA ports, and flexible expansion through MezIO, mini-PCIe, and a PCIe Cassette slot. The system includes 2x Ethernet, USB 3.2 Type-C at 20 Gbps, multiple USB-A ports, VGA, DVI-D, DisplayPort, and serial connectivity. Its robust design supports 8 to 48 VDC input and operation from -25 to 70°C.
Ultra-low-profile embedded computer supporting Intel 14th/13th/12th Gen Core™ i9/i7/i5/i3 processors (LGA1700, 35/65?W TDP), Intel® Q670E chipset, up to 64?GB DDR5-4800 via 2× SODIMM. Integrated Intel UHD Graphics 770/730, 2× 2.5GbE + 1× GbE, USB 3.2 Gen2x2 Type-C, 6× USB 3.2, 2× USB 2.0, 1× VGA, 1× DVI-D, 1× DP, 2× RS-232/422/485, 2× RS-232, Audio, 2× 2.5" SATA (RAID 0/1), 1× M.2 Gen4 NVMe, 1× mini-PCIe, 1× M.2 B-Key with SIM, 1× MezIO® slot, ignition control optional, rugged ?25?°C…+70?°C fanless, 240×225×90??mm, 3.35?kg.

Country of origin: Taiwan R.O.C.

Customs tariff number: 8471 5000 000

  • Supported CPU Generations Intel BTL-S/14th/13th/12th-Gen Core
  • Chipset Intel Q670E
  • Maximum Memory 128 GB
  • Memory Type DDR5-4800 SDRAM
  • Memory Slots 2 SODIMM slots
  • PCIe Cassette 1x PCIe x16 slot at Gen3, 8-lane signals
  • Mini PCI Express 1x full-size mini PCI Express socket
  • M.2 B-Key Socket 1x M.2 2242/3052 B key socket with SIM slot
  • MezIO Port 1x MezIO expansion port
  • Ethernet Ports 1x 2.5GbE and 1x GbE
  • Optional PoE+ IEEE 802.3at PoE+ PSE for port 3 to port 6 not applicable to 2-port model
  • USB Type-C 1x USB 3.2 Gen2x2
  • USB 3.2 Type-A 4x USB 3.2 Gen2x1 and 2x USB 3.2 Gen1x1
  • USB 2.0 Ports 2 ports
  • Video Outputs VGA; DVI-D; DisplayPort
  • Maximum DisplayPort Resolution 4096 x 2304
  • Serial Ports 2x RS-232/422/485 and 2x RS-232
  • Audio Port 1x 3.5 mm mic-in/speaker-out jack
  • SATA Ports 2x internal SATA for 2.5 inch HDD/SSD, RAID 0/1
  • M.2 NVMe 1x M.2 2280 M key NVMe PCIe Gen4x4
  • DC Input Range 8 to 48 VDC
  • Dimensions 240 x 225 x 90 mm
  • Weight 3.58 kg
  • Mounting Wall-mount standard; DIN-rail optional
  • Operating Temperature -25 to 70 °C
  • Storage Temperature -40 to 85 °C
  • Humidity 10% to 90% non-condensing
  • Vibration MIL-STD-810H Method 514.8 Category 4
  • Shock MIL-STD-810H Method 516.8 Procedure I
  • EMC CE/FCC Class A; EN 55032; EN 55035
  • TPM dTPM 2.0
  • AMT Intel vPro/AMT 16.0
