- **Multifunction DAQ Card:** Combines analog input, analog output, digital I/O, and counter/timer functions on a single PCIe board. - **High-Resolution Analog Input:** 16-bit resolution with up to 1 MS/s sampling rate for single-channel acquisition, ensuring precise signal capture. - **Flexible Channel Configuration:** Supports 16 single-ended (SE) or 8 differential (DI) analog input configurations. - **Wide Input Range:** Programmable input voltage ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.625 V, and ±0.3125 V for versatile signal compatibility. - **High Signal Integrity:** 90 dB signal-to-noise ratio (SNR) and 14.5-bit effective number of bits (ENOB) for accurate analog measurements. - **Dual 16-bit Analog Outputs:** Two independent analog output channels with ±10 V range and 10 V/μs slew rate for waveform generation and control applications. - **Comprehensive Digital I/O:** 16 digital input and 16 digital output channels, TTL-compatible, supporting up to 1 MHz switching frequency. - **High-Speed Data Transfer:** Supports both **Polling** and **Direct Memory Access (DMA)** modes for efficient data throughput. - **Multiple Trigger Sources:** Software, digital, and analog triggering options for flexible synchronization and event-driven acquisition. - **Onboard FIFO Buffers:** Dedicated FIFO memory for each subsystem—4K samples for analog input, 1K samples (shared) for analog output, and 512 samples for digital I/O—to ensure continuous data streaming without loss. - **Precision Timing:** Two 32-bit general-purpose timer/counter channels with internal and external clock options up to 32 MHz. - **Compact PCIe Form Factor:** Designed for easy integration into standard PCI Express slots in desktop or industrial PCs. - **Robust Electrical Design:** ±20 V continuous overvoltage protection on analog inputs and low output impedance (

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **Simultaneous 4-Channel Analog Input:** Four differential analog input channels with simultaneous sampling capability, ensuring accurate multi-channel signal acquisition without phase delay. - **High Resolution and Speed:** 16-bit resolution with a maximum sampling rate of 1 MS/s per channel, suitable for high-precision measurement applications. - **Flexible Input Ranges:** Programmable input voltage ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.625 V, and ±0.3125 V to accommodate a wide variety of signal levels. - **Robust Overvoltage Protection:** Continuous ±30 V overvoltage protection ensures long-term reliability and protection against accidental signal surges. - **Large Onboard FIFO Buffers:** Dedicated onboard FIFO buffers for each subsystem—4K samples for analog input, 1K samples shared for analog output, and 512 samples for digital I/O—support efficient data streaming and reduce CPU overhead. - **Dual 16-bit Analog Outputs:** Two analog output channels with ±10 V range, 10 V/μs slew rate, and 2 μs settling time for precise waveform generation and control applications. - **Comprehensive Digital I/O:** 16 digital input and 16 digital output channels, TTL-compatible, supporting up to 1 MHz frequency operation for high-speed digital control and monitoring. - **Advanced Triggering and Synchronization:** Multiple trigger sources (software, digital, analog) for flexible acquisition and generation control. - **High Signal Integrity:** 80 dB signal-to-noise ratio (SNR) and 13-bit effective number of bits (ENOB) ensure accurate and low-noise signal measurement. - **Versatile Timer/Counter Functions:** Two 32-bit general-purpose timer/counter channels with internal and external clock options up to 33 MHz internal or 8 MHz external, supporting frequency measurement, pulse generation, and event counting. - **PCI Express Interface:** High-speed PCIe connectivity for reliable data transfer and compatibility with modern PC-based systems. - **Compact Form Factor:** Slim, space-efficient design suitable for integration into industrial PCs and embedded systems.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **Simultaneous Analog Input:** Eight differential analog input channels with simultaneous sampling capability, ensuring accurate time alignment across all channels. - **High Resolution and Speed:** 16-bit resolution with a maximum sampling rate of 1 MS/s per channel, enabling precise signal capture for dynamic and transient events. - **Wide Input Range:** Programmable input voltage ranges of ±10 V, ±5 V, ±2.5 V, ±1.25 V, ±0.625 V, and ±0.3125 V to accommodate a variety of signal amplitudes. - **High Input Impedance:** 10 GΩ input impedance minimizes loading effects on measured circuits. - **Robust Overvoltage Protection:** Continuous overvoltage protection up to ±30 V ensures long-term reliability and protection against accidental signal surges. - **Dual Analog Outputs:** Two 16-bit analog output channels with ±10 V range, 10 V/μs slew rate, and 2 μs settling time for precise waveform generation and control applications. - **Comprehensive Digital I/O:** 16 digital input and 16 digital output channels, TTL-compatible, supporting up to 1 MHz frequency operation. - **Flexible Triggering:** Supports software, digital, and analog trigger sources for both input and output operations, allowing synchronized and event-driven data acquisition. - **Efficient Data Transfer:** Supports both polling and Direct Memory Access (DMA) modes for optimized data throughput and reduced CPU overhead. - **Integrated FIFO Buffers:** Onboard FIFO buffers for each subsystem (analog input, analog output, digital I/O) ensure stable, continuous data streaming without loss. - **Timer/Counter Functionality:** Two 32-bit general-purpose timer/counter channels with internal and external clock sources for timing, frequency, and pulse measurement applications. - **Compact PCIe Form Factor:** Designed for standard PCI Express slots, providing high-speed communication with host systems. - **High Signal Integrity:** Signal-to-noise ratio (SNR) of 80 dB and effective number of bits (ENOB) of 13 bits for accurate analog performance.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

PCIe 32SE/16DI AI 16bit 4MHz SE Scanning 1MS/s FIFO 4k, Range ±10/±5/±2,5/±1,25/±0,625/±0,3125V, 4DA 16bit ±10V 4k FIFO, 16TTL DI/DO, Timer/Counter 432bit, driver/SDK Windows 7/10/11 x86/x64 or later, Linux Driver and SDK, LabVIEW C/C++ Visual Basic Visual Studio.NET, Software Utility ACE Soft-Front Panel, LH 181,05mm * 126,72mm, 68-pin SCSI-type female connector, Adlink

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

PCIe 64SE/32DI AI 16bit 4MHz SE Scanning 1MS/s FIFO 4k, Range ±10/±5/±2,5/±1,25/±0,625/±0,3125V, 4DA 16bit ±10V 4k FIFO, 16TTL DI/DO, Timer/Counter 432bit, driver/SDK Windows 7/10/11 x86/x64 or later, Linux Driver and SDK, LabVIEW C/C++ Visual Basic Visual Studio.NET, Software Utility ACE Soft-Front Panel, LH 181,05mm * 126,72mm, 68-pin SCSI-type female connector, Adlink

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCIe

- **Simultaneous Sampling:** Four differential analog input channels with simultaneous sampling capability, ensuring phase-coherent data acquisition across multiple channels. - **High Resolution and Speed:** 16-bit resolution with a maximum sampling rate of 500 kS/s per channel. - **Programmable Input Ranges:** Bipolar: ±10 V, ±5 V, ±2.5 V, ±1.25 V Unipolar: 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V Programmable gain settings of ×1, ×2, ×4, ×8. - **Dual Analog Outputs:** Two 12-bit analog output channels with waveform generation capability, supporting up to 1 MS/s update rate and ±10 V or 0–10 V output ranges. - **Digital I/O:** 24-channel programmable TTL/CMOS-compatible digital I/O, 8255 PIO compatible. - **Timer/Counter:** Two 16-bit general-purpose up/down timer/counters with 40 MHz internal or up to 10 MHz external clock. - **Triggering Flexibility:** Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers. Trigger modes include pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger. - **Auto-Calibration:** Fully automatic calibration using on-board 5.000 V reference with ±2 ppm/°C temperature drift and 6 ppm/1000 hr long-term stability. - **Data Transfer:** Supports programmed I/O and scatter-gather bus-mastering DMA for high-speed data throughput. - **Synchronization:** Multiple cards can be synchronized via the SSI bus for multi-card, multi-channel acquisition systems. - **Software Support:** Compatible with Windows (NT/98/2000/XP/7/8) and Linux. Supported development environments include LabVIEW®, MATLAB®, Visual C++, Visual Basic, Delphi, and C/C++ SDKs.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **Simultaneous Sampling:** Four differential analog input channels sampled simultaneously at up to **250 kS/s per channel**, ensuring phase-coherent data acquisition across multiple inputs. - **High Resolution:** 16-bit analog-to-digital conversion with no missing codes, providing high accuracy and fine granularity in signal measurement. - **Analog Output Capability:** Two 12-bit analog output channels with waveform generation capability, supporting update rates up to **1 MS/s** and output ranges of **±10 V or 0–10 V**. - **Auto-Calibration:** Fully automatic calibration of gain and offset errors using onboard precision reference (5.000 V, ±2 ppm/°C), eliminating manual trimpot adjustments. - **Flexible Triggering:** Supports **software, external analog, external digital, and SSI (System Synchronization Interface)** triggers with multiple trigger modes: pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger. - **Digital I/O:** 24 programmable TTL/CMOS-compatible digital I/O lines (8255 PIO compatible), configurable as input or output. - **Timer/Counter Functions:** Two 16-bit general-purpose up/down counters with internal 40 MHz or external clock sources up to 10 MHz. - **Scatter-Gather DMA:** High-speed bus-mastering DMA with scatter-gather capability for efficient, CPU-independent data transfer. - **System Synchronization Interface (SSI):** Enables synchronization of multiple DAQ cards for expanded channel count and coordinated sampling. - **Compact Design:** Half-size PCI card (175 mm × 107 mm) with a 68-pin VHDCI connector for all analog, digital, and timing signals. - **Software Support:** Compatible with Windows (NT4/98/2000/XP/7/8) and Linux (kernel 2.4.x) via ADLINK’s D2K-DASK and D2K-DASK/X drivers. Supports LabVIEW®, MATLAB®, Visual C++, Visual Basic, Delphi, and ActiveX environments.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **Simultaneous Sampling:** 4 differential analog input channels sampled simultaneously at up to **2 MS/s** total throughput. - **High Resolution:** 14-bit analog-to-digital conversion with no missing codes. - **Programmable Input Ranges:** Bipolar (±10 V, ±5 V, ±2.5 V, ±1.25 V) and unipolar (0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V). - **Analog Output:** Two 12-bit voltage output channels with waveform generation capability, up to **1 MS/s** update rate. - **Digital I/O:** 24 programmable TTL/CMOS-compatible digital I/O lines (8255 PIO compatible). - **Timer/Counter:** Two 16-bit general-purpose up/down counters with 40 MHz internal or up to 10 MHz external clock. - **Triggering:** Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers. - **Auto-Calibration:** Fully automatic calibration of analog input and output channels using onboard precision reference (5.000 V ±2 ppm/°C). - **Scatter-Gather DMA:** High-speed bus-mastering DMA with scatter/gather capability for efficient data transfer without CPU overhead. - **Synchronization:** Multiple card synchronization via SSI bus for scalable multi-channel systems. - **Noise Immunity:** Differential input configuration and isolated analog/digital circuitry for high CMRR and low noise. - **Software Support:** Drivers and SDKs for Windows and Linux, including LabVIEW®, MATLAB®, Visual C++, Delphi, and ActiveX controls. - **Compact Design:** Half-size PCI card (175 mm × 107 mm) with VHDCI 68-pin connector.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **Simultaneous Sampling:** Four differential analog input channels sampled simultaneously to ensure phase alignment and minimal cross-channel delay. - **High Resolution and Speed:** 16-bit analog-to-digital conversion with a maximum sampling rate of **800 kS/s per channel**. - **Programmable Input Ranges:** Bipolar: ±10 V, ±5 V, ±2.5 V, ±1.25 V Unipolar: 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V Programmable gain settings of 1, 2, 4, and 8. - **Dual Analog Outputs:** Two 12-bit analog output channels with waveform generation capability, supporting ±10 V or 0–10 V ranges and up to **1 MS/s update rate**. - **Digital I/O:** 24 programmable digital I/O lines (8255-compatible, TTL/CMOS levels). - **Timer/Counter:** Two 16-bit general-purpose up/down counters, TTL-compatible, with internal 40 MHz or external clock up to 10 MHz. - **Triggering Options:** Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers. Trigger modes include pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger. - **Auto-Calibration:** Fully automatic calibration of analog input and output channels using onboard precision reference (5.000 V, ±2 ppm/°C). - **Bus-Mastering DMA with Scatter-Gather:** High-speed data transfer directly to system memory without CPU intervention, supporting fragmented memory blocks. - **System Synchronization Interface (SSI):** Enables synchronization of multiple DAQ cards for expanded channel count and coordinated sampling. - **Compact Design:** Half-size PCI card (175 mm × 107 mm) suitable for space-constrained systems. - **Software Support:** Compatible with Windows (NT/98/2000/XP) and Linux (kernel 2.4.x). Supported libraries: D2K-DASK, D2K-DASK/X, LabVIEW® driver (D2K-LVIEW), ActiveX (D2K-OCX), and DAQBench.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **High-Speed Analog Input:** 64 single-ended or 32 differential analog input channels with 12-bit resolution and up to 3 MS/s sampling rate. Supports both unipolar and bipolar input ranges from ±0.05 V to ±10 V and 0–10 V to 0–0.1 V. - **Analog Output Capability:** Two 12-bit analog output channels with ±10 V or 0–10 V ranges and 1 MS/s maximum update rate. Each channel includes a 1 k-sample FIFO buffer for waveform generation. - **Digital I/O:** 24-channel TTL-compatible programmable digital I/O (8255 PIO) for control and monitoring applications. - **Timer/Counter:** Two 16-bit general-purpose up/down counters with 40 MHz internal or up to 10 MHz external clock input. - **Triggering and Synchronization:** Supports software, external analog/digital, and SSI (System Synchronization Interface) triggers. Multiple trigger modes: pre-trigger, post-trigger, middle-trigger, delay-trigger, and re-trigger. Synchronization across multiple cards via SSI or PXI trigger bus. - **Auto-Calibration:** Fully automatic calibration with onboard 5.000 V reference (±2 ppm/°C) ensures long-term accuracy. - **High Bandwidth and Low Noise:** 2 MHz small-signal bandwidth at ±10 V range and 90 dB CMRR (gain = 1). Typical system noise

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **High-Resolution Analog Input:** 16-bit A/D conversion with no missing codes, supporting 64 single-ended (SE) or 32 differential (DI) channels, software-selectable per channel. - **Sampling Rate:** Maximum sampling rate of 500 kS/s for single-channel operation. - **Analog Input Ranges:** Bipolar: ±10 V, ±5 V, ±2.5 V, ±1.25 V Unipolar: 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V - **Programmable Gain:** x1, x2, x4, x8 programmable gain settings. - **Analog Output:** Two 12-bit D/A channels with ±10 V or 0–10 V output ranges, 1 MS/s update rate, and 1 k-sample FIFO per channel. - **Digital I/O:** 24-channel TTL-compatible programmable I/O (8255 PIO). - **Timer/Counter:** Two 16-bit general-purpose up/down counters with 40 MHz base clock and external clock input up to 10 MHz. - **Triggering:** Supports software, external analog, and digital triggers, as well as SSI (System Synchronization Interface) for multi-card synchronization. - **Auto Calibration:** Fully automatic calibration with onboard 5.000 V reference (±2 ppm/°C). - **FIFO Buffers:** 1 k-sample A/D FIFO and 1 k-sample D/A FIFO for efficient data buffering. - **Bus Interface:** 32-bit PCI bus, 3.3 V or 5 V signaling, plug-and-play configuration. - **Software Support:** Compatible with Windows 7/8 (x86/x64) and Linux; drivers available for LabVIEW, MATLAB, C/C++, Visual Basic, and Visual Studio.NET. - **Synchronization:** Multiple card synchronization via SSI bus or PXI trigger bus. - **Utility Software:** AD-Logger for data logging and monitoring.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **Bus Interface:** 32-bit PCI bus supporting 3.3 V or 5 V signaling; plug-and-play configuration. - **Analog Inputs:** 64 single-ended or 32 differential channels, software-selectable per channel. - **Resolution:** 16-bit, no missing codes. - **Sampling Rate:** Up to 250 kS/s aggregate throughput. - **Input Range:** Bipolar ±10 V, ±5 V, ±2.5 V, ±1.25 V; Unipolar 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V. - **Programmable Gain:** x1, x2, x4, x8. - **FIFO Buffer:** 1024-sample A/D FIFO and 1024-sample D/A FIFO. - **Analog Outputs:** Two 12-bit voltage output channels (0–10 V, ±10 V, or external reference). - **Digital I/O:** 24-channel TTL-compatible programmable I/O (8255 PIO). - **Counters/Timers:** Two 16-bit general-purpose up/down counters with 40 MHz base clock. - **Triggering:** Supports software, external analog, and digital triggers; pre-, post-, middle-, and delay-trigger modes. - **Auto Calibration:** Fully automatic calibration with onboard 5.000 V reference (±2 ppm/°C). - **Synchronization:** Multi-card synchronization via SSI (System Synchronization Interface) or PXI trigger bus. - **Software Support:** Compatible with Windows and Linux; drivers for LabVIEW, MATLAB, C/C++, Visual Basic, and .NET. - **Utility Software:** AD-Logger for data logging and analysis. - **Connectors:** Two 68-pin VHDCI connectors for analog, digital, and timing signals. - **Form Factor:** PCI card, dimensions 175 mm × 107 mm.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **High Channel Density:** 96 single-ended (SE) or 48 differential (DI) analog input channels, with software-selectable mixed-mode operation. - **High-Speed Sampling:** Maximum sampling rate of **3 mega-samples per second (3 MS/s)** with 12-bit resolution and no missing codes. - **Flexible Input Ranges:** Bipolar ranges: ±10 V, ±5 V, ±2.5 V, ±2 V, ±1.25 V, ±1 V, ±0.5 V, ±0.25 V, ±0.2 V, ±0.05 V Unipolar ranges: 0–10 V, 0–5 V, 0–4 V, 0–2.5 V, 0–1 V, 0–0.5 V, 0–0.4 V, 0–0.1 V - **Programmable Gain:** Selectable gains of ×1, ×2, ×4, ×5, ×8, ×10, ×20, ×40, ×50, and ×200. - **Auto Calibration:** Fully automatic calibration with onboard 5.000 V reference (±2 ppm/°C), ensuring long-term accuracy and stability. - **FIFO Buffer:** 1 k-sample (1024-word) onboard A/D FIFO for efficient data buffering. - **Triggering Options:** Supports software, external digital, external analog, and SSI (System Synchronization Interface) triggers. Trigger modes include pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger. - **Digital I/O:** 24-channel TTL-compatible programmable digital I/O (8255 PIO). - **Synchronization:** Multiple card synchronization via SSI bus or PXI trigger bus for multi-card, multi-channel systems. - **Software & OS Support:** Compatible with Windows 7/8 (x86/x64) and Linux. Supported development environments: LabVIEW, MATLAB, C/C++, Visual Basic, Visual Studio.NET. - **Plug-and-Play PCI Interface:** 32-bit PCI bus, 3.3 V/5 V signaling, automatic resource configuration (IRQ, DMA).

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **High‑Resolution Analog Input:** 16‑bit A/D conversion with no missing codes, supporting 16 single‑ended or 8 differential channels (software‑selectable). - **High Sampling Rate:** Maximum aggregate sampling rate of 250 kS/s for all channels combined. - **Flexible Input Ranges:** Bipolar ranges: ±10 V, ±5 V, ±2.5 V, ±1.25 V Unipolar ranges: 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V - **Programmable Gain:** Gains of ×1, ×2, ×4, ×8 selectable per channel. - **Channel Gain Queue:** 512‑entry configuration queue allowing mixed channel, gain, and range settings for sequential scans. - **FIFO Buffers:** 1 k‑sample A/D FIFO for continuous high‑speed acquisition. - **Triggering Options:** Software, external digital, external analog, and SSI (System Synchronization Interface) triggers. Supports pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and repeated trigger modes. - **Digital I/O:** 24‑channel TTL‑compatible programmable I/O (8255 PIO). - **Timer/Counter:** Two 16‑bit general‑purpose up/down counters with 40 MHz base clock and external clock input up to 10 MHz. - **Auto‑Calibration:** Fully automatic calibration with onboard 5 V reference (±2 ppm/°C). - **System Synchronization Interface (SSI):** Enables synchronization of multiple DAQ cards for simultaneous sampling. - **Bus Compatibility:** 32‑bit PCI bus supporting both 3.3 V and 5 V signaling. - **Software Support:** Drivers and SDKs for Windows 7/8 x86/x64 and Linux. Compatible with LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. - **Utility Software:** AD‑Logger for data logging and configuration.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **High‑Resolution Analog Input:** 16‑bit A/D converter with no missing codes, supporting up to 16 single‑ended or 8 differential channels. Maximum sampling rate: **250 kS/s**. - **Dual Analog Output Channels:** Two 12‑bit D/A converters with waveform generation capability. Maximum update rate: **1 MS/s** per channel. - **Flexible Input Ranges:** Bipolar: ±10 V, ±5 V, ±2.5 V, ±1.25 V Unipolar: 0–10 V, 0–5 V, 0–2.5 V, 0–1.25 V Programmable gain: ×1, ×2, ×4, ×8. - **Auto‑Calibration:** Fully automatic calibration for both A/D and D/A circuits using onboard 5.000 V reference (±2 ppm/°C). - **Triggering and Synchronization:** Supports software, external analog, and digital triggers. Multiple trigger modes: pre‑trigger, post‑trigger, middle‑trigger, delay‑trigger, and re‑trigger. Synchronization of multiple cards via **SSI (System Synchronization Interface)** bus. - **Digital I/O and Timing:** 24‑channel TTL‑compatible programmable digital I/O (8255 PIO). Two 16‑bit general‑purpose timers/counters (up to 10 MHz external clock). - **High‑Speed Data Transfer:** Scatter‑gather DMA for efficient, high‑throughput data movement. 1 k‑sample FIFO buffers for both A/D and D/A operations. - **Software and OS Support:** Compatible with Windows 7/8 x86/x64 and Linux. Drivers and SDKs for LabVIEW®, MATLAB®, C/C++, Visual Basic, and Visual Studio .NET. Utility software: **AD‑Logger** for data logging and configuration. - **Connectivity:** Two 68‑pin VHDCI connectors for analog, digital, and timing signals. Optional terminal boards and cables: DIN‑68S‑01, ACL‑10568‑1, ACL‑SSI‑2/3/4.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PCI

- **CompactPCI 3U Eurocard Form Factor:** Fully compliant with PICMG 2.0 R2.1 standards. - **High-Resolution Analog Input:** 12-bit A/D resolution with up to 110 kS/s sampling rate. - **Flexible Input Configuration:** 16 single-ended or 8 differential analog input channels. - **Programmable Input Ranges:** Bipolar (±0.625 V to ±10 V) and unipolar (0–1.25 V to 0–10 V). - **Programmable Gain Control:** x0.5, x1, x2, x4, x8 for signal scaling and precision adjustment. - **Automatic Channel Scanning:** Hardware-based auto-scan for multi-channel acquisition. - **Bus-Mastering DMA:** High-speed data transfer without CPU overhead. - **Dual 12-bit Analog Outputs:** Two multiplying DAC channels with 0–5 V or 0–10 V ranges. - **Digital I/O:** 16 TTL-compatible digital inputs and 16 TTL-compatible digital outputs. - **Timer/Counter:** One 16-bit general-purpose counter/timer (8254 compatible) with 2 MHz base clock. - **Rear I/O Option:** cPCI-9112R supports rear I/O connectivity via J2/P2 backplane interface. - **Software & OS Support:** Drivers for Windows (XP/7/10), Linux, and Windows CE; compatible with LabVIEW™, MATLAB®, and DAQBench™. - **Rugged Industrial Design:** 100-pin SCSI-II type connector, 100 × 160 mm PCB, and extended temperature range operation.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **High-Resolution Analog Input:** 12-bit A/D conversion with up to 110 kS/s sampling rate. - **Flexible Input Configuration:** 16 single-ended or 8 differential analog input channels. - **Programmable Input Ranges:** Bipolar ±0.625V to ±10V and unipolar 0–1.25V to 0–10V. - **Analog Output:** Two 12-bit D/A channels with 0–5V or 0–10V output range, ±5 mA drive, and 30 µs settling time. - **Digital I/O:** 16 TTL-compatible digital inputs and 16 TTL-compatible digital outputs. - **Programmable Counter/Timer:** Three 16-bit down counters (Intel 8254 compatible) with 2 MHz base clock. - **FIFO Buffer:** 2K-word onboard FIFO for high-speed A/D data buffering (1K FIFO for 6U version). - **Triggering Modes:** Software, internal timer pacer, and external trigger support. - **Data Transfer Modes:** Bus mastering DMA, interrupt-driven, or program-controlled transfer. - **Auto-Scan Function:** Hardware-based automatic channel scanning for multi-channel acquisition. - **Rugged Connectivity:** 100-pin SCSI-II type front connector for CompactPCI; optional rear I/O via transition board (DB-100RU). - **CompactPCI Compliance:** Fully compliant with CompactPCI 6U mechanical and electrical standards. - **Software Support:** Comprehensive driver and library support for Windows and DOS, including LabVIEW®, HP-VEE™, DASYLab™, and OPC. - **Integrated DC-DC Converter:** Provides stable analog power isolation from digital noise. - **Plug-and-Play Configuration:** Automatic resource allocation via PCI BIOS. - **Industrial Durability:** Designed for 0°C–60°C operation and 5–95% non-condensing humidity.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **High-Resolution Analog Input:** 12-bit A/D resolution with up to 110 kS/s sampling rate. - **Flexible Input Configuration:** 16 single-ended or 8 differential analog input channels with programmable gain and selectable bipolar/unipolar ranges. - **Programmable Gain Control:** Software-selectable gains of x0.5, x1, x2, x4, and x8 for precise signal scaling. - **Analog Output Capability:** Two 12-bit multiplying D/A channels with software-programmable output ranges (0–5 V, 0–10 V, or external reference). - **Digital I/O:** 16 TTL-compatible digital inputs and 16 TTL-compatible digital outputs. - **Timer/Counter:** One 16-bit general-purpose timer/counter (Intel 8254 compatible) with 2 MHz base clock and external clock input up to 10 MHz. - **Rear I/O Connectivity:** All I/O signals are routed through the CompactPCI J2/P2 connector for rear transition module access (DB-100RU). - **Bus-Mastering DMA:** High-speed data transfer via bus-mastering DMA for analog input operations. - **Automatic Channel Scanning:** Hardware-based auto-scan for sequential analog input sampling. - **FIFO Buffer:** 2K-word FIFO for analog input data buffering (expanded from 8 words on PCI-9112). - **Software & OS Support:** Compatible with Windows 7/Vista/XP/2000/2003 Server, Linux, and Windows CE (on request). Supported by ADLINK DAQPilot, PCIS-DASK, and DAQBench software suites. - **CompactPCI Compliance:** Fully compliant with PICMG 2.0 R2.1 CompactPCI specifications. - **Rugged Design:** 3U Eurocard (100 mm x 160 mm) with 100-pin SCSI-II type rear I/O connector.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **High-Resolution Analog Input:** 16-bit A/D conversion with up to 250 kS/s sampling rate. - **Flexible Channel Configuration:** 64 single-ended or 32 differential analog input channels, software-selectable per channel. - **Programmable Gain and Range:** Four programmable gains (×1, ×2, ×4, ×8) with bipolar and unipolar ranges. - **Onboard FIFO Buffer:** 1 k-sample A/D FIFO for efficient data buffering and high-speed acquisition. - **Channel-Gain Queue:** 512-entry channel-gain queue for mixed input configurations and sequential scanning. - **Multiple Trigger Modes:** Software, pre-trigger, post-trigger, middle-trigger, delay-trigger, and re-trigger modes. - **Bus-Mastering DMA:** High-speed data transfer via PCI bus-mastering DMA, minimizing CPU load. - **Digital I/O:** 8 TTL-compatible digital input and 8 digital output channels. - **Timer/Counter:** One 16-bit general-purpose up/down timer/counter with 24 MHz base clock. - **Rear I/O Option:** cPCI-9116R variant supports rear I/O connectivity through the CompactPCI backplane. - **Software Support:** Compatible with Windows and Linux; drivers for LabVIEW®, MATLAB®, and DAQPilot. - **CompactPCI Compliance:** Fully compliant with PICMG 2.0 R2.1 standard for 3U Eurocard form factor. - **Rugged Connectivity:** 100-pin SCSI-II type connector for secure and high-density signal interfacing.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **High-Resolution Analog Input:** 16-bit A/D resolution with a maximum sampling rate of 250 kS/s. - **Channel Density:** 64 single-ended (SE) or 32 differential (DI) analog input channels, software-selectable per channel. - **Programmable Input Ranges:** Bipolar: ±0.625 V, ±1.25 V, ±2.5 V, ±5 V Unipolar: 0–1.25 V, 0–2.5 V, 0–5 V, 0–10 V - **Programmable Gain:** x1, x2, x4, x8 gain settings, software-configurable. - **FIFO Buffer:** 1 k-sample onboard A/D FIFO for efficient data buffering. - **Channel-Gain Queue:** 512-entry configuration queue for channel, gain, and mode sequencing. - **Triggering Modes:** Software, pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger. - **Data Transfer Modes:** Polling, interrupt-driven, and bus-mastering DMA for high-speed data throughput. - **Digital I/O:** 8 TTL-compatible digital inputs and 8 TTL-compatible digital outputs. - **Timer/Counter:** One 16-bit general-purpose up/down timer/counter with 24 MHz base clock. - **Rear I/O Option:** Available on cPCI-9116R variant for backplane routing via J2/P2 connector. - **Software Support:** Compatible with Windows (7/Vista/XP/2000/2003), Linux, and Windows CE (on request). - **Driver & API Support:** DAQPilot, PCIS-DASK, PCIS-DASK/X, DAQBench, LabVIEW™, MATLAB®, and .NET libraries. - **Rugged Connectivity:** 100-pin SCSI-II type connector for reliable industrial interfacing. - **Plug-and-Play PCI Configuration:** Automatic IRQ and address assignment, no jumpers required.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **High-Resolution Analog Input:** 16-bit A/D conversion with up to 250 kS/s sampling rate for precise signal measurement. - **Flexible Channel Configuration:** 64 single-ended or 32 differential analog input channels, software-selectable per channel. - **Programmable Input Ranges:** Bipolar: ±0.625 V, ±1.25 V, ±2.5 V, ±5 V Unipolar: 0–1.25 V, 0–2.5 V, 0–5 V, 0–10 V - **Programmable Gain:** x1, x2, x4, x8 gain settings per channel. - **Onboard FIFO Buffer:** 1 k-sample A/D FIFO for efficient data buffering and reduced CPU load. - **Channel-Gain Queue:** 512-entry configuration queue allowing mixed channel, gain, and input type sequences. - **Triggering Flexibility:** Supports software, pre-trigger, post-trigger, middle-trigger, delay-trigger, and re-trigger modes. - **Data Transfer Modes:** Polling, interrupt-driven, and bus-mastering DMA for high-speed data throughput. - **Digital I/O:** 8 TTL-compatible digital inputs and 8 TTL-compatible digital outputs. - **Timer/Counter:** One 16-bit general-purpose up/down timer/counter with 24 MHz base clock. - **Rear I/O Connectivity:** The cPCI-9116R routes all I/O signals through the CompactPCI J2/P2 connector for rear transition modules. - **Software & OS Support:** Compatible with Windows 7/Vista/XP/2000/2003, Linux, and Windows CE (on request). Supported APIs: DAQPilot, PCIS-DASK, LabVIEW™, MATLAB®, DAQBench ActiveX. - **Plug-and-Play PCI Configuration:** Fully compliant with PCI bus auto-configuration for IRQ and memory mapping. - **Rugged Industrial Design:** 3U Eurocard form factor with 100-pin SCSI-II type connector.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

cPCI bus AD card 12bit with 16SE channels, software programmable gain 1,2,4,8 &16, SCSI connector, 100*160mm, Axiom

Manufacturer: Axiom

Category: A/D Intelligent PXI/PXIe/cPCI

- **PXI Bus Interface:** 32-bit PXI/CompactPCI compliant, plug-and-play configuration. - **Analog Inputs:** 4 differential, simultaneous-sampling channels with 16-bit resolution and up to 500 kS/s sampling rate. - **Analog Outputs:** 2 channels, 12-bit resolution, 1 MS/s update rate, ±10V or 0–10V output range. - **Digital I/O:** 24 programmable TTL/CMOS-compatible lines (8255A compatible). - **Counters/Timers:** Two 16-bit up/down general-purpose counters with multiple modes. - **Triggering:** Supports software, external digital, external analog, and SSI (System Synchronization Interface) triggers. - **Auto-Calibration:** Fully automatic calibration for both A/D and D/A circuits. - **FIFO Buffers:** - A/D: 512 samples total - D/A: 1k samples per channel (2k when one channel active) - **Clocking:** Internal 40 MHz or external clock input (1–40 MHz). - **System Synchronization Interface (SSI):** Enables synchronization across multiple PXI cards. - **Software Support:** Drivers for Windows and Linux, LabVIEW® PnP, ActiveX (D2K-OCX), and DAQBench visualization tools. - **Form Factor:** Standard PXI module (100 × 160 mm). - **Connector:** 68-pin VHDCI (AMP-787254-1) for I/O signals.

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **PXI Bus Interface:** 32-bit PXI/CompactPCI compliant, plug-and-play configuration. - **Analog Inputs:** 4 simultaneous differential analog input channels with 16-bit resolution. - **Sampling Rate:** Up to 250 kS/s per channel. - **Programmable Input Range:** Bipolar (±10V, ±5V, ±2.5V, ±1.25V) and unipolar (0–10V, 0–5V, 0–2.5V, 0–1.25V). - **Auto-Calibration:** Fully automatic calibration for both A/D and D/A channels. - **Analog Output:** Two 12-bit D/A channels with 1 MS/s update rate and ±10V or 0–10V output range. - **Digital I/O:** 24 programmable TTL/CMOS-compatible digital I/O lines (82C55A compatible). - **Counters/Timers:** Two 16-bit up/down general-purpose counters/timers (GPTC) with up to 10 MHz input frequency. - **Triggering:** Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers. - **FIFO Buffers:** 512-sample A/D FIFO and 1K-sample D/A FIFO per channel. - **Clocking:** Internal 40 MHz or external clock input (1–40 MHz, TTL-compatible). - **DMA Support:** Bus-mastering DMA with scatter/gather capability for high-speed data transfer. - **System Synchronization Interface (SSI):** Enables synchronization of multiple PXI cards. - **Software Support:** Drivers for Windows and Linux, including LabVIEW®, ActiveX, and C/C++ libraries. - **Form Factor:** Standard PXI module (100 × 160 mm).

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI

- **High-Speed A/D Conversion:** 14-bit resolution with simultaneous 4-channel sampling at up to **2 MS/s** total throughput. - **Analog Input Flexibility:** - 4 differential analog input channels. - Programmable input ranges: ±10V, ±5V, ±2.5V, ±1.25V (bipolar) and 0–10V, 0–5V, 0–2.5V, 0–1.25V (unipolar). - Programmable gain settings: ×1, ×2, ×4, ×8. - **Analog Output Capability:** - 2 channels, 12-bit resolution, up to **1 MS/s** update rate. - Bipolar (±10V) or unipolar (0–10V) output ranges. - 1 k-sample FIFO per channel (2 k-sample when single channel active). - **Digital I/O:** - 24 programmable TTL/CMOS-compatible digital I/O lines (82C55A compatible). - 8 synchronous digital inputs (SDI) sampled simultaneously with analog inputs (PXI-2010 only). - **Counters/Timers:** - Two 16-bit up/down general-purpose counters/timers. - Programmable clock source (internal/external up to 10 MHz). - **Triggering and Synchronization:** - Supports software, external analog, external digital, and SSI (System Synchronization Interface) triggers. - Four trigger modes: post-trigger, pre-trigger, middle-trigger, and delay-trigger. - Analog trigger with programmable hysteresis and 8-bit resolution. - **Data Transfer:** - Bus-mastering DMA with scatter/gather support for high-speed data throughput. - 16 k-sample A/D FIFO buffer for continuous acquisition. - **Auto-Calibration:** - Fully automatic calibration for both A/D and D/A channels using onboard precision reference. - **Software Configurable:** - Completely jumper-less design; all configurations are software-controlled. - **Software Support:** - Drivers and libraries for Windows and Linux (D2K-DASK, D2K-DASK/X). - LabVIEW® driver (DAQ-LVIEW PnP) and ActiveX controls (D2K-OCX).

Manufacturer: Adlink Technology Inc.

Category: A/D Intelligent PXI/PXIe/cPCI
