- **Galvanic Isolation:** Provides complete electrical isolation between input, output, and control circuits to prevent ground loops and protect sensitive equipment. - **Relay Multiplexing:** Integrated relay matrix allows multiple input channels to be switched to a single output or vice versa, enabling efficient signal routing and channel expansion. - **Precision Amplification:** Built‑in low‑noise amplifier stages support signal conditioning for voltage, current, or sensor‑level inputs. - **Wide Signal Compatibility:** Supports analog and digital signals, including voltage ranges from millivolts to ±10 V and current loops up to 20 mA. - **High Channel Density:** Typically supports 8, 16, or 32 channels per board (depending on configuration). - **Modular Design:** Stackable or rack‑mountable for scalable system integration. - **Industrial‑Grade Relays:** Long‑life electromechanical or solid‑state relays rated for millions of switching cycles. - **Low Crosstalk and Noise:** Optimized PCB layout and shielding minimize interference between channels. - **Status Indicators:** On‑board LEDs for relay state, power, and fault indication. - **Flexible Control Interface:** TTL, RS‑485, or USB control options for integration with PLCs, DAQs, or embedded controllers. - **Overvoltage and Surge Protection:** Built‑in transient suppression for enhanced durability. - **Compact Form Factor:** Designed for DIN‑rail or panel mounting in control cabinets.

Manufacturer: Adlink Technology Inc.

Category: OEM Add On Cards

- **Purpose‑Built LabVIEW Integration:** PCIS‑LView provides a seamless interface between National Instruments LabVIEW (v4.0 or later) and ADLINK’s NuDAQ PCI and NuIPC CompactPCI DAQ hardware. It enables direct access to ADLINK’s PCIS‑DASK driver functions through LabVIEW virtual instruments (VIs). - **Cross‑Platform Driver Support:** Compatible with multiple Microsoft Windows operating systems—Windows 95, 98, NT 4.0, and 2000—ensuring broad deployment flexibility in legacy and industrial environments. - **Comprehensive Hardware Coverage:** Supports a wide range of ADLINK PCI and CompactPCI DAQ cards, including analog input/output, digital I/O, counter/timer, and multifunction boards (e.g., PCI‑6208, PCI‑7200, PCI‑7230, PCI‑9112, PCI‑9812, etc.). - **Plug‑and‑Play Hardware Detection:** Fully utilizes Windows Plug and Play for automatic device recognition and resource allocation (I/O ports, IRQs). - **Integrated Configuration Utility:** Includes the **NuDAQ PCI Configuration Utility (PciUtil)** for driver registration, buffer allocation, and continuous I/O memory management. - **Unified Software Architecture:** Works in conjunction with **PCIS‑DASK** (Dynamic‑Link Library driver) and **PCIS‑VEE** (HP VEE interface) to provide a consistent API across programming environments. - **Extensive Documentation and Examples:** Ships with PDF manuals, online help, and sample LabVIEW VIs for each supported card type. - **Backward Compatibility:** Maintains support for older LabVIEW versions (≥4.0) and legacy Windows systems, ensuring long‑term usability in industrial automation setups.

Manufacturer: Adlink Technology Inc.

Category: ADLink Driver, Software

- **Comprehensive LabVIEW Integration:** Provides complete VI libraries (ALV.LLB and 8316.LLB) for all supported NuDAQ ISA‑bus cards, enabling direct access to analog input/output, digital I/O, and timing functions. - **Broad Hardware Support:** Compatible with a wide range of ADLINK ISA cards, including: - **Analog Input (AD):** ACL‑8111, ACL‑8112DG/HG/PG, ACL‑8113, ACL‑8216 - **Analog Output (DA):** ACL‑6126, ACL‑6128 - **Digital I/O (DIO):** ACL‑7120, ACL‑7122, ACL‑7124, ACL‑7125, ACL‑7225, ACL‑7130, PET‑48DIO - **High‑Performance DAS:** ACL‑8316/8312 - **Full VI Functionality:** Includes configuration, analog input/output, digital I/O, and timer/counter function groups. Each VI is designed for modular use within LabVIEW block diagrams. - **Continuous and One‑Shot Data Acquisition:** Supports both single‑shot and continuous analog input modes using interrupt or DMA transfer. - **Error Handling and Diagnostics:** Built‑in error codes and range validation ensure robust operation and simplified debugging. - **Sample Programs and Documentation:** Includes sample LabVIEW projects for each supported card, PDF manuals, and online help files for quick deployment. - **Backward Compatibility:** Supports legacy Windows operating systems and early LabVIEW versions, ensuring compatibility with existing industrial and laboratory setups.

Manufacturer: Adlink Technology Inc.

Category: ADLink Driver, Software

- **Comprehensive Linux Driver Support:** PCIS-DASK/X provides full Linux kernel module support for ADLINK’s NuDAQ PCI and NuIPC CompactPCI DAQ cards, enabling analog input/output, digital I/O, and counter/timer operations. - **Shared Library Architecture:** Includes a shared library (`libpci-dask.so`) for user-space applications, offering a consistent API for C/C++ programming under Linux. - **Kernel Module Integration:** Provides loadable kernel modules for each supported DAQ card, ensuring efficient communication between user applications and hardware. - **Automatic Device Detection:** Utilizes PCI bus architecture for automatic detection of NuDAQ PCI devices, simplifying installation and configuration. - **High-Performance Data Transfer:** Supports DMA (Direct Memory Access) and interrupt-driven data transfer for high-speed continuous data acquisition and output. - **Memory Management:** Includes high-memory management modules for contiguous memory allocation, essential for continuous analog or digital operations. - **Cross-Platform Consistency:** Maintains API compatibility with Windows versions of PCIS-DASK, allowing easy migration of applications between Windows and Linux. - **Extensive Hardware Compatibility:** Supports a wide range of ADLINK PCI and CompactPCI cards, including analog, digital, and multifunction DAQ boards such as PCI-6208, PCI-7200, PCI-9112, PCI-9812, and others. - **Sample Programs and Documentation:** Includes example source code, PDF manuals, and configuration utilities to accelerate development and deployment.

Manufacturer: Adlink Technology Inc.

Category: ADLink Driver, Software

- **Full IEEE‑488.1 and IEEE‑488.2 Compliance:** Ensures compatibility with all standard GPIB instruments and controllers. - **High‑Speed Data Transfer:** Achieves up to **1.5 MB/s** GPIB transfer rate using block transfer mode. - **On‑Board FIFO Buffer:** 1 KB FIFO memory buffers read/write operations, bridging the speed gap between the GPIB bus (~1.5 MB/s) and the PCI bus (132 MB/s). - **Dual Voltage PCI Support:** Operates on both **3.3 V and 5 V** PCI buses for broad system compatibility. - **Low‑Profile Design:** Conforms to MD1 low‑profile PCI mechanical specifications (120 mm × 64.5 mm). - **Software Compatibility:** Binary‑compatible with **NI‑488.2** driver API (GPIB‑32.DLL) and supports **VISA** libraries for seamless integration with existing applications. - **Wide ADE Support:** Compatible with **Microsoft Visual C++**, **Visual Basic**, **Delphi**, **NI LabVIEW**, **NI LabWindows/CVI**, and **Agilent TestExec**. - **Plug‑and‑Play Configuration:** Automatic resource allocation via PCI BIOS; no jumper or DIP switch settings required. - **Interactive Diagnostic Utility:** ADLINK GPIB Utility for testing, configuration, and communication verification. - **Robust Environmental Tolerance:** Operates from 0 °C to 55 °C; storage from −20 °C to 80 °C. - **Regulatory Compliance:** Certified to **CE** and **FCC Class A** EMC/EMI standards.

Manufacturer: Adlink Technology Inc.

Category: IEEE (GPIB) Cards

- **PCI Local Bus Specification Compliance:** Fully compliant with PCI Local Bus Specification Revision 2.2 and PCI‑to‑PCI Bridge Architecture Specification Revision 1.2. - **Full Bandwidth Extension:** Supports 32‑bit/33 MHz PCI operation, delivering up to 132 MB/s throughput. - **StarFabric Serial Link Technology:** Employs a 5 Gbps serial link (4 × 622 Mbps LVDS pairs) for high‑integrity, low‑latency data transmission. - **Hardware/Software Transparency:** Appears to the host system as a local PCI bus; no additional drivers or software required. - **Robust Connectivity:** Utilizes a 24‑pin DVI‑D connector and shielded twisted‑pair copper cabling for reliable signal quality. - **Extended Distance:** Supports cable lengths up to 10 m between host and extension chassis. - **Multi‑Chassis and Star Topology Support:** Enables multi‑chassis configurations and star‑fabric architectures for scalable PCI expansion. - **Industrial‑Grade Design:** Suitable for industrial automation, test and measurement, aerospace, and video capture applications. - **Power Efficiency:** Low power consumption (+5 V @ 190 mA, +3.3 V @ 250 mA). - **Operating Environment:** 0 °C – 50 °C operating range, 10 – 90 % RH non‑condensing.

Manufacturer: Adlink Technology Inc.

Category: Bus Extensions

- **Full IEEE-488.1 and IEEE-488.2 Compliance:** Ensures interoperability with a wide range of GPIB instruments and systems. - **PCI Express 1.1 Interface:** Provides high-speed, low-latency communication with host systems. - **High Data Transfer Rate:** Supports up to 1.2 MB/s GPIB data transfer rate for the LPCIe-3488A model. - **Onboard FIFO Buffer:** 2 kB FIFO memory for efficient read/write operations and reduced CPU overhead. - **Software Compatibility:** Fully compatible with National Instruments NI-488.2 driver APIs and VISA library, ensuring seamless integration with existing applications. - **Plug-and-Play Configuration:** Automatic resource allocation via PCIe bus; no manual jumper or switch settings required. - **Interactive Diagnostic Utility:** ADLINK GPIB Utility software for testing, configuration, and troubleshooting. - **Wide Software Support:** Compatible with Visual Studio .NET, Borland C++ Builder, LabVIEW™, MATLAB®, and Delphi environments. - **Low-Profile Form Factor:** Compact design suitable for industrial and desktop PCs with limited space. - **Environmental Compliance:** RoHS and WEEE compliant, reflecting ADLINK’s commitment to environmental responsibility. - **EMC/EMI Certification:** CE and FCC Class A certified for electromagnetic compatibility.

Manufacturer: Adlink Technology Inc.

Category: IEEE (GPIB) Cards

- **IEEE‑488.1/488.2 Compliance:** Fully compatible with both hardware and software GPIB standards. - **High Data Throughput:** Supports data transfer rates up to **1.5 MB/s** in programmed I/O mode. - **Low‑Profile PCI Form Factor:** MD1‑compliant PCB (120 mm × 64 mm) suitable for compact industrial and desktop systems. - **Dual Voltage PCI Support:** Operates on **3.3 V or 5 V PCI buses**, ensuring broad system compatibility. - **On‑Board FIFO Buffer:** 2 kB FIFO for read/write operations to bridge the speed gap between the GPIB bus (~1.5 MB/s) and PCI bus (132 MB/s). - **Software Compatibility:** Binary‑compatible with **NI‑488.2** driver software and supports **VISA** library for seamless integration with existing instrument drivers. - **Plug‑and‑Play Configuration:** Automatic resource allocation via PCI BIOS; no jumper or DIP switch settings required. - **Interactive Diagnostic Utility:** ADLINK GPIB Utility for testing, configuration, and troubleshooting. - **Wide ADE Support:** Compatible with **Microsoft Visual Studio (VC++/VB/.NET)**, **Borland C++ Builder**, **Delphi**, **NI LabVIEW™**, **LabWindows/CVI™**, **Agilent TestExec**, and **MATLAB®**. - **Multi‑Instrument Control:** Supports up to **14 instruments** connected in linear, star, or hybrid topologies. - **Industrial‑Grade Reliability:** CE and FCC Class A certified for EMC/EMI compliance. - **Operating System Support:** Windows XP, Windows 7/8 (x86/x64).

Manufacturer: Adlink Technology Inc.

Category: IEEE (GPIB) Cards

- **Four 32‑bit Quadrature Encoder Channels:** Each channel supports 1×, 2×, or 4× A/B phase decoding, CW/CCW, and OUT/DIR pulse modes. - **High‑Speed Encoder Input:** Up to 18 MHz input frequency in 4× A/B mode ensures accurate position tracking for high‑speed motion systems. - **High‑Speed Trigger Output:** Four independent trigger outputs capable of up to 4.4 MHz output frequency. - **Programmable Trigger Pulse Width:** Adjustable from 0.1 µs to 3.2765 ms for flexible timing control. - **Multiple Output Interfaces:** TTL output, 5–24 V open‑collector output, and differential output interfaces for broad device compatibility. - **14 Built‑in 32‑bit Comparators:** Enable complex position comparison and multi‑trigger mapping functions. - **FIFO and Linear Comparison Modes:** 1,023‑point FIFO per channel and 10 linear comparison functions for continuous or patterned triggering. - **Optical Isolation:** 2,500 VRMS isolation for selected I/O signals ensures noise immunity and system protection. - **Flexible Trigger Modes:** Manual, linear, table, and timer‑based triggering supported. - **Software Tools:** Includes ADLINK’s TriggerMaster configuration utility and comprehensive Windows driver and API library. - **Board Index Switch:** Hardware switch for unique board identification in multi‑card systems (up to 16 cards). - **Low‑Profile PCIe Design:** Compact 151 mm × 67 mm PCB suitable for space‑constrained industrial PCs.

Manufacturer: Adlink Technology Inc.

Category: Motion Control / EtherCAT PCIe

- **Full MATLAB Integration:** Seamless compatibility with MATLAB 6.5 or later and MATLAB Data Acquisition Toolbox 2.2 or later. - **Unified Command Interface:** Uses standard MATLAB DAQ Toolbox commands (`analoginput`, `analogoutput`, `digitalio`, `addchannel`, `getdata`, `putdata`, etc.), ensuring minimal learning curve. - **Comprehensive Hardware Support:** Supports a wide range of ADLINK PCI, PXI, and CompactPCI DAQ cards. - **Analog and Digital I/O Control:** Enables acquisition and generation of analog signals and manipulation of digital I/O lines. - **Triggering and Synchronization:** Supports multiple trigger types (Immediate, Manual, Software, Hardware Digital, Hardware Analog Channel, Hardware Analog Pin) and conditions (Rising, Falling, AboveHigh, BelowLow, etc.). - **Flexible Sampling:** Adjustable sample rates and sample counts per trigger, with automatic hardware‑based rate adjustment. - **Hardware Abstraction:** Provides a unified software layer for all ADLINK DAQ hardware, simplifying code portability. - **Example Scripts:** Includes MATLAB examples for analog input/output and digital I/O operations, including continuous waveform capture and hardware‑triggered acquisition. - **Cross‑Platform Hardware Detection:** Automatically detects installed ADLINK DAQ devices via `daqhwinfo('mwadlink')`. - **Robust Error Handling:** Built‑in MATLAB error reporting for unsupported configurations or timeout conditions.

Manufacturer: Adlink Technology Inc.

Category: ADLink Driver, Software

- **PXI Specification Compliance:** Fully compliant with PXI Specifications Rev. 2.2 and CompactPCI standards (PICMG 2.0 R3.0 and PICMG 2.1 R2.0 Hot‑Swap). - **Flexible Matrix Configuration:** Supports multiple matrix topologies selectable via the TB‑6231‑01 terminal board: - One 4×8 matrix - Two 4×4 matrices - One 2×16 matrix - Two 2×8 matrices - Four 2×4 matrices - **High‑Performance Relay Array:** Up to 32 cross‑point DPDT (2 Form C) non‑latching relays for 2‑wire switching. - **Electrical Ratings:** - 2 A switching and 2 A carrying current - 220 V DC / 125 V AC maximum switching voltage - 60 W maximum switching power - **Deterministic Scanning:** Onboard 1 k‑sample scan list for deterministic relay sequencing. - **Synchronization:** Handshaking signals and PXI trigger bus/star trigger support for multi‑module synchronization. - **Safety Functions:** Hardware emergency shutdown and programmable watchdog timer (1 ms – 420 s). - **Auxiliary Digital I/O:** Eight 3.3 V/TTL I/O channels (5 V tolerant) for general‑purpose control. - **Software Programmability:** Fully software‑controlled relay configuration and scan sequencing. - **Operating System Support:** Windows Vista/XP/2000/2003. - **Software Tools:** Compatible with VB, VC++, BCB, Delphi, and DAQBench; driver support via ADL‑SWITCH for Windows. - **Safety‑Critical Design:** Includes programmable relay safety states and watchdog protection for industrial reliability.

Manufacturer: Adlink Technology Inc.

Category: High Density Panels

- **Processor Support:** Compatible with 8th and 9th Generation Intel® Core™ i7, i5, and i3 CPUs (LGA1151 socket), offering up to 8 cores and 12 threads depending on model. - **GPU Acceleration:** Supports NVIDIA® Quadro® PEG cards, including P2200, P4000, P5000, RTX 4000, RTX 5000, RTX 6000, and RTX 8000, enabling advanced AI inference and deep learning workloads. - **Memory Capacity:** Dual SO-DIMM slots supporting up to 32GB DDR4 non-ECC memory at 2666/2400 MHz (dependent on CPU). - **Display Outputs:** Integrated 1x DVI, 1x HDMI, and 1x DisplayPort from CPU graphics, with additional outputs available from installed PEG cards. - **Expansion Options:** 1x Mini PCIe slot for Wi-Fi/Bluetooth or LTE modules and 1x M.2 M-key slot supporting 2280 SATA SSD modules. - **Storage Flexibility:** Two internal 2.5" SATA 6Gb/s drive bays plus one SATA 6Gb/s signal via M.2 M-key slot. - **Power Supply Options:** Available with 300W, 400W, or 500W Flex ATX power supplies to accommodate various GPU configurations. - **Software Compatibility:** Supports Windows 10 IoT Enterprise CBB 64-bit and Ubuntu 16.04 LTS operating systems. - **Industrial Reliability:** Operating temperature range from 0°C to 50°C (model-dependent), with compliance to EMC and safety standards (EN55032/EN55035, UL/cUL, CB, CCC). - **Compact Design:** Mini-ITX chassis with dimensions of 220 x 300 x 150 mm (W x D x H), optimized for embedded and edge deployments.

Manufacturer: Adlink Technology Inc.

Category: Inference & Deep Learning

- **Modular Architecture:** Expandable enclosure supporting one PMC module and up to three PC/104+ modules for functional scalability. - **Fanless Low-Power Design:** Optimized for embedded and industrial environments where silent operation and reliability are critical. - **Compact Front-Access Enclosure:** Dimensions of 183 × 144 × 110 mm, with an additional 16.8 mm height per extension kit. - **Multiple CPU Options:** - NS Geode GX1 300 MHz (GEME-1000) - Intel Ultra Low Voltage Celeron 650 MHz (GEME-2000/V2000) - Intel Low Voltage Pentium III 800 MHz (GEME-3000/V3000) - **Integrated Graphics:** On-board VGA controllers with 2D or 3D acceleration, supporting resolutions up to 1600 × 1200. - **Comprehensive I/O:** Dual COM ports (RS-232/422/485), parallel port, PS/2 keyboard/mouse, USB, Ethernet, IDE, CompactFlash, and floppy interfaces. - **Hardware Monitoring:** Built-in Winbond monitoring ICs for voltage, temperature, and battery status. - **Wide OS Compatibility:** Supports Windows CE, Windows XP Embedded, and Linux. - **Industrial-Grade Power Supply:** Universal AC input (100–220 VAC) with regulated DC outputs (+5V, +12V, -12V). - **Ruggedized Construction:** Designed for wall mounting and operation in environments with 0–90% humidity and temperatures up to 55°C.

Manufacturer: Adlink Technology Inc.

Category: IPC Embedded System

- **Low Power, Fanless Design:** Utilizes the NS GeodeGX1 300 MHz CPU, known for its low power consumption and minimal heat generation, enabling fanless operation for silent and maintenance-free performance. - **Compact Modular Architecture:** The system’s modular design allows integration of additional functional modules via PC/104 and PMC interfaces, supporting flexible system expansion. - **Integrated Graphics Controller:** Built-in 2D VGA accelerator supporting resolutions up to 1280 × 1024 at 85 Hz, with shared video memory configurable from 1 MB to 4 MB. - **Comprehensive I/O Connectivity:** Includes dual serial ports (RS-232/422/485), parallel port, PS/2 keyboard/mouse, USB 1.0, Ethernet (10/100Base-TX), IDE, CompactFlash, and floppy interfaces. - **Hardware Monitoring and Watchdog Timer:** Integrated Winbond W83781D hardware monitor tracks CPU temperature, voltage, and battery levels. A programmable watchdog timer ensures system reliability in unattended operation. - **Industrial-Grade Reliability:** Designed for continuous operation in environments with temperature ranges from 0°C to 55°C and humidity up to 90%. - **Flexible Storage Options:** Supports internal 2.5" HDD, Disk-on-Chip (DOC), and external IDE/FDD interfaces, as well as CompactFlash Type I storage. - **Operating System Compatibility:** Supports Windows CE, Windows XP Embedded, and Linux, providing flexibility for various embedded software stacks.

Manufacturer: Adlink Technology Inc.

Category: IPC Embedded System

- **Ultra‑Low Voltage CPU:** Intel Celeron 650 MHz processor with 256 KB on‑die Advanced Transfer Cache (ATC). - **Fanless Operation:** Passive cooling design ensures silent, maintenance‑free operation. - **Low Power Consumption:** Optimized for embedded and industrial environments requiring energy efficiency. - **Integrated SBC:** EBC‑C200 single‑board computer with Intel 815E AGP chipset. - **Expandable Architecture:** Supports one PMC (PCI Mezzanine Card) and up to three PC/104 modules for motion control, vision, DIO, communication, and high‑speed link applications. - **Comprehensive I/O:** VGA, USB 1.1/2.0, Ethernet, COM ports, IEEE 1394, CompactFlash, IDE, FDD, GPIO, and parallel interfaces. - **Rugged Design:** Compact aluminum chassis with wall‑mounting kit; vibration‑resistant and suitable for industrial deployment. - **Wide Power Input Range:** AC 100–220 V or DC 10–30 V input options. - **Operating System Support:** Windows CE, Windows XP Embedded, and Linux. - **Integrated Watchdog Timer:** Programmable 0–255 s or 0–255 min timeout for system reliability. - **Hardware Monitoring:** Winbond W83627HF monitors CPU temperature and voltage rails (+3.3 V, +5 V, +12 V). - **High‑Resolution Graphics:** On‑board AGP VGA controller supporting up to 1600 × 1200 @ 85 Hz with Intel Dynamic Video Memory Technology (DVMT). - **Industrial‑Grade Reliability:** Designed for 24/7 operation under ‑10 °C to 55 °C and 0–90 % humidity.

Manufacturer: Adlink Technology Inc.

Category: IPC Embedded System

- **Low‑Power, Fanless Design:** Utilizes a low‑voltage Pentium III 800 MHz CPU for silent, energy‑efficient operation in embedded environments. - **Integrated Embedded SBC:** Based on ADLINK EBC‑P300 SBC with Intel 815E chipset and 512 KB on‑die Advanced Transfer Cache. - **Compact, Rugged Enclosure:** 183 × 140 × 95.36 mm aluminum chassis with wall‑mounting kit; designed for industrial reliability. - **Modular Expandability:** Supports one PMC (PCI Mezzanine Card) and up to three PC/104 expansion modules for motion control, vision, digital I/O, communication, or high‑speed link applications. - **Comprehensive I/O:** Dual COM ports, parallel port, VGA, Ethernet, USB 1.1/2.0, IEEE 1394, CompactFlash, IDE, floppy, and GPIO interfaces. - **Vision‑Ready Variants:** GEME‑V3000 and GEME‑X3000 include Conexant Fusion 878A video decoder for 4‑channel NTSC/PAL input. - **Wide Power Options:** Available with universal AC (100–220 VAC) or DC (10–30 VDC) power supply modules. - **Operating System Support:** Windows CE, Windows XP Embedded, and Linux. - **High Reliability:** Fanless operation, wide temperature range (–10 °C to 55 °C), and vibration tolerance per IEC 68‑2‑64. - **Integrated Watchdog Timer:** Programmable 0–255 s or 0–255 min timeout for system reliability.

Manufacturer: Adlink Technology Inc.

Category: IPC Embedded System

- **Purpose‑built for PXI‑7921:** Provides direct connection to the PXI‑7921’s 62‑pin D‑Sub male I/O connector. - **Multiple Multiplexer Configurations:** Supports 48×1 1‑wire, 24×1 2‑wire, 12×1 4‑wire, two 12×1 2‑wire, or four 6×1 2‑wire configurations. - **High‑Density Connectivity:** Accommodates up to 24 DPDT (2 Form C) relay channels through a single 62‑pin interface. - **Screw‑Terminal Interface:** Simplifies field wiring and reconfiguration for laboratory and industrial applications. - **Software‑Selectable Switching:** All channel configurations are controlled via software through the PXI‑7921 module. - **Safety and Reliability:** Designed for safety‑critical applications with support for emergency shutdown and watchdog timer functions through the PXI‑7921. - **PXI System Integration:** Fully compatible with PXI specifications Rev. 2.2 and CompactPCI (PICMG 2.0 R3.0). - **Hot‑Swap Support:** When used with PXI‑7921, supports CompactPCI Hot‑Swap (PICMG 2.1 R2.0). - **Deterministic Scanning:** Enables deterministic relay sequencing through the PXI‑7921’s onboard 1 k‑sample scan list. - **Synchronization:** Supports PXI trigger bus and star trigger synchronization for multi‑module systems.

Manufacturer: Adlink Technology Inc.

Category: High Density Panels

- **Dual 32‑bit Counter/Frequency Inputs:** Two independent channels capable of counting up to 4,294,967,295 pulses each, supporting both counter and frequency measurement modes. - **High‑Speed Input Capability:** Maximum input frequency of **20 kHz** (typical) with minimum pulse width of **> 5 µs**, ensuring accurate detection of fast pulse trains. - **Frequency Measurement Range:** Programmable from **1 Hz to 20 kHz**, with built‑in gate times of **0.1 s or 1 s** for flexible resolution and response trade‑offs. - **Programmable Digital Filter:** Adjustable high‑ and low‑level minimum signal width (4 µs – 1.02 ms) for noise suppression and signal conditioning. - **Selectable Input Modes:** Supports **photo‑isolated** or **TTL (non‑isolated)** input operation. - Isolated mode: 5000 Vrms isolation, logic 0 ≤ 1 V, logic 1 = 3.5 – 30 V. - Non‑isolated mode: programmable thresholds (default = 0.8 V low, 2.4 V high). - **External Gate Control:** Each counter channel includes an external gate input for enabling/disabling counting or synchronizing with external events. - **Alarm and Comparator Functions:** Independent programmable alarm limits for each counter. When enabled, alarms can drive the digital outputs to activate external indicators or relays. - **Dual Digital Outputs:** Two open‑collector outputs (30 V max, 30 mA sink) configurable as alarm outputs or general‑purpose digital outputs. - **High Isolation and Noise Immunity:** 5000 Vrms isolation between field inputs and communication circuitry, with internal watchdog and EMI‑shielded ABS enclosure. - **RS‑485 Communication Interface:** Two‑wire, half‑duplex, multi‑drop network supporting up to 256 addressable modules at baud rates from **1200 bps to 115.2 kbps**. - **Programmable Watchdog Timers:** - **Module internal watchdog:** 150 ms automatic reset on internal fault. - **Host watchdog:** 100 ms – 25.5 s programmable timeout with safe‑state output. - **Software‑Configurable Parameters:** Input mode, gate mode, filter enable, threshold levels, alarm limits, and output states are all programmable via ASCII command set. - **Industrial‑Grade Design:** Compact, DIN‑rail or panel‑mountable ABS housing with screw‑terminal connectors for secure field wiring.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Three RTD Input Channels:** Supports simultaneous measurement on three independent RTD sensors. - **RTD Compatibility:** Accepts Pt‑100, Ni‑100, and Ni‑120 sensors with selectable α coefficients (0.00385 or 0.003916). - **Flexible Wiring:** Configurable for 2‑wire, 3‑wire, or 4‑wire RTD connections to compensate for lead resistance. - **High Accuracy:** ±0.05 % to ±0.1 % of full‑scale range, depending on configuration. - **High Resolution:** 16‑bit A/D conversion for precise temperature readings. - **Sampling Rate:** 10 samples per second per channel. - **Electrical Isolation:** 2500 V RMS isolation between input and communication circuits for noise immunity and safety. - **RS‑485 Communication:** Two‑wire, half‑duplex, multi‑drop network supporting up to 256 addressable modules. - **Programmable Parameters:** Input type, temperature range, baud rate, and data format configurable via ASCII commands. - **Watchdog Protection:** Internal watchdog timer for device self‑recovery and host watchdog for fail‑safe operation. - **Industrial Design:** Compact ABS enclosure with screw‑terminal connectors for easy installation. - **Power Flexibility:** Operates from unregulated +10 V DC to +30 V DC supply. - **Low Power Consumption:** Typical 0.696 W. - **Software Support:** Fully supported by NuDAM Administration Utility for configuration, calibration, and monitoring.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Dual‑function I/O:** Four relay outputs (two Form A and two Form C) and four optically isolated digital inputs. - **RS‑485 Communication:** Two‑wire, half‑duplex serial interface supporting up to 115.2 kbps for long‑distance, multi‑drop networking. - **High Isolation:** 1000 Vrms isolation between relay contacts and coil; 750 Vrms between open contacts. - **Programmable Watchdog:** Hardware and host‑programmable watchdog timers ensure safe output states during communication or power failures. - **Industrial Reliability:** Designed for harsh environments with noise immunity, surface‑coated PCB, and wide power input range (+10 V DC – +30 V DC). - **Flexible Mounting:** DIN‑rail or panel mounting with screw‑terminal connectors for field wiring. - **ASCII Command Protocol:** Simple, printable‑character command/response structure for easy integration with PCs, PLCs, or embedded controllers. - **Network Expandability:** Up to 256 addressable modules on a single RS‑485 bus; 128 per segment without repeaters. - **Compact, Rugged Design:** ABS enclosure with internal EMI shielding and conformal coating for humidity and chemical resistance.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Eight AC Relay Outputs:** Provides eight independent Form‑A (normally open) relay channels for switching AC or DC loads. - **High Load Capacity:** Each relay contact rated at **3 A @ AC 250 V** or **3 A @ DC 30 V**, suitable for controlling solenoids, lamps, contactors, or other actuators. - **RS‑485 Communication Interface:** Two‑wire, half‑duplex differential interface supporting multi‑drop networking of up to 128 modules per segment and 256 addressable modules per network. - **High Isolation Voltage:** 2000 Vrms isolation between relay coil and contact; 1000 Vrms between open contacts, ensuring electrical safety and noise immunity. - **Programmable Watchdog Timers:** - **Module internal watchdog (150 ms)** for self‑recovery on firmware failure. - **Host‑programmable watchdog (100 ms – 25.5 s)** to force outputs to a predefined safe state if host communication is lost. - **Safety and Reliability:** - Power‑failure detection threshold at 4.65 V. - User‑defined safe output values on host failure. - Expected relay life: 10⁵ operations at rated load or 2 × 10⁷ operations no‑load. - **Ease of Integration:** ASCII‑based command/response protocol compatible with any host computer or PLC supporting serial communication. Supported baud rates: 1200 – 115.2 kbps. - **Industrial‑Grade Construction:** Compact ABS enclosure with conformal‑coated PCB for resistance to humidity, dust, and chemical exposure. - **Simple Installation:** Screw‑terminal connectors for field wiring; DIN‑rail or panel mounting options.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Eight Analog Input Channels:** Six differential and two single‑ended inputs for flexible signal connection. - **Wide Input Range:** Programmable voltage ranges of ±10 V, ±5 V, ±1 V, ±500 mV, ±150 mV, and current measurement from 0 to 20 mA (via external 125 Ω resistor). - **High Resolution:** 16‑bit A/D conversion ensures precise signal acquisition. - **Sampling Rate:** 10 samples per second per channel, suitable for slow‑to‑medium dynamic signals. - **Electrical Isolation:** 5000 Vrms isolation between analog input circuitry and communication/power sections for robust noise immunity and protection against ground loops. - **RS‑485 Communication Interface:** Two‑wire, half‑duplex serial interface supporting baud rates from 1200 bps to 115.2 kbps. - **ADAM‑4017 Compatibility:** Fully compatible with ADAM‑4017 command set and wiring, simplifying integration into existing systems. - **Programmable Host Watchdog Timer:** Provides automatic fail‑safe output in case of host communication failure. - **Internal Watchdog:** Monitors module operation and resets automatically upon internal fault detection. - **Compact Industrial Design:** DIN‑rail or panel‑mountable ABS enclosure with screw‑terminal connectors for secure wiring. - **Software Configurable:** All parameters—input range, baud rate, data format, and address—are programmable via ASCII commands. - **Ease of Integration:** Operates as a slave device in a multi‑drop RS‑485 network of up to 256 modules.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Eight Form A Relay Outputs:** Each channel provides an independent normally‑open contact for switching AC or DC loads. - **Relay Ratings:** – 0.5 A @ 125 VAC (max) – 1 A @ 30 VDC (max) - **RS‑485 Communication Interface:** Two‑wire, half‑duplex differential bus supporting up to 115.2 kbps and 4000 ft (1200 m) transmission distance. - **Multi‑Drop Networking:** Up to 128 modules per bus segment, 256 modules total with repeaters. - **ASCII Command/Response Protocol:** Simple printable‑character protocol for configuration and control, compatible with most programming languages. - **Programmable Host Watchdog Timer:** Ensures safe output state if host communication fails; timeout adjustable from 100 ms to 25.5 s. - **Internal Hardware Watchdog:** 150 ms device‑level supervisor resets the module automatically on internal fault. - **Optical Isolation:** 2500 Vrms (min) isolation between logic and field circuits for industrial safety. - **High Noise Immunity:** EMI‑shielded ABS enclosure with internal conductive coating and conformal‑coated PCB for harsh environments. - **DIN‑Rail or Panel Mounting:** Compact, rugged housing with screw‑terminal connectors for quick installation. - **Software‑Configurable Address and Baud Rate:** Default ID = 01 (Hex), 9600 bps; configurable via RS‑485 commands or NuDAM Administration Utility.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Bidirectional Conversion:** Converts RS‑422/RS‑485 differential signals to standard RS‑232 levels. - **Addressable Operation:** Supports both addressable and transparent (non‑addressable) modes for flexible network integration. - **Independent Baud Rate Configuration:** RS‑232 and RS‑422/RS‑485 interfaces can operate at different baud rates (1.2 kBd – 115.2 kBd). - **Full‑Duplex and Half‑Duplex Support:** - RS‑422: 4‑wire full‑duplex differential communication. - RS‑485: 2‑wire half‑duplex differential communication with automatic direction control. - **High Isolation Voltage:** 1000 V DC galvanic isolation between communication ports to protect against ground loops and surges. - **Surge Protection:** Built‑in transient voltage suppressors (TVS) on RS‑422/RS‑485 lines. - **Auto Direction Flow Control:** Automatic transmit/receive switching for RS‑485 half‑duplex operation. - **High‑Speed Data Transfer:** Supports up to 115.2 kbps on both interfaces. - **Low Power Consumption:** Typical power draw of 1.008 W. - **Industrial‑Grade Design:** ABS enclosure with captive mounting hardware, suitable for DIN‑rail or panel installation. - **Software Compatibility:** Fully compatible with ND‑6521 and other NuDAM communication modules. - **CE Class A Conformity:** Meets industrial EMC and safety standards.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules

- **Bidirectional Signal Conversion:** Converts RS‑422/RS‑485 differential signals to RS‑232 single‑ended signals, allowing RS‑232 devices to communicate over extended RS‑485/RS‑422 networks. - **Addressable Operation:** Each ND‑6521 can be assigned a unique address (00–FF hex), enabling up to 256 modules to coexist on a single RS‑485 bus. - **Dual‑Mode Functionality:** Operates in either **addressable** or **non‑addressable (transparent)** mode, selectable via software or hardware configuration. - **High‑Speed Communication:** Supports baud rates from **1,200 to 115,200 bps**, with independent speed settings for RS‑232 and RS‑485/RS‑422 interfaces. - **Full‑Duplex and Half‑Duplex Support:** - RS‑422: 4‑wire full‑duplex differential transmission. - RS‑485: 2‑wire half‑duplex with automatic direction flow control. - **Optical Isolation:** 2,500 Vrms (typical) isolation between communication ports, protecting host systems from ground loops and electrical surges. - **Surge Protection:** Integrated transient voltage suppressors (TVS) and positive temperature coefficient (PTC) protection on all communication lines. - **Watchdog Function:** Hardware and software watchdog timers ensure automatic recovery from communication or host failures. - **Flexible Configuration:** Baud rate, parity, stop bits, and data bits are software‑configurable; checksum and delimiter options enhance communication integrity. - **Industrial‑Grade Design:** ABS enclosure with internal EMI shielding and conformal coating for resistance to humidity, salt spray, and chemical exposure. - **Ease of Installation:** Plug‑in screw terminal block for RS‑485/RS‑422 and standard DB‑9 female connector for RS‑232 simplify wiring and maintenance. - **Software Compatibility:** Supported by ADLINK’s **NuDAM Administration Utility** for Windows 3.1/95/98/NT/2000 and DOS environments. - **LED Indicators:** Power and data transfer LEDs provide visual status feedback.

Manufacturer: Adlink Technology Inc.

Category: RS485 DIN Rail IO Modules
