- **High-Performance DSP Core:** Equipped with a 250 MHz TI TMS320C6711D DSP delivering 1500 MFLOPS for real-time motion computation. - **6-Axis Analog Motion Control:** Supports up to six servo axes with ±10 V analog command outputs for differential or single-ended control. - **Closed-Loop PID + Feedforward Control:** Integrated PID with feedforward gain ensures minimal following error and fast dynamic response. - **High-Speed Encoder Feedback:** Supports incremental encoders up to 20 MHz (4x AB phase), with digital filtering to reduce noise. - **Advanced Interpolation:** - 2–4 axis linear interpolation - Any 2 of 4 axes circular interpolation - Multi-axis continuous interpolation with seamless trajectory blending - **High-Speed Trigger and Comparison:** - Up to 1 MHz trigger pulse output - Programmable pulse width (0.2 µs to 6.55 ms) - FIFO and linear comparison functions for continuous triggering - **Flexible Motion Profiles:** Supports trapezoidal and S-curve velocity profiles with programmable acceleration/deceleration. - **On-the-Fly Parameter Adjustment:** Real-time modification of speed, position, and PID parameters during motion. - **Dedicated Motion I/O per Axis:** Includes PEL/MEL limit switches, ORG home input, ALM alarm, SVON servo-on, and ZSP zero-speed signals. - **General-Purpose I/O:** 8 isolated digital inputs and 8 isolated digital outputs (PCI-8256 model). - **Data Sampling and Diagnostics:** Built-in 4-channel data sampling system for motion analysis and PID tuning. - **Software Support:** Bundled with MotionCreatorPro 2™ for configuration, tuning, and diagnostics. Includes Windows DLL libraries for C++, Visual Basic, and other languages. - **Multi-Board Support:** Up to 16 PCI-8256 cards can be installed in a single system.

Manufacturer: Adlink Technology Inc.

Category: Motion Control / EtherCAT PCI

- **Dual Independent CAN Channels:** Two fully independent CAN ports allow simultaneous communication on separate CAN networks or bridging between them. - **Optical Isolation:** Each CAN port provides up to **2500 Vrms** isolation (1000 Vrms for PM‑7841), protecting the host system from voltage surges and ground loops. - **CAN Specification Compliance:** Fully compliant with **CAN 2.0A (11‑bit ID)** and **CAN 2.0B (29‑bit ID)** standards. - **High‑Speed Communication:** Supports programmable data rates up to **1 Mbps**, with standard DeviceNet rates of **125 kbps**, **250 kbps**, and **500 kbps**. - **Bridge Functionality:** Enables interconnection between two CAN networks for data exchange or protocol translation. - **Integrated CAN Controller:** Utilizes the **Philips SJA1000** CAN controller for reliable bus arbitration, error detection, and automatic retransmission. - **Transceiver Technology:** Employs **82C250/82C251** transceivers for robust physical‑layer performance. - **Plug‑and‑Play PCI Configuration:** Automatic resource allocation via BIOS—no manual jumper settings required for PCI and cPCI versions. - **Software Support:** Includes DOS libraries, Windows 95/98/NT drivers, and comprehensive C/C++ and Visual Basic APIs for CAN and DeviceNet communication. - **Application Layer Support:** Provides master‑side interfaces for **CANopen**, **DeviceNet**, and **Smart Distributed System (SDS)** protocols. - **Industrial‑Grade Design:** Wide operating temperature range (0 – 60 °C), high humidity tolerance (5 – 95 % non‑condensing), and durable PCB construction. - **Diagnostic LEDs (cPCI/PM versions):** On‑board LEDs indicate port activity and status for quick troubleshooting. - **Termination Control:** On‑board 120 Ω termination resistors selectable via jumpers (JP1/JP2).

Manufacturer: Adlink Technology Inc.

Category: CAN Bus

- **PCI Local Bus Specification Rev. 2.2 Compliant** Ensures full compatibility with standard PCI devices and host systems. - **PCI Bridge Architecture Specification Rev. 1.2 Compliant** Implements a transparent PCI‑to‑PCI bridge for seamless system integration. - **StarFabric High‑Speed Serial Link Technology** Converts parallel PCI signals into serial frames transmitted over a 5 Gbps link (4 × 622 Mbps LVDS pairs), ensuring high‑integrity data transfer up to 10 m. - **Full 32‑bit/33 MHz PCI Bandwidth (132 MB/s)** Provides uncompromised throughput equivalent to local PCI bus performance. - **Complete Hardware and Software Transparency** No additional drivers or software required; all devices appear as local PCI devices to the host. - **Robust Connectivity via 24‑pin DVI‑D Connector** Custom shielded copper cable ensures signal integrity and EMI resistance. - **13 Full‑Size PCI Slots in 19‑inch Rack‑Mount Chassis** Industrial‑grade RK‑8014 chassis with integrated 400 W auto‑switching power supply. - **Maximum Extension Distance: 10 m** Supports 2 m, 5 m, and 10 m cable options (ACL‑PCIEXT‑2/‑5/‑10). - **Built‑in Cooling System** Two 120 mm ball‑bearing fans (88 CFM each) for stable thermal performance. - **Industrial‑Grade Design** Suitable for automation, test, and military/aerospace environments.

Manufacturer: Adlink Technology Inc.

Category: Bus Extensions

- **PCI Local Bus Specification Rev. 2.2 Compliant** – Ensures full compatibility with standard PCI devices. - **PCI Bridge Architecture Specification Rev. 1.2 Compliant** – Implements a transparent PCI‑to‑PCI bridge for seamless operation. - **Full 32‑bit/33 MHz PCI Bandwidth (132 MB/s)** – No performance degradation across the extension link. - **StarFabric High‑Speed Serial Link Technology** – Serializes PCI signals into a 5 Gbps link using 622 Mbps LVDS differential pairs. - **Complete Hardware and Software Transparency** – Devices in the expansion chassis appear as local PCI devices to the host system; no additional drivers required. - **Robust Connectivity via 24‑pin DVI‑D Connector** – Industrial‑grade connector ensures signal integrity and mechanical reliability. - **Maximum Extension Distance: 10 m** – Supports 2 m, 5 m, and 10 m cable options. - **Compact Wall‑Mount Chassis (RK‑8005)** – Shoebox‑sized enclosure with integrated 200 W power supply and active cooling. - **Pre‑installed PCI Bridge Card (LPCI‑8575)** – Simplifies setup; ready for immediate integration. - **Industrial‑Grade Design** – Rugged construction, wide input voltage range (85–265 VAC), and efficient cooling for continuous operation. - **LED Indicators for Power and Link Status** – Provides visual confirmation of system and link health. - **Applications:** Industrial automation, electronics manufacturing test, military/aerospace systems, video capture, and remote test & measurement.

Manufacturer: Adlink Technology Inc.

Category: Bus Extensions

- **48 TTL-Compatible Digital I/O Channels:** Provides 48 bidirectional digital lines configurable as input or output in 8-bit port groups. - **High Current Drive Capability:** Each output channel can source up to 15 mA and sink up to 48 mA, suitable for driving LEDs, relays, and other TTL/CMOS devices. - **Change-of-State (COS) Interrupt:** Generates an interrupt when any input bit changes state, enabling event-driven digital monitoring. - **Dual Interrupt System:** Two independent interrupt sources (INT1 and INT2) allow simultaneous handling of multiple event types such as COS, timer, or counter events. - **Output Status Readback:** Supports readback of output states for verification and closed-loop control. - **External Trigger Input:** Accepts an external trigger signal (EXTTRG, pin 99) to latch input data synchronously with external events. - **Programmable Timer/Counter:** Includes one 8254 programmable timer/counter chip providing a 32-bit timer and a 16-bit event counter for timing and counting applications. - **User-Configurable Power-On State:** Each port can be configured via jumpers to power up in a pulled-high, pulled-low, or floating state. - **Onboard Power Outputs:** Provides +5 V and +12 V outputs on the SCSI connector (protected by resettable fuses) for powering external circuits. - **Watchdog Timer:** 32-bit watchdog timer ensures system reliability and can reset outputs or trigger interrupts on timeout. - **Compact PCI Form Factor:** Half-size PCI card (158 mm × 107 mm) compliant with PCI Bus Rev. 2.1.

Manufacturer: Adlink Technology Inc.

Category: DIO Non-Isolated PCI

- **High Channel Density:** 96 TTL-compatible digital I/O channels (12 ports of 8 bits each). - **High Current Drive Capability:** Each output channel can source up to 15 mA and sink up to 48 mA, suitable for driving LEDs, relays, and other loads. - **Output Readback:** Supports real-time output status readback for verification and monitoring. - **Change-of-State (COS) Interrupt:** Generates interrupts when any input bit changes state, enabling event-driven control. - **Dual Interrupt System:** Two independent interrupt sources (INT1 and INT2) for flexible event handling. - **Programmable Timer/Counter:** Includes one 8254 programmable timer/counter chip providing a 32-bit cascaded timer and a 16-bit event counter. - **External Trigger Input:** Allows external signals to latch input data or trigger events. - **User-Configurable Power-On State:** Each port can be configured via jumpers to power up in pull-high, pull-low, or floating state. - **Watchdog Timer:** 32-bit programmable timer for system monitoring and fail-safe operation. - **High-Speed Data Transfer:** Supports up to 1 MB/s typical transfer rate via programmed I/O. - **Comprehensive Software Support:** Compatible with ADLINK’s PCIS-DASK driver library, LabVIEW®, HP-VEE™, DASYLab™, InTouch™, InControl™, ISaGRAF™, and OPC Server. - **Compact Form Factor:** Half-size PCI card (158 mm × 107 mm). - **Industrial Reliability:** Operating temperature range of 0°C to 60°C and humidity tolerance up to 95% non-condensing.

Manufacturer: Adlink Technology Inc.

Category: DIO Non-Isolated PCI

- **High-Density Digital Input:** 128 optically isolated digital input channels for large-scale signal acquisition. - **Optical Isolation:** 1,250 V RMS isolation between channels and system logic, ensuring protection from high-voltage transients and ground loops. - **Change-of-State (COS) Detection:** Programmable COS interrupt detection for all 128 input channels, enabling event-driven data acquisition without continuous polling. - **Board ID Function:** Hardware DIP switch for unique board identification when multiple PCI-744x cards are installed in a single system. - **TTL I/O Channels:** 32 programmable TTL/3.3 V TTL channels for auxiliary digital control or status monitoring. - **PCI Bus Interface:** Fully compliant with 32-bit 3.3 V/5 V PCI bus, Plug-and-Play (PnP) compatible. - **Software Support:** Compatible with ADLINK’s PCIS-DASK driver library, DAQ-LVIEW PnP for LabVIEW®, and DAQBench™ ActiveX controls. - **Industrial-Grade Design:** Wide operating temperature range (0°C to 60°C), non-condensing humidity tolerance (5–85%), and robust PCB construction. - **COS Interrupt Architecture:** Four independent COS banks (each 32 channels) with interrupt generation and latch registers for precise event capture. - **Ease of Integration:** Standard PCI form factor (174.7 mm × 106.7 mm) for easy installation in industrial PCs. - **Comprehensive Software Tools:** Includes drivers, DLLs, and example code for Windows® 98/NT/2000/XP environments.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **High Channel Density:** 128 isolated digital output (DO) channels and 32 programmable TTL I/O channels. - **Optical Isolation:** 1,250 V RMS isolation between channels and system logic, ensuring protection against voltage transients and ground loops. - **High Output Drive Capability:** Each isolated output channel can sink up to 250 mA continuous current (300 mA maximum) at 60°C, supporting direct control of relays, solenoids, and actuators. - **Open-Drain MOSFET Outputs:** Utilizes TPC8206 MOSFET drivers for reliable switching of 5–40 V loads. - **Programmable Safety and Power-Up States:** - Configurable power-up DO initial states stored in onboard flash memory. - Programmable safety DO states activated automatically upon WDT timeout. - Retains DO values after hot system reset. - **Watchdog Timer (WDT):** 32-bit timer with 10 MHz base clock for system monitoring and fail-safe output control. - **Digital Output Readback:** Real-time readback of output states for verification and diagnostics. - **Board ID Function:** DIP switch-configurable board ID for easy identification in multi-card systems. - **TTL I/O Flexibility:** 32 TTL channels configurable as input or output, supporting both 3.3 V and 5 V logic levels. - **PCI Bus Compatibility:** Fully compliant with 32-bit, 3.3 V/5 V PCI bus, Plug and Play (PnP) supported. - **Software Support:** Compatible with ADLINK PCIS-DASK driver library, DAQ-LVIEW PnP for LabVIEW®, and DAQBench™ ActiveX controls.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **Universal PCI Interface:** 32-bit, 3.3 V/5 V PCI bus, plug-and-play compliant. - **High-Density I/O:** 64 opto-isolated digital inputs and 64 opto-isolated digital outputs. - **Additional TTL I/O:** 32 programmable TTL channels (3.3 V/5 V logic compatible). - **Optical Isolation:** 1,250 V RMS isolation between channels and system logic. - **Change of State (COS) Detection:** Programmable COS interrupt for all 64 input channels; detects rising or falling edges. - **Watchdog Timer (WDT):** 32-bit timer with 10 MHz base clock; programmable overflow interval from 100 ns to 429.496 s. - **Safety Functions:** - Programmable power-up DO initial state. - Programmable safety DO state on WDT interrupt. - DO state retention after hot system reset. - **Output Drive Capability:** 250 mA sink current per channel (300 mA max). - **Digital Output Readback:** Real-time verification of output states. - **Board Identification (Board ID):** DIP switch selectable (16 unique IDs) for multi-card systems. - **Software Support:** Compatible with ADLINK PCIS-DASK, DAQ-LVIEW PnP (LabVIEW® driver), and DAQBench™ ActiveX controls. - **Comprehensive SDK:** C/C++ libraries for DOS and Windows environments. - **Industrial-Grade Reliability:** ESD protection, non-polarity inputs, and robust MOSFET output drivers.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **High Channel Density:** 64 total channels (32 isolated digital inputs + 32 isolated digital outputs). - **High Input Voltage Range:** Accepts 12–50 VDC non-polarity digital input signals, ideal for industrial sensors and actuators. - **Optical Isolation:** 2500 VRMS isolation between channels and host system, protecting against high-voltage transients and ground loops. - **High Output Drive Capability:** Each output channel can sink up to 500 mA at 24 VDC, suitable for driving relays, solenoids, and indicators. - **Open Collector Outputs:** Darlington transistor outputs provide high current sinking capability with external voltage supply (5–35 VDC). - **Dual Interrupt Sources:** Two external interrupt sources (channels 0 and 1) for event-driven control applications. - **Non-Polarity Inputs:** Simplifies wiring by allowing either polarity for input signals. - **Standard Interface:** 100-pin SCSI-II female connector for high-density, reliable connections. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; supports LabVIEW®, MATLAB®, Visual Studio®, and C/C++ SDKs. - **Utility Software:** Includes AD-Logger for data acquisition and monitoring. - **Form Factor:** Standard PCI 32-bit, 5 V bus interface. - **High Reliability:** Designed for industrial environments with wide operating temperature and humidity tolerance.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **64 Isolated Digital Input Channels:** Supports 64 independent, optically isolated digital input lines for AC signal detection. - **AC Signal Detection:** Capable of detecting 50/60 Hz AC input signals, suitable for industrial control and monitoring. - **High Isolation Protection:** 2500 VRMS optical isolation between channels and host system, preventing ground loops and protecting against high‑voltage transients. - **PCI Bus Interface:** Fully compliant with 32‑bit, 5 V PCI bus (PCI Local Bus Specification Rev. 2.1). - **High Input Voltage Range:** Accepts 5 V – 24 V AC/DC input signals (non‑polarity), with optional high‑input‑range (HIR) variants supporting up to 50 V. - **Industrial‑Grade Reliability:** Designed for harsh environments with wide operating temperature range (0 °C – 60 °C) and humidity tolerance (5 % – 95 %, non‑condensing). - **Interrupt Support:** Two external interrupt sources (channels 0 and 1) for event‑driven applications. - **Opto‑22 Compatibility:** Uses a 100‑pin SCSI‑II female connector compatible with Opto‑22 terminal boards and accessories. - **Software Support:** Drivers and SDKs for Windows 7/8.1 x86/x64 and Linux; supports LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Compact Form Factor:** Standard PCI card dimensions of approximately 137 × 93 mm (board only).

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **64 Isolated Digital Input Channels:** Provides 64 optically isolated DI channels for robust signal acquisition in noisy industrial environments. - **High Input Voltage Range:** Supports non-polarity input voltage from 12 V to 50 V DC, suitable for high-voltage industrial sensors and switches. - **Optical Isolation:** 2500 V RMS channel-to-system isolation ensures protection against high-voltage transients and ground loops. - **Non-Polarity Input Design:** Simplifies wiring by allowing either polarity connection for digital input signals. - **Interrupt Capability:** Two interrupt sources (DI channel 0 and DI channel 1) can be configured for event-driven applications. - **PCI Bus Interface:** Fully compliant with 32-bit, 5 V PCI bus (Rev. 2.1) for plug-and-play installation. - **High Reliability:** Industrial-grade design with opto-isolators and transient suppression circuitry for enhanced durability. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; includes drivers and SDKs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** Bundled with AD-Logger for data monitoring and logging. - **Compact Form Factor:** Standard PCI card dimensions (175 mm × 107 mm) suitable for industrial PCs.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **High Isolation:** 2500 V RMS isolation between analog inputs and system ground, preventing ground loops and protecting the host PC from voltage surges. - **Flexible Channel Configuration:** 32 single-ended or 16 differential analog input channels. - **High Resolution and Speed:** 12-bit resolution with a maximum sampling rate of 100 kS/s. - **Programmable Input Ranges:** Bipolar and unipolar ranges selectable via software and jumpers: - Bipolar: ±10 V, ±1 V, ±0.1 V, ±5 V, ±0.5 V, ±0.05 V - Unipolar: 0–10 V, 0–1 V, 0–0.1 V - **Programmable Gain Amplifier (PGA):** Gains of 1, 10, and 100 for flexible signal scaling. - **FIFO Buffer:** 1 K-sample (1024-word) hardware FIFO for efficient data buffering and reduced CPU load. - **Trigger Modes:** Supports software and pacer (timer-based) triggering. - **Data Transfer Modes:** Polling, interrupt-driven, and FIFO half-full interrupt modes. - **Auto-Scan Function:** Automatic channel scanning for multi-channel acquisition. - **Overvoltage Protection:** Continuous ±35 V protection on all analog input channels. - **High Input Impedance:** 10 MΩ (typical) ensuring minimal signal loading. - **Compact Design:** Half-size PCI card (173 mm × 102 mm). - **Software Support:** Comprehensive driver and library support for multiple operating systems and development environments. - **Custom Signal Conditioning Area:** On-board RC filter area for per-channel signal conditioning (attenuation or filtering).

Manufacturer: Adlink Technology Inc.

Category: A/D Isolated PCI

- **Bus Interface:** - 32-bit, 5 V PCI bus (PCI-7230) - 3U Eurocard form factor, CompactPCI compliant (cPCI-7230) - 32-bit, 3.3 V or 5 V PCI bus (LPCI-7230) - x1 lane PCI Express interface (LPCIe-7230) - **Channel Configuration:** - 16 isolated digital input channels - 16 isolated digital output channels - **Isolation Protection:** - 5000 Vrms optical isolation for PCI-7230 and cPCI-7230 - 2500 Vrms optical isolation for LPCI-7230 and LPCIe-7230 - **Output Characteristics:** - Darlington transistor open-collector outputs - Sink current up to 500 mA per channel at 100% duty cycle - Supports 5–35 VDC external supply for output circuits - **Input Characteristics:** - Non-polarity input design - Input voltage range: 0–24 VDC - Input resistance: 1.2 kΩ @ 0.5 W - Logic levels: Logic “L” = 0–1.5 V, Logic “H” = 5–24 V - **Interrupt Support:** - Two external interrupt sources on digital input channels 0 and 1 - **Throughput:** - 10 kHz maximum input/output throughput - **Software & OS Support:** - Compatible with Windows 7/Vista/XP/2000/2003 Server and Linux - Supported by ADLINK DAQPilot, PCIS-DASK, DAQBench, DAQ-LVIEW PnP, and DAQ-MTLB - **Connectors:** - 37-pin D-sub female connector (PCI-7230) - 50-pin SCSI-II connector (LPCI, LPCIe, and cPCI variants)

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **64-Channel Total I/O Capacity:** 32 isolated digital inputs and 32 isolated digital outputs on a single PCI card. - **Optical Isolation:** 2500 V RMS isolation between channels and the host system, protecting against voltage surges and ground loops. - **High Output Drive Capability:** Each isolated output channel can sink up to 500 mA at 24 V DC, suitable for driving relays, solenoids, and actuators. - **Non-Polarity Digital Inputs:** Accepts non-polarity input voltage ranges from 5 V to 24 V DC (standard) or up to 50 V DC for the high input range (HIR) version. - **Interrupt Support:** Two external interrupt sources (DI channel 0 and DI channel 1) for event-driven control. - **Opto-22 Compatibility:** Compatible with Opto-22 standard digital I/O modules and terminal boards. - **High Reliability:** Optical isolation and robust design ensure long-term stability in noisy industrial environments. - **Software Support:** Comprehensive driver and SDK support for Windows and Linux, including LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio.NET. - **Form Factor:** Standard 32-bit 5 V PCI bus interface, plug-and-play compliant with PCI specification Rev. 2.1. - **Utility Software:** Includes AD-Logger for data monitoring and logging.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **32 Isolated Digital Input Channels:** Provides 32 optically isolated input lines for interfacing with external digital signals. - **High Isolation Voltage:** 5000 Vrms optical isolation between channels and the host system ensures protection against high-voltage transients and ground loops. - **Change-of-State (COS) Detection:** Hardware-based COS detection on all 32 channels generates interrupts when input states change, enabling efficient event-driven processing. - **Wide Input Voltage Range:** Accepts non-polarity DC input signals from 5 V to 24 V, simplifying integration with various industrial sensors and devices. - **High Throughput:** Supports input sampling rates up to 10 kHz, suitable for real-time monitoring applications. - **Compact PCI Form Factor:** Standard 32-bit 5 V PCI bus interface for easy integration into industrial PCs. - **Robust Connector Interface:** Equipped with a 37-pin D-sub female connector for secure and standardized wiring. - **Software and Driver Support:** Compatible with Windows and Linux operating systems, with driver packages for LabVIEW™, MATLAB®, and ADLINK’s DAQPilot and PCIS-DASK libraries. - **Industrial-Grade Design:** Operating temperature range of 0°C to 60°C and humidity tolerance up to 95% non-condensing. - **Plug-and-Play PCI Configuration:** Fully compliant with PCI Local Bus Specification Rev. 2.1, supporting automatic resource allocation by system BIOS.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **32 Isolated Digital Input Channels:** Provides 32 optically isolated DI channels for reliable signal acquisition from external devices. - **High-Speed Change-of-State (COS) Detection:** Detects input transitions on all 32 channels, generating interrupts for real-time event monitoring. - **High Throughput:** Supports input sampling rates up to 500 kHz, suitable for high-speed digital monitoring. - **Optical Isolation:** 2.5 kV to 5 kV RMS isolation between channels and host system, protecting against voltage surges and ground loops. - **Non-Polarity Input Design:** Accepts non-polarized 0–24 V DC signals, simplifying wiring and integration. - **Compact PCI Form Factor:** Standard PCI card dimensions (158 mm × 107 mm) for easy installation in industrial PCs. - **Connector Type:** 37-pin female D-sub connector for secure and standardized I/O interfacing. - **Interrupt Support:** Dual interrupt sources for COS detection on lower and upper 16-channel groups. - **Wide Input Voltage Range:** Accepts 5–24 V logic high and 0–1.5 V logic low levels. - **Software Compatibility:** Fully supported by ADLINK’s DAQPilot, PCIS-DASK, and DAQ-MTLB drivers for Windows and Linux, as well as integration with LabVIEW™ and MATLAB®. - **Industrial-Grade Reliability:** Designed for 0°C to 60°C operation, with 5–95% non-condensing humidity tolerance.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **32 Isolated Digital Output Channels:** Provides 32 independent, optically isolated output channels for reliable control of external devices. - **High Voltage Isolation:** 2500 V RMS optical isolation between channels and the host system, ensuring protection against electrical surges and ground loops. - **High Output Drive Capability:** Each channel can sink up to 500 mA at 100% duty cycle, suitable for driving relays, solenoids, and other inductive loads. - **Wide Output Voltage Range:** Supports open-collector output from 5 V DC (minimum) to 35 V DC (maximum). - **Darlington Transistor Output Design:** Ensures high current gain and robust switching performance for industrial-grade reliability. - **Standard PCI Interface:** Fully compliant with 32-bit, 5 V PCI bus (Rev. 2.1), plug-and-play configuration with automatic resource assignment by BIOS. - **Optical Isolation Protection:** Prevents damage to the host PC from high external voltages and eliminates ground loop interference. - **Compact PCB Design:** Standard PCI form factor with dimensions of 175 mm (L) × 107 mm (H). - **Software and Driver Support:** Compatible with Windows and Linux operating systems, with driver support for LabVIEW™, MATLAB®, and ADLINK’s DAQPilot SDK. - **Industrial-Grade Reliability:** Designed for continuous operation in harsh environments with operating temperature range from 0°C to 60°C.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **64 Isolated Digital Input Channels:** Provides 64 optically isolated digital input channels for high-density signal acquisition. - **Optical Isolation:** 2500 V RMS channel-to-computer isolation protects host systems from high-voltage transients and ground loops. - **Non-Polarity Input Design:** Accepts both positive and negative logic signals without polarity constraints. - **Input Voltage Range:** 5–24 V DC (standard version) or 12–50 V DC (high input range version, PCI-7433HIR). - **Interrupt Capability:** Two external interrupt sources available on digital input channels 0 and 1. - **Opto-22 Compatibility:** Compatible with Opto-22 I/O modules and terminal boards. - **High Reliability:** Designed for industrial environments with transient voltage suppression and jumper-configurable protection circuits. - **Plug-and-Play PCI Interface:** Fully compliant with PCI Local Bus Specification Rev. 2.1, using the PLX PCI-9050 controller. - **Software Support:** Drivers and SDKs available for Windows and Linux, with APIs for LabVIEW®, MATLAB®, Visual Studio®, and C/C++. - **Utility Software:** Includes AD-Logger for data monitoring and logging. - **Form Factor:** Standard PCI card, 175 mm x 107 mm, suitable for desktop or industrial PCs. - **Operating System Support:** Windows 7/8.1 (x86/x64) and Linux.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **64 Isolated Digital Output Channels:** Provides 64 independent, optically isolated digital outputs for industrial control and automation applications. - **High Isolation Voltage:** 2500 V RMS isolation between channels and the host system, protecting the PC from high-voltage transients and ground potential differences. - **High Output Drive Capability:** Each output channel can sink up to 500 mA at 24 V DC, suitable for driving relays, solenoids, and other inductive loads. - **Open Collector Darlington Transistor Outputs:** Ensures high current drive and fast switching performance. - **Wide Output Voltage Range:** Supports 5 V to 35 V DC output voltage levels. - **Opto-22 Compatibility:** Standardized pinout and electrical characteristics for easy integration with Opto-22 modules and terminal boards. - **100-pin SCSI-II Connector:** Provides a compact, high-density interface for all 64 channels. - **PCI Bus Interface:** Fully compliant with 32-bit, 5 V PCI bus (Rev. 2.1), supporting plug-and-play configuration. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; includes drivers and SDKs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** Bundled with AD-Logger for data monitoring and testing. - **Compact Form Factor:** Standard PCI card dimensions (156 mm × 106 mm). - **Industrial-Grade Reliability:** Designed for continuous operation in harsh environments (0 °C to 60 °C, 5–95% RH non-condensing).

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **64 Isolated Digital Output Channels:** Provides 64 optically isolated DO channels for high-density digital control applications. - **Optical Isolation:** 2500 VRMS isolation voltage between channels and the host system, ensuring protection against high-voltage transients and ground loops. - **Output Type:** PNP-type transistor outputs with source current capability. - **High Output Drive Capability:** Supports up to 500 mA per channel (single channel ON) and 260 mA per channel (all channels ON) at 24 VDC. - **Output Voltage Range:** 5 VDC to 35 VDC. - **Compact PCI Form Factor:** Standard 32-bit, 5 V PCI bus interface, compatible with most industrial PCs. - **Connector Type:** 100-pin SCSI-II female connector for high-density signal interfacing. - **Form Factor Dimensions:** 156 mm × 106 mm (6.08" × 4.13"). - **Operating Temperature Range:** 0°C to 60°C (32°F to 140°F). - **Storage Temperature Range:** -20°C to 80°C (-4°F to 176°F). - **Humidity Tolerance:** 5% to 95%, non-condensing. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; includes drivers and SDKs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** AD-Logger for data acquisition and monitoring. - **Isolation Protection:** Prevents damage from high external voltages and eliminates ground loop interference. - **Industrial Reliability:** Designed for continuous operation in harsh industrial environments.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **32 Isolated Digital Output Channels:** Provides 32 independent, optically isolated digital output channels using Darlington transistor drivers. - **Source Current Output Type:** The PCI-7234P is a PNP-type output card capable of sourcing current up to **500 mA per channel** at 100% duty cycle, or **260 mA for all channels** at 10% duty cycle. - **High Isolation Voltage:** Offers **2500 V RMS optical isolation** between channels and the host system, ensuring protection against electrical surges and noise. - **Wide Output Voltage Range:** Supports output voltages from **5 V to 35 V DC**, suitable for driving relays, solenoids, lamps, and other industrial actuators. - **Standard PCI Interface:** Fully compliant with the **32-bit, 5 V PCI bus specification (Rev. 2.1)**, ensuring compatibility with a wide range of industrial PCs. - **Compact Form Factor:** PCB dimensions of **175 mm (L) × 107 mm (H)**, designed for standard PCI slots. - **High Output Drive Capability:** Each channel can handle up to **500 mA continuous current**, enabling direct control of high-current loads. - **Optical Isolation Protection:** Prevents ground loops and protects the host system from high-voltage spikes. - **Software and OS Support:** Compatible with **Windows 7/Vista/XP/2000/2003 Server** and **Linux**. Supported by ADLINK’s **DAQPilot**, **PCIS-DASK**, and **DAQBench** software suites, as well as third-party environments such as **LabVIEW™** and **MATLAB®**. - **Connector Type:** Equipped with a **37-pin D-sub female connector** for easy integration with external terminal boards and cables.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PCI

- **Purpose‑built PCI‑to‑PCI Extension Cable:** Designed specifically for ADLINK’s PCIS‑8580 series, enabling seamless extension of the PCI bus from a host system to an external chassis. - **10 m Transmission Distance:** Supports the maximum extension length allowed by the PCIS‑8580 system, maintaining signal integrity and full PCI bandwidth. - **High‑Quality Shielded Construction:** Utilizes eight pairs of shielded twisted copper wires to minimize electromagnetic interference (EMI) and crosstalk. - **DVI‑D 24‑pin Connector:** Employs a robust, high‑density DVI‑D 24‑pin connector for secure mechanical coupling and reliable electrical contact. - **Full PCI Bandwidth Support:** Maintains 32‑bit/33 MHz PCI throughput (132 MB/s) without degradation. - **StarFabric‑Based Signal Serialization:** Works in conjunction with ADLINK’s LPCI‑8575 PCI extension card and RK‑8005/RK‑8014 chassis to serialize PCI signals into a 5 Gbps StarFabric serial link. - **Hardware and Software Transparency:** Ensures that all PCI devices in the extension chassis operate as if installed directly in the host system—no additional drivers or configuration required. - **Industrial‑Grade Reliability:** Designed for demanding environments such as industrial automation, test and measurement, and defense applications.

Manufacturer: Adlink Technology Inc.

Category: Bus Extensions

- **Purpose‑Built PCI Extension Cable:** Designed specifically for PCI‑to‑PCI bridge systems, enabling remote PCI slot expansion up to 10 m from the host. - **High‑Speed Serial Transmission:** Supports 5 Gbps serial link bandwidth via StarFabric technology, ensuring full 32‑bit/33 MHz PCI throughput (132 MB/s). - **Shielded Twisted‑Pair Construction:** Eight pairs of shielded twisted copper wires minimize electromagnetic interference (EMI) and maintain signal integrity. - **Robust DVI‑D 24‑Pin Connector:** Industrial‑grade connector ensures secure mechanical coupling and reliable electrical contact. - **Hardware/Software Transparency:** Devices installed in the extension chassis appear as if directly connected to the host PCI bus—no additional drivers required. - **Scalable System Integration:** Compatible with both 4‑slot (RK‑8005) and 13‑slot (RK‑8014) extension chassis, supporting a wide range of industrial and test applications. - **Full PCI Local Bus Compliance:** Conforms to PCI Local Bus Specification Revision 2.2 and PCI Bridge Architecture Specification 1.2. - **Industrial‑Grade Reliability:** Designed for continuous operation in demanding environments such as automation, test, and aerospace systems.

Manufacturer: Adlink Technology Inc.

Category: Bus Extensions

- **Purpose‑built for PCI‑to‑PCI Extension:** Designed specifically for ADLINK’s PCIS‑8580 systems, enabling seamless communication between host and remote PCI chassis. - **High‑speed Serial Transmission:** Supports serialized PCI signals over a 5 Gbps StarFabric link, maintaining full 32‑bit/33 MHz PCI bandwidth (132 MB/s). - **Shielded Twisted‑Pair Construction:** Eight pairs of shielded twisted copper wires minimize electromagnetic interference (EMI) and ensure signal integrity over extended distances. - **Robust DVI‑D 24‑pin Connector:** Industrial‑grade connector ensures secure mechanical coupling and reliable electrical contact. - **Hardware and Software Transparency:** Operates as a transparent PCI bridge—no additional drivers or software required. - **Flexible Distance Options:** Available in 2 m (ACL‑PCIEXT‑2), 5 m (ACL‑PCIEXT‑5), and 10 m (ACL‑PCIEXT‑10) lengths to accommodate various installation environments. - **Industrial‑grade Reliability:** Designed for demanding environments such as automation, test and measurement, and defense applications. - **Full PCI Compliance:** Conforms to PCI Local Bus Specification Revision 2.2 and PCI Bridge Architecture Specification 1.2.

Manufacturer: Adlink Technology Inc.

Category: Bus Extensions
