- **High-Speed Data Transfer:** - Achieves up to **12 MB/s** transfer rate using bus-mastering DMA. - Supports multiple transfer modes: programmed I/O, interrupt-driven, timer pacer, external clock, and handshaking. - **Digital I/O Configuration:** - **32 TTL-compatible digital inputs** and **32 TTL-compatible digital outputs**. - **4 auxiliary digital input/output channels** (exclusive to cPCI-7200). - **2k + 8-word (32-bit) FIFO buffer** for digital input channels, ensuring stable high-speed data acquisition. - **Programmable Timing and Control:** - Integrated **82C54-10 programmable counter/timer** with 4 MHz base clock. - Independent timers for input and output pacing (Timer 0 for DI, Timer 1 for DO). - Supports cascaded timer configurations for extended frequency control. - **Bus Interface:** - CompactPCI 32-bit, 33 MHz bus interface. - Fully Plug-and-Play compliant; no jumper or DIP switch configuration required. - Automatic resource allocation via system BIOS. - **Electrical Isolation and Protection:** - 2.5 kV isolation between channels for signal integrity and protection. - Schottky diode termination on input channels to minimize signal reflection and noise. - **Software and OS Support:** - Compatible with **Windows 7/Vista/XP/2000/2003** and **Linux**. - Supported by ADLINK’s **DAQPilot**, **DAQBench**, **PCIS-DASK**, and **DAQ-MTLB** drivers. - Integration with **LabVIEW®**, **MATLAB®**, **HP-VEE**, and **ISaGRAF™** environments. - **Industrial Design:** - Rugged 3U CompactPCI construction with a **100-pin SCSI-II connector**. - Designed for high-reliability industrial automation, test, and measurement systems.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **Isolation Protection:** 5000 V RMS optical isolation between channels and system, ensuring protection against high-voltage transients and ground loops. - **Digital I/O Configuration:** 16 isolated digital input (DI) channels and 16 isolated digital output (DO) channels. - **Output Type:** Darlington transistor outputs capable of sinking up to 500 mA per channel at 100% duty cycle. - **Input Range:** Accepts non-polarity 0–24 V DC input signals, with logic thresholds of 0–1.5 V (Low) and 5–24 V (High). - **External Interrupts:** Two interrupt sources available on digital input channels 0 and 1. - **Bus Interface:** CompactPCI 32-bit, 5 V signaling, compliant with PICMG 2.0 R2.1. - **Connector Type:** Rugged 50-pin SCSI-II female connector for secure industrial connectivity. - **Software Support:** Compatible with Windows and Linux operating systems; supports ADLINK DAQPilot, PCIS-DASK, DAQBench, LabVIEW™, and MATLAB® integration. - **High Output Drive Capability:** Supports external load voltages from 5 V to 35 V DC for relay, solenoid, or motor control. - **Compact Design:** 3U Eurocard form factor (160 mm × 100 mm) suitable for embedded and rack-mounted CompactPCI systems. - **Industrial Reliability:** Operating temperature range of 0°C to 60°C, humidity tolerance up to 95% non-condensing.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **CompactPCI 3U Eurocard Design:** Fully compliant with PICMG 2.0 R2.1, ensuring interoperability with standard CompactPCI backplanes. - **8‑Channel SPDT Relay Outputs:** All relays are Form C (Single‑Pole Double‑Throw) type, non‑latching, supporting both AC and DC loads. - **16‑Channel Isolated Digital Inputs:** Optically isolated, non‑polarity inputs with optional RC filtering for noise suppression. - **High Isolation Voltage:** 5000 VRMS channel‑to‑system isolation for digital inputs, 1000 VRMS relay contact breakdown voltage. - **Onboard LED Indicators:** Each relay output has a dedicated LED for visual status monitoring. - **Relay Output Readback:** Software‑accessible readback registers allow verification of relay states. - **Onboard Relay Driving Circuits:** Integrated driver circuitry ensures reliable relay actuation without external components. - **Wide Input Voltage Range:** Accepts 3–24 V AC/DC input signals, tolerant to industrial noise. - **Rugged I/O Connector:** 50‑pin SCSI‑II female connector for secure, high‑density signal interfacing. - **Software Support:** Compatible with Windows and Linux drivers, and integrates with LabVIEW™, MATLAB®, and ADLINK’s DAQPilot SDK. - **Applications:** Industrial ON/OFF control, external relay driving, limit switch monitoring, and integration with A/D and D/A systems for complete data acquisition and control solutions.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High‑Density I/O:** Provides 32 isolated digital input (DI) channels and 32 isolated digital output (DO) channels on a single CompactPCI card. - **Electrical Isolation:** 5000 V RMS isolation between channels and the host system, ensuring protection against high‑voltage transients and ground loops. - **Wide Input Voltage Range:** Accepts non‑polarized input voltages from 5 V DC to 24 V DC, suitable for industrial sensors, switches, and logic signals. - **High Output Drive Capability:** Each output channel can sink up to 500 mA at 24 V DC, supporting direct control of relays, solenoids, and indicator lamps. - **Open‑Collector Darlington Outputs:** Utilizes Darlington transistor arrays for high current sinking capability and fast switching performance. - **CompactPCI Bus Interface:** Fully compliant with the CompactPCI specification (PICMG 2.0 R2.1), supporting 32‑bit, 33 MHz PCI signaling. - **Rugged Industrial Connector:** Equipped with a 100‑pin SCSI‑II female connector for secure, high‑density signal interfacing. - **Interrupt Support:** Two external interrupt sources (channels 0 and 1) for event‑driven applications. - **Software Support:** Compatible with Windows 7/8.1 x86/x64 and Linux; includes drivers and SDKs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** Bundled with AD‑Logger for data monitoring and diagnostic testing. - **High Reliability:** Designed for industrial environments with wide operating temperature range and high isolation protection.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **64‑Channel Total I/O:** 32 isolated digital input (DI) channels and 32 isolated digital output (DO) channels. - **High Isolation Protection:** 5000 V RMS channel‑to‑system isolation for CompactPCI models, ensuring protection against high‑voltage transients and ground loops. - **Source Current Output:** Each output channel can source up to 500 mA at 24 V DC, suitable for driving relays, solenoids, and other inductive loads. - **Wide Input Voltage Range:** Accepts 5 V – 24 V DC non‑polarized input signals. - **High Output Drive Capability:** Supports up to 35 V DC output voltage with Darlington transistor drivers. - **Rugged Industrial Connector:** 100‑pin SCSI‑II female connector for secure, high‑density signal interfacing. - **Compact 3U Eurocard Design:** 160 mm × 100 mm PCB dimension, compliant with CompactPCI mechanical standards. - **Dual Interrupt Sources:** Two external interrupt inputs (channels 0 and 1) for event‑driven applications. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; drivers and SDKs available for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** Bundled AD‑Logger for data acquisition and monitoring. - **High Reliability:** Optical isolation and transient suppression protect host systems from electrical noise and surges. - **Plug‑and‑Play PCI Configuration:** Automatic resource assignment via BIOS; no manual configuration required.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High‑density I/O:** 32 isolated digital inputs and 32 isolated digital outputs, providing a total of 64 channels in a single 3U CompactPCI slot. - **Rear I/O configuration:** Designed for rear I/O connectivity through the CompactPCI backplane, enabling clean front‑panel cable management and improved system reliability. - **High isolation protection:** 5000 V RMS channel‑to‑system isolation, protecting host computers from high‑voltage transients and ground loops. - **Wide input voltage range:** Accepts 0–24 V DC input signals (non‑polarity), suitable for industrial sensors and logic devices. - **High output drive capability:** Open‑collector Darlington transistor outputs capable of sinking up to 500 mA per channel at 24 V DC. - **Common ground or common power configuration:** Supports both configurations depending on system requirements. - **Rugged industrial design:** 3U Eurocard form factor compliant with PICMG 2.0 R2.1 CompactPCI standards. - **High reliability:** Optical isolation for all channels, protecting against noise and transient surges. - **Interrupt support:** Two external interrupt sources (channels 0 and 1) for event‑driven applications. - **Software compatibility:** Drivers and SDKs for Windows 7/8.1 x86/x64 and Linux; supports LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Diagnostic LEDs:** Four user‑programmable LEDs for status indication and debugging. - **Comprehensive software tools:** Includes AD‑Logger utility and PCIS‑DASK driver library for rapid development.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **32 Isolated Digital Inputs and 32 Isolated Digital Outputs:** Provides symmetrical I/O configuration for versatile control and monitoring applications. - **High Isolation Voltage:** 5000 V RMS channel‑to‑system isolation ensures protection against high‑voltage transients and ground loops. - **Source Current Output Capability:** Each output channel can source up to 500 mA at 24 V DC, suitable for driving relays, solenoids, and actuators. - **Rear I/O Configuration:** Designed for CompactPCI systems with rear I/O access via J2 connector, enabling clean front‑panel integration and improved cable management. - **Rugged Industrial Connector:** 100‑pin SCSI‑II female connector for reliable signal integrity and mechanical robustness. - **Wide Input Voltage Range:** Accepts 5 V – 24 V DC non‑polarized input signals, compatible with a variety of industrial sensors and logic levels. - **High Output Drive Capability:** Darlington transistor array outputs with common power configuration for high‑current sourcing. - **Dual Interrupt Sources:** Two external interrupt inputs (channels 0 and 1) for event‑driven control and real‑time response. - **Comprehensive Software Support:** Drivers and SDKs available for Windows 7/8.1 (x86/x64) and Linux, with APIs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** AD‑Logger for data acquisition and monitoring. - **CompactPCI Compliance:** Fully compliant with PICMG 2.0 R2.1, ensuring interoperability with standard CompactPCI backplanes.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

Compact PCI bus isolated Digital IO card, 64DI, rugged 100pin SCSI-II connector, 100*160mm, Adlink

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **64 Isolated Digital Input Channels:** Provides 64 optically isolated digital input channels for robust signal acquisition in noisy or high‑voltage environments. - **High Isolation Voltage:** 2500 Vrms channel‑to‑system isolation ensures protection against transient voltages and ground loops. - **Rear I/O Configuration:** Rear I/O interface via CompactPCI J2 connector, eliminating front‑panel cabling and enabling high‑density system integration. - **3U CompactPCI Form Factor:** Fully compliant with PICMG 2.0 R2.1 CompactPCI specifications. - **Rugged 100‑pin SCSI‑II Connector:** Industrial‑grade connector for reliable signal transmission and mechanical stability. - **Wide Input Voltage Range:** Accepts 0–24 V DC input signals (logic H: 5–24 V, logic L: 0–1.5 V). - **Optical Isolation:** Protects host systems from high‑voltage transients and eliminates ground loop interference. - **Dual Interrupt Sources:** Supports two external interrupt sources on digital input channels 0 and 1 for event‑driven applications. - **High Throughput:** Supports up to 10 kHz input sampling rate (0.1 ms response). - **Software Support:** Compatible with ADLINK’s PCIS‑DASK driver library and utilities for Windows 7/8.1 x86/x64 and Linux. - **SDK Integration:** Supports LabVIEW®, MATLAB®, Visual C/C++, Visual Basic, and .NET environments. - **Diagnostic LEDs:** Four user‑programmable LEDs for status indication and debugging. - **Geographic Addressing:** Slot number readable from CompactPCI backplane for system identification. - **Industrial‑Grade Design:** Operating temperature 0 °C – 60 °C, humidity 5 – 95 % RH non‑condensing.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

Compact PCI bus isolated Digital IO card, 64DO, rugged 100pin SCSI-II connector, 100*160mm, Adlink

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **64 Isolated Digital Output Channels:** Provides 64 independent, optically isolated digital output channels for high‑density control applications. - **Source Current Output Type:** Uses transistor source configuration (TD62783 devices) for sourcing current to external loads. - **High Isolation Voltage:** 5000 V RMS channel‑to‑system isolation ensures protection against high‑voltage transients and ground loops. - **High Output Drive Capability:** Each channel can source up to 500 mA at 24 V DC; all channels ON simultaneously can source 260 mA per channel. - **Wide Output Voltage Range:** Supports 5 V DC minimum to 35 V DC maximum output voltage. - **CompactPCI 3U Eurocard Form Factor:** Fully compliant with PICMG 2.0 R2.1 CompactPCI specification. - **Rugged 100‑Pin SCSI‑II Connector:** Provides a single, high‑density interface for all I/O channels. - **Optical Isolation:** Protects host systems from voltage surges and eliminates ground loop interference. - **Software Support:** Compatible with Windows 7/8.1 (x86/x64) and Linux; drivers and SDKs available for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** Includes AD‑Logger for data monitoring and testing. - **High Reliability:** Designed for industrial environments with operating temperature range 0 °C – 60 °C and humidity up to 95 % non‑condensing. - **Comprehensive SDK:** Supports PCIS‑DASK, LabVIEW, HP‑VEE, DAQBench ActiveX, ISaGRAF, InControl, and OPC Server integration.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **64 Isolated Digital Output Channels:** Provides 64 optically isolated digital output channels for industrial control and automation. - **High Isolation Voltage:** 5000 V RMS channel‑to‑system isolation ensures protection against high‑voltage transients and ground loops. - **Rear I/O Configuration:** Designed for rear I/O access via CompactPCI backplane, enabling clean front‑panel integration and cable management. - **Common Ground Configuration:** All output channels share a common ground reference, simplifying wiring for standard industrial loads. - **High Output Drive Capability:** Each output channel can sink up to 500 mA at 24 V DC, suitable for driving relays, solenoids, and indicators. - **Wide Output Voltage Range:** Supports 5 V DC minimum to 35 V DC maximum output voltage. - **Optical Isolation:** Protects host systems from voltage spikes, surges, and noise interference. - **CompactPCI Compliance:** Fully compliant with PICMG 2.0 R2.1 CompactPCI specification, 3U Eurocard form factor. - **Rugged Industrial Connector:** 100‑pin SCSI‑II female connector for secure, high‑density signal interfacing. - **Software Support:** Compatible with Windows 7/8.1 x86/x64 and Linux; drivers and SDKs available for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Diagnostic LEDs:** Four user‑programmable LEDs for system status indication and debugging. - **Geographic Addressing:** Supports CompactPCI slot number identification via backplane geographic addressing. - **High Reliability:** Designed for continuous operation in industrial environments with extended temperature and humidity tolerance.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **64 isolated digital output channels** with common power configuration (source current type). - **Rear I/O interface** via a 100‑pin SCSI‑II female connector for compact system integration. - **High isolation voltage:** 5000 V RMS channel‑to‑system isolation for maximum protection. - **High output drive capability:** - Source current up to **500 mA per channel** (single channel ON). - **260 mA per channel** when all channels are ON at 24 V. - **Wide output voltage range:** 5 V DC minimum to 35 V DC maximum. - **Common power configuration:** all outputs share a single external power source (VDD). - **3U CompactPCI form factor**, compliant with **PICMG 2.0 R2.1**. - **Rear I/O signaling** through J2 connector; no front‑panel I/O connectors. - **Rugged design** with optical isolation to protect host systems from high voltages and ground loops. - **Plug‑and‑Play PCI configuration** using the PLX PCI‑9050 controller, fully compliant with PCI 2.1. - **Software support:** Windows 7/8.1 x86/x64 and Linux drivers; compatible with LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility software:** AD‑Logger for data monitoring and testing. - **High reliability:** designed for continuous operation in industrial environments (0 °C – 60 °C).

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High‑Density I/O:** 256 total channels — 128 isolated digital inputs and 128 isolated digital outputs. - **Electrical Isolation:** 2500 V RMS channel‑to‑system isolation ensures protection against voltage surges and ground loops. - **Wide Input Range:** Non‑polarity digital input range up to 28 V DC, allowing flexible interfacing with various sensors and switches. - **Wide Output Range:** Open‑collector Darlington transistor outputs supporting 5 V to 35 V DC external supply, suitable for driving relays, solenoids, and indicators. - **High Sink Current Capability:** Up to 300 mA per channel continuous sink current at 100 % duty cycle. - **Change‑of‑State (COS) Interrupts:** Programmable COS detection on all 128 input channels for event‑driven data acquisition. - **Output Readback:** Real‑time digital output status readback for verification and diagnostics. - **Watchdog Timer:** Onboard 32‑bit watchdog timer with programmable overflow interval (1 s – 4500 s) to ensure system reliability. - **Board ID Function:** DIP‑switch selectable board identification (0–15) for multi‑card systems. - **Software & Driver Support:** - **Operating Systems:** Windows 7/Vista/XP/2000/2003 Server, Linux, Windows CE (on request). - **Drivers:** PCIS‑DASK (Windows), PCIS‑DASK/X (Linux), DAQPilot (Windows/LabVIEW), DAQ‑MTLB (MATLAB). - **Development Tools:** VB.NET, VC.NET, Delphi, BCB, DAQBench, AD‑Logger. - **CompactPCI Compliance:** Fully compliant with PICMG 2.0 R3.0 standard for mechanical and electrical interoperability.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High-Density I/O:** Up to 64 isolated digital input or output channels per board. - **Electrical Isolation:** Up to 5000 Vrms channel-to-computer isolation (2500 Vrms for certain models). - **Multiple Configurations:** - PCI-7432: 32 DI + 32 DO - PCI-7433: 64 DI - PCI-7434: 64 DO - cPCI-7432/33/34: 3U CompactPCI versions - cPCI-7434P/7434R/7434RP: Common power or common ground configurations with rear I/O options. - **High Output Drive Capability:** Up to 500 mA sink current per channel. - **Input Protection:** 24 V DC input protection and transient suppression. - **Interrupt Support:** Dual interrupt triggers on digital input channels 0 and 1. - **Connector Interface:** 100-pin SCSI-II type connector for all models. - **Plug-and-Play PCI Compliance:** Fully compliant with PCI Local Bus Specification Rev. 2.1 using PLX PCI-9050 controller. - **Software Support:** Comprehensive driver suite for Windows 95/98/NT/2000, DOS, and integration with LabVIEW®, HP VEE™, DASYLab™, InTouch™, InControl™, ISaGRAF™, and OPC Server environments. - **Rear I/O Support:** Available on CompactPCI 743XR variants with optional transition boards (DB‑100RU). - **Onboard Isolated Power:** +5 V DC isolated output (150–200 mA). - **High Reliability:** Designed for industrial environments with optical isolation and noise immunity.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **64 Opto-Isolated Digital Inputs:** Provides 64 independent digital input channels, each isolated from the system bus to prevent ground loops and electrical interference. - **Positive Common Configuration:** Each group of 16 inputs shares a positive common line, simplifying wiring for sensors and switches using a common positive voltage. - **Wide Input Voltage Range:** Accepts input signals from +12 to +24 VDC, suitable for standard industrial logic levels. - **High Isolation Voltage:** 1 kVrms isolation between input channels and the CompactPCI bus ensures protection against surges and electrical noise. - **CompactPCI Bus Interface:** Fully compliant with the CompactPCI (cPCI) standard, supporting 32-bit, 33 MHz operation. - **High Reliability Opto-Couplers:** Utilizes high-speed, high-reliability photo-couplers for signal isolation and noise suppression. - **Compact Form Factor:** Short-size PCI board dimensions (176 mm × 107 mm) allow installation in space-constrained systems. - **Industrial-Grade Design:** Designed for continuous operation in harsh industrial environments with high electrical noise. - **Interrupt Support:** Supports multiple interrupt lines combined into a single interrupt request signal for efficient event handling. - **Software Support:** Compatible with CONTEC’s API-PAC(W32) library and drivers for Windows and Linux, enabling easy integration into custom applications.

Manufacturer: Contec

Category: DIO Isolated PXI/PXIe/cPCI

- **CompactPCI Bus Interface:** Fully compliant with the CompactPCI (cPCI) standard, enabling integration into industrial PC systems with cPCI backplanes. - **Opto-Isolated I/O Channels:** 32 isolated digital inputs and 32 isolated digital outputs, each channel isolated by photo-couplers to protect the host system from electrical noise and surges. - **Positive Common Configuration:** Designed for positive common wiring, simplifying integration with industrial sensors and actuators that share a common positive line. - **Wide Input Voltage Range:** Accepts 12 V DC to 24 V DC input signals, compatible with standard industrial logic levels. - **High Output Drive Capability:** Each output channel can sink up to 150 mA at 35 V DC maximum, with a total of 2 A per common line. - **High Isolation Voltage:** 1 kVrms isolation between the PC bus and external I/O circuits ensures reliable operation in electrically noisy environments. - **Compact Form Factor:** Short-size cPCI board (176 mm × 107 mm) suitable for space-constrained industrial systems. - **High Reliability:** Industrial-grade components and design for continuous operation in automation, process control, and data acquisition systems. - **Software Support:** Compatible with CONTEC’s API-PAC(W32) and API-TOOLs for Windows/Linux, providing easy integration with custom applications and third-party environments such as LabVIEW and MATLAB.

Manufacturer: Contec

Category: DIO Isolated PXI/PXIe/cPCI

- **64 Opto-Isolated Digital Output Channels:** Provides 64 independent output points for controlling external devices such as relays, solenoids, and indicators. - **Positive Common Configuration:** Each group of 16 outputs shares a positive common line, simplifying wiring for devices requiring a shared positive voltage. - **High Output Capacity:** Supports up to **35 VDC** output voltage and **150 mA per channel**, with a maximum of **2 A per common group**. - **Optical Isolation:** 1 kVrms isolation between the PC bus and external I/O circuits prevents ground loops and protects the host system from electrical noise and surges. - **CompactPCI Bus Interface:** Fully compliant with the CompactPCI (cPCI) standard, ensuring compatibility with industrial-grade embedded systems and rack-mounted controllers. - **High Reliability and Noise Immunity:** Opto-coupler isolation and robust circuit design ensure stable operation in electrically noisy environments. - **Standard 96-Pin Half-Pitch D-Type Connector:** Provides a compact, high-density interface for external wiring. - **Compact Form Factor:** Short-size cPCI board (176 mm × 107 mm) suitable for space-constrained industrial systems. - **Software Support:** Compatible with CONTEC’s API-PAC(W32) and API-TOOLS for Windows and Linux, enabling easy integration into custom applications. - **Wide Accessory Support:** Compatible with CONTEC’s range of terminal blocks, shielded cables, and DIN-rail adapters for flexible installation.

Manufacturer: Contec

Category: DIO Isolated PXI/PXIe/cPCI

- **High‑Density Digital I/O:** Up to 64 isolated digital input or output channels per board, configurable by model. - PCI‑7432 / cPCI‑7432: 32 DI + 32 DO - PCI‑7433 / cPCI‑7433: 64 DI - PCI‑7434 / cPCI‑7434: 64 DO - **Electrical Isolation:** Up to **5000 Vrms channel‑to‑computer isolation** (2500 Vrms for certain rear I/O variants), protecting host systems from high‑voltage transients and ground loops. - **High Output Drive Capability:** Each output channel can sink up to **500 mA**, supporting inductive loads such as relays and solenoids. - **Wide Input Voltage Range:** Accepts **0–24 V DC** input signals with logic thresholds of 0–1.5 V (Low) and 5–24 V (High). - **High Throughput:** Supports up to **10 kHz (0.1 ms)** update rate for both input and output operations. - **Interrupt Support:** Dual interrupt sources on digital input channels 0 and 1, with external interrupt triggering capability. - **Connector Interface:** Standard **100‑pin SCSI‑II** connector for all models, ensuring compatibility with ADLINK’s DB‑100 series terminal boards. - **Form Factor Options:** Available in **PCI**, **CompactPCI (3U)**, and **CompactPCI with Rear I/O** configurations, including common‑ground and common‑power variants. - **Software Integration:** Comprehensive driver suite supporting Windows 95/98/NT/2000, DOS, and major automation environments (LabVIEW®, HP‑VEE™, DASYLab™, InTouch™, InControl™, ISaGRAF™, OPC). - **Plug‑and‑Play PCI Compliance:** Fully compliant with **PCI Local Bus Specification Rev. 2.1**, using the PLX PCI‑9050 controller for automatic resource assignment.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High-Density I/O:** Up to 64 isolated digital input or output channels per board. - **Isolation Protection:** Up to 5000 Vrms channel-to-computer isolation (2500 Vrms for certain models). - **Flexible Configurations:** Available in PCI, 3U CompactPCI, and CompactPCI with rear I/O form factors. - **High Output Drive Capability:** Each output channel can sink up to 500 mA. - **Wide Input Voltage Range:** Accepts 0–24 VDC input signals with logic thresholds (H: 5–24 V, L: 0–1.5 V). - **High-Speed Operation:** Supports throughput up to 10 kHz (0.1 ms response time). - **Interrupt Support:** Dual interrupt sources on digital input channels 0 and 1. - **Connector Interface:** Standard 100-pin SCSI-II connector for all models. - **Software Integration:** Comprehensive driver support for Windows and DOS environments, including LabVIEW®, HP-VEE™, DASYLab™, InTouch™, InControl™, ISaGRAF™, and OPC. - **Plug-and-Play PCI Configuration:** Automatic resource assignment via BIOS (IRQ and I/O base address). - **Compact Form Factor:** Standard 3U CompactPCI and PCI short card dimensions for space-constrained systems. - **Rear I/O Options:** Rear transition modules available for cPCI-R variants. - **LED Indicators:** User-programmable LEDs on rear I/O models for status indication. - **Robust Design:** Optical isolation, transient suppression, and ESD protection for industrial reliability.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **PXI / CompactPCI 3U Form Factor:** Designed for 3U PXI and CompactPCI chassis, ensuring compatibility with standard modular instrumentation systems. - **16 Independent Relay Channels:** Provides 16 individually controlled relay outputs for flexible signal switching and control applications. - **Hot-Swappable Design:** Fully compliant with **PICMG 2.1 R1.0** hot-swap specifications, allowing insertion and removal without powering down the chassis. - **High Switching Capacity:** Each relay supports up to **60 W**, **220 VDC**, or **2 A** maximum load, suitable for both low- and medium-power switching tasks. - **Plug-and-Play Operation:** Automatically recognized by PXI systems for simplified configuration and integration. - **D-Type Connector Interface:** Standard D-type connector for secure and reliable external wiring and signal interfacing. - **Compact Dimensions:** Standard **100 mm × 160 mm** PCB size, optimized for PXI 3U slot installation. - **Industrial-Grade Reliability:** Built for continuous operation in demanding test environments, ensuring long relay life and stable performance. - **Software Integration:** Compatible with PXI system software environments and drivers for easy control and automation.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **32 Independent Relay Channels:** Provides 32 individually controlled relay outputs for versatile signal switching and control applications. - **PXI / CompactPCI 3U Form Factor:** Fully compliant with PXI and CompactPCI 3U mechanical and electrical specifications, ensuring compatibility with standard PXI chassis and controllers. - **PICMG 2.1 R1.0 Hot-Swappable Compliance:** Supports hot-swap functionality, allowing insertion and removal without powering down the PXI chassis, minimizing system downtime. - **High Switching Capacity:** Each relay channel supports up to **60 W**, **220 VDC**, or **2 A**, enabling control of moderate power loads and signal lines. - **Plug-and-Play Operation:** Automatically recognized by PXI systems for simplified configuration and integration. - **D-Type Connector Interface:** Equipped with a standard D-type connector for secure and reliable external wiring connections. - **Compact Dimensions:** Standard 3U PXI board size of **100 mm x 160 mm**, optimized for dense system integration. - **Industrial-Grade Reliability:** Designed for long operational life and consistent performance in demanding test environments. - **Flexible Application Support:** Suitable for signal routing, load switching, device simulation, and automated test equipment (ATE) systems.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High-Density Switching:** 60-channel Scan/Multiplexer configuration for efficient signal routing in compact PXI 3U form factor. - **Form A Relays:** Utilizes Form A (normally open) electromechanical relays for reliable signal switching and isolation. - **Wide Bandwidth:** 1 MHz (-3 dB) analog bandwidth supports a broad range of signal frequencies for general-purpose switching. - **PXI/cPCI 3U Compatibility:** Fully compliant with PXI and CompactPCI 3U mechanical and electrical standards, ensuring interoperability with modular test systems. - **Hot-Swappable Design:** Conforms to **PICMG 2.1 R1.0** hot-swap specifications, allowing insertion and removal without system power-down. - **Plug and Play Operation:** Automatic resource detection and configuration through PXI system controller for simplified setup. - **High Power Handling:** Maximum switching capacity of **30 W**, **125 VAC**, **30 VDC**, and **0.5 A**, suitable for low-to-medium power signal routing. - **Compact and Rugged Construction:** 3U PXI form factor with 160-pin 2 mm connector for secure and reliable signal connections. - **Versatile Application Range:** Ideal for automated test equipment (ATE), data acquisition systems, signal routing, and instrumentation switching.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **High-Density Switching:** 60-channel Scan/Multiplexer configuration providing extensive signal routing capability within a single 3U PXI slot. - **Form B Relay Architecture:** Utilizes Form B (normally closed) relays for enhanced reliability and signal integrity, suitable for both low-level and moderate power switching. - **PXI / CompactPCI 3U Form Factor:** Fully compliant with PXI and CompactPCI 3U mechanical and electrical specifications, ensuring compatibility with standard PXI chassis and controllers. - **Wide Bandwidth:** 1 MHz (-3 dB) analog bandwidth supports a broad range of signal frequencies, suitable for both DC and low-frequency AC applications. - **Hot-Swappable Design:** Conforms to **PICMG 2.1 R1.0** hot-swap specification, allowing safe insertion and removal without powering down the PXI chassis. - **Plug and Play Operation:** Automatic resource detection and configuration through PXI system software, simplifying integration and reducing setup time. - **High Isolation and Low Crosstalk:** Ensures signal integrity across multiple channels, critical for precision measurement and automated test systems. - **Durable Relay Design:** Mechanical relays rated for long operational life and consistent performance under repeated switching cycles. - **Compact and Modular:** Occupies a single 3U PXI slot, optimizing space utilization in dense test configurations. - **Standardized Connectivity:** Equipped with a **160-pin 2 mm connector** for secure and reliable signal interfacing.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI

- **PXI / CompactPCI 3U Form Factor:** Fully compliant with PXI and CompactPCI 3U mechanical and electrical specifications, ensuring compatibility with standard PXI chassis and controllers. - **16-Channel Scan/Multiplexer Configuration:** Provides 16 independent Form A relay channels for flexible signal routing and multiplexing operations. - **Form A Relays:** Utilizes Form A (normally open, single-pole single-throw) electromechanical relays for reliable switching of analog and digital signals. - **High Bandwidth Performance:** Offers a **10 MHz (-3 dB) bandwidth**, enabling accurate signal transmission for a wide range of analog and mixed-signal applications. - **Hot-Swappable Design:** Compliant with **PICMG 2.1 R1.0 Hot Swap** specification, allowing safe insertion and removal of the module without powering down the PXI chassis. - **Plug and Play Operation:** Supports automatic detection and configuration within PXI systems, simplifying integration and reducing setup time. - **High Power Handling:** Rated for **30 W**, **125 VAC**, **30 VDC**, and **0.5 A** maximum switching capacity per channel, suitable for moderate power signal routing. - **Compact and Robust Construction:** Built on a **100 mm x 160 mm** PCB with a **160-pin 2 mm connector**, ensuring secure electrical connections and mechanical stability. - **PXI Trigger and Synchronization Support:** Compatible with PXI trigger bus and timing features for synchronized operation with other PXI modules. - **Industrial-Grade Reliability:** Designed for continuous operation in demanding test environments with long relay life and stable performance.

Manufacturer: Adlink Technology Inc.

Category: DIO Isolated PXI/PXIe/cPCI
