Comprehensive Product Summary: ADLINK DAQBench ActiveX Controls

---

### 1. Product Overview

Product Name: DAQBench
Model: DAQBench ActiveX Controls
Series: NuDAQ / DAQBench Series
Article Number: DAQBench
Manufacturer: ADLINK Technology Inc.
Manufacturer Address: 9F, No. 166, Jian Yi Road, Chungho City, Taipei 235, Taiwan, R.O.C.
Website: [www.adlink.com.tw](http://www.adlink.com.tw)
Support Contacts:
- Sales & Service: service@adlink.com.tw
- Technical Support (NuDAQ): nudaq@adlink.com.tw
- Software Support: sw@adlink.com.tw

Product Type: 32-bit ActiveX control suite for measurement, automation, and data acquisition (DAQ) software development.
Manual Revision: 2.10 (November 20, 2000)

---

### 2. Key Features

- Comprehensive ActiveX Control Suite:
DAQBench provides a complete set of 32-bit ActiveX controls for measurement, automation, and data visualization. It supports ADLINK’s NuDAQ PCI cards and NuDAM modules, enabling rapid development of DAQ and control applications.

- Cross-Platform Development Support:
Fully compatible with Microsoft Visual Basic, Visual C++, and Delphi environments. Controls can be embedded in any ActiveX container application.

- User Interface Controls:
Includes DBoolean, DSlide, DKnob, D7Segment, DLEDMeter, DGraph, DChart, DXYGraph, DIntenGraph, and DIntenChart for real-time data display and control.

- Hardware Integration:
Provides NuDAQ PCI and NuDAM module controls for analog/digital I/O, counter/timer operations, and serial communication.

- Analysis Library:
Built-in DQAnalysis ActiveX control for mathematical and statistical operations, including FFT, matrix algebra, and signal processing.

- Information Integration Controls:
ExcelLinker, DBAccess, WebSnapshot, and OPCClient controls for seamless integration with Excel, ODBC databases, web servers, and OPC servers.

- Thermocouple Support:
Dedicated control for J-, K-, and T-type thermocouples with automatic voltage-to-temperature conversion.

- SCADA and MMI Development:
Equipment controls (Pump, Valve, Motor, Pipe, Tank) for industrial automation visualization.

- Remote Device Access (RDA):
Enables remote configuration and control of NuDAQ devices over a network.

- DDE/NetDDE Communication:
Built-in DDE client capability for data exchange with DDE servers and remote NetDDE communication.

---

### 3. Technical Specifications

System Requirements:
- Operating Systems: Windows 95/98/NT/2000
- Processor: 66 MHz 80486 or higher
- Memory: Minimum 32 MB RAM
- Disk Space: Minimum 10 MB free
- Display: VGA or higher
- Input Device: Microsoft-compatible mouse
- ActiveX Container: Visual Basic, Visual C++, or Delphi (32-bit versions)

Installed Components:
- ActiveX Controls:
Digital.ocx, Multiple.ocx, DBUI.ocx, DBGraph.ocx, NDDigital.ocx, NDAnalog.ocx, NDHost.ocx, NDCounter.ocx, DQAnalysis.ocx, DBEquip.ocx, ExcelLinker.ocx, DBAccess.ocx, WebSnapshot.ocx, OPCClient.ocx, Thermocouple.ocx
- Utilities:
DAQDevMgr.exe, NuDAQCfg.exe, RDASvr.exe, DAQCvt.exe
- Libraries:
VarPacker.dll, VarPacker.lib, VarPacker.h
- Documentation:
DAQBenchRef.hlp, DAQBenchRef.cnt

File Locations:
- OCX Files: `\DAQBench\OCX`
- Utilities: `\DAQBench\PCIDAQ`
- Samples: `\DAQBench\Samples\VB`, `\DAQBench\Samples\VC`
- Manuals: `\DAQBench\Manual`

---

### 4. Functionality

Primary Functions:
- Data acquisition, analysis, and visualization using ADLINK hardware.
- Rapid GUI development for measurement and automation systems.
- Integration with databases, spreadsheets, and web interfaces.

Use Cases:
- Industrial process monitoring and control (SCADA/MMI systems)
- Laboratory data acquisition and analysis
- Embedded test and measurement systems
- Remote device monitoring via OPC or NetDDE

Compatibility:
- Supports ADLINK NuDAQ PCI cards (e.g., PCI-7200, PCI-9112, PCI-9812)
- Supports NuDAM serial modules (e.g., ND-6011, ND-6050)
- Compatible with Microsoft Office (Excel), ODBC databases, and OPC servers.

---

### 5. Components & Accessories

Included Components:
- Full suite of ActiveX controls (.OCX files)
- NuDAQ configuration and RDA utilities
- Example projects for Visual Basic, Visual C++, and Delphi
- Analysis library and data conversion tools

Optional Add-ons:
- NuDAQ PCI hardware cards
- NuDAM serial I/O modules
- OPC servers from third-party vendors

Connectors & Interfaces:
- PCI bus interface for NuDAQ cards
- RS-232/RS-485 serial interface for NuDAM modules
- Ethernet/TCP-IP for RDA and NetDDE communication

---

### 6. Installation & Setup

Installation Steps:
1. Insert the ADLINK DAQBench CD and run `SETUP.EXE`.
2. Follow on-screen instructions to install ActiveX controls and utilities.
3. For Windows NT/2000, installation requires Administrator privileges.
4. After installation, launch the NuDAQ Configuration Utility (`NuDAQCfg.exe`) to register and configure hardware devices.

Configuration:
- Define local and remote devices using NuDAQCfg.
- Register device drivers and allocate buffer memory for continuous I/O.
- Configure RDA servers for network-based device access.

Development Environment Setup:
- Add DAQBench controls to the Visual Basic Toolbox or Visual C++ Component Gallery.
- Use Delphi’s “Import ActiveX Control” to load controls into the Component Palette.

---

### 7. Performance & Capabilities

Data Acquisition:
- Supports analog input/output, digital I/O, and counter/timer operations.
- Continuous and single-sample modes available.
- Stream-to-file capability for high-speed data logging.

Performance Metrics:
- Sampling rates up to 1 MS/s (depending on hardware)
- 8 to 32-bit digital I/O resolution
- 12- to 16-bit analog resolution

Efficiency:
- Optimized for real-time data visualization and control.
- Supports event-driven programming for responsive applications.

Limitations:
- 32-bit architecture (no native 64-bit support)
- Requires Windows-based ActiveX container
- Dependent on ADLINK hardware drivers

---

### 8. Standards & Compliance

Certifications:
- Compliant with Microsoft COM/ActiveX standards
- Supports OLE Automation and OPC (OLE for Process Control)
- Compatible with ODBC 2.0+ for database connectivity

Regulatory Compliance:
- CE and FCC compliance (hardware dependent)
- Software conforms to standard Windows API and COM guidelines

Industry Standards:
- OPC Foundation Client/Server model
- DDE/NetDDE communication protocols
- IEEE 488.2 (via supported hardware)

---

### 9. Additional Information

Warranty & Support:
- Standard ADLINK limited warranty (refer to product documentation)
- Technical support via email and online resources
- Software updates available through ADLINK’s website

Maintenance:
- Regular updates to maintain compatibility with new Windows versions
- Driver and firmware updates for NuDAQ hardware
- Backup configuration files and registry entries before upgrades

Documentation & Resources:
- User’s Guide and Function Reference Manuals (PDF/Help)
- Example source code for Visual Basic, Visual C++, and Delphi
- Online reference for properties, methods, and events

Distribution Guidelines:
- Redistribution of OCX and DLL files permitted under ADLINK’s licensing terms.
- Required files for deployment include OCX controls, support DLLs, and driver files.
- Registration of ActiveX components via `REGSVR32.EXE` is mandatory on target systems.

---

### Summary

DAQBench is a robust, modular ActiveX control suite designed by ADLINK Technology Inc. for developing high-performance measurement and automation applications. It integrates seamlessly with ADLINK’s NuDAQ and NuDAM hardware, providing developers with a unified environment for data acquisition, analysis, and visualization. With built-in support for OPC, DDE, and ODBC, DAQBench enables comprehensive system integration across industrial, laboratory, and enterprise environments. Its extensive library of user interface controls, analysis functions, and connectivity tools makes it an essential platform for engineers and developers building custom DAQ and SCADA solutions.
