- **High-Resolution A/D Conversion:** 12-bit resolution ensures precise analog signal digitization, suitable for applications requiring accurate voltage measurement and signal analysis. - **Sampling Rate:** Capable of up to **40,000 samples per second (40 kS/s)**, enabling real-time data acquisition for dynamic signals. - **Analog Input Configuration:** Provides **8 single-ended (SE)** analog input channels with an input voltage range of **±5 V**, allowing simultaneous monitoring of multiple analog sources. - **ISA Bus Interface:** Designed for standard **ISA bus** architecture, ensuring compatibility with legacy and industrial PC systems. - **Digital I/O Capability:** Includes **3 or 4 TTL-level digital input/output lines**, configurable for control or monitoring of external devices. - **Integrated Counter/Timer Functions:** Features **three 16-bit counter/timer channels**, enabling event counting, frequency measurement, or timing control applications. - **Interrupt Support:** Supports multiple **IRQ lines (2, 3, 4, 5, 6, 7)** for flexible system configuration and efficient CPU interrupt handling. - **Low Power Consumption:** Operates with minimal power requirements: **+5 VDC at 30 mA** and **±12 VDC at 22 mA**, making it suitable for energy-efficient embedded systems. - **Compact Form Factor:** Board dimensions of **127 mm × 107 mm** allow installation in space-constrained PC enclosures or compact industrial systems. - **Standard Connector Interface:** Equipped with a **D-type 37-pin male connector**, providing a robust and standardized interface for analog, digital, and timing signals. - **Reliable Manufacturer:** Produced by **Contec Co., Ltd.**, a recognized manufacturer of industrial computing and measurement hardware, ensuring quality and long-term support.

Manufacturer: Contec

Category: A/D General Purpose ISA

- **High-Resolution Analog-to-Digital Conversion:** 12-bit resolution ensures precise analog signal measurement with fine granularity and low quantization error. - **Sampling Rate:** Capable of up to **30,000 samples per second (30 kS/s)**, suitable for medium-speed data acquisition tasks. - **Analog Input Configuration:** Supports **8 single-ended (SE)** analog input channels, allowing simultaneous monitoring of multiple analog signals. - **Input Voltage Ranges:** Configurable for **±5 V** or **0–10 V** input ranges, providing flexibility for different signal levels and sensor outputs. - **Digital I/O Capability:** Includes **4 TTL-compatible digital input lines** and **4 TTL-compatible digital output lines** for control and monitoring of external devices. - **Counter/Timer Functions:** Equipped with **three independent 16-bit counter/timer channels**, ideal for event counting, frequency measurement, or timing control. - **Interrupt Support:** Compatible with **IRQ 2, 3, 4, 5, 6, or 7**, allowing flexible integration into PC-based systems with interrupt-driven data acquisition. - **Connector Type:** Features a **D-type 37-pin female connector** for secure and standardized external signal interfacing. - **Compact Form Factor:** Physical dimensions of **120 mm × 107 mm**, optimized for installation in standard ISA slots. - **ISA Bus Interface:** Designed for legacy and industrial PC systems using the ISA bus architecture, ensuring stable and deterministic performance.

Manufacturer: Contec

Category: A/D General Purpose ISA

- **High-Resolution Analog-to-Digital Conversion:** 12-bit resolution ensures precise signal digitization suitable for scientific and industrial measurement applications. - **Flexible Input Configuration:** Supports **16 single-ended (SE)** or **8 differential (DI)** analog input channels, allowing users to select between higher channel count or improved noise immunity. - **Multiple Input Voltage Ranges:** Configurable input ranges of **±10 V**, **±5 V**, and **0–10 V**, enabling compatibility with a wide variety of analog sensors and transducers. - **Sampling Rate:** Maximum sampling speed of **50 kS/s (50,000 samples per second)**, providing sufficient temporal resolution for medium-speed data acquisition tasks. - **ISA Bus Interface:** Designed for **ISA-bus** PCs, ensuring compatibility with legacy industrial systems and laboratory setups that rely on ISA expansion slots. - **Integrated Counter/Timer:** Equipped with an **Intel 8254-2 programmable counter/timer** with a **1 µs resolution**, suitable for event counting, frequency measurement, and timing control. - **Digital I/O Capability:** Includes **1 input and 1 output TTL-level I/O line**, allowing simple digital control or status signaling. - **Interrupt Support:** Supports multiple interrupt request (IRQ) lines: **IRQ 2, 3, 4, 5, 6, or 7**, providing flexible system integration and efficient data handling. - **Compact Form Factor:** Physical dimensions of **143 mm × 107 mm**, optimized for standard ISA slots while maintaining sufficient space for connectors and circuitry. - **Standard Connector Interface:** Features a **D-type 37-pin female connector**, providing a robust and standardized interface for analog and digital signal connections. - **Industrial Reliability:** Manufactured by Contec, a trusted provider of industrial PC components, ensuring long-term reliability, stable performance, and consistent quality.

Manufacturer: Contec

Category: A/D General Purpose ISA

- **Analog-to-Digital Conversion:** 12-bit resolution ensures accurate signal digitization for precise measurement and control applications. - **Sampling Rate:** Supports up to 12.5 kS/s (kilosamples per second), providing sufficient speed for low- to mid-frequency signal acquisition. - **Analog Input Channels:** 16 single-ended (SE) analog input channels allow simultaneous monitoring of multiple analog sources. - **Programmable Input Range:** Selectable gain ranges of ±5V, ±2.5V, ±1.25V, ±0.63V, and ±0.32V enable flexible adaptation to various signal amplitudes and sensor outputs. - **Digital I/O:** 8 digital input and 8 digital output TTL-compatible lines for control, monitoring, and interfacing with external devices. - **Counter/Timer Functions:** Three independent counter/timer channels for event counting, frequency measurement, or timing control. - **Bus Interface:** ISA bus interface for legacy PC systems, ensuring compatibility with industrial and laboratory setups still utilizing ISA architecture. - **Software Support:** Drivers available for BASIC, C, and Pascal programming environments, with additional Windows and UNIX driver packages deliverable. - **Compact Design:** Board dimensions of 155 mm × 99 mm allow easy integration into standard PC enclosures. - **Manufacturer Reliability:** Produced by Axiom, known for robust and long-lasting industrial data acquisition hardware.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Resolution Analog Input:** 12-bit analog-to-digital conversion ensures precise signal measurement and accurate data representation. - **Sampling Rate:** Supports up to 12.5 kS/s (kilosamples per second), suitable for low- to medium-speed data acquisition tasks. - **Channel Configuration:** 16 single-ended (SE) analog input channels allow simultaneous monitoring of multiple analog sources. - **Programmable Input Range:** Selectable gain settings of ±5V, ±2.5V, ±1.25V, ±0.63V, and ±0.32V enable flexible adaptation to various signal amplitudes and sensor outputs. - **Digital I/O Capability:** 8 TTL-compatible digital input lines and 8 TTL-compatible digital output lines provide direct interfacing with logic-level devices, switches, and control circuits. - **Counter/Timer Functions:** Three integrated counter/timer channels support event counting, frequency measurement, and timing control applications. - **Interrupt Support:** Configurable IRQ lines (2–15) for efficient interrupt-driven data acquisition and system integration. - **Software Support:** Includes drivers and libraries for BASIC, C, and Pascal programming environments; Windows and UNIX drivers are available for broader compatibility. - **Compact Form Factor:** Standard AT/ISA card dimensions (155 mm × 122 mm) ensure compatibility with legacy PC systems and industrial computers. - **Manufacturer Reliability:** Designed and produced by Axiom, known for durable and precise data acquisition hardware.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Resolution Analog Input:** 12-bit analog-to-digital conversion with a maximum sampling rate of **12.5 kS/s**, suitable for medium-speed data acquisition and control tasks. - **Multiple Analog Input Channels:** Provides **16 single-ended (SE)** analog input channels, allowing simultaneous monitoring of multiple analog sources. - **Programmable Input Gain:** Selectable input voltage ranges of **±5V, ±2.5V, ±1.25V, ±0.63V, and ±0.32V**, enabling optimized signal scaling and improved measurement accuracy across various signal amplitudes. - **Dual 12-bit Digital-to-Analog Outputs:** Two independent **12-bit DA channels** for generating analog control signals, waveform outputs, or feedback control voltages. - **Digital I/O Interface:** Includes **8 TTL-compatible digital inputs** and **8 TTL-compatible digital outputs**, providing flexible digital control and monitoring capabilities. - **Integrated Counter/Timer Functions:** Three programmable **counter/timer channels** for event counting, frequency measurement, or timing control applications. - **Interrupt Support:** Configurable **IRQ lines (2–15)** for efficient interrupt-driven data acquisition and real-time control. - **Comprehensive Software Support:** Supplied with **drivers and libraries for BASIC, C, and Pascal**, with optional **Windows and UNIX drivers** for modern operating systems. - **Compact Form Factor:** Standard **AT/ISA card dimensions (155 mm × 122 mm)** for easy integration into legacy or industrial PC systems. - **Industrial Reliability:** Designed for stable operation in laboratory and industrial environments, with robust electrical design and high signal integrity.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Speed Analog Input:** 60 kS/s (kilosamples per second) sampling rate for accurate and responsive data acquisition. - **Resolution:** 12-bit analog-to-digital conversion, providing fine granularity and precision in signal measurement. - **Analog Input Channels:** 16 single-ended (SE) channels, allowing simultaneous monitoring of multiple analog signals. - **Analog Output (D/A):** Two 12-bit digital-to-analog output channels with selectable output ranges of 0–5 V or 0–10 V. - **Programmable Gain Amplifier (PGA):** Adjustable input ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.63 V, and ±0.32 V for flexible signal conditioning and improved resolution across varying signal amplitudes. - **Digital I/O:** 24 digital input/output lines (TTL-level), providing 24 input and 24 output channels for control and monitoring tasks. - **DMA Support:** Direct Memory Access (DMA) capability for efficient, high-speed data transfer between the card and system memory, minimizing CPU load. - **Compatibility:** Fully compatible with the DAS-16 standard (single-ended mode only), ensuring interoperability with existing software and hardware ecosystems. - **Driver Support:** Includes drivers for Basic, C, and Pascal programming environments; Windows and Unix drivers are available for broad OS compatibility. - **Form Factor:** ISA bus interface, suitable for legacy and industrial PC systems requiring reliable, deterministic data acquisition. - **Compact Design:** Physical dimensions of 334 mm × 99 mm, optimized for standard ISA slots.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Resolution Analog Input:** 12-bit analog-to-digital conversion for precise signal measurement. - **Sampling Rate:** Supports up to 60,000 samples per second (60 kS/s), enabling real-time data acquisition for dynamic signals. - **Analog Input Channels:** 16 single-ended (SE) channels for multi-signal monitoring. - **Analog Output Channels:** Two 12-bit digital-to-analog (D/A) output channels with selectable output ranges of 0–5 V or 0–10 V. - **Programmable Gain:** Adjustable input ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.63 V, and ±0.32 V for flexible signal scaling and improved resolution. - **Digital I/O:** 24 digital input/output lines (TTL-compatible), providing 24 input and 24 output channels for control and monitoring tasks. - **Bus Interface:** ISA (AT) bus interface for legacy PC-based data acquisition systems. - **DMA and Interrupt Support:** Direct Memory Access (DMA) and interrupt request (IRQ) channels 2–15 supported for efficient data transfer and system integration. - **Compatibility:** Fully compatible with the DAS-16 standard (single-ended mode only), ensuring interoperability with existing software and hardware ecosystems. - **Software Support:** Includes drivers and libraries for BASIC, C, and Pascal programming environments, simplifying integration into custom applications. - **Form Factor:** Half-size ISA card, suitable for compact system configurations.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Speed Sampling:** Supports up to **90 kS/s** (kilosamples per second) sampling rate, enabling precise and rapid analog signal acquisition. - **High Resolution:** **12-bit** analog-to-digital conversion for accurate signal representation and fine measurement granularity. - **Flexible Input Configuration:** Provides **16 single-ended (SE)** or **8 differential (DI)** analog input channels, allowing users to select between higher channel count or improved noise immunity. - **Programmable Input Ranges:** Supports multiple voltage input ranges of **±0.02 V, ±0.1 V, ±1 V, ±10 V** or **0–0.02 V, 0–0.1 V, 0–1 V, 0–10 V**, with programmable gain settings of **1, 10, 100, and 500**. - **Dual Analog Outputs:** Two **12-bit digital-to-analog (DA)** output channels for waveform generation, control signals, or analog actuation. - **Digital I/O Capability:** Includes **8 TTL-compatible digital I/O lines**, configurable for general-purpose input/output operations. - **DMA and Interrupt Support:** Direct Memory Access (DMA) channels **1 and 3** supported for high-speed data transfer; interrupt request (IRQ) lines **2–7** selectable for flexible system integration. - **Software Compatibility:** Comes with drivers and libraries for **Windows**, **BASIC**, **C**, and **Pascal**, simplifying integration into custom applications. - **Hardware Compatibility:** Fully **DAS-16G compatible**, ensuring interoperability with existing software and hardware ecosystems. - **Compact Form Factor:** Standard ISA card dimensions of **334 mm × 99 mm**, suitable for installation in industrial PCs and legacy systems. - **Connector Interface:** Equipped with a **50-pin connector** for signal interfacing, ensuring secure and organized connectivity.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Speed Analog-to-Digital Conversion:** Capable of sampling rates up to **90 kS/s (kilosamples per second)** with **12-bit resolution**, providing precise and reliable analog signal digitization for demanding measurement applications. - **Flexible Analog Input Configuration:** Supports **16 single-ended (SE)** or **8 differential (DI)** analog input channels, allowing users to select between higher channel count or improved noise immunity depending on the application. - **Programmable Input Voltage Ranges:** Configurable input ranges of **±1.25 V, ±2.5 V, ±5 V, ±10 V**, or **0–1.25 V, 0–2.5 V, 0–5 V, 0–10 V**, with **programmable gain settings of 1, 2, 4, or 8**, enabling precise adaptation to various signal levels. - **Dual 12-bit Analog Outputs:** Two independent **12-bit D/A channels** provide analog output capability for control, simulation, or waveform generation tasks. - **Digital I/O Capability:** Includes **8 TTL-compatible digital input/output lines**, configurable for general-purpose digital control, status monitoring, or interfacing with external devices. - **DMA and Interrupt Support:** Supports **DMA channels 1 and 3** and **IRQ lines 2–7**, allowing efficient data transfer and flexible interrupt-driven operation for real-time performance. - **Software Compatibility:** Supplied with drivers and libraries for **Windows**, **BASIC**, **C**, and **Pascal**, simplifying integration into custom software environments and legacy systems. - **Hardware Compatibility:** Fully **DAS-16G compatible**, ensuring seamless integration with existing software and hardware ecosystems that adhere to this widely used data acquisition standard. - **Compact ISA Form Factor:** Designed for standard **ISA bus** PCs, with a physical dimension of **334 mm × 99 mm**, suitable for industrial PCs and legacy systems requiring ISA expansion.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Speed Analog Input:** - Sampling rate up to **90 kS/s** (kilosamples per second) for precise and rapid data acquisition. - **12-bit resolution** ensures accurate analog-to-digital conversion suitable for scientific and industrial measurements. - **Flexible Channel Configuration:** - Supports **16 single-ended (SE)** or **8 differential (DI)** analog input channels. - Programmable input configuration allows adaptation to various sensor and signal types. - **Programmable Input Ranges:** - Voltage input ranges: **±0.02 V, ±0.1 V, ±1 V, ±10 V** or **0–0.02 V, 0–0.1 V, 0–1 V, 0–10 V**. - **Programmable gain settings:** ×1, ×10, ×100, ×500. - Enables precise measurement of both low-level and high-level signals. - **Analog Output (D/A):** - **2 channels** of 12-bit digital-to-analog conversion. - Ideal for control signal generation, waveform output, or actuator control. - **Digital I/O:** - **8 TTL-compatible digital input/output lines** for general-purpose control and monitoring. - **Bus Interface:** - **AT ISA bus** interface for legacy and industrial PC systems. - **DMA channels 1 or 3** and **IRQ lines 2–15** selectable for flexible system integration. - **Software Support:** - Compatible with **Windows**, **BASIC**, **C**, and **Pascal** programming environments. - Includes driver libraries and sample code for rapid application development. - **Compatibility:** - **DAS-16G compatible**, ensuring interoperability with existing software and hardware ecosystems. - **Connector:** - **50-pin header connector** for analog and digital I/O connections. - **Compact Design:** - **Half-size AT card** form factor suitable for space-constrained systems.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **High-Speed Analog Input:** 90 kS/s (kilosamples per second) maximum sampling rate, enabling accurate and responsive data capture for dynamic signals. - **High Resolution:** 12-bit analog-to-digital conversion for precise signal quantization and measurement accuracy. - **Flexible Channel Configuration:** Supports **16 single-ended (SE)** or **8 differential (DI)** analog input channels, allowing users to select between higher channel count or improved noise immunity. - **Programmable Input Ranges:** ±1.25 V, ±2.5 V, ±5 V, ±10 V or 0–1.25 V, 0–2.5 V, 0–5 V, 0–10 V ranges, with programmable gain settings of 1, 2, 4, or 8. - **Dual Analog Outputs:** Two 12-bit D/A channels for waveform generation, control signals, or analog actuation. - **Digital I/O Capability:** 8 TTL-compatible digital input/output lines for control, monitoring, or synchronization tasks. - **DMA and Interrupt Support:** Direct Memory Access (DMA) channels 1 or 3 and interrupt request (IRQ) lines 2–15 for efficient data transfer and flexible system integration. - **Software Compatibility:** Includes drivers and libraries for **Windows**, **BASIC**, **C**, and **Pascal**, simplifying software development and integration. - **Hardware Compatibility:** Fully **DAS-16G compatible**, ensuring interoperability with existing software and hardware ecosystems. - **Compact Form Factor:** Half-size AT ISA card design for easy installation in standard industrial PCs. - **Connector Interface:** 50-pin header connector for analog and digital signal interfacing.

Manufacturer: Axiom

Category: A/D General Purpose ISA

- **PCI Express Interface:** x1 lane PCIe® interface ensuring high‑speed data throughput and plug‑and‑play configuration. - **Simultaneous Sampling:** Four differential analog input channels sampled simultaneously at up to **500 kS/s per channel**. - **High Resolution:** 16‑bit analog‑to‑digital conversion with no missing codes for precise signal measurement. - **Programmable Input Ranges:** Bipolar ±10 V, ±5 V, ±2.5 V, ±1.25 V and unipolar 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V. - **Dual Analog Outputs:** Two 12‑bit voltage outputs with 1 MS/s update rate, ±10 V or 0–10 V ranges, and waveform generation capability. - **Digital I/O:** 24‑channel TTL‑compatible programmable digital I/O (8255 PIO compatible). - **Timer/Counter:** Two 16‑bit general‑purpose up/down counters with 40 MHz internal or up to 10 MHz external clock. - **Triggering:** Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers. - **Auto‑Calibration:** Fully automatic calibration of analog input and output channels using on‑board precision reference (5.000 V ±2 ppm/°C). - **Scatter‑Gather DMA:** High‑speed bus‑mastering DMA with scatter/gather capability for efficient data transfer without CPU overhead. - **Synchronization:** Multiple‑card synchronization via SSI bus for scalable multi‑channel systems. - **Software Support:** Drivers and SDKs for Windows and Linux; compatible with LabVIEW®, MATLAB®, Visual C++, Visual Basic, and .NET environments. - **Compact Design:** 168 mm × 107 mm half‑size PCIe card with VHDCI‑68 connector. - **Operating Range:** 0 °C – 55 °C, 5 – 95 % RH non‑condensing.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **PCI Express x1 Interface:** Fully compliant with PCI Express architecture, supporting both 3.3 V and 5 V signaling environments. - **Simultaneous Sampling:** Four differential analog input channels sampled simultaneously at up to **250 kS/s per channel** with 16‑bit resolution. - **High‑Resolution Analog Input:** 16‑bit A/D conversion with no missing codes, ensuring precise signal digitization. - **Programmable Input Ranges:** Bipolar ±10 V, ±5 V, ±2.5 V, ±1.25 V and unipolar 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V. - **Analog Output Capability:** Two 12‑bit voltage outputs with waveform generation up to **1 MS/s** update rate, supporting ±10 V or 0–10 V ranges. - **Digital I/O:** 24‑channel TTL‑compatible programmable I/O (8255‑compatible). - **Timer/Counter:** Two 16‑bit up/down general‑purpose counters with 40 MHz internal or up to 10 MHz external clock. - **Triggering:** Software, external analog, external digital, or SSI‑bus triggers; supports pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and repeated trigger modes. - **Auto‑Calibration:** Fully automatic calibration of analog input and output channels using on‑board precision reference (5.000 V, ±2 ppm/°C). - **High Noise Immunity:** Differential inputs and isolated analog/digital sections minimize interference. - **Scatter‑Gather DMA:** High‑speed bus‑mastering DMA with scatter/gather capability for efficient data transfer without CPU overhead. - **Multiple‑Card Synchronization:** SSI bus allows synchronization of up to four cards for expanded channel count. - **Software Support:** Drivers and SDKs for Windows and Linux; compatible with LabVIEW®, MATLAB®, Visual C/C++, Visual Basic, and .NET environments. - **Compact Form Factor:** 168 mm × 107 mm half‑size PCIe card suitable for industrial PCs and embedded systems.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **High‑speed simultaneous sampling:** 4 differential AI channels, 14‑bit resolution, 2 MS/s aggregate rate. - **Dual analog outputs:** 2 × 12‑bit voltage outputs (±10 V or 0–10 V ranges) with 1 MS/s update rate and 2 k‑sample FIFO. - **Digital I/O:** 24 TTL/CMOS‑compatible lines (8255 PIO architecture). - **Timer/Counter:** 2 × 16‑bit general‑purpose up/down counters (40 MHz base clock, external up to 10 MHz). - **Triggering:** software, external analog or digital, and SSI bus trigger sources with pre‑, post‑, middle‑, delay‑, and re‑trigger modes. - **Auto‑calibration:** on‑board 5 V reference (±2 ppm/°C) with digital trim DACs for gain/offset correction. - **Scatter‑gather DMA:** bus‑mastering DMA for high‑throughput data transfer without CPU intervention. - **Multiple‑card synchronization:** System Synchronization Interface (SSI) for clock and trigger sharing among up to four cards. - **Comprehensive software support:** Windows 7/8 x86/x64 and Linux drivers; SDKs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Compact design:** low‑noise analog/digital segregation and half‑size PCB for space‑constrained systems.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **Simultaneous Sampling:** Four differential analog input channels sampled simultaneously at up to **800 kS/s per channel**, ensuring phase‑accurate acquisition across multiple signals. - **High Resolution:** 16‑bit analog‑to‑digital conversion with no missing codes for precise signal representation. - **Flexible Input Ranges:** Programmable bipolar ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V and unipolar ranges of 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V. - **Dual Analog Outputs:** Two 12‑bit voltage outputs (0–10 V, ±10 V, or external reference) with 1 MS/s update rate and waveform generation capability. - **Digital I/O:** 24 programmable TTL/CMOS‑compatible digital I/O lines (8255 PIO compatible). - **Timer/Counter:** Two 16‑bit up/down general‑purpose counters with 40 MHz internal or up to 10 MHz external clock. - **Triggering:** Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers with multiple trigger modes: pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and repeated trigger. - **Auto‑Calibration:** On‑board precision 5.000 V reference with ±2 ppm/°C drift and 6 ppm/1000 h stability; automatic gain and offset calibration eliminates manual trimpot adjustment. - **High Noise Immunity:** Piggy‑back analog/digital board design and dedicated DC/DC regulation minimize digital noise coupling. - **Bus‑Mastering DMA with Scatter‑Gather:** High‑speed data transfer directly to system memory without CPU overhead, supporting fragmented memory blocks. - **Multiple‑Card Synchronization:** SSI bus allows synchronization of up to four cards for expanded channel counts and coherent sampling. - **Software Support:** Compatible with ADLINK D2K‑DASK (Windows), D2K‑DASK/X (Linux), LabVIEW® (D2K‑LVIEW), and ActiveX (D2K‑OCX) drivers.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **High‑Speed Analog Input:** 64 single‑ended or 32 differential analog input channels with 12‑bit resolution and up to 3 MS/s sampling rate. Supports mixed‑mode channel configuration (SE/DI selectable per channel). - **Analog Output:** Two 12‑bit analog output channels with ±10 V or 0–10 V ranges, 1 MS/s update rate, and 1 k‑sample FIFO per channel. - **Digital I/O:** 24‑channel TTL‑compatible programmable digital I/O (8255 PIO). - **Counter/Timer:** Two 16‑bit general‑purpose up/down counters with 40 MHz internal or up to 10 MHz external clock. - **Triggering:** Supports software, external analog, and digital triggers, as well as synchronization via SSI (System Synchronization Interface) bus. - **Auto‑Calibration:** Fully automatic calibration with onboard 5.000 V reference (±2 ppm/°C). - **High Bandwidth and Accuracy:** 2 MHz small‑signal bandwidth, 1 µs settling time to 0.1% error, ±0.06% FSR gain error, ±2 mV offset error. - **Scatter‑Gather DMA:** High‑speed bus‑mastering DMA with scatter/gather capability for efficient data transfer. - **Synchronization:** Multi‑card synchronization through SSI or PXI trigger bus. - **Software Support:** Compatible with Windows 7/8 (x86/x64) and Linux; drivers for LabVIEW, MATLAB, C/C++, Visual Basic, and Visual Studio.NET. - **Utility Software:** Includes AD‑Logger for data logging and monitoring.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **PCI Express Interface:** x1 lane PCIe bus for high‑speed data throughput and plug‑and‑play configuration. - **Analog Input Channels:** 64 single‑ended (SE) or 32 differential (DI) channels, software‑selectable per channel. - **Resolution and Sampling:** 16‑bit resolution, maximum sampling rate of 500 kS/s. - **Analog Input Ranges:** Bipolar ±10 V, ±5 V, ±2.5 V, ±1.25 V; unipolar 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V. - **Programmable Gain:** x1, x2, x4, x8. - **Auto‑Calibration:** Fully automatic calibration with onboard 5 V reference (±2 ppm/°C). - **FIFO Buffers:** 1 k‑sample A/D FIFO and 1 k‑sample D/A FIFO for efficient data streaming. - **Analog Output:** Two 12‑bit voltage output channels (0–10 V or ±10 V) with 1 MS/s update rate. - **Digital I/O:** 24‑channel TTL‑compatible programmable I/O (8255 PIO). - **Timer/Counter:** Two 16‑bit general‑purpose counters with 40 MHz base clock. - **Triggering:** Supports software, external analog, and digital triggers; pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and repeated trigger modes. - **Synchronization:** Multi‑card synchronization via SSI (System Synchronization Interface) or PXI trigger bus. - **Software Support:** Drivers for Windows and Linux; SDKs for LabVIEW, MATLAB, C/C++, Visual Basic, and Visual Studio.NET. - **Operating Systems:** Windows 7/8 x86/x64, Linux kernels 2.4.x and later. - **Form Factor:** PCIe half‑length card, 175 mm × 107 mm. - **Connectors:** Two 68‑pin VHDCI female connectors for analog/digital I/O and timing signals.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **PCI Express x1 Interface:** High‑speed, plug‑and‑play PCIe connectivity for modern PC platforms. - **High‑Resolution Analog Input:** 64 single‑ended or 32 differential channels, 16‑bit resolution, up to 250 kS/s sampling rate. - **Flexible Input Ranges:** Bipolar ±10 V to ±1.25 V and unipolar 0–10 V to 0–1.25 V ranges, software‑selectable per channel. - **Programmable Gain:** x1, x2, x4, x8 gain settings for optimized signal scaling. - **Dual Analog Outputs:** Two 12‑bit voltage outputs (0–10 V or ±10 V) with 1 MS/s update rate and 20 V/µs slew rate. - **Digital I/O:** 24‑channel TTL‑compatible programmable I/O via Intel 8255 PIO architecture. - **Timer/Counter:** Two independent 16‑bit general‑purpose counters with 40 MHz base clock and external clock input up to 10 MHz. - **Triggering:** Supports software, external analog/digital, and SSI (System Synchronization Interface) triggers with multiple trigger modes (pre‑, post‑, middle‑, delay‑trigger). - **Auto‑Calibration:** Fully automatic calibration with onboard 5 V reference (±2 ppm/°C). - **FIFO Buffers:** 1 k‑sample A/D FIFO and 1 k‑sample D/A FIFO for continuous data streaming. - **Scatter‑Gather DMA:** Efficient high‑speed data transfer with minimal CPU overhead. - **Synchronization:** Multi‑card synchronization via SSI bus or PXI trigger bus. - **Software Support:** Drivers and SDKs for Windows and Linux; compatible with LabVIEW, MATLAB, C/C++, Visual Basic, and Visual Studio.NET. - **Utility Software:** AD‑Logger for data logging and monitoring.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **PCI Express Interface:** x1 lane PCIe interface for high‑speed data throughput and plug‑and‑play configuration. - **High Channel Density:** 96 single‑ended (SE) or 48 differential (DI) analog input channels; mixed‑mode operation supported. - **High Sampling Rate:** Up to 3 MS/s maximum sampling rate (single‑channel). - **12‑bit Resolution:** No missing codes; precise A/D conversion for accurate signal representation. - **Programmable Gain:** 10 selectable gains (×1, ×2, ×4, ×5, ×8, ×10, ×20, ×40, ×50, ×200). - **Wide Input Range:** Bipolar ranges from ±0.05 V to ±10 V; unipolar ranges from 0–0.1 V to 0–10 V. - **Auto‑Calibration:** Fully automatic calibration with onboard 5 V reference (±2 ppm/°C). - **FIFO Buffer:** 1 k‑sample A/D FIFO for continuous high‑speed acquisition. - **Triggering:** Software, external analog, external digital, and SSI (System Synchronization Interface) triggers. - **Trigger Modes:** Pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and repeated trigger. - **Scatter‑Gather DMA:** High‑speed bus‑mastering DMA with scatter/gather support for efficient data transfer. - **Digital I/O:** 24‑channel TTL‑compatible programmable I/O (8255 PIO). - **Synchronization:** Multi‑card synchronization via SSI or PXI trigger bus. - **Software Support:** Drivers and SDKs for Windows 7/8 (x86/x64) and Linux; compatible with LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** AD‑Logger for data logging and monitoring. - **Compact Design:** 168 mm × 107 mm PCB with dual 68‑pin VHDCI connectors.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **PCI Express x1 Interface:** Fully compliant with PCIe x1 lane, supporting both 3.3 V and 5 V signaling environments. - **High‑Resolution Analog Input:** 16‑bit A/D converter with no missing codes, supporting 16 single‑ended or 8 differential channels. - **Sampling Rate:** Up to 250 kS/s aggregate throughput. - **Programmable Input Ranges:** Bipolar ±10 V, ±5 V, ±2.5 V, ±1.25 V and unipolar 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V. - **Programmable Gain:** x1, x2, x4, x8 with per‑channel configuration via a 512‑entry channel gain queue. - **Auto‑Calibration:** Fully automatic calibration with onboard 5 V reference (±2 ppm/°C). - **Triggering:** Supports software, external analog, external digital, and SSI triggers with multiple trigger modes (pre‑, post‑, middle‑, delay‑trigger). - **FIFO Buffers:** 1 k‑sample A/D FIFO for efficient data buffering. - **Digital I/O:** 24‑channel TTL‑compatible programmable I/O (8255 PIO). - **Timers/Counters:** Two 16‑bit general‑purpose up/down counters with 40 MHz base clock and external clock up to 10 MHz. - **Scatter‑Gather DMA:** High‑speed bus‑mastering DMA with scatter/gather capability for efficient data transfer. - **System Synchronization Interface (SSI):** Enables multi‑card synchronization for simultaneous sampling. - **Software Support:** Drivers and SDKs for Windows 7/8 x86/x64 and Linux; compatible with LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** AD‑Logger for data logging and configuration. - **Plug‑and‑Play Configuration:** No jumpers required; automatic resource allocation.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **PCI Express x1 Interface:** Fully compliant with 3.3 V and 5 V PCIe bus signaling; plug‑and‑play configuration. - **High‑Resolution Analog Input:** 16‑bit resolution, no missing codes, up to 250 kS/s sampling rate. - **Flexible Channel Configuration:** 16 single‑ended or 8 differential analog input channels, software‑selectable per channel. - **Programmable Gain and Range:** Gains of ×1, ×2, ×4, ×8; bipolar ranges (±10 V, ±5 V, ±2.5 V, ±1.25 V) and unipolar ranges (0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V). - **Auto‑Calibration:** Fully automatic calibration for both A/D and D/A circuits using onboard 5 V reference (±2 ppm/°C). - **Analog Output:** Two 12‑bit multiplying DACs with waveform generation capability, 1 MS/s update rate, ±10 V or 0–10 V output range. - **Digital I/O:** 24‑channel programmable TTL I/O via 8255 PIO interface. - **Timer/Counter:** Two 16‑bit general‑purpose up/down counters with 40 MHz base clock and external clock up to 10 MHz. - **Triggering:** Supports software, external analog, and digital triggers; pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and repeated trigger modes. - **DMA Support:** Scatter‑gather bus‑mastering DMA for high‑speed data transfer with minimal CPU load. - **FIFO Buffers:** 1 k‑sample A/D FIFO and 1 k‑sample D/A FIFO for continuous streaming. - **Synchronization:** System Synchronization Interface (SSI) for multi‑card synchronization. - **Software Support:** Drivers and SDKs for Windows 7/8 x86/x64 and Linux; compatible with LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** AD‑Logger for data logging and configuration. - **Compact Form Factor:** 168 mm × 107 mm PCB with dual 68‑pin VHDCI connectors.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **High-Resolution Analog Input:** 16-bit resolution with up to 250 kS/s sampling rate for single-channel operation, ensuring precise signal capture and analysis. - **Flexible Channel Configuration:** Supports 16 single-ended (SE) or 8 differential (DI) analog input channels, allowing users to adapt to various measurement topologies. - **Wide Input Range:** Programmable input voltage ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.625 V, and ±0.3125 V accommodate diverse signal levels. - **High Signal Integrity:** 10 MΩ input impedance and 90 dB signal-to-noise ratio (SNR) deliver accurate, low-noise measurements. - **Dual 16-bit Analog Outputs:** Two analog output channels with ±10 V range and 10 V/μs slew rate for precise waveform generation and control applications. - **Comprehensive Digital I/O:** 16 digital input and 16 digital output channels, TTL-compatible, supporting up to 1 MHz frequency operation. - **Advanced Triggering:** Multiple trigger sources including software, digital, and analog triggers for flexible synchronization. - **Efficient Data Handling:** Onboard FIFO buffers for analog input (4K samples), analog output (1K samples shared), and digital I/O (512 samples each) ensure smooth data throughput. - **High-Speed Data Transfer:** Supports both polling and DMA (Direct Memory Access) modes for optimized system performance. - **Integrated Timer/Counter:** Two 32-bit general-purpose timer/counter channels with internal and external clock options up to 32 MHz. - **Compact PCIe Form Factor:** Designed for easy integration into modern PC-based systems with a standard PCI Express interface. - **Robust Overvoltage Protection:** Continuous ±20 V protection on analog input channels safeguards against accidental overvoltage conditions.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **High-Resolution Analog Input:** 16-bit resolution with up to 500 kS/s sampling rate for precise signal measurement and analysis. - **Flexible Channel Configuration:** Supports **32 single-ended (SE)** or **16 differential (DI)** analog input channels, allowing users to balance between channel count and noise immunity. - **Wide Input Range:** Programmable input voltage ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.625 V, and ±0.3125 V accommodate a variety of signal levels. - **High Signal Integrity:** Input impedance of 10 MΩ and DC coupling ensure accurate signal capture with minimal loading effect. Continuous overvoltage protection up to ±15 V enhances durability. - **Onboard FIFO Buffer:** 4 k-sample onboard FIFO buffer supports efficient data streaming and reduces data loss during high-speed acquisition. - **Multiple Trigger Sources:** Supports software, digital, and analog triggering for flexible synchronization with external events or system processes. - **Isolated Digital I/O:** 16 isolated digital input channels and 16 isolated digital output channels provide robust protection against ground loops and electrical interference. - **High-Speed Data Transfer:** Supports both **Polling** and **Direct Memory Access (DMA)** modes for optimized data throughput and reduced CPU load. - **Precision Timer/Counter:** One 32-bit general-purpose timer/counter with internal and external clock options for timing, frequency measurement, and event counting. - **Compact PCIe Form Factor:** Designed for standard PCI Express slots, ensuring compatibility with modern PC-based control and monitoring systems. - **Industrial-Grade Reliability:** Isolation, overvoltage protection, and high signal-to-noise ratio (SNR) of 90 dB ensure stable operation in electrically noisy environments.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **High-Resolution Analog Input:** 14-bit resolution with up to 800 kS/s sampling rate for single-channel operation, ensuring precise signal capture and analysis. - **Flexible Channel Configuration:** Supports **16 single-ended (SE)** or **8 differential (DI)** analog input channels, allowing users to adapt to various signal configurations and noise environments. - **Wide Input Voltage Range:** Programmable input ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.625 V, and ±0.3125 V accommodate diverse signal levels. - **High Signal Integrity:** Input impedance of 10 MΩ and DC coupling minimize loading effects and preserve signal fidelity. Overvoltage protection up to ±20 V ensures robust operation in industrial environments. - **Dual 16-bit Analog Outputs:** Two analog output channels with ±10 V range, 16-bit resolution, and 10 V/μs slew rate for precise waveform generation and control applications. - **Comprehensive Digital I/O:** 16 digital input and 16 digital output channels, TTL-compatible, supporting up to 1 MHz signal frequency for high-speed digital control and monitoring. - **Integrated Timer/Counter:** Two 32-bit general-purpose timer/counter channels with internal and external clock sources up to 33 MHz and 8 MHz respectively, enabling precise timing, event counting, and frequency measurement. - **High-Speed Data Transfer:** Supports both **Polling** and **Direct Memory Access (DMA)** modes for efficient data throughput and reduced CPU overhead. - **Multiple Trigger Sources:** Software, digital, and analog trigger options for flexible synchronization of data acquisition and generation tasks. - **Compact PCIe Form Factor:** Designed for standard PCI Express slots, offering high bandwidth and reliable connectivity for modern PCs and industrial computers.

Manufacturer: Adlink Technology Inc.
