1. Product Overview

Product Name: M-5360A-EV ARM Cortex A8 800MHz SoM Starter Kit
Model: M-5360A-EV
Series: M-5360-A i.MX53 Cortex A8 System-on-Module (SoM)
Article Number: M-5360A-EV
Manufacturer: Artila Electronics Co., Ltd.

The Artila M-5360A-EV is a complete industrial-grade System-on-Module (SoM) starter kit built around the Freescale i.MX537 ARM Cortex-A8 processor running at 800 MHz. Designed for embedded and industrial applications, it integrates a high-performance CPU, GPU, memory, and extensive I/O interfaces into a compact, fanless 3.5-inch form factor. The kit includes a development carrier board providing VGA, LVDS, USB, COM, Ethernet, and audio interfaces, making it ideal for rapid prototyping and deployment of embedded Linux, Android, or Windows Compact 7 systems.

---

2. Key Features

- Processor: Freescale i.MX537 ARM Cortex-A8, 800 MHz core frequency
- Memory: 1 GB DDR3 RAM (expandable to 2 GB optional)
- Storage: 4 GB eMMC Flash onboard
- Graphics: Integrated GPU supporting OpenGL ES 2.0, OpenVG 1.1, and full HD 1080p video decode
- Display Interfaces: Dual 24-bit LVDS channels and analog VGA output (up to 1920×1080 @ 60 Hz)
- Touchscreen Support: 4-wire resistive touchscreen interface
- Networking: 10/100 Mbps Ethernet (SMSC LAN8720AI PHY)
- Serial Interfaces:
- 2 × RS-232 (one full, one 4-wire)
- 1 × RS-485
- 2 × CAN 2.0 channels
- USB Connectivity:
- 4 × USB 2.0 Host ports
- 1 × USB OTG (Mini-AB)
- Expansion Interfaces: SATA, SD, SPI, I²C, I²S, 1-Wire, GPIO
- Power Input: 9–48 VDC wide-range input (5V and 3.3V internal rails)
- Operating Temperature: 0°C to +70°C
- Form Factor: 146 mm × 102 mm (3.5-inch board)
- Operating Systems Supported: Ubuntu Linux 10.4 (preinstalled), Android, Windows Compact 7.0
- Fanless Design: Passive cooling for industrial reliability

---

3. Technical Specifications

Processor:
- Freescale i.MX537 ARM Cortex-A8, 800 MHz
- Integrated NEON SIMD engine
- Hardware floating-point unit

Memory:
- 1 GB DDR3 SDRAM (optional 2 GB)
- 4 GB eMMC Flash storage

Display & Graphics:
- Dual 24-bit LVDS outputs (LVDS0 and LVDS1)
- Analog VGA output synchronized with LVDS0
- GPU supports OpenGL ES 2.0, OpenVG 1.1, and 1080p video decode

Audio:
- I²S digital audio interface
- Line-out and microphone-in 3.5 mm jacks

Networking:
- 10/100 Mbps Ethernet (SMSC LAN8720AI PHY)
- RJ45 connector with link/activity LEDs

Serial Communication:
- COM1: RS-232 (full signals: TX, RX, RTS, CTS, DCD, DSR, DTR, GND)
- COM2: RS-485 (D+, D–)
- COM3: RS-232 (TX, RX, RTS, CTS, GND)
- COM4: Serial console (TX, RX, GND)
- 2 × CAN 2.0B channels

USB:
- 4 × USB 2.0 Host ports (CN4, CN5)
- 1 × USB OTG (CN6, Mini-AB type)

Storage Interfaces:
- 1 × SATA port (CN16)
- 1 × MicroSD socket (CN7)

Expansion Interfaces:
- SPI (CN14)
- I²C (CN15)
- GPIO (CN13, 8 programmable lines)
- 1-Wire (CN18)

Power:
- Input: 9–48 VDC
- Internal rails: 5VDC and 3.3VDC
- Backup battery input (V_BAT)

Physical Dimensions:
- 146 mm × 102 mm (3.5-inch SBC form factor)
- Weight: Approx. 200 g (module + carrier)

Environmental:
- Operating Temperature: 0°C to +70°C
- Storage Temperature: –20°C to +85°C
- Humidity: 10–90% non-condensing

---

4. Functionality

The M-5360A-EV functions as a complete embedded computing platform. The SoM (M-5360-A) integrates the CPU, memory, and essential I/O controllers, while the included carrier board (M-5360-ST) exposes these interfaces through standard connectors.

Operation:
- The i.MX537 CPU executes embedded Linux or other supported OS directly from onboard eMMC or SD card.
- The GPU handles 2D/3D acceleration and video decoding for LVDS or VGA displays.
- The system supports touchscreen input via a 4-wire resistive interface.
- Communication interfaces (RS-232, RS-485, CAN) enable industrial control and automation connectivity.
- USB and Ethernet ports provide peripheral and network expansion.

Use Cases:
- Industrial HMI panels and control terminals
- Embedded data acquisition systems
- IoT gateways and protocol converters
- Digital signage and kiosk systems
- Edge computing and automation controllers

Compatibility:
- Compatible with Linux (Ubuntu 10.4 preinstalled), Android, and Windows Compact 7.
- Supports standard peripheral interfaces for sensors, displays, and communication modules.

---

5. Components & Accessories

Included in Starter Kit:
- M-5360-A SoM (i.MX537 Cortex-A8 module)
- M-5360-ST carrier/development board
- Preinstalled Ubuntu 10.4 Linux OS
- Power input terminal (9–48 VDC)
- Connectors for VGA, LVDS, USB, COM, Ethernet, Audio
- Touchscreen connector
- MicroSD slot
- Mounting holes and standoffs

Optional Accessories:
- LCD panels with LVDS interface
- Resistive touchscreen panels
- External battery for RTC backup
- SATA storage devices
- USB peripherals (keyboard, mouse, Wi-Fi dongle)

Connectors Overview:
- CN1–CN3: SoM B2B connectors
- CN4–CN6: USB host/device connectors
- CN7: MicroSD socket
- CN8/CN9: LCD backlight control (5V/12V options)
- CN10: Touchscreen interface
- CN11–CN14: COM, GPIO, SPI connectors
- CN15: I²C interface
- CN16: SATA connector
- CN17: CAN bus
- CN18: 1-Wire interface
- CN19/CN20: Audio (Line-out, Mic-in)
- CN21/CN12: LVDS display connectors
- CN22: VGA output (DB15)
- CN23: RS-485 port
- CN25: LAN (RJ45)
- CONSOLE1: Debug serial port
- DB9M1: COM1 RS-232 port

---

6. Installation & Setup

Power Requirements:
- Input voltage: 9–48 VDC via terminal block
- Internal regulation to 5V and 3.3V rails
- Optional backup battery connection for RTC

Mounting Options:
- 3.5-inch SBC form factor with mounting holes for enclosure or panel integration
- Fanless design suitable for sealed or industrial environments

Configuration:
- Boot from onboard eMMC or external MicroSD
- OS preinstalled (Ubuntu 10.4); user can reflash Android or Windows Compact 7
- Serial console (COM4) for bootloader and system configuration
- JP2 jumper for RS-485 termination (1–2 = 120Ω, 2–3 = none)

Display Setup:
- Connect LVDS or VGA display via CN12/CN21 or CN22
- Configure backlight voltage (5V or 12V) via CN8/CN9
- Adjust brightness and power control via DISP0_BRIGHTNESS and LCD_PWR_EN signals

Peripheral Setup:
- USB host ports (CN4, CN5) for keyboard, mouse, or storage
- USB OTG (CN6) for device mode or firmware update
- Ethernet (CN25) for network connectivity
- COM ports for serial communication
- CAN bus (CN17) for industrial networking

---

7. Performance & Capabilities

Processing Performance:
- 800 MHz ARM Cortex-A8 core with NEON SIMD acceleration
- Efficient for multimedia, control, and networking tasks

Graphics & Multimedia:
- Hardware-accelerated 2D/3D rendering
- Full HD 1080p video decode capability
- Dual LVDS and VGA outputs for flexible display configurations

Memory & Storage:
- 1 GB DDR3 ensures smooth multitasking
- 4 GB eMMC for OS and application storage
- Expandable via MicroSD or SATA storage

Networking & Communication:
- Reliable 10/100 Ethernet with integrated PHY
- Multiple serial ports for legacy and industrial devices
- Dual CAN 2.0B channels for automotive or automation networks

I/O Expansion:
- 8 GPIO lines for custom control or sensing
- SPI, I²C, and 1-Wire for peripheral expansion
- USB 2.0 host and OTG for external devices

Power Efficiency:
- Low power ARM architecture
- Wide input voltage range (9–48 VDC) for industrial power systems

Limitations:
- No native Gigabit Ethernet
- Limited to 1080p video output
- Operating temperature limited to 0–70°C (non-extended industrial range)

---

8. Standards & Compliance

Electrical & Interface Standards:
- USB 2.0 compliant (Host and OTG)
- RS-232/RS-485 serial communication standards
- CAN 2.0B protocol support
- SATA 2.0 interface
- I²C, SPI, I²S, and 1-Wire standard protocols
- LVDS and VGA video output standards

Regulatory Compliance:
- Designed for industrial EMC and safety standards (manufacturer dependent)
- RoHS compliant materials and lead-free manufacturing

Software Standards:
- Linux kernel and driver compatibility
- Android and Windows Compact 7 BSP support
- OpenGL ES 2.0 and OpenVG 1.1 graphics APIs

---

9. Additional Information

Warranty:
- Standard manufacturer warranty (typically 1 year, depending on region)

Technical Support:
- Documentation, schematics, and BSPs available from Artila Electronics
- Online resources for Linux, Android, and Windows CE development
- Serial console access for debugging and firmware updates

Maintenance:
- Fanless design minimizes mechanical wear
- Solid-state storage (eMMC) for reliability
- Optional RTC battery replacement

Software Updates:
- OS images and firmware updates available via USB OTG or SD card
- Open-source Linux BSP for customization
- Support for kernel and driver updates

Summary:
The Artila M-5360A-EV ARM Cortex-A8 SoM Starter Kit provides a robust, feature-rich platform for embedded system developers. Combining the Freescale i.MX537 processor with comprehensive I/O, multimedia, and networking capabilities, it serves as an ideal foundation for industrial automation, HMI, and IoT applications. Its modular SoM + carrier architecture allows rapid prototyping and easy transition to production hardware, while its support for multiple operating systems ensures flexibility across diverse embedded environments.

---
