- **All-in-One Industrial Gateway Solution:** Combines edge computing, protocol conversion, data acquisition, and secure cloud connectivity in a single device. - **Industrial-Grade Design:** Fully compliant with **IEC 61850-3**, ensuring electromagnetic compatibility, vibration resistance, and extended temperature operation for harsh industrial environments. - **Redundant 4G LTE Connectivity:** Dual SIM or load-balanced 4G LTE connections certified by **AT&T**, providing high availability and failover for mission-critical communications. - **Integrated 8-Port Gigabit Ethernet Switch:** - 4 × 10/100/1000Base-T(X) RJ45 ports - 4 × Gigabit SFP combo ports for fiber uplinks - Supports VLAN, QoS, and redundant ring topologies. - **Serial Communication Interfaces:** - 1 × RS-232/422/485 (DB9 connector) - 1 × RS-422/485 (terminal block) - Supports Modbus RTU, ASCII, and other serial protocols. - **Edge Computing Platform:** - **Inductive Automation Ignition / Ignition Edge** pre-installed for HMI, SCADA, MES, and IIoT applications. - **Node-RED** integrated for visual data flow programming and rapid prototyping. - **Protocol Support:** - **MQTT / Sparkplug B / CoAP** for IoT data exchange. - **Modbus TCP/RTU** for industrial automation integration. - **Data Storage & Database Support:** - Built-in **64GB SSD** for local data logging (expandable to 128GB or 256GB). - **PostgreSQL** database preloaded for structured data management. - **Secure Networking:** - VPN support: **OpenVPN, PPTP, IPSec** for encrypted remote access. - Event notification via **Syslog, Email, SNMP Trap, or Relay Output**. - **Power & Protection:** - Dual isolated power inputs (12–48VDC). - **PoE IEEE 802.3at** compliant powered device with 1kV isolation. - **Rugged Construction:** - **IP30-rated metal enclosure** for industrial durability. - Wide operating temperature range for extreme environments.

Manufacturer: Oring

Category: IoT Gateway

- **ARM‑based Industrial Gateway:** Built around the TI Sitara AM3352 1 GHz ARM Cortex‑A8 processor, optimized for low‑power, high‑reliability embedded control. - **Pre‑installed Debian OS:** Ships with Debian 8 or 9 for immediate deployment and compatibility with open‑source IoT frameworks. - **Dual microSDHC Storage:** One internal and one external T‑Flash slot for flexible OS and data partitioning, simplifying mass deployment and maintenance. - **Rich Industrial I/O:** - 4 × isolated digital inputs and 4 × isolated digital outputs (IGT‑20) - 2 × software‑configurable RS‑232/422/485 serial ports - 1 × 10/100 Mbps Ethernet port - 1 × USB 2.0 host port - 1 × 3‑wire RS‑232 console port - **Wireless Expansion:** Full‑size mini‑PCIe slot (USB 2.0 signal only) and external USIM holder for 3G/4G/LTE or Wi‑Fi modules. - **Programmable Controls:** Six user‑programmable LEDs and two user‑programmable buttons for custom functions and system feedback. - **Rugged Design:** Fanless operation from –25 °C to +70 °C at 100 % CPU load; vibration tolerance 5 Grms; shock resistance 50 Grms. - **Wide Power Input Range:** 8 – 25 V DC input with terminal block connector. - **Compact Footprint:** 41 mm (W) × 77 mm (D) × 104 mm (H), weight 0.4 kg. - **DIN‑Rail Mounting:** Industrial‑grade mounting kit included for quick installation in control cabinets. - **Compliance:** CE/FCC Class A, EN 55032 EMC compliance, shock and vibration certified.

Manufacturer: Neousys Technology

Category: IoT Gateway

- **ARM‑based Industrial Gateway:** Built around the TI Sitara AM3352 ARM Cortex‑A8 processor running at 1 GHz, optimized for low‑power, high‑reliability embedded applications. - **Pre‑installed Debian OS:** Ships with Debian 8 or 9, providing a stable, open‑source Linux environment for application development and deployment. - **Rugged Fanless Design:** Operates fanlessly from –25 °C to +70 °C at 100 % CPU load, ensuring reliability in industrial and outdoor environments. - **Wide Power Input Range:** Accepts 8 VDC – 25 VDC input, suitable for factory and field power systems. - **Comprehensive I/O:** - 1 × 10/100 Mbps Ethernet port - 1 × USB 2.0 port - 2 × software‑configurable RS‑232/422/485 serial ports - 1 × 3‑wire RS‑232 console port - 4 × isolated digital inputs and 4 × isolated digital outputs - 1 × isolated CAN bus 2.0 A/B interface (IGT‑21 only) - **Wireless Expansion:** Full‑size mini‑PCIe slot (USB 2.0 signal only) and external USIM holder for 3G/4G/LTE or Wi‑Fi modules. - **Dual microSDHC Storage:** One internal and one external slot for system and user data separation or rapid OS deployment. - **User Interaction:** Six user‑programmable LEDs and two programmable function buttons for custom control and status indication. - **Industrial Durability:** CE/FCC Class A certified, 5 Grms vibration and 50 Grms shock resistance. - **Compact Footprint:** 41 mm (W) × 77 mm (D) × 104 mm (H), weight 0.4 kg, DIN‑rail mountable.

Manufacturer: Neousys Technology

Category: IoT Gateway

- **Industrial‑grade ARM‑based gateway:** Built around the TI Sitara AM3352 ARM Cortex‑A8 1 GHz processor for efficient, low‑power operation. - **Rugged design:** Fanless, vibration‑ and shock‑resistant enclosure rated for –25 °C to +70 °C continuous operation at 100 % CPU load. - **Real‑Time Clock (RTC):** Integrated RTC for precise timekeeping and event logging. - **High I/O density:** 8 isolated digital inputs and 8 isolated digital outputs for direct connection to sensors, switches, and actuators. - **Flexible communication:** - 1 × 10/100 Mb Ethernet port - 1 × USB 2.0 port - 1 × RS‑232 console port - 1 × RS‑485 port - 1 × full‑size mini PCIe slot (USB signal only) for 3G/4G/LTE or Wi‑Fi modules - 1 × external SIM card slot - **Dual microSDHC storage:** Internal and external T‑Flash slots supporting SDHC cards, allowing separation of system and user data or rapid OS deployment. - **User interface elements:** 6 user‑programmable LEDs and 2 user‑programmable buttons for custom control and status indication. - **Compact footprint:** 41 mm (W) × 77 mm (D) × 104 mm (H), 0.4 kg, DIN‑rail mountable. - **Wide power input range:** 8 V DC to 25 V DC input with 3‑pin terminal block connector. - **Pre‑installed Debian Linux:** Ready‑to‑use system with open‑source flexibility for industrial IoT applications. - **Wireless expansion:** Optional NSIO‑LTE‑7455 Cat. 6 LTE embedded modem supported. - **Industrial certifications:** CE/FCC Class A compliance, 5 Grms vibration and 50 Grms shock resistance.

Manufacturer: Neousys Technology

Category: IoT Gateway

- **High-Performance ARM9 Core:** Powered by the Atmel AT91SAM9G20 SoC featuring a 400 MHz ARM926EJ-S ARM Thumb processor with integrated Memory Management Unit (MMU), 32 KB instruction cache, and 32 KB data cache. - **Compact, Industrial Design:** Credit-card-sized (80 mm × 50 mm) module with fanless operation and low power consumption (2 W typical). - **Pre-Installed Embedded Linux:** Linux kernel 2.6.29 with U-Boot bootloader, BusyBox utilities, and lighttpd web server preconfigured for immediate use. - **Comprehensive Connectivity:** - 4 × UART ports (RS-232/422/485 software-selectable) - 1 × 10/100 Mbps Ethernet port with 1.5 kV isolation - 2 × USB 2.0 full-speed (12 Mbps) host ports - 1 × USB 2.0 device (client) port - 32 × programmable GPIO lines (3.3 V CMOS compatible) - SD/MMC interface, SPI, I²C, I²S, and 8-bit local bus - **Integrated Real-Time Clock (RTC):** ST M41T81 RTC with 48 mAh lithium backup battery for timekeeping during power loss. - **Flexible Software Environment:** Supports Linux and WinCE; includes GNU C/C++ cross-compilation toolchain for Linux/Windows hosts. - **Security and Networking:** Built-in support for SSL, SSH 1.0/2.0, SNMP v1/v3, and standard TCP/IP protocols. - **Industrial Reliability:** Operating temperature range 0 °C – 70 °C, solid-state storage (NAND Flash + DataFlash), and fanless design ensure durability in harsh environments.

Manufacturer: Artila

Category: IoT Gateway

- **ARM9-based Embedded Computer:** Powered by the Atmel AT91SAM9G20 SoC featuring a 400 MHz ARM926EJ-S ARM Thumb processor with integrated Memory Management Unit (MMU). - **Compact Form Factor:** Credit-card-sized SoM (50 × 80 mm) suitable for space-constrained embedded designs. - **Pre-installed Linux System:** Linux kernel 2.6.29 with U-Boot bootloader, BusyBox utilities, and lighttpd web server preloaded in NAND Flash. - **Comprehensive Connectivity:** - 10/100 Mbps Ethernet interface with 1.5 kV magnetic isolation. - Four UARTs (RS-232/422/485 software-selectable). - Two USB 2.0 full-speed (12 Mbps) host ports and one USB 2.0 device port. - SD memory card interface compliant with SD Specification 1.0. - SPI, I²C, and I²S buses for peripheral expansion. - **Programmable I/O:** 32 general-purpose digital I/O lines (3.3 V CMOS compatible) with interrupt capability. - **Onboard Real-Time Clock:** ST M41T81 RTC with 48 mAh lithium backup battery. - **Low Power Consumption:** Operates from 3.0–3.6 V DC (nominal 3.3 V) with typical power consumption of 2–2.5 W. - **Industrial-Grade Design:** Fanless operation, flash-based architecture, and 0 °C to 70 °C operating temperature range. - **Software Development Environment:** Includes GNU C/C++ cross-compilation toolchain for Linux and Windows, with support for Java acceleration and WinCE. - **Security and Networking:** Built-in SSH (v1/v2), SSL, FTP, Telnet, and SNMP services. - **Carrier Board Integration:** Provides convenient access to all SoM interfaces, DIN-rail mountable enclosure, and ready-to-use Linux toolchain.

Manufacturer: Artila

Category: IoT Gateway

- **High-Performance ARM9 Processor:** Powered by the Atmel AT91SAM9G20 SoC featuring a 400 MHz ARM926EJ-S core with integrated Memory Management Unit (MMU), 32 KB instruction cache, and 32 KB data cache. - **Pre-Installed Embedded Linux:** Ships with Linux kernel 2.6.29, U-Boot bootloader, and a suite of preconfigured utilities including BusyBox, lighttpd web server, SSH, FTP, and package management via ipkg. - **Comprehensive Connectivity:** Includes one 10/100 Mbps Ethernet port (DAVICOM DM9161 PHY with 1.5 kV isolation), four UARTs (RS-232/422/485 selectable), two USB 2.0 host ports, one USB 2.0 device port, and an SD memory card interface. - **Extensive I/O Options:** 32 programmable 3.3 V general-purpose digital I/O lines, configurable as input or output, with interrupt support. - **Integrated Real-Time Clock (RTC):** ST M41T81 RTC with 48 mAh lithium backup battery ensures timekeeping during power loss. - **Compact and Robust Design:** Measures only 80 mm × 50 mm, consumes approximately 2 W, and operates reliably in extended temperature ranges from −20 °C to +80 °C. - **Software Development Ready:** Includes GNU C/C++ cross-compilation toolchain for Linux and Windows, POSIX-compliant GLIBC libraries, and SDK with example programs. - **Industrial-Grade Reliability:** Fanless, flash-based architecture with watchdog timers, hardware flow control, and secure communication protocols (SSL, SSH 1.0/2.0).

Manufacturer: Artila

Category: IoT Gateway

- **Processor:** ATMEL AT91SAM9G45 ARM926EJ-S CPU with integrated MMU, operating at 400 MHz. - **Memory:** 128 MB DDR2 SDRAM and 256 MB NAND Flash, plus 2 MB DataFlash® for system backup. - **Operating System:** Linux kernel 2.6.38 with U-Boot bootloader and full file system support (UBI, JFFS2, EXT2/3, VFAT/FAT, NFS, NTFS). - **Networking:** On-board 10/100 Mbps Ethernet interface with integrated PHY (DAVICOM DM9161) and 1.5 kV magnetic isolation. - **Serial Communication:** Four UARTs (up to 921.6 Kbps) with hardware flow control; configurable RS-232/422/485 modes. - **USB Connectivity:** One USB 2.0 high-speed host port (480 Mbps) and one USB 2.0 device/client port. - **Expansion Interfaces:** SD card slot (up to 32 GB), SPI, I2C, I2S, and 32 programmable GPIO lines (3.3V CMOS). - **Real-Time Clock:** ST M41T81 RTC with on-board 48 mAh lithium backup battery. - **Power Efficiency:** Operates from 3.0–3.6 VDC (nominal 3.3 V) with typical consumption of 2 W. - **Compact Design:** 80 × 50 mm board with 128-pin (2.0 mm pitch) connectors for integration. - **Software Ecosystem:** Preloaded Linux utilities, web server (lighttpd), SSH, FTP, SNMP, and Artila management tools. - **Development Support:** GNU C/C++ cross-compilation toolchain for Linux and Windows, Webmin for web-based administration, and IPKG package management.

Manufacturer: Artila

Category: IoT Gateway

- **ARM9-based System-on-Module:** Powered by the Atmel AT91SAM9G45 CPU running at 400 MHz with integrated Memory Management Unit (MMU). - **Pre-installed Linux OS:** Linux kernel 2.6.38 with U-Boot bootloader and full file system support (UBI, JFFS2, EXT2/3, VFAT, NFS, NTFS). - **Comprehensive Development Environment:** Includes GNU C/C++ cross-compilation toolchain for Linux and Windows, GLIBC POSIX libraries, and IPKG package management. - **High Connectivity:** - 1 × 10/100 Mbps Ethernet port with onboard PHY and transformer (DAVICOM DM9161). - 4 × UARTs (RS-232/422/485 selectable) supporting up to 921.6 Kbps. - 1 × USB 2.0 high-speed host (480 Mbps) and 1 × USB 2.0 device port. - 1 × SD card interface (up to 32 GB, SD 2.0 compliant). - I²C, I²S, and SPI interfaces for peripheral expansion. - **Extensive I/O:** 32 programmable 3.3 V GPIO channels with interrupt support on PIO32. - **Integrated Real-Time Clock:** ST M41T81 RTC with onboard lithium backup battery (48 mAh). - **Compact and Efficient:** 80 × 50 mm SoM, 3.3 VDC input, typical power consumption 2 W. - **Carrier Board Integration:** Provides additional RS-232/422/485 ports, dual USB hosts, Ethernet, SD socket, GPIO connectors, EEPROM, and local bus interface. - **Fanless, DIN-rail mountable enclosure:** Suitable for industrial and embedded environments. - **Wide Operating Temperature Range:** 0 °C to +70 °C.

Manufacturer: Artila

Category: IoT Gateway

- **High-Performance ARM9 Processor:** Powered by the **ATMEL AT91SAM9G45** running at **400 MHz**, providing efficient processing for industrial control and automation tasks. - **Pre-installed Embedded Linux:** Ships with **Linux kernel 2.6.29**, including a pre-built web server (lighttpd), SSH, and SSL support for secure remote management. - **Comprehensive Connectivity:** - **1× 10/100 Mbps Ethernet port** with 1.5 kV magnetic isolation. - **4× USB 2.0 host ports** (12 Mbps each). - **4× RS-232/485 serial ports**, one of which supports **RS-422**. - **16× programmable GPIO channels** (3.3 V logic). - **Display and User Interface:** Supports **VGA output** and **LCD touch screens** up to **1280×860 resolution**, enabling direct human–machine interface (HMI) integration. - **Memory Architecture:** - **128 MB SDRAM** - **128 MB NAND Flash** - **2 MB DataFlash** for system backup and bootloader storage. - **Storage Expansion:** SD memory card interface compliant with **SD Specification 1.0**. - **Fanless, Compact Design:** Operates silently and reliably in harsh environments with a **-10 °C to +60 °C** temperature range. - **Low Power Consumption:** Operates from **3.0–3.6 V DC (nominal 3.3 V)** with a typical power draw of **2 W**. - **Industrial-Grade Reliability:** Flash-based architecture eliminates moving parts; includes watchdog timers and RTC for system stability. - **Software Development Support:** Includes **GNU C/C++ toolchain** for Linux and Windows, **WinCE** support, and **Java accelerator**.

Manufacturer: Artila

Category: IoT Gateway

- **High-Performance ARM9 Processor:** Powered by the Atmel AT91SAM9G45 400 MHz ARM926EJ-S core with integrated memory management unit (MMU), optimized for embedded Linux applications. - **Industrial Linux Platform:** Pre-installed Linux 2.6.29 kernel with BusyBox utilities, lighttpd web server, and SSH/SSL support for secure remote management. - **Comprehensive Connectivity:** - 1 × 10/100 Mbps Ethernet port (DAVICOM DM9161 PHY with 1.5 kV isolation) - 4 × USB 2.0 host ports (480 Mbps) - 3 × RS-232 and 1 × RS-422/485 high-speed serial ports - 4 × programmable GPIO channels - LCD interface supporting LVDS/TTL displays up to 1280 × 860 resolution - **Integrated Storage:** 128 MB SDRAM and 256 MB NAND Flash memory, with microSD expansion slot. - **Robust Industrial Design:** Operates from 12 – 40 V DC input, with low power consumption (200 mA @ 12 V DC) and an operating temperature range of 0 °C – 70 °C. - **Software Development Support:** Includes GNU C/C++ toolchain for Linux and Windows, Java accelerator, and full driver support for peripherals. - **Reliability Features:** Hardware watchdog timer, real-time clock (RTC) with backup battery, and flash-based architecture for non-volatile operation. - **Compact Form Factor:** 146 × 102 mm (3.5″ form factor), suitable for embedded integration.

Manufacturer: Artila

Category: IoT Gateway

- **Processor:** ARM926EJ-S core (Atmel AT91SAM9G45) operating at 400 MHz with integrated MMU. - **Operating System:** Pre-installed Microsoft Windows CE 6.0 Professional with file system support. - **Memory:** 128 MB SDRAM, 256 MB NAND Flash, and 2 MB DataFlash for system recovery. - **Display Support:** - Supports TFT LCD panels up to 1280 × 860 resolution. - Dual interface: 24-bit TTL/CMOS and LVDS. - Integrated 4-wire resistive touch screen controller. - **Networking:** 10/100 Mbps Ethernet interface with 1.5 kV magnetic isolation. - **Serial Communication:** - 3 × RS-232 ports. - 1 × RS-422/485 port (software configurable). - Baud rate up to 921.6 Kbps. - **USB Connectivity:** - 4 × USB 2.0 high-speed (480 Mbps) host ports. - 1 × USB 2.0 client port for ActiveSync and data transfer. - **GPIO:** 4 programmable digital I/O channels (TTL/CMOS compatible). - **Storage Expansion:** microSD card slot for additional storage. - **Power Input:** 12–40 VDC wide-range input (200 mA @ 12 VDC). - **Environmental:** Operating temperature range 0°C to 70°C. - **Software Development:** SDK available for Microsoft Visual Studio 2005 (C/C++). - **Network Services:** Built-in web server (ASP), FTP, and Telnet servers. - **Security:** Supports SSL and SSH 1.0/2.0 protocols. - **Additional Hardware:** Watchdog timer, real-time clock with backup battery, buzzer, and Java accelerator.

Manufacturer: Artila

Category: IoT Gateway

- **Processor:** NXP i.MX6ULL Cortex‑A7 MPCore, up to 800 MHz - **Memory:** 512 MB Low‑voltage DDR3 SDRAM - **Storage:** 16 GB eMMC onboard flash; expandable via Micro‑SD (up to 128 GB) - **Operating System:** Linux kernel 4.19.x with BareBox bootloader and EXT4 file system - **Toolchain:** gcc 8.2.0 + glibc 2.28; supports in‑place C/C++ compilation - **Networking:** Dual 10/100 Mbps Ethernet ports (RJ45 with LED indicators) - **USB Connectivity:** 1 × USB 2.0 OTG (micro‑USB connector) - **Serial Communication:** - Port 1: RS‑485 or RS‑232 (software‑selectable) - Port 2: RS‑232 - Auto direction control for RS‑485 - **CAN Bus:** 1 × CAN 2.0 A/B compliant port, up to 1 Mbps, 2500 Vrms isolation - **Digital I/O:** - 2 × Digital Inputs (photo‑coupler isolation, 5–24 V logic high) - 2 × Relay Outputs (solid‑state, NO type, 80 VDC @ 1.5 A) - **Expansion:** - 1 × Full‑size miniPCIe socket - 1 × Micro‑SIM slot (USB interface reserved) - 2 × SMA antenna holes reserved - **Storage Expansion:** 1 × Micro‑SD slot (SD 2.0 compliant, SDHC up to 128 GB) - **Power Input:** +9 V to +48 V DC via terminal block - **Power Consumption:** Typical 12 V DC @ 250 mA - **Operating Temperature:** 0 °C to 70 °C (32 °F to 158 °F) - **Mounting Options:** Wall‑mount or DIN‑rail (optional kit) - **Certifications:** CE Class A, FCC Class A - **Additional Hardware:** Watchdog timer, Real‑Time Clock (RTC) with super‑capacitor backup - **Ultra‑low power design** for continuous industrial operation

Manufacturer: Artila

Category: IoT Gateway

- **ARM9 Processor Platform:** Powered by the Atmel AT91RM9200 ARM920T CPU running at 180 MHz, delivering approximately 200 MIPS performance with integrated MMU and 16 KB instruction/data caches. - **Linux-Ready Architecture:** Pre-installed Linux 2.6.x kernel with U-Boot 1.1.2 bootloader, supporting JFFS2, EXT2/EXT3, VFAT/FAT, and NFS file systems. - **Multiple Communication Interfaces:** - Four high-speed serial TTY ports (up to 921.6 Kbps). - One 10/100 Mbps Ethernet port with 1.5 kV magnetic isolation. - Two USB 2.0 full-speed host ports (12 Mbps) for peripheral expansion. - One internal SD card slot (SD 1.0 compliant, up to 2 GB). - **Digital I/O:** 16 programmable TTL-compatible GPIO channels via 20-pin header. - **Compact and Fanless Design:** Dimensions 78 × 108 × 24 mm; fanless metal enclosure for industrial reliability. - **Wide Power Input Range:** 9–48 V DC input, 300 mA at 12 V DC typical consumption (

Manufacturer: Artila

Category: IoT Gateway

- **ARM9 Processor Platform:** Based on the **Atmel AT91RM9200 (ARM920T core)** with integrated MMU, delivering up to **200 MIPS at 180 MHz**. - **Pre-installed Linux OS:** Fully compatible with **Linux kernel 2.6.x**, supporting standard file systems (JFFS2, EXT2/3, VFAT, NFS). - **Integrated Web Server:** Includes **Boa HTTP server**, **SSH**, **SSL**, and **SNMP v1/v2** for secure remote management. - **Multiple Serial Interfaces:** Four high-speed serial ports (up to **921.6 Kbps**) with flexible configuration: - Port 1: RS-232/422/485 selectable - Ports 2–4: RS-232 (Port 2 supports full modem signals) - **Networking:** One **10/100 Mbps Ethernet port** with 1.5 kV magnetic isolation. - **USB Expansion:** Two **USB 2.0 host ports** supporting flash drives, Wi-Fi dongles (IEEE 802.11b/g), USB-to-Serial, and CDC modems. - **Digital I/O:** 16 programmable **GPIO channels** (TTL compatible). - **Storage Expansion:** Internal **SD card slot** (SD 1.0 compliant, up to 2 GB non-SDHC). - **Compact and Fanless Design:** Dimensions **78 × 108 × 24 mm**, metal enclosure, DIN-rail mountable. - **Low Power Consumption:** Less than **3 W**, operating from **9–48 VDC** input. - **Wide Temperature Range:** Operational from **-20°C to +80°C** (industrial version). - **Development Ready:** Includes **GNU C/C++ cross-compiler**, **GLIBC POSIX library**, and **U-Boot 1.1.2 bootloader**. - **Security and Protocol Support:** SSH 1.0/2.0, SSL, TCP/IP stack, DHCP, FTP, Telnet, PPP, SNMP, SMTP, and firewall (iptables).

Manufacturer: Artila

Category: IoT Gateway

- **Processor & Architecture:** ARM926EJ-S (ARM9) 400 MHz CPU with Memory Management Unit (MMU), 32 KB instruction cache, and 32 KB data cache. - **Memory:** 64 MB SDRAM and 256 MB NAND Flash; 2 MB DataFlash® for system backup. - **Storage Expansion:** Internal microSD socket supporting up to 32 GB SDHC cards. - **Operating System:** Pre-installed Linux kernel 2.6.29 with U-Boot 1.1.2 bootloader. - **Networking:** 1 × 10/100 Mbps Ethernet port (RJ45) with 1.5 kV magnetic isolation. - **Serial Communication:** - 1 × software-configurable RS-232/422/485 port. - 3 × RS-232/485 ports. - All ports use RJ45 connectors; baud rates up to 921.6 kbps. - **USB Connectivity:** - 2 × USB 2.0 full-speed (12 Mbps) host ports. - 1 × reserved USB client port. - **Digital I/O:** 5 × programmable GPIO channels (CMOS I/O, configurable as input/output). - **Indicators:** Power, Ready, Ethernet Link/Activity, and per-port serial TX/RX LEDs. - **Power Supply:** 9–48 V DC input, 250 mA @ 12 V DC (≈ 3 W). - **Form Factor:** Compact metal enclosure, fanless, DIN-rail mountable. - **Software Tools:** GNU C/C++ cross-compilation toolchain for Linux and Windows; supports Java accelerator. - **Security & Networking:** SSH 1.0/2.0, SSL, FTP, Telnet, and Web server (Apache2 or lighttpd). - **Low Power Design:**

Manufacturer: Artila

Category: IoT Gateway

- **Embedded ARM9 Processor:** Atmel AT91SAM9G20, 400 MHz ARM926EJ‑S core with MMU, 32 KB instruction and 32 KB data cache. - **Pre‑installed Linux System:** Linux kernel 2.6.29 with U‑Boot 1.1.2 bootloader and full root file system. - **Memory Architecture:** 128 MB SDRAM and 128 MB NAND Flash; includes 2 MB DataFlash® for system backup. - **Storage Expansion:** Internal microSD socket supporting up to 16 GB SDHC cards. - **Networking:** One 10/100 Base‑T Ethernet port (RJ45) with 1.5 kV magnetic isolation. - **Serial Communication:** Four software‑configurable serial ports (1 × RS‑232/422/485, 3 × RS‑232/485) supporting up to 921.6 kbps. - **USB Connectivity:** Two USB 2.0 full‑speed (12 Mbps) host ports and one reserved client port. - **Digital I/O:** Five programmable GPIO channels (TTL compatible). - **Low Power Design:** Operates from 9–48 V DC, consuming less than 3 W (≈ 250 mA @ 12 V). - **Compact, Fanless Construction:** Metal enclosure, DIN‑rail mountable, dimensions 78 × 108 × 24 mm. - **Wide Operating Range:** Standard 0 – 70 °C; optional Matrix‑504T version supports −20 – 80 °C. - **Software Development Support:** GNU C/C++ cross‑toolchain for Linux and Windows (via Cygwin), Java accelerator, and pre‑installed utilities. - **Security & Networking Services:** SSH 1.0/2.0, SSL, FTP, Telnet, HTTP (Apache2 or lighttpd), and iptables firewall. - **Maintenance & Recovery:** Built‑in DataFlash recovery system, watchdog timer, and system recovery console.

Manufacturer: Artila

Category: IoT Gateway

- **Processor:** ARM926EJ-S (Atmel AT91SAM9G20) running at 400 MHz with integrated MMU. - **Memory:** 64 MB SDRAM and 256 MB NAND Flash; 2 MB DataFlash for system backup. - **Storage Expansion:** Internal microSD socket supporting up to 32 GB. - **Operating System:** Pre-installed Linux kernel 2.6.29 with U-Boot 1.1.2 bootloader. - **Networking:** 1 × 10/100 Mbps Ethernet port (RJ45) with 1.5 kV magnetic isolation. - **Serial Communication:** - 1 × software-configurable RS‑232/422/485 port. - 3 × RS‑232/485 ports. - All ports via RJ45 connectors, up to 921.6 kbps. - **USB Connectivity:** 2 × USB 2.0 full-speed (12 Mbps) host ports; 1 × reserved client port. - **GPIO:** 5 × programmable digital I/O lines (CMOS level, 100 kΩ pull-up). - **Power Input:** 9–48 V DC, 250 mA @ 12 V DC (≈ 3 W). - **Form Factor:** Ultra-compact metal enclosure, 78 × 108 × 24 mm. - **Mounting:** DIN rail mountable (optional DK‑35A kit). - **Environmental:** Operating temperature 0–70 °C (standard) or –20–80 °C (Matrix‑504T). - **Certifications:** CE Class A, FCC Class A. - **Software Tools:** GNU C/C++ cross-compilation toolchain for Linux and Windows (Cygwin). - **Security:** Supports SSH 1.0/2.0, SSL, and secure remote management. - **Web Services:** Built-in web server (lighttpd) and FTP server (vsftpd). - **Low Power Design:** Fanless, flash-based architecture with

Manufacturer: Artila

Category: IoT Gateway

- **Processor & Architecture:** ARM926EJ-S (ARM9) core, 400 MHz with MMU, 32 KB instruction cache and 32 KB data cache. - **Operating System:** Pre-installed Linux kernel 2.6.29 with U-Boot 1.1.2 bootloader. - **Memory:** 64 MB SDRAM and 256 MB NAND Flash (some configurations 128 MB/128 MB). - **Storage Expansion:** microSD socket supporting up to 32 GB SDHC cards. - **Networking:** 1 × 10/100 Mbps Ethernet (RJ45) with 1.5 kV magnetic isolation. - **Serial Communication:** 4 × software-configurable TTY ports (RS‑232/422/485), up to 921.6 kbps. - **USB Connectivity:** 2 × USB 2.0 full-speed (12 Mbps) host ports; 1 × USB client port (reserved). - **GPIO:** 5 × programmable digital I/O channels (CMOS level, 100 kΩ pull-up). - **Power Input:** 9 – 48 V DC, 250 mA @ 12 V DC (≈ 3 W). - **Form Factor:** Ultra-compact fanless metal enclosure, 78 × 108 × 24 mm. - **Operating Temperature:** 0 – 70 °C (standard), optional ‑20 – 80 °C (Matrix‑504T). - **Software Tools:** GNU C/C++ cross-compilation toolchain for Linux and Windows (Cygwin). - **Security & Networking:** SSH 1.0/2.0, SSL, FTP, Telnet, Web server (Apache2 or Lighttpd). - **Low Power Design:**

Manufacturer: Artila

Category: IoT Gateway

- **Embedded ARM9 Platform:** Powered by the Atmel AT91SAM9G20 (ARM926EJ-S core) running at 400 MHz with integrated MMU, 32 KB instruction cache, and 32 KB data cache. - **Pre-installed Linux System:** Ships with Linux kernel 2.6.29, U-Boot 1.1.2 bootloader, and a preconfigured root file system supporting UBI, JFFS2, EXT2/3, VFAT, and NFS. - **Memory Architecture:** 64 MB SDRAM, 256 MB NAND Flash, and 2 MB DataFlash for system backup. Includes a microSD slot supporting up to 32 GB SDHC cards. - **Networking:** One 10/100 Base‑T Ethernet port (RJ45) with 1.5 kV magnetic isolation. - **Serial Communication:** Four high-speed serial ports (up to 921.6 kbps). Port 1 configurable as RS‑232/422/485; Ports 2–4 configurable as RS‑232/485. - **USB Connectivity:** Two USB 2.0 full-speed (12 Mbps) host ports and one reserved USB client port. Supports USB storage, Wi‑Fi (Ralink RT73), serial adapters (PL‑2303, FTDI), modems (CDC), and USB cameras. - **Digital I/O:** Five programmable GPIO channels accessible via the console RJ45 port, configurable as input or output (default input with 100 kΩ pull‑up). - **Low Power Consumption:** Typical 250 mA @ 12 V DC (≈ 3 W). - **Compact, Fanless Design:** Rugged metal enclosure, 78 × 108 × 24 mm, DIN‑rail mountable. - **Wide Power Input Range:** 9–48 V DC input with reverse polarity protection. - **Operating Temperature:** Standard 0 – 70 °C; Matrix‑504T variant supports –20 – 80 °C. - **Software Development Support:** Includes GNU C/C++ cross‑compiler toolchain for Linux and Windows (Cygwin), plus example programs and utilities. - **Integrated Web and Network Services:** Pre‑installed Apache2 and Lighttpd web servers, SSH, FTP, Telnet, and broadcast discovery daemon (amgrd). - **System Recovery and Maintenance:** Built‑in DataFlash recovery system, loader menu for firmware updates, and USB‑based recovery utilities.

Manufacturer: Artila

Category: IoT Gateway

- **ARM9 400 MHz Processor:** Based on the Atmel AT91SAM9G20 ARM926EJ‑S core with MMU, 32 KB instruction and 32 KB data cache. - **Pre‑installed Linux OS:** Linux kernel 2.6.29 with U‑Boot 1.1.2 bootloader and full file system support (UBI, JFFS2, EXT2/3, VFAT, NFS). - **Memory Architecture:** 64 MB SDRAM, 256 MB NAND Flash, and 2 MB DataFlash for system backup. - **Storage Expansion:** Internal microSD socket supporting up to 32 GB SDHC cards. - **Networking:** One 10/100 Base‑T Ethernet port with 1.5 kV magnetic isolation. - **Serial Connectivity:** Four high‑speed TTY ports (up to 921.6 kbps) configurable as RS‑232/422/485; one port supports all three modes, others support RS‑232/485. - **USB Interfaces:** Two USB 2.0 full‑speed (12 Mbps) host ports and one reserved USB client port. - **GPIO:** Five programmable CMOS digital I/O channels accessible via the console RJ45 connector. - **Compact, Fanless Design:** 78 × 108 × 24 mm aluminum enclosure, DIN‑rail mountable. - **Wide Power Range:** 9 – 48 V DC input, typical consumption ≈ 3 W (250 mA @ 12 V). - **Extended Temperature Operation:** ‑20 °C to +80 °C for Matrix‑504T. - **Software Development Support:** GNU C/C++ cross‑toolchain for Linux and Windows (Cygwin), Java accelerator, and WinCE support. - **Security & Networking:** Built‑in SSH 1.0/2.0, SSL, FTP, Telnet, and web server (lighttpd). - **Low Power Consumption:**

Manufacturer: Artila

Category: IoT Gateway

- **Linux-Ready Platform:** Pre-installed Linux 2.6.38 kernel and file system, ready for immediate deployment and application development. - **ARM9 Processor:** Powered by the Atmel AT91SAM9G45 (400 MHz) with integrated MMU, 32 KB instruction cache, and 32 KB data cache. - **Memory & Storage:** 128 MB DDR2 SDRAM, 256 MB NAND Flash, and 2 MB DataFlash for system backup. Internal microSD slot supports up to 32 GB SDHC cards. - **Networking:** Two independent 10/100 Mbps Ethernet ports with 1.5 kV magnetic isolation for reliable industrial networking. - **Serial Communication:** Four software-configurable serial ports—one RS-232/422/485 and three RS-232/485—supporting baud rates up to 921.6 kbps. - **USB Connectivity:** Two USB 2.0 high-speed (480 Mbps) host ports for peripherals such as flash drives, Wi-Fi dongles, and serial adapters. - **Compact & Fanless Design:** Dimensions 78 × 108 × 24 mm, fanless metal enclosure for DIN-rail mounting. - **Low Power Consumption:** Less than 3 W typical power draw (200 mA @ 12 VDC). - **Wide Power Input Range:** 9–48 VDC input for flexible industrial power systems. - **Operating Temperature:** 0 °C to 70 °C (32 °F to 158 °F). - **Software Development Support:** Includes GNU C/C++ cross-compilation toolchain, ipkg package management, and web-based administration via Webmin. - **Security & Networking Services:** SSH, SSL, FTP, Telnet, and HTTP servers preconfigured. - **Reliability Features:** Integrated watchdog timer, real-time clock, and system recovery utilities.

Manufacturer: Artila

Category: IoT Gateway

- **ARM9-based Industrial Computer:** Powered by the Atmel AT91RM9200 ARM920T processor running at 180 MHz, delivering approximately 200 MIPS performance with integrated MMU and 16 KB instruction/data caches. - **Linux 2.6.x Ready:** Fully compatible with standard Linux kernel 2.6.x, supporting multiple file systems (JFFS2, EXT2/3, VFAT/FAT, NFS). - **High Connectivity:** - **8 serial ports** (5 configurable as RS-232/422/485, 3 fixed RS-232). - **2 Ethernet ports** (10/100 Mbps, RJ-45, 1.5 kV isolation). - **2 USB 2.0 host ports** for peripheral expansion (Wi-Fi, flash drives, serial adaptors). - **21 TTL-level GPIOs** for digital control and monitoring. - **Integrated Web and Network Services:** Preloaded with web server (Boa), SSH, FTP, Telnet, SNMP, and firewall utilities. - **Expandable Storage:** Internal SD card slot (SD 1.0 compliant, up to 2 GB non-SDHC). - **Audio Output:** Supports MP3 and WAV playback for multimedia or alert applications. - **Low Power, Fanless Design:** Consumes less than 3 W, operates from 9–40 V DC input, and supports DIN-rail or wall mounting. - **Open Development Environment:** Includes GNU C/C++ cross-compilation toolchain for Linux and Windows (Cygwin). - **Industrial Reliability:** CE Class A and FCC Class A compliant, with watchdog timer, RTC, and wide operating temperature range (0 – 70 °C).

Manufacturer: Artila

Category: IoT Gateway

- **ARM9 Architecture:** Powered by the Atmel AT91RM9200 ARM920T processor (180 MHz, 200 MIPS) with integrated MMU, 16 KB instruction cache, and 16 KB data cache. - **Linux-Ready Platform:** Pre-installed with Linux kernel 2.6.x, fully compatible with open-source GNU C/C++ toolchains for both Linux and Windows (Cygwin) environments. - **Dual Ethernet Ports:** Two independent 10/100 Mbps Ethernet interfaces (RJ-45) with 1.5 kV magnetic isolation for redundant or segmented networking. - **Four Configurable Serial Ports:** Four software-selectable RS-232/422/485 ports (DB9 male connectors) supporting up to 921.6 Kbps baud rate. Port 2 includes full modem control signals. - **USB Expansion:** Two USB 2.0 host ports supporting low-speed (1.5 Mbps) and full-speed (12 Mbps) devices such as flash drives, Wi-Fi dongles, and serial adapters. - **Digital I/O:** 21 programmable CMOS/TTL-level GPIO channels (DB25 female connector), each configurable as input or output. - **Storage Expansion:** Internal SD 1.0-compliant slot supporting up to 2 GB SD (non-SDHC) cards for additional data storage. - **Industrial Design:** Fanless, metal enclosure suitable for DIN-rail or wall mounting; wide 9–40 V DC input range; low power consumption (

Manufacturer: Artila

Category: IoT Gateway

- **Processor:** Atmel AT91SAM9G45 ARM9 CPU, 400 MHz with Memory Management Unit (MMU) - **Memory:** 128 MB DDR2 SDRAM, 256 MB NAND Flash - **Storage Expansion:** MicroSD slot supporting up to 32 GB SDHC cards - **Networking:** Two 10/100 Mbps Ethernet ports (LAN 1 and LAN 2) - **Wireless Connectivity:** - Optional 802.11 b/g/n WLAN via half‑size miniPCIe (Ralink RT5390U) - Optional 2G/3G cellular via full‑size miniPCIe (Cinterion module) with SIM socket - **Serial Communication:** Four RS‑232/422/485 software‑selectable ports - **USB Interfaces:** Two USB 2.0 high‑speed (480 Mbps) host ports and one USB device port - **Digital I/O:** - Two isolated digital inputs (2500 Vrms isolation) - One relay output (Form A or B, 30 VDC @ 1 A, jumper‑selectable) - **Operating System:** Pre‑installed Linux 2.6.38 kernel and root file system - **Software Environment:** - GNU C/C++ toolchain for Linux and Windows (via Cygwin) - BusyBox utilities and Artila‑specific management tools - Web server (lighttpd), SSH, FTP, and Telnet services pre‑configured - **Power Input:** 9 – 48 V DC, 500 mA @ 12 V DC typical - **Enclosure:** Fanless, metal housing suitable for DIN‑rail or wall mounting - **Operating Temperature:** 0 °C – 70 °C - **Dimensions:** 175 mm × 103 mm × 43 mm

Manufacturer: Artila

Category: IoT Gateway
