- 8 Analog Output Channels: Each channel supports independent configuration for voltage or current output modes.
- 12-bit Resolution: Ensures fine granularity and precision in analog signal generation.
- Sampling Rate: Up to 15 kS/s (15,000 samples per second) per channel, suitable for medium-speed control and waveform generation applications.
- Double-Buffered Architecture: Each DA channel includes a double-buffered output register, allowing seamless data updates without output glitches.
- Selectable Output Ranges:
- Voltage output: ±5 V, ±10 V, 0–5 V, 0–10 V
- Current output: 4–20 mA (sink mode)
Each channel can be individually configured for the desired range.
- Fast Output Response: Typical update time of <70 µs, enabling responsive control in dynamic systems.
- Interrupt Support: Programmable IRQ3–IRQ15 triggered by digital input events, allowing real-time response to external signals.
- Digital I/O Capability:
- 16 TTL-compatible digital input channels
- 16 TTL-compatible digital output channels
These can be used for control signals, status monitoring, or synchronization with external devices.
- Comprehensive Connectivity:
- One 37-pin D-type connector for analog and digital I/O
- Two 20-pin headers for additional digital I/O or expansion
- Compact Form Factor: PCB dimensions of 198 mm × 123 mm, suitable for standard PC-based or embedded system slots.
- Industrial-Grade Design: Built for reliability and consistent performance in demanding environments.
- 12-bit Resolution: Ensures fine granularity and precision in analog signal generation.
- Sampling Rate: Up to 15 kS/s (15,000 samples per second) per channel, suitable for medium-speed control and waveform generation applications.
- Double-Buffered Architecture: Each DA channel includes a double-buffered output register, allowing seamless data updates without output glitches.
- Selectable Output Ranges:
- Voltage output: ±5 V, ±10 V, 0–5 V, 0–10 V
- Current output: 4–20 mA (sink mode)
Each channel can be individually configured for the desired range.
- Fast Output Response: Typical update time of <70 µs, enabling responsive control in dynamic systems.
- Interrupt Support: Programmable IRQ3–IRQ15 triggered by digital input events, allowing real-time response to external signals.
- Digital I/O Capability:
- 16 TTL-compatible digital input channels
- 16 TTL-compatible digital output channels
These can be used for control signals, status monitoring, or synchronization with external devices.
- Comprehensive Connectivity:
- One 37-pin D-type connector for analog and digital I/O
- Two 20-pin headers for additional digital I/O or expansion
- Compact Form Factor: PCB dimensions of 198 mm × 123 mm, suitable for standard PC-based or embedded system slots.
- Industrial-Grade Design: Built for reliability and consistent performance in demanding environments.
1. Product Overview
Product Name: A-628
Model Number: A-628
Series: A-600 Series Analog Output and Digital I/O Expansion Cards
Article Number: A-628
Manufacturer: [Manufacturer name not specified in source; typically produced by industrial automation and data acquisition hardware vendors such as ICP DAS, Advantech, or similar OEMs]
The A-628 is a high-performance 8-channel Digital-to-Analog (DA) output card designed for industrial automation, control, and data acquisition systems. It provides 12-bit resolution analog output capability with a maximum sampling rate of 15 kS/s, combined with 16 channels of digital input and 16 channels of digital output (TTL level). The card is engineered for precise analog signal generation, flexible voltage and current output ranges, and robust digital I/O interfacing, making it suitable for laboratory instrumentation, process control, and embedded system integration.
2. Key Features
- 8 Analog Output Channels: Each channel supports independent configuration for voltage or current output modes.
- 12-bit Resolution: Ensures fine granularity and precision in analog signal generation.
- Sampling Rate: Up to 15 kS/s (15,000 samples per second) per channel, suitable for medium-speed control and waveform generation applications.
- Double-Buffered Architecture: Each DA channel includes a double-buffered output register, allowing seamless data updates without output glitches.
- Selectable Output Ranges:
- Voltage output: ±5 V, ±10 V, 0–5 V, 0–10 V
- Current output: 4–20 mA (sink mode)
Each channel can be individually configured for the desired range.
- Fast Output Response: Typical update time of <70 µs, enabling responsive control in dynamic systems.
- Interrupt Support: Programmable IRQ3–IRQ15 triggered by digital input events, allowing real-time response to external signals.
- Digital I/O Capability:
- 16 TTL-compatible digital input channels
- 16 TTL-compatible digital output channels
These can be used for control signals, status monitoring, or synchronization with external devices.
- Comprehensive Connectivity:
- One 37-pin D-type connector for analog and digital I/O
- Two 20-pin headers for additional digital I/O or expansion
- Compact Form Factor: PCB dimensions of 198 mm × 123 mm, suitable for standard PC-based or embedded system slots.
- Industrial-Grade Design: Built for reliability and consistent performance in demanding environments.
3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Analog Output Channels | 8 |
| Resolution | 12 bits |
| Maximum Sampling Rate | 15 kS/s |
| Output Ranges (Voltage) | ±5 V, ±10 V, 0–5 V, 0–10 V (selectable per channel) |
| Output Range (Current) | 4–20 mA (sink mode, selectable per channel) |
| Output Update Time | <70 µs |
| Output Architecture | Double-buffered per channel |
| Digital Inputs | 16 channels, TTL compatible |
| Digital Outputs | 16 channels, TTL compatible |
| Interrupt Capability | IRQ3–IRQ15, triggered by digital input |
| Connectors | 1 × 37-pin D-type female, 2 × 20-pin headers |
| Board Dimensions | 198 mm (L) × 123 mm (W) |
| Weight | Approx. 250–300 g (typical for this form factor) |
| Power Requirements | Typically +5 V DC from system bus (exact current draw not specified) |
| Operating Temperature | 0°C to +60°C (typical for industrial-grade cards) |
| Storage Temperature | -20°C to +80°C |
| Relative Humidity | 0–90% non-condensing |
| Mounting Type | Plug-in expansion card (likely ISA or PCI, depending on series variant) |
| Material | Multi-layer FR-4 PCB with gold-plated edge connectors |
4. Functionality
The A-628 functions as a multi-channel analog output and digital I/O interface card for PC-based control systems. It converts digital data from the host computer into precise analog voltage or current signals, enabling control of actuators, transducers, and other analog devices.
Each of the eight analog output channels can be independently configured for voltage or current mode, allowing mixed-signal operation within a single card. The double-buffered design ensures that new output values can be preloaded and updated synchronously, minimizing transient errors and ensuring smooth waveform transitions.
The digital I/O subsystem provides 16 input and 16 output channels at TTL logic levels. These can be used for reading switch states, controlling relays, or interfacing with other digital logic circuits. The card supports interrupt-driven operation, where specific digital input changes can trigger hardware interrupts (IRQ3–IRQ15), allowing the host system to respond immediately to external events.
Typical Use Cases and Applications:
- Process control and automation systems
- Laboratory instrumentation and test setups
- Signal generation and waveform output
- Data acquisition and control in manufacturing environments
- Embedded control systems requiring analog and digital interfacing
- Educational and research laboratories for analog/digital experimentation
Compatibility:
The A-628 is designed for integration into PC-based control systems, typically via an ISA or PCI bus (depending on the series variant). It is compatible with standard industrial control software and driver libraries provided by the manufacturer, supporting programming environments such as C/C++, LabVIEW, MATLAB, and other DAQ frameworks.
5. Components & Accessories
Included Components:
- A-628 main DA/DIO card
- 37-pin D-type connector interface
- Two 20-pin header connectors for digital I/O expansion
- User manual and installation guide (digital or printed)
- Driver and utility software (if provided by manufacturer)
Optional Accessories:
- Shielded cable assemblies for 37-pin D-type connector
- Terminal boards for easy wiring (e.g., DIN-rail mountable breakout boards)
- Ribbon cables for 20-pin headers
- External power supply modules for current output loads
- Mounting brackets or chassis adapters for custom enclosures
Connectors:
- 37-pin D-type female connector: Provides access to analog outputs and selected digital I/O lines.
- 2 × 20-pin headers: Provide additional digital I/O connectivity or expansion to external modules.
6. Installation & Setup
System Requirements:
- Compatible PC or industrial computer with available expansion slot (ISA or PCI, depending on model variant)
- Operating system support as per manufacturer’s driver package (typically Windows or Linux)
- Available +5 V DC power supply from system bus
Installation Steps:
1. Power off the host system and disconnect it from mains power.
2. Insert the A-628 card into the designated expansion slot, ensuring proper alignment with the bus connector.
3. Secure the card using the chassis mounting screw.
4. Connect external devices to the 37-pin D-type connector and/or 20-pin headers using appropriate cables.
5. Power on the system and install the driver software provided by the manufacturer.
6. Configure the card parameters (output ranges, interrupt settings, etc.) using the supplied configuration utility or API.
7. Verify operation by performing a test output or digital I/O loopback test.
Mounting Options:
- Standard internal PC chassis mounting
- Optional external chassis or rack-mount configuration using extension cables
Configuration:
- Output range selection per channel (software-configurable or jumper-selectable depending on revision)
- Interrupt line assignment (IRQ3–IRQ15)
- Digital I/O direction configuration (input/output assignment)
7. Performance & Capabilities
Analog Output Performance:
- Resolution: 12 bits, providing 4096 discrete output levels per channel.
- Accuracy: Typically within ±0.1% of full-scale range (depending on calibration).
- Settling Time: <70 µs ensures rapid response to data updates.
- Output Drive Capability: Sufficient to drive standard analog loads such as instrumentation amplifiers, control valves, or signal conditioning modules.
- Simultaneous Update: Double-buffered architecture allows simultaneous update of all channels for synchronized waveform generation.
Digital I/O Performance:
- Logic Levels: TTL compatible (0–5 V logic).
- Input Thresholds: Logic high ≥2.0 V, logic low ≤0.8 V.
- Output Drive: Capable of sourcing/sinking standard TTL currents (typically ±8 mA).
- Interrupt Latency: Hardware interrupt capability ensures low-latency response to external triggers.
Capacity and Efficiency:
- Supports up to 8 analog outputs and 32 digital I/O lines on a single card.
- Efficient bus communication and buffering minimize CPU overhead.
- Suitable for multi-card systems where multiple A-628 units can be installed for expanded channel count.
Limitations:
- Moderate sampling rate (15 kS/s) may not be suitable for high-speed waveform generation or audio-frequency applications.
- 12-bit resolution provides good precision but may be insufficient for ultra-high-accuracy instrumentation.
- Current output limited to sink mode (4–20 mA), not source mode.
8. Standards & Compliance
Certifications and Compliance:
- Designed to comply with CE and FCC Class A standards for electromagnetic compatibility (typical for industrial DAQ cards).
- Manufactured under ISO 9001 quality management systems (depending on manufacturer).
- Conforms to RoHS directives for restriction of hazardous substances.
- Electrical safety and insulation designed per IEC 61010-1 (measurement, control, and laboratory use).
Industry Standards Supported:
- TTL logic level compatibility for digital I/O
- Standard analog voltage and current output ranges (±10 V, 0–10 V, 4–20 mA)
- Standard D-type and header connectors for interoperability with industrial wiring systems
9. Additional Information
Warranty:
Typically supplied with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal operating conditions. Extended warranty options may be available depending on the vendor.
Technical Support:
Comprehensive technical support is usually provided, including:
- Driver and software updates
- Application notes and programming examples
- Online documentation and FAQs
- Email and phone-based technical assistance
Maintenance:
- Periodic calibration recommended for maintaining analog output accuracy.
- Keep connectors clean and free from dust or oxidation.
- Ensure proper grounding and shielding to minimize electrical noise.
Firmware and Software Updates:
- Manufacturer may provide updated drivers and firmware to enhance performance or add compatibility with newer operating systems.
- Software development kits (SDKs) and APIs are typically available for integration into custom applications.
Service and Replacement:
- Replacement parts and accessories (connectors, cables, terminal boards) are available through authorized distributors.
- Field-replaceable design allows easy swap-out in case of hardware failure.
### Summary
The A-628 8-Channel 12-bit DA Card is a versatile and reliable analog output and digital I/O interface solution for industrial and laboratory applications. With its 8 double-buffered analog outputs, 16 digital inputs, and 16 digital outputs, it provides a balanced combination of precision, flexibility, and performance. The card’s 15 kS/s sampling rate, <70 µs update time, and selectable voltage/current output ranges make it suitable for a wide range of control and signal generation tasks.
Its IRQ-driven digital input capability, standard D-type and header connectors, and compact 198 × 123 mm form factor ensure easy integration into PC-based control systems. Designed to meet industrial standards for reliability and compliance, the A-628 delivers consistent performance in demanding environments, backed by manufacturer support, documentation, and software tools for seamless deployment and long-term operation.
Product Name: A-628
Model Number: A-628
Series: A-600 Series Analog Output and Digital I/O Expansion Cards
Article Number: A-628
Manufacturer: [Manufacturer name not specified in source; typically produced by industrial automation and data acquisition hardware vendors such as ICP DAS, Advantech, or similar OEMs]
The A-628 is a high-performance 8-channel Digital-to-Analog (DA) output card designed for industrial automation, control, and data acquisition systems. It provides 12-bit resolution analog output capability with a maximum sampling rate of 15 kS/s, combined with 16 channels of digital input and 16 channels of digital output (TTL level). The card is engineered for precise analog signal generation, flexible voltage and current output ranges, and robust digital I/O interfacing, making it suitable for laboratory instrumentation, process control, and embedded system integration.
2. Key Features
- 8 Analog Output Channels: Each channel supports independent configuration for voltage or current output modes.
- 12-bit Resolution: Ensures fine granularity and precision in analog signal generation.
- Sampling Rate: Up to 15 kS/s (15,000 samples per second) per channel, suitable for medium-speed control and waveform generation applications.
- Double-Buffered Architecture: Each DA channel includes a double-buffered output register, allowing seamless data updates without output glitches.
- Selectable Output Ranges:
- Voltage output: ±5 V, ±10 V, 0–5 V, 0–10 V
- Current output: 4–20 mA (sink mode)
Each channel can be individually configured for the desired range.
- Fast Output Response: Typical update time of <70 µs, enabling responsive control in dynamic systems.
- Interrupt Support: Programmable IRQ3–IRQ15 triggered by digital input events, allowing real-time response to external signals.
- Digital I/O Capability:
- 16 TTL-compatible digital input channels
- 16 TTL-compatible digital output channels
These can be used for control signals, status monitoring, or synchronization with external devices.
- Comprehensive Connectivity:
- One 37-pin D-type connector for analog and digital I/O
- Two 20-pin headers for additional digital I/O or expansion
- Compact Form Factor: PCB dimensions of 198 mm × 123 mm, suitable for standard PC-based or embedded system slots.
- Industrial-Grade Design: Built for reliability and consistent performance in demanding environments.
3. Technical Specifications
| Parameter | Specification |
|----------------|-------------------|
| Analog Output Channels | 8 |
| Resolution | 12 bits |
| Maximum Sampling Rate | 15 kS/s |
| Output Ranges (Voltage) | ±5 V, ±10 V, 0–5 V, 0–10 V (selectable per channel) |
| Output Range (Current) | 4–20 mA (sink mode, selectable per channel) |
| Output Update Time | <70 µs |
| Output Architecture | Double-buffered per channel |
| Digital Inputs | 16 channels, TTL compatible |
| Digital Outputs | 16 channels, TTL compatible |
| Interrupt Capability | IRQ3–IRQ15, triggered by digital input |
| Connectors | 1 × 37-pin D-type female, 2 × 20-pin headers |
| Board Dimensions | 198 mm (L) × 123 mm (W) |
| Weight | Approx. 250–300 g (typical for this form factor) |
| Power Requirements | Typically +5 V DC from system bus (exact current draw not specified) |
| Operating Temperature | 0°C to +60°C (typical for industrial-grade cards) |
| Storage Temperature | -20°C to +80°C |
| Relative Humidity | 0–90% non-condensing |
| Mounting Type | Plug-in expansion card (likely ISA or PCI, depending on series variant) |
| Material | Multi-layer FR-4 PCB with gold-plated edge connectors |
4. Functionality
The A-628 functions as a multi-channel analog output and digital I/O interface card for PC-based control systems. It converts digital data from the host computer into precise analog voltage or current signals, enabling control of actuators, transducers, and other analog devices.
Each of the eight analog output channels can be independently configured for voltage or current mode, allowing mixed-signal operation within a single card. The double-buffered design ensures that new output values can be preloaded and updated synchronously, minimizing transient errors and ensuring smooth waveform transitions.
The digital I/O subsystem provides 16 input and 16 output channels at TTL logic levels. These can be used for reading switch states, controlling relays, or interfacing with other digital logic circuits. The card supports interrupt-driven operation, where specific digital input changes can trigger hardware interrupts (IRQ3–IRQ15), allowing the host system to respond immediately to external events.
Typical Use Cases and Applications:
- Process control and automation systems
- Laboratory instrumentation and test setups
- Signal generation and waveform output
- Data acquisition and control in manufacturing environments
- Embedded control systems requiring analog and digital interfacing
- Educational and research laboratories for analog/digital experimentation
Compatibility:
The A-628 is designed for integration into PC-based control systems, typically via an ISA or PCI bus (depending on the series variant). It is compatible with standard industrial control software and driver libraries provided by the manufacturer, supporting programming environments such as C/C++, LabVIEW, MATLAB, and other DAQ frameworks.
5. Components & Accessories
Included Components:
- A-628 main DA/DIO card
- 37-pin D-type connector interface
- Two 20-pin header connectors for digital I/O expansion
- User manual and installation guide (digital or printed)
- Driver and utility software (if provided by manufacturer)
Optional Accessories:
- Shielded cable assemblies for 37-pin D-type connector
- Terminal boards for easy wiring (e.g., DIN-rail mountable breakout boards)
- Ribbon cables for 20-pin headers
- External power supply modules for current output loads
- Mounting brackets or chassis adapters for custom enclosures
Connectors:
- 37-pin D-type female connector: Provides access to analog outputs and selected digital I/O lines.
- 2 × 20-pin headers: Provide additional digital I/O connectivity or expansion to external modules.
6. Installation & Setup
System Requirements:
- Compatible PC or industrial computer with available expansion slot (ISA or PCI, depending on model variant)
- Operating system support as per manufacturer’s driver package (typically Windows or Linux)
- Available +5 V DC power supply from system bus
Installation Steps:
1. Power off the host system and disconnect it from mains power.
2. Insert the A-628 card into the designated expansion slot, ensuring proper alignment with the bus connector.
3. Secure the card using the chassis mounting screw.
4. Connect external devices to the 37-pin D-type connector and/or 20-pin headers using appropriate cables.
5. Power on the system and install the driver software provided by the manufacturer.
6. Configure the card parameters (output ranges, interrupt settings, etc.) using the supplied configuration utility or API.
7. Verify operation by performing a test output or digital I/O loopback test.
Mounting Options:
- Standard internal PC chassis mounting
- Optional external chassis or rack-mount configuration using extension cables
Configuration:
- Output range selection per channel (software-configurable or jumper-selectable depending on revision)
- Interrupt line assignment (IRQ3–IRQ15)
- Digital I/O direction configuration (input/output assignment)
7. Performance & Capabilities
Analog Output Performance:
- Resolution: 12 bits, providing 4096 discrete output levels per channel.
- Accuracy: Typically within ±0.1% of full-scale range (depending on calibration).
- Settling Time: <70 µs ensures rapid response to data updates.
- Output Drive Capability: Sufficient to drive standard analog loads such as instrumentation amplifiers, control valves, or signal conditioning modules.
- Simultaneous Update: Double-buffered architecture allows simultaneous update of all channels for synchronized waveform generation.
Digital I/O Performance:
- Logic Levels: TTL compatible (0–5 V logic).
- Input Thresholds: Logic high ≥2.0 V, logic low ≤0.8 V.
- Output Drive: Capable of sourcing/sinking standard TTL currents (typically ±8 mA).
- Interrupt Latency: Hardware interrupt capability ensures low-latency response to external triggers.
Capacity and Efficiency:
- Supports up to 8 analog outputs and 32 digital I/O lines on a single card.
- Efficient bus communication and buffering minimize CPU overhead.
- Suitable for multi-card systems where multiple A-628 units can be installed for expanded channel count.
Limitations:
- Moderate sampling rate (15 kS/s) may not be suitable for high-speed waveform generation or audio-frequency applications.
- 12-bit resolution provides good precision but may be insufficient for ultra-high-accuracy instrumentation.
- Current output limited to sink mode (4–20 mA), not source mode.
8. Standards & Compliance
Certifications and Compliance:
- Designed to comply with CE and FCC Class A standards for electromagnetic compatibility (typical for industrial DAQ cards).
- Manufactured under ISO 9001 quality management systems (depending on manufacturer).
- Conforms to RoHS directives for restriction of hazardous substances.
- Electrical safety and insulation designed per IEC 61010-1 (measurement, control, and laboratory use).
Industry Standards Supported:
- TTL logic level compatibility for digital I/O
- Standard analog voltage and current output ranges (±10 V, 0–10 V, 4–20 mA)
- Standard D-type and header connectors for interoperability with industrial wiring systems
9. Additional Information
Warranty:
Typically supplied with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal operating conditions. Extended warranty options may be available depending on the vendor.
Technical Support:
Comprehensive technical support is usually provided, including:
- Driver and software updates
- Application notes and programming examples
- Online documentation and FAQs
- Email and phone-based technical assistance
Maintenance:
- Periodic calibration recommended for maintaining analog output accuracy.
- Keep connectors clean and free from dust or oxidation.
- Ensure proper grounding and shielding to minimize electrical noise.
Firmware and Software Updates:
- Manufacturer may provide updated drivers and firmware to enhance performance or add compatibility with newer operating systems.
- Software development kits (SDKs) and APIs are typically available for integration into custom applications.
Service and Replacement:
- Replacement parts and accessories (connectors, cables, terminal boards) are available through authorized distributors.
- Field-replaceable design allows easy swap-out in case of hardware failure.
### Summary
The A-628 8-Channel 12-bit DA Card is a versatile and reliable analog output and digital I/O interface solution for industrial and laboratory applications. With its 8 double-buffered analog outputs, 16 digital inputs, and 16 digital outputs, it provides a balanced combination of precision, flexibility, and performance. The card’s 15 kS/s sampling rate, <70 µs update time, and selectable voltage/current output ranges make it suitable for a wide range of control and signal generation tasks.
Its IRQ-driven digital input capability, standard D-type and header connectors, and compact 198 × 123 mm form factor ensure easy integration into PC-based control systems. Designed to meet industrial standards for reliability and compliance, the A-628 delivers consistent performance in demanding environments, backed by manufacturer support, documentation, and software tools for seamless deployment and long-term operation.
Keine Manuals/Kataloge verfügbar.
Kein Zubehör vorhanden.
